WALDNER COMBI STAR User manual

SHHH!
WE ARE GRINDING
AND FLAKING.
USER GUIDE & CERTIFICATE
OF WARRANTY
COMBI STAR

We trust in domestic
woods and handcraft 100 %
made in Tyrol.
MILL COMBI STAR
GETREIDEMÜHLEN WALDNER BIOTECH GMBH
Kärntnerstraße 62, A-9900 Lienz/Osttirol
[phone], offi[email protected]
www.waldner-biotech.at
design: aberjung.com
photos: ramonawaldner.com

GRAIN MILL & FLAKER
COMBI STAR TECHNICAL DATA
1
Overload protection with thermal
sensors. Certified ÖVE quality;
child protection
Type of wood
Grinding output fine
Diameter millstone
Millstone
Grinding chamber
Hopper capacity /mill
Dimensions H/W/D
Weight
Volt/Hertz/Watt - mill
Stone pine
130 g/min.
90 mm
white corundum
and ceramic
self-cleaning
1.200 g
33/28/18 cm
10 kg
230/50/400
MILL COMBI STAR
KG
Squeezer output
Squeezer
Hopper capacity/flaker
Volt/Hertz/Watt - flaker
80 g/min.
2 rolls of stainless
steel
120 g
230/50/240
2
MILL COMBI STAR
COMPONENTS
1
2
3
5
678
9
10
11
1. Cover hopper
2. Hopper
3. Safety loop (not visible)
4. Upper and lower millstone
(not visible)
5. Coarseness scale
6. Locking screw
7. Safety push-button/mill
(not visible)
8. Direction arrow
9. Output flour
10. Power switch mill ON/OFF
11. Power supply (not visible)
12. Safety push-button/flaker (not visible)
13. Squeezer (not visible)
14. Output flakes
15. Hopper flaker
16. Power Switch flaker ON/OFF
(not visible)
4
12
13
14
15
16

MILL COMBI STAR
The device may be operated by children from 8 years and
above, as well as from persons with reduced physical, sen-
sorial and mental abilities or persons having a lack of expe-
rience and knowledge, if supervised or instructed carefully
regarding the proper use of the device and if they are fully
aware of the possible risks of any misuse of the device. Chil-
dren are not allowed to play with this device. Cleaning and
maintenance may not be handled by unsupervised children.
When not supervised and prior to the assembling and disas-
sembling or cleaning the device has to be disconnected from
the power supply. The device may not be used by children.
Keep device and power cable away from children.
!ATTENTION: Misuse can cause injuries.
SAFETY: Never immerse the device into water. Only au-
thorized customer service is allowed to perform repairs
using original parts and spare parts.
GENERAL
REQUIREMENTS
34
SPICES AND SALTS
Fennel, kummel, sea salt, etc.
Tip: add to grains
COARSENESS SETTING
FINE TO ROUGH
GRAINS AND SEEDS
Oat, flax seed, soya bean,
wild beans, etc.
OARSENESS SETTING MEDIUM
FINE TO ROUGH
GRAINS
Spelt, wheat, millet, rye, corn,
rice, chickpea, etc.
COARSENESS SETTING FINE
TO ROUGH
GRAIN MILL FLAKER
GRAINS
Oat, spelt, wheat, millet, rye, etc
GRAINS AND SEEDS
sesame, flax seed, etc.
SPICES AND SALTS
fennel, kummel, cilantro, etc.
NOT SUITABLE:
orn, rice, chickpea & soya
!
MILL COMBI STAR

56
INITIAL OPERATION
1. Place mill on a ground surface. Attention: Never place the
mill on a hot surface (eg stovetop)
2. Check if supply voltage corresponds to the required voltage
for the device
3. Plug power plug into socket.
4. Press power switch to ON.
SETTING OF GRINDER
Coarseness can be regulated continuously. Just turn hopper
and adjust the distance of the 2 millstones according to the
desired coarseness. A locking screw on the side assures the
setting and prevents from loosening.
INITIAL OPERATION,
SETTING OF GRINDER
!NOTE: Efficiency & result of the grinding depend on the
quality of the mill material. The drier the mill material,
the higher the efficiency.
3
3. Release locking
screw in order to
urn hopper
1
1. Plug power plug
into socket
2
2. Press power switch
to ON
4
4. urn hopper in the di-
rection of >MIKRO< until
you hear a slight grinding
sound.
0
M
IKR
O
20
1
0
f
ein
g
ro
b
MILL COMBI STAR MILL COMBI STAR

78
5 6
7
5. Twist back hopper until
the grinding sound disap-
pears - this is the finest
coarseness setting.
6. Mark this coarseness
setting on your mill. All
further settings can be
customized (from fine
to rough).
7. Put a bowl under flour
output prior to every use
of the device.
8
7. Have fun grinding!
TROUBLE
SHOOTING
The device can’t be
switched ON
REASON
Hopper is not completely closed
(safety button has no contact)
HELP
turn hopper in the direction fine
>fein<
REASON
The mill material used was too
damp for the desired coarseness.
HELP
Clean hopper and output (see also
chapter CLEANING). Dry the mill
material.
The flour output
is blocked.
Device stops during
grinding process.
REASON
Overheating of the motor
HELP
The device has a overload protecti-
on with thermal sensors and turns
on again automatically.
REASON
The mill material was too damp for
the desired coarseness or seeds
were ground too fine without ad-
ding dry mill material.
HELP
remove smudge from millstones
using a wire brush and afterwards
grind rice or corn roughly. (grinder
setting rough >grob<).
The grinder
is smudged
0MIKRO 2030
4050 10
fein grob
0MIKRO 2030
4050 10
fein grob
0MIKRO 2030
4050 10
fein grob
MILL COMBI STAR MILL COMBI STAR

910
PASSION FOR
DETAIL
MILL COMBI STAR MILL COMBI STAR

CLEANING OF
THE FLAKER
11 12
Clean housing with a soft, damp towel.
Use a brush or hot water to clean the squeezer.
Never use sharp items or chemicals for the clea-
ning of the housing.
Open the flaker: The device can be opened easily
by removing the cover. When closing make sure the
cover is in place properly.
The device has a safety button. When removing the
cover the motor stops automatically - children pro-
tection.
The device is free of service and maintenance. How-
ever, keep original packing for possible transport.
!
1
1. Plug off from
power supply
2
2. Remove cover
by pulling off towards you
3
3. Remove
squeezer
4
4. Clean
squeezer
MILL COMBI STAR MILL COMBI STAR

CLEANING
OF MILL
1
1. Turn off
hopper
3
3. Put on hopper
by turning
13 14
4
4. Start operation as
indicated on page 6
2
2. Clean with a brush
or aspirator
Clean housing with a soft, damp towel.
Clean grinding chamber with a brush or aspirator.
Clean the millstones by grinding roughly rice or
corn or by using a brush.
Never use sharp items or chemicals for the clea-
ning of the housing.
Open the mill: The device can be opened easily by
removing the hopper. When closing make sure the
hopper is in place properly.
The device has a safety button. When removing the
hopper the motor stops automatically - children
protection.
The device is free of service and maintenance.
However, keep original packing for possible trans-
port.
!
MILL COMBI STAR MILL COMBI STAR

WARRANTY
INFORMATION
1. Terms
The warranty of this device is 8 years from date of purcha-
se (proof of purchase). Any warranty service work will not
have an impact on the term. The warranty for spare parts
remains intact.
2. Coverage
Within said term all defects in materials or workmanship of
the device will be covered. Replaced parts remain our pro-
perty. The customer will be charged for transport of the de-
vice. Transport is at customer’s risk. Any damages during
the transport have to be reported immediately to the carri-
er. Any further claims are excluded, in particular claims for
recession, reduction in price or damages.
Excluded from this warranty are: Regular wear and tear
(eg millstones), misuse (eg device not used properly), sc-
arce care and cleaning, nonobservance of the user guide,
damages during transport and droppage, also excluded are
damages due to non corresponding power supply and also
damages caused by unauthorized third parties.
3. Area of validity
Warranty services will be covered in the country of purcha-
se. The warranty is solely valid if the device was purchased
by our defined chain of distribution. For devices which were
purchased in one European Union country and delivered to
another European Union country the warranty services are
subject to the country’s specific warranty conditions. There
will be an obligation for warranty services just in case the
device meets the technical requirements of the country in
which the warranty service will be executed.
8
15 16
KOOPERATIONSPARTNER DES OVE
MILL COMBI STAR MILL COMBI STAR

Type:
COMBI STAR - Grain mill and flaker
Waldner biotech GmbH guarantees that this device
fulfills within the term of the warranty the purpose
of use according to compliance with the user gui-
de and to proper care and cleaning. The customer
agrees to check immediately after purchase the
conditions and functionality of the device and to re-
port possible defects immediately to vendor. Only
authorized customer service is allowed to render all
type of services. Proof of purchase is always requi-
red for any desired service.
WARRANTY
Waldner biotech GmbH grants a warranty of 8 years
from date of purchase (proof of purchase) for your
device according to following conditions:
8
W
A
L
D
N
E
R
B
I
O
T
E
C
H
G
M
B
H
y
e
a
r
s
w
a
r
r
a
n
t
y
