Wampat A-SCT0891W User manual

A-SCT0891W
Assembly Instructions

1
2
3
4
5
6
7
8
12
11
9
10
13
7
10
10
12
13
１

1 2
1 2
● The provided glue(I) is to
secure wood dowels(A) in place .
When first inserting dowels,
locate the appropriate hole for
the dowel , place a small amount
of glue in the hole and insert the
dowel . Wipe away excess glue
immediately.
● In future assembly steps when
dowels are necessary to attach
assembly parts together,place a
small amount of glue on the end
of the dowel before attaching
parts together. Wipe away
excess glue immediately.
Wooden dowel
Ø8x30mm
A x 20
Cam bolt
Ø6x35mm
B x 16 C x 16
Cam lock
Ø15x11mm
D x 16
Sticker
E x 2
Plate
F x 6
G x 12 H x 4
Screw
Ø4x15mm
Shelf support pin
Ø8x5x16mm
Bolt Glue tube
I x 1
Ø4x50mm
J x 6 K x 8
Plastic wedge
L x 8
Flat-head screwScrew
Ø3x17mm
Hexagon socket key
M 4
M x 1
Ø6x13mm
N x 16 O x 2 P x 2
Pulley
Bolt
Philips head screwdriver
required for assembly
(not included)
Ø6x13mm
Q x 1 R x 1
S x 1 T x 1
Handle bolt
Ă4x19mm Handle Screw Ø4x12mm
Screw
Ø4x25mm
U x 1
Plastic strap Nut
２

Ø6x35mm
· Screw parts (B) into panels (8,9).
9
8
B
B x 8
３

1 2 3
Ø8x30mm Ø15x11mm
· Insert dowels(A) into panels(3,5).
· Attach panel (9) to panel (5).
Attach panel (8) to panel (3).
· Insert and secure cam lock (C) to panels
(3,5) to lock it.
5
9
3
8
A C A x 4 C x 6
４

Ø8x30mm Ø15x11mm
A x 2 C x 2
1 2 3
3
5
6
A
C
· Insert dowels(A) into panels(3,5).
· Attach panel (6) to panels (3,5).
· Insert and secure cam lock (C) to panel
(6) to lock it.
５

Ø4x50mmØ8x30mm
J
3
5
4
· Insert dowels(A) into panels(3,4,5).
· Attach panels (3,4,5) to panel (2)
using screws(J).
2
A
A x 6 J x 6
６

13
12 13
12
N
· Attach parts (12) to parts (13)
using Bolts(N).
M 4 Ø6x13mm
M x 1 N x 8
７

Ø6x13mm
· Attach parts(12,13) to panel(2) using Bolts(N). N x 8
2
N
12
12
13
13
８

H x 4
Ø6x13mm
O x 2 P x 2 Q x 1
Ă4x19mm
· Attach parts(O) to panel (11) using
bolts(H).
· Attach part(Q) to panels(11) using
bolts(P).
９
H O
11
P
Q

１０
· Slide panel (11) into designated area.
6
11

１１
Ø4x15mm
E F
· Attach parts(E) to back of panel (11)
using screws(F) as shown. 11
5
3
E x 2 F x 6

１２
·Carefully slide panels (7) into place
along the back of the assembly.
7
7

１３
Ø6x35mm
· Screw parts (B) into panel (1).
B x 8
B
1

１４
1 2 3
Ø8x30mm Ø15x11mm
· Insert dowels(A) into panels(3,4,5,6).
· Attach panel (1) to panels (3,4,5,6).
· Insert and secure cam lock (C) to panels
(3,4,5,6) to lock it.
A x 8 C x 8
1
6
5
4
3
A
C

１５
Ø3x17mm
K
L
· Secure parts(K) using Screws(L).
7
7
K x 8 L x 8

１６
Ø8x5x16mm
· Attach panel(10) to panels(4,5) using parts(G).
Finished edge
G x 4
G
5
10

１７
Ø8x5x16mm
· Attach panels (10) to panels(3,4) using parts(G).
Finished edge
Finished edge G x 8
3
G
10
10
4

１８
1 2 3
WARNING
Ø4x12mm Ø4x25mm
Wall
R x 1 S x 1 T x 1 U x 1
Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from
tipping over we recommend that it is permanently fixed to the wall. Wall anchor and
hardware are included with this product. Please make sure hardware is suitable for your
walls before installing, as different wall materials may require different types of anchors.
S
1T
R
U
