Watcher E2 Series User manual

E2-Series DVR Manual
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 1

Table of Contents
Function Menu Access...............................................................................................................................3
Video Playback...........................................................................................................................................
Video Backup ............................................................................................................................................5
Setup Motion Recording ...........................................................................................................................6
System Configuration ...............................................................................................................................6
Camera Display Settings ...........................................................................................................................8
Connecting the DVR to a Network .........................................................................................................10
Setting Up a PTZ Camera .......................................................................................................................11
Setup User Rights.....................................................................................................................................12
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 2

Function Menu Access
This guide will refer to the Function Menu to access various setup configurations. To access the
Function Menu, right-click on the main camera screen to bring up the control bar at the bottom. From
here, the Function Menu is accessed from the icon on the bottom left side of the control bar.
You will then be asked to input the username and password. The default username is admin and the
default password is 123456.
You will then be at the main Function Menu screen.
From here, there will be various options that will be used in this guide for video search, video backup,
shutdown, etc.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 3

Video Playback
Access the Function Menu and click on the Search icon then click on Time Search.
Select the Date on the right. Then select the camera number(s) that you want to view. Click the Search
button in the upper-right corner. This will bring up a timeline for the day specified along with each
camera and the recordings. Click on the time (in the grid) that you would like to view and click the
Play button at the top. Use the playback controls at the bottom.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282

Video Backup
**Video backup can only be performed on a USB Flash drive. It will not backup to portable USB DVD
drive.**
Access the Function Menu and click on the Backup icon.
On the right-hand side, set the Start and End date and time. Check the camera numbers below the
date/time settings you wish to backup. Click the Search button. The files that are found for the search
criteria will be displayed on the list. You can check the files individually or check the All box at the
bottom. Then click the Backup button.
Then, from the backup information tab, you can check some options that may be relevant for you. The
storage media should be USB drive. Player backup can be checked to allow the video to be played on a
Windows PC. Save file type allows the backup file format to be changed to AVI so that these files can
be played from a common media player.
**Note: If the backup files are saved in DVR format, please check the backup player. Only this player
can play these files in DVR format. If the backup files are saved in AVI format, you can play these files
with any common media player**
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 5

Setup Motion Recording
Access the Function Menu and click the Setup icon. Click on Schedule then the Motion Tab.
If you would like to setup motion on every camera, select 1, from the drop-down menu next to channel.
You will then copy the channel settings to the other channels once the schedule is set. Hold the left
mouse button down in the upper-left corner of the grid and drag to the lower-right corner. This will set
a 2 hour, 7 days a week schedule for motion recording. Then, at the bottom, click the Copy button to
apply the settings to the remaining channels.
System Configuration
Enter the Function Menu and click the Setup icon. Click the System Tab in the top left of the screen.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 6

Device Name: The name of the device as it will appear on the client end or CMS, this would help to
recognize the device remotely.
Device ID: Do Not Change
Video Format: Always set to NTSC.
Password Check: If this option is enabled, you would need to input the user name and password for
any operation.
Show Time: If selected, the current time will be displayed during live monitoring.
Show wizard: Do Not Change.
VGA Resolutio : The resolution of the live display interface, range from: VGA 800*600, VGA
102 *768, VGA 1280*102 and CVBS. Switching between VGA and CVBS will change the menu
output mode. Please connect the relevant monitor.
Logout After (Mi utes): You can setup the screen to logout after a certain amount of time (30s, 60s,
180s, & 300s). When the time passes the system will auto log you out and you will need to log back in
again.
No Image Whe Logout: If this item is selected, there will be no image showing when the system is
logged out.
Click the Apply button to save your changes.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 7

Camera Display Settings
Access the Function Menu and click the Setup icon. Then click the Live tab.
Camera Name: Change the name of the camera.
Show Name: This chooses whether to the display the camera name on the main screen.
Color: Change the color settings on each camera.
Click the Apply button to save your changes.
To change the layout of the cameras, click on the Main Monitor tab.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 8

Split Mode: Sets the Main screen display mode (1x1, 2x2, 3x3, x ). The boxes below allow you to
change which cameras appear in which window of the main screen.
Dwell Time: Sets the time to change between the cameras on the main screen. This will cause the
cameras to cycle through each camera in each window.
Click the Apply button to save your changes.
If you have a secondary monitor connected to the “spot” port of the DVR, you can change the layout of
that by using the Spot tab. The setup is exactly like Main Monitor options. Other monitors will only
display a copied image of the Main Monitor.
Split Mode: This sets up the display for the secondary monitor. The box below the split mode will set
the Group. You can setup multiple groups to display on the screen.
Dwell Time: Sets the amount of time each camera will display before it changes to the next camera in
the sequence.
Click the Apply button to save your changes.
You can also mask out portions of a camera picture with the Mask tab.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 9

Click the Setting button that corresponds to the camera you would like to add a mask. Then, draw an
outline of the area that you would like not to be seen. Here is an example of how masking works.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 10

Connecting the DVR to a Network
To connect the DVR to a network, the IP address scheme should be know as well as an available IP
address for the scheme. If you have a PC connected to the network that the DVR will be on, you can go
to the command prompt in Windows. (Start Menu, type cmd in the search bar, then hit the Enter key).
Once in the command prompt, type ping followed by the IP address that you would like to check. (ex.
Ping 192.168.1.25). If you get a request time out, then the IP address is open and you can use it. If you
get a response, then the IP address is already being used.
You will also want to forward ports in your firewall to allow for remote access. Please consult your IT
department/team or contact Watcher Technical Support for assistance. If you do have an IT
administrator that can perform the port forwarding, see the information below regarding the port
forward settings.
**Ports: 80 and 6036 on both UDP and TCP (If port 80 is not available, you can pick another port. Just
make sure that it is changed in the DVR.)
To access the network settings in the DVR, access the Function Menu and click on the Setup icon.
Then click the Network tab.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 11

HTTP Port: Port for remote access (if 80 cannot be used, change to the port setup in the firewall)
Server Port: Port for remote access
Obtai IP address automatically: Recommended to leave unchecked and set the IP address to a static
one.
IP Address: The IP address of the DVR. Set this to any open IP address on the network.
Sub et Mask: Same subnet mask as the network.
Gateway: Same gateway as the network.
Setting Up a PTZ Camera
Access the Function Menu and click the P.T.Z. icon. Then click on the Serial Port tab.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 12

Chose the channel that the PTZ camera is connected to and make sure the Enable check box is checked.
Set the address of the PTZ camera (usually defaults to 1). Set the Baud Rate to 2 00. Set the Protocol
to PelcoP. Click the Apply button to save the changes and then Exit. Right-click on the main screen and
select P.T.Z camera option. This will bring up a PTZ control window and you should be able to control
the camera (as long as all of the wiring is correct.).
Setup User Rights
Access the Function Menu then click the Setup button. Then click on the User Management
Configuration icon.
Then click the Add button. In the General tab, input the username, password, and user type. You can
also delete users and change passwords for users from this User Management interface.
Then, in the Authority tab, you can select/deselect different functions that the user can access.
Watcherproducts.com ♦ Watcher Products ♦ 877-289-282 13

Remember, it is very important to remember the administrator username/password as the DVR will
have to be shipped back to us for a password reset, which could take up to 7 business days.
