WATANABE WPMZ-5 User manual

MODEL WPMZ-5-□□□-□□-□□□ 1/12
IM-0834-03
Thank you for purchasing the WPMZ graphical digital panel meter.
This manual is a quick instruction manual only for preparation,
connection and basic condition settings of the WPMZ. For the all
functions of WPMZ, please refer to a detailed instruction manual
which can be downloaded from our homepage.
For models with RS communication functions, please refer to
"Modbus communication manual" or "RS-232C communication
manual" which also can be downloaded from our homepage.
（http://www.watanabe-electric.co.jp/en/）
Checks before suppling power, preparations, wiring
１. CHECKING THE PRODUCT
１－１. MODEL CODES
Please check that the product has been delivered matches the
model code has been ordered in reference to
“17. SPECIFICATIONS”.
２. PRECAUTIONS ＦＯＲ ＵＳＥ
２－１. ENVIRONMENTS AND CONDITIONS OF USE
Please do not use the product under the following circumstances.
It might cause malfunctions and shortening the life of the
product.
1）Ambient temperature of out of -5 to 50℃
2）Ambient humidity of out of 35 to 85%, or freezing
condensing
3）High dust or metallic powder level
(Storing in a dust-proof chassis and a countermeasure
against heat dissipation are required.)
4）Environment of corrosive gas, salty air or oily smoke
5）Environment of much vibration or impact
6）Environment of rain or water drops (except the frontpanel)
7）Environment of strong electromagnetic field or much
exogenous noises.
２－２. INSTALLATION AND CONNECTION
1）Please read this manual before the installation and the
connection of wires. And they should be performed by a
person having a specialized technique. In addition, the
insulation class of the WPMZ is as shown by the figure
below. Please confirm that the insulation class satisfies a
use condition prior to the installation.
Reinforced Insulation Basic Insulation
Operational Insulation
AC
power
Comparative outputs, External
control inputs, Analog output,
BCD output,RS-232C
RS-485
Modbus
RTU
Input Ach
Input Bch
DC
power
Comparative outputs, External
control inputs, Analog output,
BCD output,RS-232C
RS-485
Modbus
RTU
Input Ach
Input Bch
2）Do not wire the power supply line, input signal lines and
output signal lines near noise sources or relay drive lines.
3）Bundling or containing in a same duct with lines including
noises might cause malfunctions.
4）The WPMZ becomes available functionally right after
power activation, but requires 30 minutes' warming to
satisfy all performance requirements.
Note: The inputs “A channel” and “B channel”may be
abbreviated to “Ach”and “Bch”in this manual.
２－３. CHECKING BEFORE USE
Install the WPMZ under the environments and conditions of use
which meet requirements.
If you find any damage to the product or any problem, please
contact to your dealer or our company directly.
３. HOW TO INSTALL (PANEL CUT DIMENTIONS)
To install the WPMZ, panel cut dimensions are as shown by the
figure below.
４. CONNECTING TERMINALS
４－１. BACK VIEW
４－２. WIREING TO SCREWLESS TERMINALS
Pushing the wire release button with a flat-blade screwdriver,
insert the wire to the wire insert hole deeply and then release
the button.
（Suitable tool for pushing buttons ：flat-blade screwdriver blade
width 2.5mm）
４－３. CONNECTON FOR LOWER ROW TERMINALS
（COMPARETIVE OUTPUT／EXTERNAL CONTROL
INPUT, POWER）
４－３－１. Comparetive Output／External Control Input
*Screwless connector
【Open-collector output products】
No.
Name
Description
1
AL1 c
AL1 open-collector output (collector)
2
AL2 c
AL2 open-collector output (collector)
3
AL3 c
AL3 open-collector output (collector)
4
AL4 c
AL4 open-collector output (collector)
5
AL+COM e
Common terminal for PNP output (emitter)
(NPN output : no connection)
6
AL-COM e
Common terminal for NPN output (emitter)
(PNP output : GND for PNP)
7,8
COM
Common terminal for external control inputs
9
1
External control input No.1
10
2
External control input No.2
11
3
External control input No.3
12
4
External control input No.4
13
5
External control input No.5
【Relay output products】
Graphical Digital Panel Meter
ＷＰＭＺ－５－□□□－□□－□□□
Quick instruction manual
AL2 (c)
5
COM
AL1 (c)
AL4 (c) AL3 (c)
COM
AL +COM(e)
AL -COM(e)
1 2 3 4 5 6 7 8 9
10 11 12 13
4
32
1
EXT CONTROL
PNP
NPN
Suitable wire：AWG24 to 16
*⑥、⑦、⑧：connected internally
Ach inputs Bch inputs
Power
Comparetive output/External control input
outputs
UPPER ROW TERMINALS
MIDDLE ROW
TERMINALS
LOWER ROW TERMINALS
120mm min.
70mm min.
+0.6 -0
45
92 -0
+0.8
Wire insert hole
Wire release button

MODEL WPMZ-5-□□□-□□-□□□ 2/12
IM-0834-03
AL1・2 COM
COM
AL1
Suitable wire：AWG 24 to 16
AL3 AL2
×
AL3・4 COM
AL4
1 2 3 4 5 6 7 8 9
10 11 12 13
EXT 1 EXT 2
EXT 3
EXT 4
EXT 5
External control inputsRelay outputs
No.
Name
Description
1
AL1
AL1 relay output
2
AL1.2 COM
Common terminal for relay outputs of AL1 and AL2
3
AL2
AL2 relay output
4
AL3
AL3 relay output
5
AL3.4 COM
Common terminal for relay outputs of AL3 and AL4
6
AL4
AL4 relay output
7
×
No connection
8
COM
Common terminal for external control inputs
9
EXT 1
External control input No.1
10
EXT 2
External control input No.2
11
EXT 3
External control input No.3
12
EXT 4
External control input No.4
13
EXT 5
External control input No.5
４－３－２. Supply Power
Terminal
Name
Description
P1
POWER
(+)
Power source terminal
(In case of DC power, ＋V）
P2
POWER
(－)
Power source terminal
(In case of DC Power, 0V）
P3
FG
(NC)
FG terminal
(DC power option: no connection
( Non-usable for a relay terminal))
４－４. CONNECTION FOR UPPER ROW TERMINALS
４－４－１. Pulse Inputs (Open collector/Logic/Zero cross/2wire)
*Screwless connector
●A channel pulse input
terminal
name
description
14
IN
Ach pulse input terminal
15,16
GND
Ach input GND terminal
17
+EXC
Ach sensor power output terminal (+)
18
－EXC
Ach sensor power output terminal (－)
19,20
NC
No connection
*Non-usable for a relay terminal
●B channel pulse input
terminal
name
description
21
IN
Bch pulse input terminal
22,23
GND
Bch input GND terminal
24
+EXC
Bch sensor power output terminal (+)
25
－EXC
Bch sensor power output terminal (－)
26,27
NC
No connection
*Non-usable for a relay terminal
・Examples for Input connections
４－４－２. Line Driver Inputs *Screwless connector
●A channel line driver input
terminal
name
description
14
LINE(+)
Ach Line driver input terminal (+)
15
LINE(－)
Ach Line driver input terminal (－)
16
GND
Ach GND input terminal (+)
17
+EXC
Ach sensor power output terminal (+)
18
－EXC
Ach sensor power output terminal (－)
19,20
NC
No connection
*Non-usable for a relay terminal
●B channel line driver input
terminal
name
description
21
LINE(+)
Bch Line driver input terminal (+)
22
LINE(－)
Bch Line driver input terminal (－)
23
GND
Bch GND input terminal (+)
24
+EXC
Bch sensor power output terminal (+)
25
-EXC
Bch sensor power output terminal (－)
26,27
NC
No connection
*Non-usable for a relay terminal
・Examples for Input connections
４－５. CONNECTION FOR MIDDLE ROW TERMINALS
４－５－１. Analog Output *Screwless connector
POWER
FG
（－） （＋）
P2 P1 5.8max.
Suitable crimping
terminal
5.8max.
P3
（NC）
( )：DC POWER
V.OUT
V.COM
NC
A.OUT
A.COM
NC NC
34
28 29 30 31 32 33
* 、 :connected internally
29 32
Suitable wire：AWG24 to 16
IN
GND
+EXC -EXC
GND
IN
GND
+EXC -EXC
GND
20
14 15 16 17 18 19 27
21 22 23 24 25 26
*⑮、⑯、⑱:connected internally * 、 、 :connected internally
22 23 25
NC NC
NC NC
Suitable wire：AWG24 to 16 Suitable wire：AWG24 to 16
Ach pulse input Bch pulse input
LINE(+) LINE(-)
+EXC -EXC
GND
LINE(+) LINE(-)
+EXC -EXC
GND
20
14 15 16 17 18 19 27
21 22 23 24 25 26
*⑯、⑱ :connected internally * 、 :connected internally
23 25
NC NC NC NC
Suitable wire：AWG24 to 16 Suitable wire：AWG24 to 16
Bch Line driver inputAch Line driver input
+5V
+EXC
LINE+
LINE-
-EXC
WPMZ-5 Line driver input
Line driver signal
VCC
GND
330Ω
2kΩ
2kΩ
47kΩ
47kΩ
+5V
-1.2V
+12V
(+24V)
GND
-EXC
+EXC
IN
VCC
GND
WPMZ-5
Input type：Open collector
NPN Open collector
Approx.10kΩ
(Approx.25kΩ)Approx.5kΩ
Approx.10kΩ
+12V (+24V)
GND
-EXC
+EXC
IN
VCC
GND
VCC
GND
WPMZ-5 Input type：Logic
PNP
Open collector
Voltage
pulse
Approx.5kΩ
Approx.10kΩ
+12V (+24V)
+EXC
IN
GND
-EXC
WPMZ-5 Input type：Two-wire
Approx.5kΩ
Approx.900Ω
Two-wire sensor
Proximity sensor etc.
+12V (+24V)
+EXC
IN
GND
-EXC
WPMZ-5 Input type：Zero-cross
Approx.5kΩ
Approx.10kΩ
Zero-cross signal
+12V
(+24V)
GND
-EXC
+EXC
IN
VCC
GND
WPMZ-5
Input type：Open collector
NPN Open collector
Approx.10kΩ
(Approx.25kΩ)Approx.5kΩ
Approx.10kΩ
+12V (+24V)
GND
-EXC
+EXC
IN
VCC
GND
VCC
GND
WPMZ-5 Input type：Logic
PNP
Open collector
Voltage
pulse
Approx.5kΩ
Approx.10kΩ
+12V (+24V)
+EXC
IN
GND
-EXC
WPMZ-5 Input type：Two-wire
Approx.5kΩ
Approx.900Ω
Two-wire sensor
Proximity sensor etc.
+12V (+24V)
+EXC
IN
GND
-EXC
WPMZ-5 Input type：Zero-cross
Approx.5kΩ
Approx.10kΩ
Zero-cross signal

MODEL WPMZ-5-□□□-□□-□□□ 3/12
IM-0834-03
●WPMZ-5-□□□-1□-□□□
terminal
name
description
28
V.OUT
Analog voltage output terminal (+)
29
V.COM
Analog voltage output terminal (－)
30
NC
No connection
*Non-usable for a relay terminal
31
A.OUT
Analog current output terminal (+)
32
A.COM
Analog current output terminal (－)
33,34
NC
No connection
*Non-usable for a relay terminal
４－５－２. BCD Output *MIL connector
●WPMZ-5-□□□-2or3□-□□□
terminal
name
description
1 to 4
1001-8
Bit 1-8 of BCD 100 digit output terminals
5 to 8
1011-8
Bit 1-8 of BCD 101 digit output terminals
9 to 12
1021-8
Bit 1-8 of BCD 102 digit output terminals
13 to 16
1031-8
Bit 1-8 of BCD 103 digit output terminals
17 to 20
1041-8
Bit 1-8 of BCD 104 digit output terminals
21 to 24
1051-8
Bit 1-8 of BCD 105 digit output terminals
25
POL
BCD polarity output terminal
26
OVER
BCD over output terminal
27
PC
BCD synchronous signal output terminal
28
ENABLE
BCD enable terminal
By bringing to same voltage level of -D.COM
or connecting to –D.COM, transistors of BCD
outputs become OFF.
29 to 32
-D.COM
Common terminal for BCD open collector
NPN
33,34
+D.COM
External power terminal for BCD open
collector PNP
４－５－３. RS-232C *Screwless connector
●WPMZ-5-□□□-4□-□□□
terminal
name
description
28
RXD
receive data terminal
29
TXD
transmit data terminal
30
SG
common terminal for communication function
31 to 34
NC
no connection
*Non-usable for a relay terminal
４－５－４. RS-485 Modbus RTU *Screwless connector
●WPMZ-5-□□□-5□-□□□
terminal
name
description
28
＋
Non-inverting signal
29
－
Inverting signal
30
SG
Signal ground
31
＋
Non-inverting signal
32
－
Inverting signal
33,34
TERM
Terminal resistance （120Ω）terminals
* Short 33 and 34 to be enable the resistance.
５. NAMES OF EACH PART
５－１. NAMES OF EACH PART
５－２. EXPLANATION OF ICONS
５－２－１. Display Icons On The Measurement Display
These icons are displayed on the top or the bottom of the
measurement display.
Icon
Meanings
Indicates pattern No. in use.
Indicates key lock function is effective.
Indicates comparative output reset function（an external
control function）is effective.
Indicates measurement inhibit function（an external control
function）is effective.
Indicates display hold function（an external control function）
is effective.
Indicates maximum value or minimum value hold function（an
external control function）is effective.
５－２－２. Key Operation Icons On The Setting Display
Key operation icons which are displayed on setting displays
are shown below.
Icon
Meanings
Icon
Meanings
MENU key
ARROW key（LEFT）
FUNC key
ARROW key（RIGHT）
ENTER key
ARROW key（UP&DOWN）
DISP key
ARROW key
（LEFT&RIGHT）
ARROW key（UP）
ARROW key（ALL）
ARROW key（DOWN）
Pattern No. under setting
No.
Name
Function
①
Display title
Indicates contents of display
②
Comparison result
Lights when the result of comparative output is
ON.
③
Key lock
Lights when the key lock is effective.
④
Pattern
Indicates pattern No. in use.
⑤
1st item display
Displays measured value of 1st item
⑥
FUNC key
Used for registering external control shortcut
function.
⑦
MENU key
Used for moving to setting display and returning
measurement display.
⑧
Arrow keys
Used to move the cursor and to move to other
displays while setting mode.
*When the shortcut function is registered, the
assigned function will be valid by holding down
the key over 1 second.
⑨
ENTER key
Used to validate setting value.
⑩
DISP key
Used to switch measurement display.
⑪
Display unit
Unit for 1st item display
⑫
External control
Lights when any of external control functions are
valid
⑬
3rd item display
Displays measured value of 3rd item
⑭
2nd item display
Displays measured value of 2nd item
⑮
Comparison result
Lights when the result of comparative output is
ON.
⑯
Judgement value
Shows value or area of comparison judgement
ENABLE
34
33
-D.COM
OVER
2
1
10
2 8 2 8 2 8 2 8
1 4 1 4 1 4 1 4
010 110 210 3
10 010 110 210 3
-D.COM
PC
POL
1 4
10 4
2 8
10 4
-D.COM
+D.COM (PNP)
-D.COM
+D.COM
(PNP)
Suitable wire：AWG#28 flat cable(7/0.127mm)
2 8
10 5
1 4
10 5
RXD
TXD
SG
NC NC NC NC
34
28 29 30 31 32 33
Suitable wire：AWG24 to 16
＋
RS-485
TERM
TERM
SG
－＋
RS-485
－
34
28 29 30 31 32 33
Suitable wire：AWG24 to 16
ENTER
DISP
MENUFUNC
⑦
⑧
⑨
⑩
③②①
⑪⑫
④ ⑥⑫
⑤
⑭
⑬
⑮
⑯

MODEL WPMZ-5-□□□-□□-□□□ 4/12
IM-0834-03
BASIC OPERATIONS, SETTINGS
６. BASIC OPERATIONS OF MEASUREMENT DISPLAY
During measurement mode, the following key operations can be done.
①By pushing the “DISP key” in the measurement mode, the display can be switched to others which are selected in “display select”.
②By pushing the “MENU key” in the measurement mode, the display moves to the setting display.
Alternatively, by pushing the “MENU key” in the setting display, the display returns to the measurement display
③By pushing the “FUNC key” in the measurement mode, the display moves to the shortcut entry display.
Alternatively, by pushing the “FUNC key” in the shortcut entry display, the display returns to the measurement display.
④During measurement, by holding down the “arrow key” in 1 second, the shortcut function registered to the key will be executed.
On this occasion, the display has no change.
７. SETTING LAYER OVERVIEW
The setting menus of the WPMZ which are represented by key words and have layers, therefore desired setting menu can be selected
accurately. The layers consist of 1st layer to 4th layer (Only custom unit setting has the 5th layer).
Please refer to “8. BASIC OPERATION OF SETTING DISPLAY” about how to set up.
1st layer
Large categories
2nd layer
Small categories
3rd layer (setting items)
4th layer (setting contents)
Remarks
name of item
Character strings on
display
(abbreviated form)
Initial values
Settable variables
1.Input
(WPMZ-5-□P□)
Pulse input A
Pulse input B
Pattern select
PatternSelect
Pattern1(or pattern No.
in use)
Pattern1/ Pattern 2/ Pattern 3/ Pattern 4/ Pattern
5/ Pattern 6/ Pattern 7/ Pattern 8
Select pattern No. to set.
Input type
InputType
OpenCollector
OpenCollector/Logic/ZeroCross/2Wire
Select input signal type
Input filter
InputFilter
None
None/30Hz/1.5kHz/15kHz
Select analog input filters
Sensor power
SensorPower
12V
12V/24V
Switch Sensor power voltage
Instantaneous value
display coefficient
InsDispCoef
1.00000×100
0.00000 to 9.99999×10-9～9
For scaling setting of instantaneous value display,
multiply frequency by instantaneous coefficient and
unit time.
Instantaneous unit
time
InsUnitTime
Sec
Sec/Min/Hour
Instantaneous value
decimal point position
InsDecPoint
######
(No decimal point)
######/ #####.#/ ####.##/ ###.###/ ##.####/
#.#####
Set number of digits after decimal point
Instantaneous value
display unit
InsDispUnit
None
None/select from 62 units (See 6-2)/custom unit
Refer to detailed instruction manual about custom
unit
Instantaneous value
auto zero
InsAutoZero
0.00
0.00 to 99.99sec
Displays 0 if no pulse input over more than setting
time
Instantaneous value
moving average
InsMoveAve
None
None/2times/3times /4times /5times /6times
/7times /8times / 9times
Set number of moving average.
Instantaneous
value simple average
InsSimpleAve
None
None/2 times /4 times /8 times /16 times /32 times
/64 times /128 times /256 times
Set number of simple average for internal sampling
(10ms)
Instantaneous value
display step
InsDispStep
None
None/5steps/10steps
Setting of steps of display （If set to 5steps, displayed
only 0 or 5 on LSB）
(WPMZ-5-□L□)
Pulse Input A
Pulse Input B
Pattern select
PatternSelect
Pattern1(or pattern No.
in use)
Pattern1/ Pattern 2/ Pattern 3/ Pattern 4/ Pattern
5/ Pattern 6/ Pattern 7/ Pattern 8
Select pattern No. to set.
Input Type
InputType
Line driver
Line driver
Only line driver
Input filter
InputFilter
None
None
None analog filters
Sensor Power
SensorPower
5V
5V
Sensor power is 5V only
Instantaneous value
display Coefficient
InsDispCoef
1.00000×100
0.00000 to 9.99999×10-9～9
For scaling setting of instantaneous value display,
multiply frequency by instantaneous coefficient and
unit time.
Instantaneous value
unit time
InsUnitTime
Sec
Sec/Min/Hour
Instantaneous value
decimal point position
InsDecPoint
######
(No decimal point)
######/ #####．#/ ####．##/ ###．###/
##．####/ #.#####
Set number of digits after decimal point
Instantaneous value
display unit
InsDispUnit
None
None/select from 62 units (See 6-2)/custom unit
Refer to detailed instruction manual about custom
unit
Instantaneous value
auto zero
InsAutoZero
0.00
0.00 to 99.99 sec
Displays 0 if no pulse input over more than setting
time
Instantaneous value
moving average
InsMoveAve
None
None/2times/3times /4times /5times /6times
/7times /8times / 9times
Set number of moving average for analog inputs
Instantaneous
value simple average
InsSimpleAve
None
None/2 times /4 times /8 times /16 times /32 times
/64 times /128 times /256 times
Set number of simple average
Instantaneous value
display step
InsDispStep
None
None/5steps/10steps
Setting of steps of display （If set to 5steps, displayed
only 0 or 5 on LSB）
2 input
calculation
Pattern select
PatternSelect
Pattern1(or pattern No.
in use)
Pattern1/ Pattern 2/ Pattern 3/ Pattern 4/ Pattern
5/ Pattern 6/ Pattern 7/ Pattern 8
Select pattern No. to set.
Expression for
instantaneous value
InsExpression
None
None/ (B/A)*100 / (B/A-1)*100 /B-A /
(B/(A+B))*100 / A+B
Select expression for calculation of instantaneous
value.
Instantaneous value
decimal point position
InsDecPoint
######
(No decimal point)
######/ #####.#/ ####.##/ ###.###/ ##.####/
#.#####
Set number of digits after decimal point
Instantaneous value
display unit
InsDispUnit
None
None/select from 62 units (See 6-2)/custom unit
Refer to detailed instruction manual about custom
unit
Instantaneous value
display step
InsDispStep
None
None/5steps/10steps
Setting of steps of display （If set to 5steps, displayed
only 0 or 5 on LSB）
MENU
DISP DISP DISP
FUNC
Execute a shortcut function
*The function is valid, only if the
shortcut function is assigned to
the arrow key.
（Hold down 2 sec.）
or or or
①①①①
②③ ④
DISP
MENU FUNC

MODEL WPMZ-5-□□□-□□-□□□ 5/12
IM-0834-03
2nd layer
Small categories
3rd layer (setting items)
4th layer (setting contents)
Remarks
name of item
Character strings on
display
(abbreviated form)
Initial values
Settable variables
1.Input
External
Control
Function of external
control terminal 1 to 5
ExtCtrl1Func
ExtCtrl2Func
ExtCtrl3Func
ExtCtrl4Func
ExtCtrl5Func
None
None/ CompareReset/ MeasureBlockA/
MeasureBlockB/ MeasureBlockA&B/
DispHoldA&B/ DispHoldA/ DispHoldB/
MaxHoldA/ MaxHoldB/ MaxHoldA&B/ MinHoldA/
MinHoldB/ MinHoldA&B/PatternChange1/
PatternChange2/ PatternChange3/
MonitorChange/ TrendHold
Select functions assigned to external control
terminals.
2.Output
Comparative
Output AL1
Comparative
Output AL2
Comparative
Output AL3
Comparative
Output AL4
Pattern select
PatternSelect
Pattern1(or pattern No.
in use)
Pattern1/ Pattern 2/ Pattern 3/ Pattern 4/ Pattern
5/ Pattern 6/ Pattern 7/ Pattern 8
Select pattern No. to set.
Source output display
value
OutputDispValue
None
None/InsA/InsB/InsCalc
Select source output display value to compare.
Compare mode
CompareMode
LevelJudge
LevelJudge/ ZoneJudge
Select compare mode
Condition of ON
OnConditions
Excess
Excess/LessThan
In level judge mode
InTheZone
InTheZone/OutsideTheZone
In Zone judge mode
Comparison
judgement value
Threshold
10000
0
Threshold：±999999
Hysteresis：0 to 999999
In level judge mode
0
10000
0
Zone lower limit：±999999
Zone upper limit ：±999999
Hysteresis：0 to 999999
In Zone judge mode
Comparison ON delay
OnDelay
None
None/20ms/50ms/100ms/200ms/500ms
1s/5s/10s/20s
Comparative output turns ON, if ON condition
continues over set delay time.
Comparison OFF
delay
OffDelay
None
Comparative output turns OFF, if OFF condition
continues over set delay time.
Output mode
OutputMode
Normal
Normal/Latch/OneShot5ms/ OneShot 10ms/
OneShot 20ms/OneShot 50ms/ OneShot 0.1s/
OneShot 0.2s/ OneShot 0.5s/ OneShot 1s/
OneShot 2s
Select output mode of comparison
Output logic
OutputLogic
Negative(NO)
Positive(NC)/Negative(NO)
NC/NO are for relay output product.
Background Color at
ON
OnBgColors
Black
Black/Red/Yellow/Green
Background color priority
AL1>AL2>AL3>AL4
Analog Output
Pattern select
PatternSelect
Pattern1(or pattern No.
in use)
Pattern1/ Pattern 2/ Pattern 3/ Pattern 4/ Pattern
5/ Pattern 6/ Pattern 7/ Pattern 8
Select pattern No. to set.
Output range
OutputRange
0-10V
0-10V/±10V/1-5V/0-20mA/4-20mA
Select output range (type).
Source output display
value
OutputDispValue
None
None/InsA/InsB/InsCalc
Select a displayable item for analog output
Output scale
OutputScale
0
10000
0% display value ：±999999
100% display value ：±999999
Set scaling for analog output.
Set expected display values at 0% and 100% output.
BCD Output
Pattern select
PatternSelect
Pattern1(or pattern No.
in use)
Pattern1/ Pattern 2/ Pattern 3/ Pattern 4/ Pattern
5/ Pattern 6/ Pattern 7/ Pattern 8
Select pattern No. to set.
Source output display
value
OutputDispValue
None
None/InsA/InsB/InsCalc
Select a displayable item for BCD output
Data signal logic
DataSignalLogic
Negative
Positive /Negative
Select logic of data signal output.
Synchronous signal
logic
SyncSignalLogic
Negative
Positive /Negative
Select logic of synchronous signal (PC) output.
RS-485
Modbus
communication
SlaveAddress
SlaveAddress
1
1/2/3/4/ ･････ /30/31
Set ID number.
Baudrate
Baudrate
19200bps
9600bps/19200bps/38400bps
Set baud rate.
Parity
Parity
Even
None/Even/Odd
Set parity bit.
RS-232C
commu
nication
Protocol
Protocol
Modbus-RTU
Modbus-RTU/OriginalCommand/OriginalOutput
Set protocol
Baud rate
Baudrate
19200bps
9600bps/19200bps/38400bps
Set baudrate.
Data length
DataLength
8bit
7bit/8bit
Set data character length
Parity
Parity
None
None/Even/Odd
Set parity bit.
Stop bit
Stopbit
1bit
1bit/2bit
Set stop bit length.
Delimiter
Delimiter
CR
CR/CR LF
Set delimiter type.
3.Display
Display Select
Measure select
MeasureSelect
1input:
InsA
2inputs：
InsA+ InsB
InsA/InsB/InsCalc/ InsA+InsB / InsCalc+A+B/
InsA+Comp/InsB+Comp/InsCalc+Comp
Select displayable items can be switched by DISP
key or external control (multiple selects are
available)
Level select
LevelSelect
InsA/InsB/InsCalc/ InsA+InsB
Select an item displayed on level display
Trend select
TrendSelect
Select an item displayed on trend display.
Level Display
Pattern select
PatternSelect
Pattern1(or pattern No.
in use)
Pattern1/ Pattern 2/ Pattern 3/ Pattern 4/ Pattern
5/ Pattern 6/ Pattern 7/ Pattern 8
Select pattern No. to set.
Instantaneous value A
scale
InsA Scale
0
10000
Lower limit：±999999
Upper limit：±999999
Set display scale of level display.
Left edge of display is lower limit and right edge of
display is higher limit
Instantaneous value B
scale
InsB Scalse
Instantaneous
calculation scale
InsCalcScale
Trend Display
Pattern select
PatternSelect
Pattern1(or pattern No.
in use)
Pattern1/ Pattern 2/ Pattern 3/ Pattern 4/ Pattern
5/ Pattern 6/ Pattern 7/ Pattern 8
Select pattern No. to set.
Instantaneous value A
scale
InsA Scale
0
10000
Lower limit ：±999999
Upper limit ：±999999
Set display scale of trend display.
Bottom edge of display is lower limit and top edge of
display is higher limit.
Instantaneous value B
scale
InsB Scale
Instantaneous
calculation scale
InsCalcScale
Time axis
TimeAxis
1s/div
1s/div,2s/div,5s/div,10s/div,30s/div,60s/div
120s/div
Select time for 1 division of time axis.
4.System
General
Brightness
Brightness
5 Bright
5 Bright/4/3/2/1 Dark/0 Off
Select brightness of display
*”0 Off” is set, whole display is black out
Power on delay
PowerOnDelay
None
None/2Sec/5Sec/10Sec/20Sec/30Sec/60Sec
Select time from power on to starting measurement
Power saving time
PowerSavingTime
None
None/1min/2 min/5 min/10 min/30 min/60 min
In power saving state, brightness becomes “1 Dark”
level.
Language
Language
日本語
日本語 /English
Select language
Direction of display
DisplayDirection
Horizontal
Horizontal/Vertical
Select direction of display
Setting protect
SettingProtect
Disable
Disable/Enable
If Enable, changing settings are disabled.
Pattern Copy
PatternCopy
Pattern5（source）
PatternAll（destination）
Excuse
Pattern1/2/3/4/5/6/7/8
Pattern1/2/3/4/5/6/7/8/PatternAll
Operationselect Excuse
Function of copying settings for each pattern.
Initialize
Save user defaults
UserDefaultSave
Message “Save current settings as user initial values?”
Initialize to user
defaults
UserDefaultLoad
Message “Initialize setting values to user initial values?”
Initialize to factory
default
FactoryDefaultLoad
Message “Initialize setting values to factory default?”
5.Diagnosis
Input Diagnosis
Pulse input A Pulse
input B
PulseInputA
PulseInputB
－
－
Check for input signal existence.
(Displays pulse counts）
Analog input A Analog
input B
AnalogInputA
AnalogInputB
－
－
Check for input signal existence.
(Displays level in percentage of rating.)
External control
inputs
ExternalCtrl
－
－
Check for ON/OFF state of terminals
Output Test
Comparative output
AL1 to AL4
CompareAL1
CompareAL2
CompareAL3
CompareAL4
－
－
Outputs ON level or OFF level
Analog output
AnalogOutput
－
－
Outputs level of 10% steps of rating.
BCD Output(Data)
BCD Output(PC)
BCD Output(Data)
BCD Output(PC)
－
－
Outputs ON level or OFF level for each bit
Modbus
Communication
RS-485
ModbusCom
－
－
Displays receive data and transmit data
RS-232C
RS-232C Com
－
－
Displays receive data and transmit data
1st layer
Large categories

MODEL WPMZ-5-□□□-□□-□□□ 6/12
IM-0834-03
８. BASIC OPERATIONS FOR SETTING DISPLAYS
Basic operations for setting displays are shown as below.
The following is an example for changing the voltage of sensor power supply.
①By pushing the “MENU” key in the measurement mode, the display moves to the setting display and displays the 1st layer (major
categories).
By moving the cursor with “arrow key (UP/DOWN)”, the selection of major categories to set can be changed.
*On the 1st layer, by pushing the “MENU” key, the display returns to the measurement display.
②Pointing the cursor to a major category to set and pushing “arrow key (RIGHT)”, the display moves to the 2nd layer (small categories)
By moving the cursor with “arrow key (UP/DOWN)”, the selection of small categories of the setting can be changed.
If the “arrow key (LEFT)”is pushed, the display returns to the 1st layer.
*On the 2nd layer, by pushing the “MENU” key, the display returns to the measurement display.
③Pointing the cursor to a small category to set and pushing “arrow key (RIGHT)”, the display moves to the 3rd layer (setting items).
If the “arrow key (LEFT)”is pushed, the display returns to the 2nd layer.
*On the 3rd layer, by pushing the “MENU” key, the display returns to the measurement display.
④By moving the cursor with “arrow key (UP/DOWN)”, select a setting item.
If the “arrow key (LEFT)” is pushed, the display returns to the 2nd layer.
⑤At the selected setting item, by pushing “arrow key (RIGHT)”, the display moves to the 4th layer (setting contents) and a current
selected content has a check mark. If the “arrow key (LEFT)” is pushed, the display returns to the 3rd layer.
⑥By moving the cursor with “arrow key (UP/DOWN)”, select a content.
If the “arrow key (LEFT)” is pushed, the display returns to the 3rd layer.
⑦By pushing the “ENTER” key”, the selected content is confirmed and a check mark accompanies.
If the “arrow key (LEFT)” is pushed, the display returns to the 3rd layer.
⑧By pushing the “MENU” key, the selected content is stored and returns the measurement display.
*If the power is shut down before being pushed the “MENU” key, the selected content is not stored.
ENTER
MENU
MENU
In any setting displays, the display returns to the
measurenent display by pushing .
MENU
MENU
（Measurement display）1st layer 2nd layer 3rd layer
4th layer
①②③
⑤
⑥
⑦
⑧
④
or
or
Setting items can be selected by or
（Measurement
display）

MODEL WPMZ-5-□□□-□□-□□□ 7/12
IM-0834-03
９. SETTING EXAMPLES
The instantaneous followings are some examples for some
necessary setting point and operation methods to perform flow
measurements.
９－１. SETTING EXAMPLE 1
Detecting pulses from a gear wheel which generates 5 pulses
per 1 round by proximity switch (open collector output) and
displays the revolving speed in [rpm].
①Input type setting
The sensor is an open collector type, therefore “open
collector” should be selected as the input type.
②Setting for revolving speed display
For setting of Instantaneous display coefficient, Number of
rotation per 1 pulse is needed.
・Calculate the number of rotation per 1 pulse.
Because of 5 [Pulse] per 1 round, therefore,
1/5＝2×10-1[round]
・Set ” 2.00000×10-1” as the Instantaneous display
coefficient
・Unit to display is [rpm],therefore, select “Min” for the
instantaneous unit time.
・By “instantaneous decimal point position”, set the number
of digits after the decimal point.
③Setup steps
Although setup steps are basically same as “8.BASIC
OPERATION OF SETTING DISPLAY”, setting of
instantaneous display factor is needed, an example is
shown below.
９－２. Setting Example 2
Using a gearbox of 805[rpm] with an open collector output,
displaying the circumferential speed of the roll diameter
350[mm] in [m/min]
（conditions）
・rotation speed 805[rpm] （output pulse 60[P/R] built-in）
・reduction ratio 1/90
・roll diameter 350[mm]
①Input type setting
The sensor is an open collector type, therefore “open
collector” should be selected as the input type.
②Setting for circumferential speed display
For setting of Instantaneous display coefficient, travel distance of
rotation per 1 pulse is needed.
・calculation of circumferential speed
805[rpm] ×1/90× (0.35[m]×3.14)=9.82994[m/min]
・Cumulate travel distance per 1 pulse
1/60[P/R]×1/90×（0.35[m]×3.14）＝2.03518×10-4[m/Pulse]
・Set “2.03518×10-4” as the Instantaneous display coefficient
・Display is in [min],therefore, “Min” is selected for the
instantaneous unit time.
・By “instantaneous decimal point position”, set the number
of digits after the decimal point.
９－３. SETTING EXAMPLE 3
When maximum flow rate is approx. 40[ℓ/min], using a sensor of
rating 7.5[mℓ/Pulse] (open collector type), instantaneous flow
rate will be displayed in [ℓ/min].
①Input type setting
The sensor is an open collector output type, therefore select
“open collector” as input type.
②Setting for instantaneous flow rate display
Set flowrate per 1 pulse as instantaneous display
coefficient
Although instantaneous flow rate will be displayed in
[ℓ/min], the rating of the sensor is 7.5[mℓ/Pulse], it should
be converted to 7.5×10-3[ℓ/Pulse].
・Set the “Instantaneous display factor” as “7.50000×10-3”
・Displayed unit is [ℓ/min], therefore select “Minute” as the
instantaneous unit time.
By “instantaneous decimal point position”, set the number
of digits after the decimal point
９－４. SETTING EXAMPLE 4
Using a sensor (Voltage output type) which outputs 15 [Hz] for
90[ℓ/min], instantaneous flow rate will be displayed in [ℓ/sec].
①Input type setting
The sensor is Voltage output type, therefore select “LOGIC”
for “input type”.
②Setting for instantaneous flow rate display
Set flowrate per 1 pulse as “instantaneous display
coefficient”.
・Calculate number of pulses per 1 [ℓ].
The sensor outputs pulses of 15[Hz] at 90[ℓ/min], therefore,
（15×60）/90＝10[Pulse/ℓ] .
・Calculate flowrate per 1 pulse.
Number of pulses per 1 litter is 10[Pulse/ℓ], therefore,
1/10＝1×10-1[ℓ/Pulse].
・Set “1.00000×10-1” for the “instantaneous value display
coefficient”.
* Any settings of “1.00000×10-1”, “0.10000×100” and
“0.01000×101”for the “instantaneous value display
coefficient” bring same results.
・Unit to display is [ℓ/sec], therefore, select “Sec” for the
“instantaneous unit time”.
・By “instantaneous decimal point position”, set the number
of digits after the decimal point.
１０. SETTING OF UNITS
Units are selectable and can be displayed optionally.
If units should be used is not available, custom units up to
6 characters are can be made.
*For custom units, please refer to the detailed manual which can be
downloaded from our home page.
１０－１. LOCATIONS OF PARAMETERS FOR UNIT SETTING
1st layer
2nd layer
3rd layer
1.input
setting
pulse input A
（pulse input B）
Instantaneous display
unit
2 input
calculation
Instantaneous display
unit
MENU
（Measurement display）1st layer
2nd layer 3rd layer
Moves to setting display(1st layer)by
MENU key.
Moves to 2nd
layer by right
arrow key.
Moves to
instantaneous
display coefficient
by down arrow key.
Moves to 3rd layer
by right arrow key.
3rd layer 4th layer
Moves to
numerical value
setting display
by ENTER key.
Moves to 4th layer
by right arrow key.
ENTER
4th layer（numerical value setting）
Registers selected
numerical value by
ENTER key.
Selects numerical value by arrow
keys (up/down/left/right)
4th layer 3rd layer
Returns to 3rd
layer by left
arrow key.
ENTER
MENU
Returns to 2nd layer
by left arrow key.
Moves to other setting
items by up/down
arrow keys. Stores selected parameters
and returns measurement
display by MENU key.
4th layer（numerical value setting）

MODEL WPMZ-5-□□□-□□-□□□ 8/12
IM-0834-03
１０－２. AVAILABLE UNITS
The WPMZ has selectable 62 units.
Unit
μA,mA,A,kA,μV,mV,V,kV,VA,W,kW,MW,
μm,mm,cm,m,Ω,kΩ,MΩ,g,kg,N,kN,MN,
Pa,kPa,MPa,hPa,J,kJ,MJ,Hz,kHz,MHz,m3,
mm/s,mm/min,cm/min, m/s,m/min,m/h,m/s2,
m3/s,m3/min,m3/h,kg/h,kg/m2,kg/m3,N/m2,
ℓ,ℓ/s,ℓ/min,ℓ/h,%,%0,%RH,℃,
pH,ppm,rpm,t,inch
１０－３. SETTING OPERATION
Setting procedure is same as “8. BASIC OPERATIONS FOR
SETTING DISPLAY”. Operate in the track of SETTING DIPLAY.
１１. COMPARATIVE OUTPUT FUNCTION
Settings of comparative output functions needs 10 parameters to
set for each output.
The following describe only main setting parameters and refer to
detailed manual which can be downloaded from our homepage for
other parameters.
１１－１. LOCATIONS OF PARAMETERS FOR COMPARATIVE
OUTPUT FUNCTION SETTING
1st layer
2nd layer
3rd layer
4. Output
settings
Comparative output AL1
（Comparative output AL2）
（Comparative output AL3）
（Comparative output AL4）
pattern select
output source display
value
camparison mode
compare ON condition
compare judgement value
campare ON delay
campare OFF delay
output mode
output logic
compare ON background
color
*Refer to “7. SETTING LAYER OVERVIEW”
１１－２. SETTING OF OUTPUT SOURCE DISPLAY VALUE
Comparative outputs AL1-AL4 are settable independently and
they have no magnitude relationship.
For example, instantaneous measured value of Ach is assigned to
AL1, instantaneous measured value of Bch is assigned to AL2
and instantaneous calculate value is assigned to AL3,4 and so on.
Every display item can be freely assigned to comparative
outputs.
Setting procedure is same as “8. BASIC OPERATIONS FOR
SETTING DISPLAYS”. Operate in the track of the procedure of
SETTING DISPLAYS.
Caution: COM (emitter) terminal is common for AL1-AL4 in
open-collector output products. Each AL1&2, AL3&4 have
common terminal in relay ouput products.
１１－３. COMPARISON JUDGEMENT VALUE
The comparison judgement value is a threshold value to judge.
Although, the setting procedure is same as “8. BASIC
OPERATIONS FOR SETTING DISPLAY”, comparison
judgement values need the settings of numerical values.
Therefore, its procedure is shown below.
*The following is an explanation for the compare mode of “Level
judgement ”.
●Level judgement action
Comparative
Output
Comparison
type
Comparison
formula
judgement
result
AL1
alarm when
over
display value＞AL1
judgement value
AL1 ON
AL2
alarm when
over
display value＞AL2
judgement value
AL2 ON
AL3
alarm when
under
display value＜AL3
judgement value
AL3 ON
AL4
alarm when
under
display value＜AL4
judgement value
AL4 ON
*Refer to “17. SPECIFICATIONS –output specifications
[comparative output]”
（Measurement display）
ENTER
Moves to setting display(1st layer)by
MENU key.
ENTER
Moves to 2nd layer by right
arrow key.
Moves to 4th
layer by right
arrow key.
Moves to numerical value
setting display by ENTER key.
Selects numerical
value by arrow keys
(up/down/left/right)
Registers selected numerical
value by ENTER key.
Returns to 3rd
layer by left
arrow key.
Stores selected parameters
and returns measurement
display by MENU key.
1st layer
3rd layer
MENU
1st layer
Moves to 3rd
layer by right
arrow key.
2nd layer
3rd layer
4th layer 4th layer（numerical value setting）
4th layer
3rd layer
MENU
Returns to 2nd layer by
left arrow key.
Moves to other setting items
by up/down arrow keys.
4th layer（numerical value setting）
Moves to setting
“2.output”by down
arrow keys.
Moves to “Threshold
value”by down arrow keys.
AL1 Hysteresis
Display value
AL1 Judgement value（Over）
AL2 Hysteresis
AL2 Judgement value（Over）
AL3 Hysteresis
AL3 Judgement value（Under）
AL4 Hysteresis
AL4 Judgement value（Under）
AL2
AL1
AL3
AL4
Judgement
result

MODEL WPMZ-5-□□□-□□-□□□ 9/12
IM-0834-03
１２. EXTERNAL CONTROL FUNCTION
As external control functions, the WPMZ has comparative
output reset function, measurement inhibit function, display
hold function, maximum value hold function, minimum value
hold function and pattern select function, each function can be
executed by assigning to external control terminal 1 to 5.
*External control functions are also assigned (entered) to 4
arrow keys as shortcut functions.
１２－１. TERMINAL CONTROL
The control of assigned functions is performed by shorting each
terminal to the com terminal or bringing to the “0” level
“0” level: 0 to 1.5V, “1” level: 3.5 to 5V, Input current: -1.2mA
* The control terminals 1 to 5 are isolated from power and
input as DC signals.
１２－２. COMPAＲATIVE OUTPUT RESET FUNCTION
Comparative output reset function makes all of comparative
judgement results and their outputs OFF.
１２－３. MEASUREMENT INHIBIT FUNCTION
The measurement inhibit function ignores the input and the
display value accompanies this.
Measurement inhibit A：inhibits the input of Ach
Measurement inhibit B：inhibits the input of Bch
Measurement inhibit A&B：inhibits the inputs of both Ach
and Bch
１２－４. DISPLAY HOLD FUNCTION
Display hold function holds display value. While this function is
valid, measurement action is performed internally and the latest
measurement value is displayed when the function become
invalid.
Display hold A：holds the display of Ach
Display hold B：holds the display of Bch
Display hold A&B：holds the display of Ach and Bch
１２－５. MAXIMUM VALUE HOLD FUNCTION
Maximum value hold function is the function which holds the
maximum display value.
Maximum hold A：holds the maximum display value of Ach
Maximum hold B：holds the maximum display value of Bch
Maximum hold A&B：holds the maximum display value of
Ach and Bch
１２－６. MINIMUM VALUE HOLD FUNCTION
Minimum value hold function is the function which holds the
minimum display value.
*When both of the maximum value hold and the minimum value
hold are ON simultaneously, only the maximum value hold
becomes valid.
Minimum hold A：holds the minimum display value of Ach
Minimum hold B：holds the minimum display value of Bch
Minimum hold A&B：holds the minimum display value of Ach
and Bch
１２－７. PATTERN SELECT FUNCTION
The pattern select function is the function which switches the
pattern number to use for measurement. By using pattern select
1-3, Up to 8 patterns can be switched.
Function
Name
Selected pattern No. （pattern No. in use）
1
2
3
4
5
6
7
8
Pattern
select1
Open
Short
Open
Short
Open
Short
Open
Short
Pattern
select2
Open
Open
Short
Short
Open
Open
Short
Short
Pattern
select3
Open
Open
Open
Open
Short
Short
Short
Short
Open：pattern select terminal is open or connected to “1” level.
Short: pattern select terminal is shorted to COM terminal or
connected to “0” level.
１２－８. MONITOR CHANGE FUNCTION
The monitor change function is the function which switches
display and performs same action of DISP key.
１２－９. TREND HOLD FUNCTION
The trend hold function is a function which holds the trend
display.
*When the function is disabled, the WPMZ starts plotting the
trend display with the current measurement value.
１３. SHORTCUT FUNCTION
External control functions are registered to arrow keys and are
performed not by the terminal control but by the operation of the
keys.
１３－１. REGISTERING SHORTCUTS
External control functions which would be performed by
shortcuts are assigned to arrow keys by the following steps.
１３－２. PERFORMING SHORTCUTS
A shortcut function is performed by holding down the arrow key
which an external control function is registered for 1 second.
An active function becomes inactive by holding down the arrow
key which the function is registered for 1 second.
ENTER
FUNC
ENTER
FUNC
Store registration
parameters and returns
the measurement display
by FUNC key
(Completion of
registration)
Register the function by
ENTER key
Return to “Shortcut Register”
display by left arrow key
Move to “Shortcut Register”
display by right arrow key
Select the function by
up/down arrow keys
Return to “Shortcut Register”
display by left arrow key
Move to the arrow
key to set by
up/down arrow key
Register the function
by ENTER key
Select the function by
up/down arrow keys
Move to shortcut register
display by FUNC key
1)Select 1 of 4 arrow
keys to set a shortcut
function by up/down
arrow keys.
*This example sets a
shortcut function to the
up arrow key.
2)Move to “Shortcut
Registor”display by right
arrow key.
（Measurement display）
（Shortcut Register
display）
Holding down the arrow
key for 1 second
The icon for active external control
lights up
ENTER
DISP
MENUFUNC
ENTER
DISP
MENUFUNC

MODEL WPMZ-5-□□□-□□-□□□ 10/12
IM-0834-03
*If an external control function assigned to a key is valid by the
terminal control, the short cut function is not acceptable.
１４. INITIALIZE
Setting values can be initialized to factory default settings or
user saved settings.
１４－１. LOCATIONS OF PARAMETERS FOR INITIALIZE
1st layer
2nd layer
3rd layer
4.System
Initialize
UserDefaultSave
UserDefaultLoad
FactoryDefaultLoad
*Refer to “7. SETTING LAYER OVERVIEW”.
１４－２. INITIALIZE TO THE FACTORY DEFAULTS
By performing the following steps, setting values can be
initialized to the factory defaults.
MENU
（Measurement display）1st layer
2nd layer 3rd layer
Select “4.System”and
press right arrow key
Select “FactoryDefaultLoad”
and press right arrow key
Select “Initialize”and
press right arrow key
3rd layer
3rd layer MENU
Return to 2nd layer
by left arrow key
Select other setting
items by up arrow key
Checking the
confirmation message,
you select “OK”and
press ENTER key
Initialization was done for each values
So return to 3rd layer by ENTER key
When you finish the setting,
please press ENTER key.
Move to setting display(1st layer)
by MENU key
Select “Yes”and
press ENTER key
ENTER ENTER
ENTER
（Confirmation message）
（Confirmation message）
１４－３. INITIALIZE TO USER DEFAULTS
Beside of initializing to factory defaults, current setting values
can be saved as user default data and setting values will be
initialized to the data.
１４－３－１. Saving User Defaults
For initializing to user default values, entering setting values
used as default values are required.
①Setting each values
Set all setting values which are needed as user default
values.
②Saving user initial values
By executing to save user default values, current setting
values are saved as user default values.
Steps for the save operation are same as “14-2. Initializing
to the factory defaults”. Operate the WPMZ according to
the setting displays.
*Please refer to “14-1. Locations of parameters for
initialize”.
１４－３－２. Initializing To User Defaults
By executing to initialize to user defaults, current setting values
are replaced by user defaults.
Steps for the initialize operation are same as “14-2. Initializing
to the factory defaults”. Operate the WPMZ according to the
setting displays.
*Please refer to “14-1. Locations of parameters for initialize”.
１５. LANGUAGE
Language can be selected from the system setting. Below is the
flow when changing from Japanese to English.
MENU
（Measurement display）1st layer
3rd layer2nd layer
4th layer
Press MENU key
Select “4.システム設定” and
press right arrow key
(“システム設定” means “System”)
Select “全般” and press right arrow key
(“全般” means “General”)
Select “言語” and
press right arrow key
(“言語” means “Language”)
4th layer
Select “English”and press ENTER key
The language is translated
into English
ENTER
１６. KEY LOCK FUNCTION
To prevent unconsidered key operations, the WPMZ has the key
lock function.
１７. ERROR CODES
When some malfunctions occur, error codes are displayed
according to the factor of the error.
ERROR CODE
ERROR MESSAGE
RECOVERY
PROCEDURE
E000
Program sum error
During the error mode,
hold down the ENTER key
for 1 seconds (long-press)
to reset or power down and
on.
*If the WPMZ does not
recover by this procedure,
please contact your dealer
or our company.
E006
RAM error
E100 to 102
Errors associated with
serial flash memory
E103 to 105
E210 to 211
Errors associated with
FRAM
E110 to 111
Error associated with
sensor power short
E202 to 203
Errors associated with
calibration values
E204 to 205
Errors associated with
setting values
E206 to 209
Errors associated with
initial values
Other than
above codes
Other errors
・If start-up delay is enabled, the WPMZ displays “------”
according to the delay time.
・If display value becomes out of displayable range, “OVER” is
displayed in the display.
ENTER
DISP
MENUFUNC
Indicates KEY LOCK is valid
KEY LOCK on:
Enabled by pushing DISP
key and ENTER key
simultaneously
* lights up.
KEY LOCK off:
Disabled by pushing DISP
key and ENTER key
simultaneously
* lights down.

MODEL WPMZ-5-□□□-□□-□□□ 11/12
IM-0834-03
１８. SPECIFICATIONS
MODEL CODES
Number of
measurement
channel
：
1 or 2 （according to model codes）
Display
：
2.4 inch TFT liquid crystal display
Used in 1ch input ：Ach measurement result
Used in 2ch inputs ：Ach measurement result,
Bch measurement result, calculation result,
Ach and Bch measurement results,
Ach or Bch measurement result and calculation
result
Display range
：
0 to 999999
Zero display
：
Reading zero suppress
Decimal point
：
Settable freely
Over warning
：
By exceeding the range of display, displays OVER or
-OVER
Sampling rate
：
10ms（calculation period）
Display updating
period
：
100ms
External controls
：
5 functions of the followings can be assigned to
control terminals (user-configurable).
①Comparative output reset function
②Measurement inhibit function ：Measurement
inhibit A/B/A&B
③Current value hold function：Current value hold
A/B/A&B
④Maximum value hold function：Maximum value
hold A/B/A&B
⑤Minimum value hold function ：Minimum value
hold A/B/A&B
⑥Pattern select function：Pattern select 1/2/3
⑦Display select function
⑧Trend Hold function
Ambient
temperature range
：
-5 to 50℃35 to 85％RH（Non condensing）
Storage
temperature range
：
-10 to 70℃up to 60％RH
Supply power
：
AC power（WPMZ-5-1□□-□□-□□□）
AC100 to 240V±10% 50／60Hz
DC power（WPMZ-5-3□□-□□-□□□）
DC12V±10%
DC power（WPMZ-5-4□□-□□-□□□）
DC24 to 48V±10%
Power
consumption
：
AC power（WPMZ-5-1□□-□□-□□□）
At AC100V：10VA max At AC240V：14VA max
DC power（WPMZ-5-3□□-□□-□□□）
At DC12V：6W max、
DC power（WPMZ-5-4□□-□□-□□□）
At DC24V：6W max、At DC48V：6.5W max
Sensor power
Pulse input
DC 12V ±10% 100mA max.
DC24V±10% 50mA max.
*For 2ch inputs, allowable current of both Ach and
Bch is same as above.
*Combine at DC12V, 24V: 1.2W max.
Line driver input
DC5V±10% 200mA max.
*For 2ch inputs, allowable current of both Ach and
Bch is same as above.
External
dimensions
：
96mm（W）×52mm（H）×145mm（D）
Weight
：
Approx. 350g
Withstand voltage
：
AC power （WPMZ-5-1□□-□□-□□□）
Between Power terminals and inputs/external
controls/comparative outputs/other outputs
AC3000V for 1 minute
DC power （WPMZ-5-3or4□□-□□-□□□）
Between Power terminals and inputs/external
controls/comparative outputs/other outputs
AC1500V for 1 minute
AC power and DC power
Between input terminals and external
controls/comparative outputs/other outputs
AC1500V for 1 minute
Between enclosure and each terminals AC3000V
for 1 minute
Insulation
resistance
：
Between terminals mentioned above, at DC500V
100MΩ or higher
Vibration
tolerance
：
10 to 55Hz half amplitude 0.15mm in X,Y,Z
directions for 30 minutes
Protective
structure
：
IP66（front）
Installation
environment
：
indoor use
Rated altitude
：
up to 2000m
Transient
overvoltage
：
Ⅱ
Measurement
category
：
Ⅱ
Pollution degree
：
2
Conformed EN
standard
：
EN61326-1 （EMS ：industrial electromagnetic
environment／EMI：Class A）
(Applicable to line length only under 30m)
EN61010-1
EN50581
Material of
enclosure
：
polycarbonate（PC）black UL94V-0
Input Specifications
【Pulse input instantaneous measurement】
●Input specifications（common to Ach、Bch）
Frequency
range
：
0.01Hz to 500kHz (*2ch input:250kHz)
Input signal
：
Single ended
Open collector(NPN/PNP type),Voltage pulse, Totem
pole, AC pulse, Proximity sensor
Input level
：
Open collector
Pullup to 12V or 24V
Logic
L level：≦1.0V
H level：3.9 to 30V （max. allowable voltage ±50V）
Zero Cross
AC60mV to 40V （max. allowable voltage 70V）
*AC signal which gets across 0V.
Input
resistance
：
Open collector
Pulled up to 12 V through approx. 10kΩ(in the case of
sensor power 12V）
Pulled up to 24 V through approx. 25kΩ(in the case of
sensor power 24V）
Pulled down to GND through approx. 10kΩ.
Logic/Zero Cross
Pulled down to GND through approx. 10kΩ
2 wire
Pulled down to GND through approx. 900Ω
Input pulse
width
：
≧0.9μs （both of L level and H level）
(2 channel inputs: ≧1.8 μs)
Measurement
method
：
Cyclic calculation method
Display unit
time
：
Can be selected one of second, minute, hour
Accuracy
：
±（20ppm rdg +1digit）@23±5℃
【Line driver input measurement】
●Input specifications （Common to Ach,Bch）
Conversion
method
：
0.01Hz to 500kHz (*2ch input:250kHz)
Input signal
：
Differential input (Line driver signal)
Input level
≧±1V（Differential voltage）
Input
resistance
330Ω
Maximum
allowable
voltage
±10V (Differential voltage)
Input pulse
width
：
≧0.9μs （both of L level and H level）
(2 channel inputs: ≧1.8 μs)
Measurement
method
：
Cyclic calculation method
Display unit
：
Can be selected one of second, minute, hour
Basic specifications
WPMZ
ＷＰＭＺ－5
１Voltage power：AC100 to 240V
Voltage power：DC12V
ＸTest report：No test report
ＴTest report：With test report
００
３
Ｌ
Ｐ
Ｅ
５
Opencollector output （NPN）
RS-485（Modbus RTU）
ＰPulse input （*1）
5
Tachometer/Speed Meter
１Analog output
ＸDisplay only（No output）
Line driver input Ｌ
No Bch inputＸ
４RS-232C
２BCD output （Opencollector NPN）
３BCD output （Opencollector PNP）
ＦOpencollector output （PNP）
Voltage power：DC24 to 48V４
Pulse input
Line driver input （*1）
Series name
Power
Input Ach
Input Bch
Output
Comparetive
output
Description
Additional
code
Test report
(*1) Combination of 2 inputs
The combination of a pulse input and an line driver input is NOT selectable.
(WPMZ-5-□PL and WPMZ-5-□LP are NOT available.)
Standard (Initial language : Japanese)
Ｅ０ Initial language setting : English
R Relay output （Normally open）

MODEL WPMZ-5-□□□-□□-□□□ 12/12
IM-0834-03
time
Accuracy
：
±（20ppm rdg +1digit）@23±5℃
OUTPUT SPECIFICATIONS
【Comparative outputs】
Open collector
output
：
Output rating
NPN：sink current 50mA MAX.
PNP：source current 50mA MAX.
Applied voltage 30V MAX.
Output saturation voltage ≦1.2V at 50mA
Number of outputs 4 transistor outputs
Relay output
：
Contact rating：AC250V 2A,DC30V 2A
Mechanical life：20 million times
Electrical life：100 thousand times or more
4 A contacts, AL1 and AL2, AL3 and AL4 share common
Control
method
：
Microcomputer calculating method
Judgement
value settable
range
：
-999999 to 999999
Hysteresis
：
Settable within the range of 1-999999 digits for each
judgement value independently.
Comparison
action
：
According to sampling rate (calculate period).
Setting
condition
：
Condition of comparison can be set to AL1 to AL4
independently.
●Level judgement mode
The alarm is ON when display value exceeds
judgement value （over alarm）
The alarm is ON when display value underruns
judgement value （under alarm）
Over alarm（upper limit judgement）
Condition of comparison
Judgement
result
display value ＞AL1 judgement value
AL1
display value＞AL2 judgement value
AL2
display value＞AL3 judgement value
AL3
display value＞AL4 judgement value
AL4
Under alarm （Under limit judgement）
Condition of comparison
Judgement
result
AL1 judgement value＞display value
AL1
AL2 judgement value＞display value
AL2
AL3 judgement value＞display value
AL3
AL4 judgement value＞display value
AL4
●Zone judgement mode
The alarm is ON when display value between upper
and lower judgement values （inside of zone alarm）
The alarm is ON when display value out of upper and
lower judgement values（outside of zone alarm）
Inside of zone alarm
Condition of comparison
Judgement
result
AL1 zone upper limit≧display value≧
AL1 zone lower limit
AL1
AL2 zone upper limit≧display value≧
AL2 zone lower limit
AL2
AL3 zone upper limit≧display value≧
AL3 zone lower limit
AL3
AL4 zone upper limit≧display value≧
AL4 zone lower limit
AL4
Outside of zone alarm
Condition of comparison
Judgement
result
display value＞AL1 zone upper limit
or AL1 zone lower limit＞display value
AL1
display value＞AL2 zone upper limit
or AL2 zone lower limit＞display value
AL2
display value＞AL3 zone upper limit
or AL3 zone lower limit＞display value
AL3
display value＞AL4 zone upper limit
or AL4 zone lower limit＞display value
AL4
Conversion
method
：
D/A conversion method
Resolution
capability
：
Equivalent of 13bit
Scaling
：
Digital scaling
Output
objective
Response
speed
Specification
for each
output
：
:
:
An item can be selected from source displayable values
Up to 25ms （0→90% response）
Refer to the following chart.
Output type
Load resistance
Accuracy
Ripple
0 to 10V
≧2kΩ
±(0.1% of FS)
±50mVp-p
±10V
1 to 5V
0 to 20mA
≦550Ω
±25mVp-p
4 to 20mA
【BCD output】
Output t y pe
：
Open collector output NPN/PNP type
Measurement
data
：
Negative logic transistor is ON at logical “1”
Polarity signal
：
Negative logic transistor is ON at minus display
Over signal
：
Negative logic transistor is ON at over display
Synchronized
signal (PC)
：
Transistor is ON for a fixed period every time data becomes
valid. .
Transistor
output
capability
：
Voltage 30V max. Current 10mA max.
Output saturation voltage up to 1.2V at 10mA
Enable
：
By shorting the enable terminal to -D.COM or bringing to
same voltage level, the BCD output transistors become
OFF.
【RS-232C】
Communication
protocol
：
Modbus-RTU/OriginalCommand/OriginalOutput
Synchronizatio
n method
：
Asynchronous
Communication
method
：
Full duplex
Baud rate
：
9600bps、19200bps、38400bps
Data length
：
7bit、8bit
Start bit
：
1bit
Parity bit
：
None, Odd, Even
Stop bit
：
1bit、2bit
Delimiter
：
CR LF、CR
Character code
：
ASCII
Transmission
control
procedure
：
No control sequence
Used signal
names
：
TXD、RXD、SG
Number of
connectable
units
：
1
Cable length
：
Max. 15m
【RS-485】
Communication
protocol
：
Modbus RTU
Synchronization
method
：
Asynchronous
Communication
method
：
2-wire half- duplex
Baud rate
：
9600bps、19200bps、38400bps
Data length
：
8bit
Start bit
：
1bit
Parity bit
：
None, Odd, Even
Stop bit
：
1bit
Used signal
names
：
Non-inverting (+), Inverting (-)
Number of
connectable
units
：
31
Cable length
：
Max.1.2km （total）※Conforming CE mark, less than 30m
The contents of this instruction manual are subject to change without
prior notice.
WATANABE ELECTRIC INDUSTRY CO.,LTD.
http://www.watanabe-electric.co.jp/en/
6-16-19, JINGUMAE, SHIBUYA-KU,TOKYO 150-0001,JAPAN
TEL [phone] FAX [phone]
【Analog output 】
*Ripple for 4 to 20mA is at load resistance 250Ω, 20mA output.
