Watec WAT-230V2 User manual

Danger
Danger
Danger
• Design and specifications are subject to change without notice.
• Watec is not responsible for any inconvenience or the attendant damages
to the video and monitoring recording equipment caused by misuse, mis-
operation or improper wiring of our equipment.
• If for any reason the WAT-230V2 does not work properly, or if you have any
questions regarding installation or operation, please contact the distributor or
dealer from which it was purchased.
1604Z00-Y2000002
Color CCD Camera
WAT-230V2
Operation Manual
This Operation Manual covers safety, camera functions, installation and the
correct operating procedure for the WAT-230V2. First, we ask you to read
this Operation Manual thoroughly, then install and operate the WAT-230V2
as advised. In addition, for future reference, we also advise safekeeping of
this manual.
Please contact the distributor or dealer from which the WAT-230V2 was
purchased, if you do not understand the installation, operation or safety
instructions laid out in this manual. Not understanding the contents of the
Operation Manual sufficiently may cause damage to the camera.
Guide to the Safety Symbols
The definitions of the symbols used in this operation manual are:
When you do not adhere to or take notice of the “Danger” sign,
it may lead to a serious accident such as death or injury caused
by fire or electric shock.
When you do not adhere to or take notice of the “Warning” sign,
it may cause severe damage such as a physical injury.
When you do not adhere to or take notice of the “Caution” sign,
it may incur injury and cause damage to peripheral objects in
the immediate surroundings.
Cautions for Safety
The WAT-230V2 is designed to be used safely; however, if not used safely,
it may lead to a physical accident caused by fire and electric shock.
Therefore, please keep and read the “Cautions for safety” below for
protection against accidents.
• Do not disassemble and/or modify the WAT-230V2.
• Do not operate the WAT-230V2 with wet hands.
• Use a stabilized power adaptor designed for DC+4.6 -
+14V, with a current capacity of more than 250mA for the
WAT-230V2.
The recommended voltage is DC+4.6 - +14V
• Do not expose the WAT-230V2 to wetness or high
moisture conditions.
The WAT-230V2 is designed and approved for indoor use only.
The WAT-230V2 is not water-resistant or waterproof. If the
location of the camera is outdoors or in an outdoor like
environment, we recommend that you use an outdoor camera
housing.
• Protect the WAT-230V2 from condensation.
Keep the WAT-230V2 dry at all times during storage and
operation.
• Should the camera not work properly, switch off the power
immediately. Then check the camera according to the
“Problems and Trouble shooting” section.
• Avoid the striking of hard objects or dropping the
WAT-230V2.
The WAT-230V2 uses high quality electrical parts and
precision components.
• Do not connect any power supply directly to the video out
terminal of the unit.
Do not connect the WAT-230V2 with any monitor using a
video/power single transmission terminal. The WAT-230V2 is
not designed for use with this type of equipment. We also
advise you to read the operation manual of the monitor you
plan to use before any connections are made.
•
Do not install the WAT-230V2 in a position subject to
direct sunlight.
Sunlight shinning directly onto the WAT-230V2 lens can cause
damage to the CCD.
• Select a stable place for installation of the WAT-230V2.
Use a support of durable strength around an installation
position on a ceiling or wall when a camera stand or tripod is
used.
• Do not move the WAT-230V2 with the cables connected.
Before moving the WAT-230V2, always remove the video
cable and power cable from the rear of the camera first.
• Avoid using the WAT-230V2 near any strong electro-
magnetic field.
After installing into main equipment, if the WAT-230V2 is
exposed to electromagnetic waves causing the monitored
image to become distorted, we recommend the camera be
shielded by appropriate protective casing.
Problems and Trouble Shooting
If any of the following problems occur when using the WAT-230V2,
• An optimal picture cannot be obtained, after checking that all the cables
and connections are correctly in place
• Smoke or any unusual odor emerges from the WAT-230V2
•
An object becomes embedded or a quantity of liquid seeps into the
camera housing
• More than the recommended voltage or/and amperage has been applied
to the WAT-230V2 by mistake
• Anything unusual occurring to any equipment connected to the
WAT-230V2
Disconnect the camera immediately according to the following procedures:
①Switch off the main power supply to the camera.
②Remove the power and video cables connected to the WAT-230V2.
③Contact the distributor or dealer from which the WAT-230V2 was
purchased.
About EMC
The WAT-230V2 is in conformity with EMC test standards carried out by
authorized organizations in Japan.
NTSC FCC Part15 class B
P A L EN61000-6-3/EN50130-4
※Please use an auxiliary power supply (eg: UPS) to this camera to comply
with EN50130-4 of EMC standards.
Do not modify the WAT-230V2.A modified camera may not
conform to EMC test standards.
Contents
Using the contents figures below, check to make sure all parts are present
before use.
WAT-230V2 4P cable
Power Supply
Use a stabilized power adaptor designed for DC+4.6 - +14V, with a current
capacity of more than 250mA.
The wiring on the connector must be exact.
Be careful not to touch the other terminals while wiring. Protect the wired
portion by using insulation tape after wiring. If the above care and attention
is not adhered to, damage to the WAT-230V2 and power adaptor may occur
and may also cause fire.
Mounting
The WAT-230V2 has two bosses on both
sides featuring M2 thread and screws.
Use these if the camera is to be mounted
to the B001 bracket.
Set-up and Operation
①Refer to the 【Power Supply】and the wiring must be exact.
②Join the video out cable with the video in cable of the monitor or
peripheral equipment.
③Join the power supply using the correct procedure.
④Make sure that a picture can be seen on the monitor
⑤To focus, turn the lens clockwise or counterclockwise while observing the
picture on the monitor. (Take care when focusing not to scratch or
damage the lens.)
Options
To purchase these options, please contact the distributor or dealer from
which you purchased the WAT-230V2.
Specifications
Contact information
Watec Co., Ltd.
Add.: 254-2 Nihonkoku, Daihoji, Tsuruoka- Shi,
Yamagata-Ken, 997-0017 Japan
TEL: [phone] FAX: [phone]
Email: [e-mail]
URL: http://www.watec.co.jp
Model WAT-230V2 (NTSC)
WAT-230V2 (PAL)
Pick-up Element 1/4 inch interline transfer CCD image sensor
Number of Total Pixels 1020(H)×508(V) 1020(H)×596(V)
Number of
Effective Pixels 976(H)×494(V) 976(H)×582(V)
Unit Cell Size 3.75µm(H)×5.56µm(V)
3.75µm(H)×4.69µm(V)
Imaging system Ye, Cy, Mg, and G complementary
color mosaic filters on chip
Sync. System Internal
Scanning System 2:1 interlaced
Video Output Composite video, 1.0 V(p-p), 75Ω(Unbalanced)
Resolution (H) More than 650TVL (Center)
Minimum Illumination 0.1 lx F1.8
S/N More than 50dB
Function settings OSD(On Screen Display) operated
by optional remote controller
AE Mode
Fixed 1/60, 1/100 sec. 1/50, 1/120 sec.
1/250, 1/500, 1/1000,
1/2000, 1/4000, 1/10000 sec.
EI 1/60 - 1/100000 sec.
1/50 - 1/100000 sec.
AGC 0 - 45dB
MGC 8steps (Selectable)
Gamma Characteristics
γ≒0.45
Video Level 0 – 255 (BRIGHTNESS)
White Balance ATW/PUSH/USER1/USER2/
ANTI CR/MANUAL/PUSH LOCK
Noise Reduction 2DNR ON(Level selectable) / OFF
Back Light Compensation
OFF/BLC/HLC
Privacy Mask 8masks
Mirror Image OFF / ON(H-FLIP)
White Blemish Correction
Max 64 dots
Output switching AUTO/COLOR/BW
Sharpness 0 - 255(SHARPNESS)
Power Supply DC+4.6 - +14V
Power Consumption 0.78W/155mA (DC+5V)
Operating Temperature
-10 - +50℃
Operating Humidity Less than 95% RH (Without condensation)
Storage Temperature -30 - +70℃
Storage Humidity Less than 95% RH (Without condensation)
Lens mount M12 P=0.5
Standard Lenses f=3.7mm F1.8 57.0°(H)×42.3°(V)
Cable Length 300mm
Size 35.5(W)×29.5(H)×32.5(D) (mm)
Weight Approx. 35g
Warning
Caution
Warning
Caution
M2 bosses with
thread and screw
Remote Controller (RC-01)
Remote control for controlling the On
Screen Display menu to change camera
settings.
Cable with BNC, Socket and connector
The cable with BNC/DC socket.
(Cable Length: 1m)
To 75 Ocoax. cable
for monitor
To power supply
（
DC+6V
）
To power supply
（
GND
）
Black: Common GND
Black: Common GND
Blue: Video out
Red: DC
＋
6V
(DC+4.6
～
14V)
(DC+4.6 ～ 14V)

1600Z00-Y2000102
Quick guide for the WAT-230V2 OSD(On Screen Display) menu
SETUP MENU
SHUTTER/AGC
Set the operation mode of the exposure control.
AUTO：Automatically control the shutter speed and the
gain according to lighting condition of the
object.
MANUAL：Select the shutter speed and Gain level from
8 set values.
WHITE BAL (WHITE BALANCE)
Switch the WHITE BALANCE MODE.
ATW：Automatically correct the white balance when the
color temperature of the object is in the range
of the specified correction value.
PUSH：Automatically correct the white balance
regardless the range of the specified correction value
USER1：correct the image at 5100K.
USER2：correct the image at 6300K.
ANTI CR：Suppress the color rolling.
MANUAL：Set the correction value manually.
PUSH LOCK：Set the corrected value following the
actual color temperature of the illumination of
the object. Imaging the object that color is
achromatic at the full screen, and the press
the [Enter]. The corrected value is set.
BACKLIGHT
Switch the operation modes of backlight.
OFF：Disable.
BLC：Correct the luminance of the darkened object
again the backlight (center-weighted metering).
HLC：Mask processing ageing the bright light source.
PICT ADJUST
Adjust the image quality
MIRROR：Flip the image at left/right (H)
BRIGHTNESS：Adjust the brightness of the image.
CONTRAST：Adjust the contrast of the image.
SHARPNESS：By emphasizing the contoured part,
resolution is improved.
HUE：Adjust the HUE
GAIN：Adjust the GAIN
DEFOG：Improve a low contrast image captured in poor
weather condition such as fog.
ATR (Adaptive Tone-Curve Reproduction)
Correct the contrast and suppress the overexposure and
underexposure.
PRIVACY
Mask processing to the required area on the screen.
DAY/NIGHT
Switch the output
COLOR：Color image
B/W：Monochrome image
AUTO：Automatically switch output image (color or
monochrome) depending on the ambient brightness.
NR (Noise Reduction)
Suppress the noise in a low light condition by image
processing.
CAMERA ID
Set the camera ID
CAMERA RESET
Restore the factory setting.
NEXT
Move to next page of SETUP MENU 2/2
BACK
Move to previous page of SETUP MENU 1/2
EXIT
Close the OSD menu
SAVE ALL
Save the changed camera setting.
*White blemish correction
Close the OSD menu, press and hold LEFT key of
Remote control unit RC-01 and White blemish correction
menu is displayed. Cover the lens completely then press
ENTER key. By automatically detection, blemish pixels
are corrected.
Remote control unit RC-01(option)enables to control the OSD menu and change camera settings.
SETUP MENU 1/2 SETUP MENU 2/2
SHUTTER/AGC AUTO ATR OFF PRIVACY OFF
NAMUAL ON ON
WHITE BAL ATW DAY/NIGHT AUTO
PUSH COLOR
USER1 B/W
USER2
ANTICR NR
MANUAL
PUSH LOCK CAMERAID OFF
ON
BACKLIGHT OFF
BLC CAMERA RESET
HLC NEXT BACK
PICT ADJUST EXIT EXIT
SAVE ALL SAVE ALL
※ ：Default setting
