Assembly Instructions
P.1
Revised 07/2020
Item # : BR3DSLDR
2018

P.2
VIII. Maintenance Guide
To maintain long term performance and easy gliding of your solid wood drawers, we recommend
applying wax to the wooden guide rails.
1. Bee's wax is recommended or Paraffin wax from a standard candle can be used.
2. Apply the wax by rubbing it on the wooden guide rails where there is wood-on-wood contact
when opening and closing the drawer. (Wax should be room temperature, do not melt the wax
onto the wood)
3. Wax should be applied every few months for the first year and then only when needed after
that to keep the drawers sliding smoothly.

P.3
Right side panel
Top panel
Back panel
Left crossbeam foot
Left side panel
Base
1
2
3
4
5
6
7
01
01
01
01
02
02
02
Drawer bottom
Right drawer side
12
13
01
03
Drawer back
14 01
Right crossbeam foot
Foot
Drawer runner
8
9
04
06
Small drawer front
Large left drawer side
Large right drawer side
Large drawer back
15
16
17
18
01
02
02
02
Large drawer front
10 02
Leg crossbeam
19 01
Description QtyPart# Description QtyPart#
1
2
3
4
5
6
9
19
14
13
12
2x
9
9
9
9
9
7
8
8
8
8
5
6
7
11
13
20
15
10
16
17
18
Front crossbeam
20 01
Left drawer side
11 01
Anti-tipping
23 01
12
The side drawer with
WARNING LABEL,
should be mouted in
highest drawer.
23

P.4
KWall anchor 01 pc
J574mm “H” Profile 01 pc
LWasher 02 pc
MØ6mm 01 pc
A
B
C
D
E
F
Ø8*30mm Wooden dowel 54 pcs
12 pcs
Screw 12 pcs
Ø3,5*30mm Screw 40 pcs
Ø4,0*40mm Screw 16 pcs
Ø10*10 Nail 18 pcs
Ø7*60mm Screw
4mm Hex Key
G04 pcs
H01 pcs
I Glue 01 pcs
Ø8*20mm Wooden dowel
Ø3,5*25mm
PScrew 04 pcs
Ø3,5*16mm
Hammer
recommended for assembly
(not included)

P.5
Step 1 A
A
AØ8*30mm 42
I01
Insert wood dowel (A) and glue (I)
into parts (2, 3, 5, 6, 11, 12, 16, 17, 19).
Insert wood dowel (B) and glue (I)
into part (9).
BØ8*20mm 12
A
A
A
A
A
A
A
A
A
A
A
A
AA
A
A
AA
A
A
A
A
A
B
B
A
A
A
A
A
A
A
A
Please assemble on
a clean soft surface
to avoid damage.
6x
3
2
20
5
6
19
9
2x
2x
12
11
17
16
2x
2x
Step 2
D
D
20 D
DØ3,5*30mm 02
Secure front cross beam (20)
to panels (2,3) using screw (D)
3
2

P.6
Step 3
Step 4
E
E
E
E
E
E
EØ4,0*40mm 06
Attach base(4)
to body using screw (E)
4
DØ3,5*30mm 04
Use screw (D) to attach part (5) to part (8)
and attach part (6) to part (8), do this step twice
D
2x
8
8
5
6
D
D
2x

P.7
Step 5
Step 6
E
E
E
EE
E
E
E
G+H
Ø7*80mm
4mm
G04
H01
EØ4,0*40mm 10
Use screw (E) to attach legs to body and
use screw (G) and hex key (H) to attach
the feet to the body.
Attach cross beam (19) to body using screw (E)
5
6
G+H
19
H
G
DØ3,5*30mm 06
1
D
D
D
Use screw (D) to attach
part (1) to body
D

P.8
Step 7
Step 8
Step 7
P
P
P
P
D
Secure anti-tipping (23) using screw (D) (P)
P
23
PØ3,5*16mm 04
D
DØ3,5*30mm 02
FØ10*10 18
J01
???mm
F
F
F
F
F
F
FFF
F
F
F
F
F
FFFF
J
J
7
7
Secure back panel (7) with part (J) to body with nails (F)
D
Please assemble on
a clean soft surface
to avoid damage.
Please assemble on
a clean soft surface
to avoid damage.

P.9
Step 9
Step 10
Insert wood dowel (A) into part
(9) (Runner small).
A
A
A
A
A
A
A
C
C
C
C
C
C
C
C
C
9
9
9
9
9
9
9
2
3
FRONT
CØ3,5*25mm 12
FRONT
AØ8*30mm 06
to attach

Step 11
Step 12
DD
D
D
DD
DD
DØ3,5*30mm 08
DD
D
D
DD
DD
2x
2x
DØ3,5*30mm 16
Step 13
Attach parts (11,12) to part (15) ,
insert panel (13) into groves and
secure part (14) with screws(D).
Attach parts (16,17) to part (10) ,
insert panel (13) into groves and
secure part (18) with screws(D).
14
13
12
11
15
10
16
17
18
13
A
A
A
P.10
15
10
10
AØ8*30mm 06
Insert wood dowel (A) on the
inside of all drawers while
drawer is inside the unit.
Make sure dowel is flush
with panel.
