Introduction
Introduction
Welcome to the WatchGuard® Video VISTA HD Wearable Camera User Guide. This guide is
designed to walk you through the basics of using your VISTA™ Wearable Camera to collect
quality video evidence.
About this document
The VISTA HD Wearable Camera User Guide covers the basic components and operation of
VISTA and VISTA WiFi including:
lDocking, charging, provisioning, and uploading
lAssociating with a recording group (VISTA WiFi only)
lPowering on and off
lWearing VISTA
lRecording evidence
lCategorizing events
This guide includes a section on VISTA special features:
lPre-event and Record-After-the-Fact® (RATF)
lAutomatic sleep and power off to help you save battery
lMaximum recording length and periodic recording alerts to help you save storage space
lCovert Mode
This guide also includes a section on recording groups and how VISTA WiFi and the WiFi Base
work within a local recording group network.
Two appendices to the guide contain:
lInstructions for using the VISTA SmartConnect smartphone app with VISTA WiFi
lInstructions for setting up the VISTA Transfer Station
Note: This user guide covers the basic use of the VISTA Wearable Camera. It is
not a comprehensive manual for every possible action or situation you could
experience when using VISTA. If you have a question about VISTA that is not
covered in the user guide, contact your WatchGuard Video representative.
VISTA Wearable Camera
WGD00120 Revision E 9

Introduction
Related documents and information
For subjects related to the WatchGuard Video video evidence system that are not covered by
the VISTA HD Wearable Camera User Guide, see the following documents:
lVISTA HD Wearable Camera Quick Start Guide
lEvidence Library 4 Web User Guide
lEvidence Library Express User Guide
l4RE In-Car Video User Guide
l4RE Vehicle Installation Instructions
What's new for version 2
The following features are new for version 2 of the WatchGuard Video VISTA Wearable Camera:
lOptional Wi-Fi™ (page 44)and GPS (page 45) (VISTA WiFi only)
Version 2 gives you the option of adding 802.11n Wi-Fi and GPS date/time and location
information to the VISTA Wearable Camera. Wi-Fi allows the VISTA WiFi camera to participate
in group recordings and provide an access point (hotspot) for the VISTA SmartConnect
smartphone application. GPS date and time allows your Evidence Library software to
synchronize playback of recorded events.
lSupport for recording groups/group recordings (Distributed Multi-Peer
Recording™) (VISTA WiFi only) (page 63)
oEvidence Library software configuration items (page 20)
oPairing with VISTA WiFi Base (page 25)
Version 2, VISTA WiFi option, gives you the ability to associate your VISTA WiFi cameras with
local recording group networks to create group recordings.
lSupport for the VISTA SmartConnect iPhone® application (VISTA WiFi only) (page
71)
Version 2 gives you the ability to set up VISTA WiFi to connect to and interact with the VISTA
SmartConnect iPhone application.
lSupport for additional VISTAconfiguration options, including:
oMuting recorded event audio (page 33)
oRecorded event stop confirmation (page 32)
oWireless event upload to Evidence Library 4 Web (EL4 Web) through the VISTA
WiFi Base (page 21)
Version 2 gives you the ability to apply the additional VISTA configuration options and features
offered with Evidence Library Express, version 3.5 or Evidence Library 4 Web, version 4.1.
lImproved Sleep power state (page 60)
Version 2 allows VISTA to remain in its Sleep state longer and exit its Sleep state significantly
faster than previous versions.
10 VISTA Wearable Camera
