1. INTRODUCTION
Power Sharing Smart
EN - V2.0 3
INSTALLATION GUIDE

1. Introduction
EN - V2.0 4
What is the biggest problem when installing many chargers?
• Available power is limited (upgrade of installation is very expensive).
How do we solve the problem?
• Most eicient distribution of the available power – without extra cost / additional device.
Which factors did we take into account?
• A car stays longer than it charges – Wallbox will use that available power.
• Each installation has their own characteristics – Wallbox allows a most flexible installation.
• The installation is often not connected to the Internet – Wallbox does not require
Internet-connection.
• When connecting many devices, easy troubleshooting is key – Wallbox gives full visibility
over the status.
Re-assignation of unused power, example:
• A car uses actually less than it has assigned from power sharing.
• A car is full and will not charge anymore.
Eiciency
20 kW 20 kW
15 kW 20 kW
20 kW 25 kW
15 kW 25 kW
INSTALLATION GUIDE

• If a charger looses connection (due to bad cabling) it can charge with 6 A and Master
will say “missing slaves”
• A newly powered on charger will be added to the system within 1 minute.
Robustness
EN - V2.0 5
• Connect between 1 and 24 chargers with the Master.
• Any kind of installation .
• Configuration of the system (power/chargers) can be easily changed.
• Up to 250 m distance of communication.
Possibility to install more chargers than can charge at the same time
“First-come-first-serve” principle
Example:
Flexibility
!
No. Chargers 3
Max. Current
12 A
Min. Current 6 A
1
Charging
23
In queue
