Operating Manual

Dear Customer,
Thank you for choosing a WALTRON daytime® LED light.
Your daytime® LED light is a high-quality product that was specially designed for aquatic and
terrarium applications. It satisfies the most demanding safety requirements.
The selection and design of the light's materials enables it to illuminate in the most adverse
conditions, even in saltwater aquariums.
The usage of modern, high-quality LEDs from a reputable supplier together with a heat removal
system guarantees that the light source will have a virtually unlimited service life. They also ensure
that the lighting will maintain the required energy efficiency for years to come.
The entire team at WALTRON wishes you a "bright" future with our daytime® lighting!
Notice, warning and safety symbols
The European Standard prescribes the use of the following symbols for specific situations; they
are not intended to unsettle the user.
They are a part of modern operating manuals for any electrically operated appliance.
General description:
Warning!
Serious injuries can result from an electric
shock if you do not follow the information
marked by this symbol.
NOTICE!
The daytime® products may malfunction or be
damaged if the information marked by this
symbol is not observed.
Info
Sections marked by this symbol contain
helpful recommendations and tips for using
the daytime® products.
Information for disposing of the product in an
environmentally responsible manner
Compliance with EC directives

Proper and intended usage
This product is designed for private home use. It is only intended as aquarium lighting and should
not be used for general lighting purposes.
Thus, this is not subject to the mandatory labelling requirements regarding energy efficiency
classification (refer to Regulation 874/2012 + 1194/2012).
Read and observe the entire operating manual before using the lighting for the first time. The
warranty does not cover damage or defects which have resulted from not observing the
information in the operating manual. Keep this operating manual accessible near the device. Make
sure that it is given to any subsequent users.
WALTRON assumes no liability for the consequences of improper usage.
For your safety
Warning! Carefully read and observe the
following important safety information. In
order to avoid an electric shock:
Position the device in a suitable place to
ensure that it is not exposed to water (from
condensation or falling into water).
Info! WALTRON recommends making
"drip loops" in the converter cables to prevent
water (condensation) from running along the
cable to the converter or outlet.
NOTICE! Make sure that all cables:
 have no kinks in them,
 are not routed over sharp edges, and
 cannot be jammed or snagged,
 cannot come into contact with hot
surfaces (> 60 °C).
Warning! If you notice that the power
cable is damaged, disconnect the device from
mains power supply immediately. Contact an
authorized daytime® service partner or the
manufacturer (WALTRON GmbH) directly.
Warning! If the operating device's power
cable or secondary cable(s) are damaged,
they must be repaired, either by an
authorized daytime® service partner or
directly by the manufacturer.
Never use a device which has a damaged or
defective power cable (operating device).
Warning! Never open or repair the
operating devices and lights by yourself. Do
not make any changes which are not
described in these operating instructions. The
operating device contains live (current-
carrying) parts (with 230 V AC). A fatal injury
can result from an opened device.
Repairs may only be carried out by
authorized daytime® service partners or by
WALTRON GmbH, using only original spare
parts and accessories.

We hereby confirm that the design and construction of the daytime® lighting series
matrix
complies with all relevant regulations, directives and safety requirements, as listed below:
Low Voltage Directive
2006/95/EG
Waste Electrical Equipment Directive
(WEEE) 2002/96/EC
EMC Directive
2004/108/EG
Product Safety Directive
2001/95/EG
ErP Directive (energy related design)
2009/125/EG
and the applicable standards
DIN EN 60598-1
Lighting – general requirements and tests
DIN EN 60598-2-11
Special requirements – aquarium lighting
DIN EN 62471
Photo-biological safety of LEDs
.......
Any changes in the lighting that are made without the approval of Waltron GmbH will invalidate
this declaration.

1) At least one matrix module and converter per lamp is required for operation
1. Scope of delivery
The standard delivery of the daytime® matrix includes:
1 pc. lamp, with 2-metre connection cable and protective panel
1 pc. "Inline" universal adapter set with rubber pads
1 pc. special key (tool for mounting and disassembling
the module, and for attaching the Inline adapter
system)
2. Required accessories1
NOTICE! Follow the instructions and notices concerning the installation and operation that
are included with the accessories.
The following accessories are available or required1 for setting up and operating the lighting:
2.1 matrix LED modules1
matrix module WW
 Warm White
 4,000 K
 PAR: 4.73 μmol/s/watt
 Power: 10 watts
matrix module NW
 Neutral White
 6,000 K
 PAR: 4.50 μmol/s/watt
 Power: 10 watts

matrix module UW
 Ultra White
 8,000 K
 PAR: 4.30 μmol/s/watt
 Power: 10 watts
matrix module UBRW
 Ultra Blue Red White
 Ratio of blue and red to white LED is
1:1:2
 440-455 nm + 620-630 nm + 8,000 K
 PAR: 4.26 μmol/s/watt
 Power: 10 watts
matrix module UBW 1:1
 Ultra Blue White 1:1
 Ratio of blue to white LED is 1:1
 440-455 nm + 8,000 K
 PAR: 4.06 μmol/s/watt
 Power: 10 watts
matrix module UBW 3:1
 Ultra Blue White 3:1
 Ratio of blue to white LED is 3:1
 440-455 nm + 8,000 K
 PAR: 3.94 μmol/s/watt
 Power: 10 watts
matrix module BR
 Royal Blue
 440-455 nm
 PAR: 3.81 μmol/s/watt
 Power: 10 watts

matrix-Modul SLF
 SunLike fresh
 25% SunLike-LED Seoul Semi.
 6.000 K + 440-455 nm + 620-630 nm
 PAR: 4,39 µmol/s/Watt
 Power: 10 watts
matrix-Modul SLM
 SunLike marine
 25% SunLike-LED Seoul Semi.
 8.000 K + 440-455 nm
 PAR: 4,06 µmol/s/Watt
 Power: 10 watts
1) At least one matrix module and converter per lamp is required for operations.
2.2 Converter (power supply) including power supply cable1
"Premium" 24 V LED converter
 40 watts
 60 watts
 90 watts
 120 watts
 180 watts
 240 watts
1) At least one matrix module and converter per lamp is required for operation

3. Optional accessories
NOTICE! Follow the instructions and notices concerning the installation and operation that
are included with the accessories.
3.1 matrix adapter sets
matrix acrylic adapter set
 For open aquariums
 For placing on aquarium edges
matrix swing adapter set
 For open aquariums
 For placing on aquarium edges
matrix insertion/screw-on adapter set
 For closed aquariums with terraced
levels
 For screwing onto suitable surfaces
matrix T8 adapter set
 For mounting into existing T8 lamp
holders
matrix T5 adapter set
 For mounting into existing T5 lamp
holders
matrix magnet holder set
 For attaching to magnetic surfaces
matrix wire suspension set
 For hanging over open aquariums

matrix cross-connector set
 For hanging two or three lamps over an
open aquarium
matrix Tetra AquaArt 100/130 adapter set
matrix Giesemann Sphera adapter set
matrix Aquatlantis adapter set
3.2 Adapter profiles for matrix
Adapter profile for JUWEL® aquariums
 For converting to matrix

3.3 Design profiles for matrix
Design-Profiles: Top White/Black
 For elegantly integrating the matrix into
open aquariums
Design-Profiles: Pendant White/Black
 For elegantly integrating the matrix into
open aquariums using wire suspension
3.4 Light controls for matrix
Smart Control SC20 3-channel
 Operating and programming using a
smartphone, tablet or PC
Basic Control BC16 1-channel
 Operating and programming using
3 buttons
3.5 Distributor, adapter cables for matrix
2-way distributor
 For operating two matrix lamps with a
converter or a light control unit
Adapter cables
 5-pin female connector, wire-end ferrule
 5-pin male connector, wire-end ferrule
 Set for GHL LEDControl4 V2 / ProfiLux

Set for EHEIM LEDcontrol+
Extension cables
 Length: 1 metre
 Length: 2 metre

3.6 Miscellaneous accessories for the matrix
Glare protection
 Anti-glare profile strip
 Reduces glare for a seated observer
Info! Further details, tips and technical data on these accessories can be found on our
homepage: www.daytime.de.
Our current product line is also described there. It is constantly being developed and
supplemented.

4. Overview and explanations of lamps

5. Setup and initial usage
5.1 Mounting and disassembling the protective panels
NOTICE! Carefully read the following description for installing and removing the protective
panels. Carry out the necessary steps as described.
Info! The matrix is configured by default with a non-breakable protective panel made of
polycarbonate. It reduces deposits and formation of encrustation inside of the lamp, thus
minimizing the required maintenance.
Mounting:
1. Insert one side of the panel over the
entire length into the profile groove.
2. Bend the end of the panel in a slight arc;
insert it into the opposite profile groove.
3. Press the panel in using a grazing
motion along the panel.

Disassembly:
1. Lift the panel slightly at one side
until the panel edges "jump out" of the
profile grooves.
NOTICE! Do not pull out, bend or
fold!
2. Use the special key tool to remove the
panel along its entire length.

5.2 Mounting the matrix LED modules
NOTICE! Carefully read the following description of the module's placement and attachment.
Carry out the steps described in the order listed.
The correct polarity must be observed (also refer to the mounting instructions enclosed
with the modules)!
The modules are inserted into the lamp profile by hand without extra equipment.
Use only the special key tool (included with the matrix) when attaching or removing the modules of
the Inline adapter system.
Verify that that module sets are complete:
 1 pc. matrix LED module
 4 pcs. cylinder head screws M4x8 (V4A)
 1 pc. installation instructions
Depending on the version, the modules can
have from 2 to 4 contact pins (on the bottom).
All pins must be fitted with a seal. Modules
with damaged or missing seal gaskets must
not be used.
Checking the inside of the lamp profile; remove
any residues from previous usage and clean
the inside.
For optimal heat dissipation, the partitions, in
particular, must be free of residues or other
foreign contaminants.
Select the module position and insert (but do
not press in yet) the module. Make sure the
polarity is properly aligned:
1 to 1 / 2 to 2 / 3 to 3 / + to +
(Refer to the label on the module and the lamp
profile.)
Remove the modules in order to change their
positions. Do not move any installed modules
within the lamp profile (the contacts must not
be "scraped").

Press in manually to mount the manual,
with two steps:
1. Side with no contacts
2. Side with contacts
Push the module into the profile as far as it
will go. Do not use any tools since they
could damage the module.
Screw the module into the lamp profile. Use
only the tool included in the delivery.
1. Screw all the screws straight in until you
feel resistance. (The screws should be
easy to screw in from the start. If they
cannot be easily screwed in, unscrew
them a bit and put them back in.)
NOTICE! Inclined (diagonal)
insertion will damage the thread
grooves.
2. Tighten the screws with moderate and
uniform force until the gap between the
bottom of the module and the profile
partitions is closed.
NOTICE! Screwing in too tightly
will damage the thread grooves.
Info: The gap is considered
closed when you can no longer push
the corner of a sheet of standard
copy paper (80 g/m²) into it.
1.
2.

5.3 Disassembly of the matrix LED modules
NOTICE! Carefully read the following description of the module's removal. Carry out the
steps described in the order listed.
The modules should be removed using the special key tool supplied with the matrix.
...
Loosen and remove all screws.
Lift and remove the module in two steps:
Insert the short, rubber shank of the special
key tool into the thread grooves and lever
out the module.
1. On the contact side
NOTICE! The rubber part must be
on the short shank of the key tool. It
must also cover the key edges
completely so that it does not
damage the bottom of the module.
2. On the non-contact side
NOTICE! Check to make sure that
there are no sealing gaskets
remaining between the profile
partitions. Check that all contact pins
still have a seal on them. Thread
them on by hand if necessary.
1.
2.

5.4 Adjusting and attaching the Inline adapter system
NOTICE! During the setup and initial usage, make sure that there is at least a 15-mm gap
between the bottom of the lamp and the water surface.
The matrix includes the Inline adapter system
(four adapter rods in the non-slip profile).
In their delivered state, these are already
attached with screws so that they are flush with
the lamp ends.
The rods can be moved by loosening (¼-
turn)* the screws.
You can use the special key tool to remove
the rods.
* Do not loosen the screws more than a ¼ turn,
so that the adapter rods always remain in their
correct positions.
The adapter rods are graduated at one side
and have a rubber bumper. These can be used
for support (e.g. directly at the tank edge or on
one partition of the cover).
After adjusting to fit the tank width, tighten
the screws gently a bit so that the rods are
secured in place.
There is a metric-threaded hole (size: M3) on
the opposite side that can be used to attach
various adapter sets (refer to the the Available
Accessories chapter).
The Inline adapter system allows two matrix
lights to be connected at the front side.
1. Push the adapter rods halfway out of
one lamp and secure in place. Remove
the rods from the second lamp.
2. Put them together and secure in place.
NOTICE! We recommend using the cord
suspension or a middle support (e.g. glass
partition) when using this connection; this will
avoid any bending that could be visually
disturbing.
1/4

5.5 Electrical connections
NOTICE! Never connect or disconnect the secondary cables while voltage is applied (while
the power cable is plugged in).
Info! To switch on or off, we recommend using a timed switch, a switched outlet or a power
strip with an integrated fuse.
1. Connect the secondary cable (output)
from the converter to the lamp's
connecting cable.
NOTICE: Make sure that the
connection is secure and tightly
fitting. You should be able to notice
when the round plug clicks into its
connection.
2. Connect the power cord of the converter
to a grounded (earthed) electrical outlet.
The optional daytime® light controllers,
distributors, adapters and extension cables
(refer to the accessories list) are all equipped
with an identical circular plug. They are
plugged (simply "Plug & Play") between the
converter and lamp.
For further information and notes on installation
and initial commissioning, please refer to the
documents supplied with the accessories.
6. Maintenance and cleaning
The lamps should be cleaned of any dirt or deposits regularly, especially the insides. (Also refer to
the "Mounting the matrix LED modules" chapter.) Use a clean, lint-free cloth (e.g. a microfibre
cloth) moistened with lukewarm water and, if necessary, a little vinegar. Do not use abrasive,
chemical or solvent-based cleaners.

7. Technical specifications
Size Length of profile
[cm]
Max. number of
modules [pc.
]
Max. power [w]
matrix20.0 16.6 1 10
matrix30.0 25.0 1 10
matrix40.0 35.0 2 20
matrix50.0 45.0 3 30
matrix60.0 55.0 4 40
matrix70.0 65.0 5 50
matrix80.0 75.0 6 60
matrix90.0 85.0 7 70
matrix100.0 95.0 8 80
matrix110.0 105.0 9 90
matrix120.0 115.0 10 100
matrix130.0 125.0 11 110
matrix140.0 135.0 12 120
matrix150.0 145.0 13 130
matrix160.0 155.0 14 140
matrix170.0 165.0 15 150
matrix180.0 175.0 16 160
matrix190.0 185.0 17 170
matrix200.0 195.0 18 180
matrix210.0 205.0 19 190
matrix220.0 215.0 20 200
matrix230.0 225.0 21 210
• • 22 220
• • 23 230
• • 24 240
matrix400.0 395.0 24 240
