WALDNER LADY User manual

USER GUIDE & CERTIFICATE
OF WARRANTY
MILL
LADY

We trust in domestic
woods and handcraft 100 %
made in Tyrol.
MILL LADY
GETREIDEMÜHLEN WALDNER BIOTECH GMBH
Kärntnerstraße 62, A-9900 Lienz/Osttirol
[phone], [e-mail]
www.waldner-biotech.at
design: aberjung.com
photos: ramonawaldner.com

GRAIN MILL LADY
TECHNICAL DATA
Overload protection with thermal sensors
child protection
Type of wood
Grinding output fine
Diameter millstone
Millstone
Grinding chamber
Hopper capacity
Dimensions H/D
Weight
Voltage/Hertz/Watt
Stone pine
120 g/min.
90 mm
white corundum
and ceramic
self-cleaning
1.000 g
32/18 cm
7,5 kg
220-240/50/400
KG
MILL LADY
2
MILL LADY
1
SAFTEY
INSTRUCTIONS
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person respon-
sible for their safety. Children should be supervised to ensure that
they do not play with the appliance.
This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops,
offices and other working environments;
- farm houses;
- by clients in hotels, motels and
other residential type environements;
- bed and breakfast type environments.
!ATTENTION: Misuse can cause injuries.
SAFETY: Never immerse the device into water. Only autho-
rized customer service is allowed to perform repairs using
original parts and spare parts. If the power cable of this
device is damaged, it must be replaced by the manufacturer
or its Customer service or a similarly qualified person in
order to avoid any danger.

4
MILL LADY
SPICES AND SALTS
Fennel, kummel, cilantro, sea salt, etc.
Tip: add to grains
COARSENESS SETTING FINE TO ROUGH
GRAINS AND SEEDS
Oat, flax seed, soya bean,
wild beans, etc.
COARSENESS SETTING MEDIUMFINE TO ROUGH
GRAINS
Spelt, wheat, millet, rye,
corn, rice, chickpea, etc.
COARSENESS SETTING FINE TO ROUGH
3
MILL LADY
1
2
3
56
7
8
9
10 11
4
COMPONENTS
1. Cover hopper
2. Hopper
3. Safety loop (not visible)
4. Upper and lower millstone
(not visible)
5. Coarseness scale
6. Locking screw
7. Safety push-button/mill (not visible)
8. Direction arrow
9. Output flour
10. Power switch mill ON/OFF
11. Power supply (not visible)

5
MILL LADY
6
MILL LADY
LIVING TRADITIONS

78
3
3. Release locking
screw in order to
turn hopper
1
1. Plug power plug
into socket
2
2. Press power switch
to ON
4
4. Turn hopper in the
direction of >MIKRO<
until you hear a slight
grinding sound.
MILL LADY
MILL LADY
MIKRO
0
M
IKR
O
MIKRO
2
0
1
0
gro
b
0MIKRO 2030
4050 10
fein grob
INITIAL OPERATION
1. Place mill on a ground surface. Attention: Never place the
mill on a hot surface (eg stovetop)
2. Check if supply voltage corresponds to the required voltage
for the device
3. Plug power plug into socket.
4. Press power switch to ON.
SETTING OF GRINDER
Coarseness can be regulated continuously. Just turn hopper
and adjust the distance of the 2 millstones according to the
desired coarseness. A locking screw on the side assures the
setting and prevents from loosening.
INITIAL OPERATION,
SETTING OF GRINDER
!NOTE: Efficiency & result of the grinding depend on the
quality of the mill material. The drier the mill material,
the higher the efficiency.

910
5 6
7
5. Twist back hopper until
the grinding sound disap-
pears - this is the finest
coarseness setting.
6. Mark this coarseness
setting on your mill. All
further settings can be
customized (from fine to
rough).
7. Put a bowl under flour
output prior to every use
of the device.
8
8. Have fun grinding!
MILL LADY
MILL LADY
0MIKRO 2030
4050 10
fein grob
0MIKRO 2030
4050 10
fein grob
0MIKRO 2030
4050 10
fein grob
0MIKRO 2030
4050 10
feing rob
TROUBLE
SHOOTING
The device can’t be
switched ON
REASON
Hopper is not completely closed
(safety button has no contact)
HELP
turn hopper in the direction fine
>fein<
REASON
The mill material used was too
damp for the desired coarseness.
HELP
Clean hopper and output (see also
chapter CLEANING). Dry the mill
material.
The flour output
is blocked.
Device stops during
grinding process.
REASON
Overheating of the motor
HELP
The device has a overload protecti-
on with thermal sensors and turns
on again automatically.
REASON
The mill material was too damp for
the desired coarseness or seeds
were ground too fine without ad-
ding dry mill material.
HELP
remove smudge from millstones
using a wire brush and afterwards
grind rice or corn roughly. (grinder
setting rough >grob<).
The grinder
is smudged

12
MILL LADY
MILL LADY
11
PASSION FOR
DETAIL

1
1. Turn off
hopper
3
3. Put on hopper
by turning
13 14
4
4. Start operation as
indicated on page 8
2
2. Clean with a brush
or aspirator
MILL LADY
MILL LADY
CLEANING
OF MILL
0MIKRO 2030 10
Clean housing with a soft, damp towel.
Clean grinding chamber with a brush or aspirator.
Clean the millstones by grinding roughly rice or
corn or by using a brush.
Never use sharp items or chemicals for the clea-
ning of the housing.
Open the mill: The device can be opened easily by
removing the hopper. When closing make sure the
hopper is in place properly.
The device has a safety button. When removing the
hopper the motor stops automatically - children
protection.
The device is free of service and maintenance.
However, keep original packing for possible trans-
port.
!

15 16
MILL LADY
MILL LADY
WARRANTY
INFORMATION
1. Terms
The warranty of this device is 8 years from date of purchase
(proof of purchase). Any warranty service work will not have
an impact on the term. The warranty for spare parts remains
intact.
2. Coverage
Within said term all defects in materials or workmanship of
the device will be covered. Replaced parts remain our pro-
perty. The customer will be charged for transport of the de-
vice. Transport is at customer’s risk. Any damages during
the transport have to be reported immediately to the carri-
er. Any further claims are excluded, in particular claims for
recession, reduction in price or damages.
Excluded from this warranty are: Regular wear and tear
(eg millstones), misuse (eg device not used properly), sc-
arce care and cleaning, nonobservance of the user guide,
damages during transport and droppage, also excluded are
damages due to non corresponding power supply and also
damages caused by unauthorized third parties.
3. Area of validity
Warranty services will be covered in the country of purcha-
se. The warranty is solely valid if the device was purchased
by our defined chain of distribution. For devices which were
purchased in one European Union country and delivered to
another European Union country the warranty services are
subject to the country’s specific warranty conditions. There
will be an obligation for warranty services just in case the
device meets the technical requirements of the country in
which the warranty service will be executed.
8

Type:
LADY - Grain mill
Waldner biotech GmbH guarantees that this device
fulfills within the term of the warranty the purpose
of use according to compliance with the user gui-
de and to proper care and cleaning. The customer
agrees to check immediately after purchase the
conditions and functionality of the device and to re-
port possible defects immediately to vendor. Only
authorized customer service is allowed to render all
type of services. Proof of purchase is always requi-
red for any desired service.
WARRANTY
Waldner biotech GmbH grants a warranty of 8 years
from date of purchase (proof of purchase) for your
device according to following conditions:
8
W
A
L
D
N
E
R
B
I
O
T
E
C
H
G
M
B
H
y
e
a
r
s
w
a
r
r
a
n
t
y
