Slide back panels (10,11) into the appropriate grooves at the back of the stand assembly.
Attach fell (21) to stand base (2) using large bolts (R) and wrench (S).

Attach stand base (2) to the stand assembly using large bolts (R) and wrench (S).
Attach the slat (20,22,23) assembly to stand base (2) using cam blots and dowels as guides.

Attach door hinges (K) to panels (3,4) using large screws(L) and small screws (M).
Attach the panel (14,15) assembly to the stand assembly at door hinges (K) using large screws (L).

Attach the panel (17,18) assembly to the stand assembly at door hinges (K) using large screws (L).
Insert shelf support pins (N) into the stand assembly at desired shelf heights. Carefully place
shelves (8)onto shelf support pins (N).Note that there will be two shelf support pins (N) on either
end of each shelf (8).

Secure back panels (10,11) using plastic wedges (P) and large screws (Q).
