Warmtec RSD-10 User manual

RSD-10
manual
USER
v_1_03
Temperature
controller

1. Product descripon
DIN-TC type temperature controller is most use in the electric
distribuon box，it can be easy install on the din rail and with the
NTC10K temperature sensor, which is included in the kit. Aer proper
connecon, the device allows you to control:
2
2. Technical specificaon temperature controller RSD-10
źrefrigerated counters,
źrefrigerator,
źfans,
źfreezers,
źother refrigeraon
equipment.
Heang
Cooling
COLD HOT
Thank you for choosing our product.
See the latest version of the manual at www.warmtec.pl.
źother heang devices.
źheang cables, an-icing systems
źboilers, heaters, central heang
pumps,
źelectric heaters, storage heaters,
źincubators, terrariums,
aquariums,
Power supply
~230 V / 50 Hz
Measure range -20°C - +100°C
Pomiar i nastawa z dokładnością 0,1°C
Sampling speed 10 second each me
Working environment 0 - 50°C
Sensor type NTC 10K (2m cable length)
Sensor ingress Protecon IP44
Ingress Protecon IP20
Installaon method DIN-RAIL
Max. load 10 A
Protecon against electric shock II

3. Dimensions & drawing
4. Wiring diagram
SET
RUN COLD HOT
C
3
CLH IN
°C
Heating
SET
NTC sensor
L
N
L
CH IN
°C
NTC sensor
SET
Cooling
L
N

5. Control panel
4
3. The COLD icon lights up when the cooling mode is on.
4. The HOT icon lights up when the heang mode is on.
6. Buon allows you to undo the sengs or go to the main mode
of the displayed temperature.
1. Display temperature
7. Buon increases the value.
8. Buon decreases de wartość.
5. Buon allows you to go to the sengs of the regulator's
operaon (press and hold for 5 seconds). This buon is also used to
confirm the preset sengs.
2. The RUN icon indicates that heang/cooling is on.
SET
SET
RUN COLD HOT
C
1
24
7
5
3
6 8
6. Error display
“-20” the sensor is not connect to the device

5
By default, the digital display shows the currently measured
temperature. To go to the preview of the set temperature sengs,
press the SET buon. Then press the SET buon again and use the +/-
buons to set the appropriate temperature.
7. Device operaon
A) Simple mode
Preview
temperature
set
Changing the sengs
(+/- buons)
Current
temperature
+
-
SET(1 press)SET(1 press)
B) Advanced mode
- "SC" temperature calibraon.
Then press the SET buon again and use the +/- buons to change
the seng values.
To change the sengs in advanced mode, press the SET buon unl
the appropriate "d", "delay" or "SC" appears on the display.
Advanced mode also allows you to change the following sengs:
To start the advanced mode, hold the SET buon for 5 seconds, then
use the +/- buons to select the appropriate operang mode and
confirm again with the SET buon.
- seng the "COLD" cooling mode,
- hysteresis value "d",
- me delay "delay”
- seng the "HOT" heang mode,
Simple mode sengs diagram

Code Descripon
Cold mode should be set if you want
for the temperature controlle to control the
operaon cooling device.
Hot mode should be set if you want
for the temperature controller to control
the operaon heang device.
The temperature controller allows you to
adjust the hysteresis value in the range
from 0 to 15°C.
Cooling
mode
(COLD)
C
HTryb
ogrzewania
(Hot)
dValue
hysteresis
dely Relay operaon
delay me
Temperature
deviaon
sc
The temperature controller allows you to
set the delay of switching on the device in
the range of 0-300 seconds.
The temperature controller allows you to
calibrate temperature indicaons in the
range of +/-15°C.
6
Name

7
Current
temperature
Changing the operang
mode (Cooling - COLD)
Changing the operang
mode (Heang - HOT)
Seng mode
hysteresis values
Seng mode
delays
temporary
Increased value
me delay
by +/-
Seng mode
calibraon
temperature
SET(5s)
SET(1 press)
SET(1 press)
SET(1 press) SET(1 press)
SET(1 press)
SET(1 press)
SET(1 press)
SET(1 press)
+
-
Advanced mode sengs diagram
Changing the sengs
(+/- buons)
Changing the sengs
(+/- buons)
You can return your used device to the retailer where you can buy a new one. They will be
collected by the CCR REEWEEE Recovery Organizaon, with which we have signed a contract for
the collecon of waste equipment.
We hereby inform you that the main purpose of the European regulaons and the Act
ofSeptember 11, 2015 on waste electrical and electronic equipment is to reduce the amount of
waste generated from equipment, ensure an appropriate level of collecon, recovery and
recycling of waste equipment and increase social awareness of its harmfulness to the natural
environment at every stage of use of electrical and electronic equipment.
Therefore, it should be pointed out that households play a key role in contribung to reuse and
recovery, including recycling of waste equipment. The user of equipment intended for
households is obliged to return waste electrical and electronic equipment to a collector aer its
use. However, it should be remembered that products belonging to the group of electrical or
electronic equipment should be disposed of at authorized collecon points.
INFORMATION ON USED ELECTRICAL AND ELECTRONIC EQUIPMENT
8. Environmental protecon and recycling

v_1_03
IMPORTANT INFORMATION FOR CORRECT DISPOSAL IN ACCORDANCE WITH
EC DIRECTIVE 2012/19/EU.
At the end of its useful life, the product must not be disposed of as household
waste. It must be delivered to the special collection point of the different
local authorities or to a retailer providing this service. Disposing of your
household appliance separately avoids possible negative consequences for
the environment and health resulting from improper disposal and enables
the recovery of component materials to achieve significant energy
savingsand resources. Reminding you of the need to dispose of household
appliances separately, the product is marked with a crossed-out wheeled bin.
ATTENTION! DO NOT THROW THE DEVICE INTO DOMESTIC WASTE
