WAT-933&WAT-2400S
User’s Manual
Rev. 1.03
Watec Co., Ltd.
2018/6/11

2
Revision Record
Rev.
Date
Changes
Remarks
1.00
November 15, 2017
-
-
1.01
January 25, 2018
・New function added.
-
1.02
April 10, 2018
・Specification changed.
-
1.03
June 11, 2018
・New function added.
-

3
Table of Contents
WAT-933&WAT-2400S User’s Manual................................................................................. 1
Revision Record..................................................................................................................... 2
Table of Contents .................................................................................................................. 3
1. Network connection and power activation of the camera........................................... 4
2. Network settings............................................................................................................ 5
2.1. WAT-933 network settings ..................................................................................... 5
2.2. PC network settings ............................................................................................... 6
3. Checking the image from the camera .......................................................................... 8
A case of VLC media player.............................................................................................. 8
4. Changing the camera settings .................................................................................... 10
4.1. Configuration changes from the Web browser ................................................... 10
4.1.1. WAT-933 System Configuration: Overview (top page) ............................... 10
5. Setting file Retrieve & Load ....................................................................................... 13
5.1. Retrieve Settings .................................................................................................. 13
5.2. Load Settings ........................................................................................................ 13
6. SD Card Information................................................................................................... 14
6.1. Continuous Recording .......................................................................................... 14
6.2. Format................................................................................................................... 14
6.3. Video & Snapshot Files........................................................................................ 14
7. FTP Access.................................................................................................................... 15
7.1. A case of FileZilla ................................................................................................. 15
8. Selection of Streaming to Record................................................................................ 16
9. Display / hide timestamp ............................................................................................ 17
10. Selection of Audio Input .......................................................................................... 18
11. ONVIF....................................................................................................................... 19
11.1. A case of ONVIF Device Manager ................................................................... 19
11.2. Login .................................................................................................................. 19
11.3. Live video........................................................................................................... 20
11.4. Stream switching .............................................................................................. 20

4
1. Network connection and power activation of the camera
The WAT-933＆WAT-2400S has two power supply systems. The one is powered by
+12VDC input plug on back panel of the camera, and the other is powered by PoE using a
LAN connector.
※simply called “WAT-933” from now on if there is no difference in the function “WAT-933”
and “WAT-2400S”
Please supply power by the one or the other of the way above and do not supply the both
power systems simultaneously.
The below figure is a connection example of the power supply by PoE hub. In addition, you
need to have the power individually to the router and the PoE hub.
Connect the LAN cable of camera side to a PoE port of the PoE hub and connect the LAN
cable of the router side to a normal LAN port.
If you want to power the camera using theAC power supplies, connect the camera and the
router directly with exception of the PoE hub from the above. In a closed network
configuration, the DHCP protocol and the router are not required. In that case, connect the
PC and the camera directly in LAN cable.
It takes about 20 seconds to fully boot the WAT-933 from the power supply start.
LAN cable
LAN cable
LAN cable
router
WAT-933
PoE hub
PC

5
2. Network settings
2.1. WAT-933 network settings
The network default setting of the WAT-933 is as follows.
IPAddress: 192.168.1.250 (static)
Netmask: 255.255.255.0
Gateway: 192.168.1.1
The network settings of the WAT-933 can be changed in the setting change by the Web
browser which will be described later.

6
2.2. PC network settings
Set the PC network settings in order to accommodate WAT-933’s requirement.
PC network settings for a local area connection in Windows7 as follows.
Control Panel>>Network and Internet>>Network and Sharing Center
>>LocalArea Connection >>Properties>>Internet Protocol Version 4(TCP/IPv4) Properties

7
An example of PC network settings
Connect the WAT-933 and your PC as shown in the below figure. And if the network setting
of the camera is in default configuration (IP Address: 192.168.1.250 (static)), go through the
following steps to set up the PC network settings.
Input the values as follow, press the “OK” and close the property.
PC
LAN cable
PoE hub
WAT-933
LAN cable

8
3. Checking the image from the camera
You could check the video image after the network settings are completed. This section
describes the method in the case of viewing the image from the camera using the VLC
media player.
A case of VLC media player
Download the appropriate VLC which meets your PC from VideoLAN official download page
(https://www.videolan.org/vlc/index.html) and install.
Open the VLC media player when the installation is complete.
Click on Media <Open Network Stream from the menu.
Paste your copied URL in the ‘Network Protocol’ box and click the play button. Wait till the
video start streaming in your VLC.
H264：rtsp://”WAT-933 IPAddress”:554/h264
MJPEG：rtsp:// ”WAT-933 IP Address”:554/jpeg
（Example: rtsp://192.168.1.250:554/h264）

9
The network connections and settings work property, video starts to stream. Please check
again the network settings if it does not start.
The screen might become grey during the viewing, in that case, please click the stop button
in the lower left and click the play button again.

10
4. Changing the camera settings
4.1. Configuration changes from the Web browser
(WAT-933 System configuration)
The network settings of the WAT-933 can be changed in the setting change by the Web
browser. The Web browser must correspond to html5 and recommended web browser is
Internet Explorer 11.
4.1.1. WAT-933 System Configuration: Overview (top page)
Open your web browser and go to following address page.
http://”WAT-933 IP Address”/
(Example: http://192.168.1.250/)
At the first time connection, the authentication window will open such as shown in the below
figure.
User name: root
Password: 1234
Enter the above and click the ”OK” button.
The server 192.168.1.250 is asking for your user name and
password. The server reports that it is from admin.
Warning: Your user name and password will be sent using
basic authentication on a connection that isn’t secure.

11
”WAT-933 MENU” will be displayed as shown in the below figure. This page is the top page.

12
Network Settings
Click on “Ethernet” from the menu.
”Network Information” will be displayed as shown in the below figure.
At this page, you can change the following network settings;
Switching of AUTO IP (DHCP) and STATIC IP
Advanced settings for STATIC IP
Enter the each item and click the “Submit” button then network settings will be changed.

13
5. Setting file Retrieve & Load
The present setting can be downloaded.
In addition, you can reflect the downloaded setting file on your setting by uploading.
5.1. Retrieve Settings
Click on the download link to download the file "setting.w933".
5.2. Load Settings
Click the "Brows" button to display the file selection dialog and select "setting.w933".
When a message appears asking you to restart “WAT-933”, click "OK".

14
6. SD Card Information
This screen is used to make settings related to the SD card.
6.1. Continuous Recording
"Continuous Recording" function can be arbitrarily turned ON/OFF.
"Video&Snapshot Files" described later can be used only when "Continuous Recording" is
off.
6.2. Format
Format the SD card.
6.3. Video & Snapshot Files
You can see the contents of the SD card.
It can be used only when "Continuous Recording" function is off.
Click the file to download it.

15
7. FTP Access
You can access internal storage by using FTP.
This section explains the connection method of using "FileZilla".
7.1. A case of FileZilla
Download the appropriate Installer which meets your PC from FileZilla official download
page (https://filezilla-project.org/) and install it.
Open the FileZilla when the installation is completed.
Enter the following in the red line above.
Host：192.168.1.250
Username：root
Password：1234
Port：(Blank)
Click "Quickconnect" to access internal storage.

16
8. Selection of Streaming to Record
You can select video streaming to be recorded on the SD card.
Switch the h264 Main / Sub with the red line "Select Recording" shown below.
Main Settings
Sub Settings

17
9. Display / hide timestamp
You can choose to show / hide the timestamp of the image.
Toggle display / non-display on "Timestamp Display" in the figure below.

18
10.Selection of Audio Input
You can select audio input.
Select from "INTERNAL MICROPHONE", "EXTERNAL AUDIO" or "MIX BOTH" with the red
line "SelectAudio" shown below.

19
11.ONVIF
You can use the ONVIF Profile S.
This section explains the display method of using "ONVIF Device Manager".
11.1. A case of ONVIF Device Manager
Download the appropriate Installer which meets your PC from ”ONVIF Device Manager”
official download page (https://sourceforge.net/p/onvifdm/wiki/Home/) and install it.
Open the “ONVIF Device Manager”when the installation is completed.
11.2. Login
Enter the following in the red line below.
Name：root
Password：1234
Click "Log in" to access camera device.

20
11.3. Live video
Click the red line part "Live video" in the figure below to enable live viewing.
11.4. Stream switching
Although it is streaming "H264 Main" in the initial state, you can switch to "H264 Sub" and
"MJPEG".
Click the red line part "Profiles" in the figure below to display the Profiles setting screen.
Select "subStream" for H264 Sub streaming, "jpegStream" for MJPEG streaming, and click
"Select".
