Watec WAT-400D User manual

Cauti on
Danger
Danger
Danger
Cauti on
•
Design and specifications are subject to change without notice.
• Watec is not responsible for any inconvenience or the attendant damages
to
the video and monitoring recording equipment caused by misuse, mis-
operation or improper wiring of our equipment.
• If for any reason the WA -400D does not work properly, or if you have any
questions regarding installation or operation, please contact
the distributor or
dealer from which it was purchased.
Cauti on
Waterproof Color CCD Camera
WAT
WATWAT
WAT-
--
- 400D
400D 400D
400D
Operation Manual
his Operation Manual covers safety, camera functions, installation and the
correct operating procedure for the WA -400D. First, we ask you to read this
Operation Manual thoroughly, then install and operate the WA -400D as
advised. In addition, for future reference, we also advise safe keeping of this
manual.
Please contact the distributor or dealer from which the WA -400D was
purchased, if you do not understand the installation, operation or safety
instructions laid out in this manual. Not understanding the contents of the
Operation Manual sufficiently may cause damage to the camera.
Guide to the safety symbols
he meanings of the symbols used in this operation manual are:
When you do not adhere to or take notice of the “Danger” sign, it
may lead to a serious accident such as death or injury caused
by fire or electric shock.
When you do not adhere to or take notice of the “Warning” sign,
it may cause severe damage such as a physical injury.
When you do not adhere to or take notice of the “Caution” sign,
it may incur injury and cause damage to peripheral objects in the
immediate surroundings.
Cautions for safety
he WA -400D is designed to be used safely; however, electrical goods
may lead to a physical accident caused by fire and electric shock if not used
correctly. herefore, please keep and read the “Cautions for safety” for
protection against accidents.
• Do not disassemble and/or modify the WAT- 400D.
• Do not operate any urrent- arrying part with wet hands.
• Use only the AD-156 with the WAT- 400D .
• Do not use the WAT- 400D under unusual environmental
onditions.
he WA -400D is specified as waterproof. However, the
WA -400D is not compliant with dust-proof and explosion-
proof standards.
• Should the camera not work properly, switch off the power
immediately. hen check the camera according to the
“Problems and rouble shooting” section.
• Avoid the striking of hard obje ts or dropping the
WAT- 400D.
he WA -400D uses high quality electrical parts and
precision components.
• he WA -400RX must be used with the WA -400D.
Connect the WA -400RX with the AD-156, monitor, and the
WA -400D.
• Do not install the WAT- 400D in a position subje t to dire t
sunlight.
Sunlight shinning directly onto the WA -400D lens can cause
damage to the CCD.
• Sele t a stable pla e for installation of the WAT- 400D.
Use a support of durable strength around an installation
position on a ceiling or wall when a camera stand or tripod is
used.
• Do not move the WAT- 400D with the ables onne ted.
Before moving the WA -400D, always remove the video
cable and power cable from the rear of the camera first.
• Avoid using the WAT- 400D near any strong
iele tromagneti field.
Avoid emission sources of electromagnetic waves when the
WA -400D is installed into main equipment.
• Dry the WAT- 400D well after use.
When the WA -400D is used in seawater, flush well with pure
water, and then wipe. If the WA -400D is steeped in water for
many hours or left without wiping after use, the surface of the
WA -400D may become white.
EMC Conformity
he WA -400D is in conformity with EMC test standards carried out by
authorized organizations in Japan.
N SC FCC Part15 class B
P A L EN61000-6-3 / EN50130-4
Do not modify the WA -400D. A Modified camera may not
conform to EMC test standards.
Waterproof Conformity
he external body of the WA - 400D is in conformity with the following
waterproof standard.
JIS C 0920 (IEC60529)
Degrees of protection provided by enclosures: IPX8
t(Water pressure: 2kgf/cm
2
, est time: 2 hours)
※Waterproof capability of the WA -400D is confirmed according to the
above conditions. his waterproof standard does not cover the quality of
the operation under unusual condition.
For ④VIDEO OU /POWER IN, this part is not included in the
compatible range of the waterproof standard. reat the
connecter area for waterproofing if needed.
Problems and Trouble Shooting
If any of the following problems o ur when using the WAT- 400D,
• An optimal picture cannot be obtained, after checking that all the cables
and connections are correctly in place.
• Smoke or any unusual odor emerges from the WA -400D.
• An object becomes embedded or a quantity of liquid seeps into the camera
housing.
• More than the recommended voltage or/and amperage has been applied
to the WA -400D by mistake.
• Anything unusual occurring to any equipment connected to the WA -400D.
Dis onne t the amera immediately a ording to the following
pro edures:
①Switch off the main power supply to the camera.
②Remove the power and video cables connected to the WA -400D.
③Contact the distributor or dealer from which the WA -400D was
purchased.
Contents
Check to make sure all parts are present before use.
WAT- 400D AC adaptor (AD-156)
Des ription of parts
①VIDEO OU (MONI OR)
・
・・
・BNC for connecting with the monitor. Use a cable with 75Ω impedance,
such as RG-58/U.
②POWER IN (POWER IN)
・
・・
・he terminal for connecting the AD-156.
③BNC for connection of the WA -400D (CAMERA)
・
・・
・BNC for connecting with ④VIDEO OU /POWER IN.
④VIDEO OU /POWER IN
・
・・
・he BNC coaxial cable for video out and power in.
⑤BRACKE MOUN ING SCREWS
・
・・
・he screws for mounting the bracket to the camera.
⑥BRACKE
・
・・
・he bracket for fixing to the camera.
⑦RIPOD MOUN ING SCREW HOLES
・
・・
・Mounting holes for stands. he size of these threads are 1/4”, 20 threads,
4.5±0.2mm, which is the same as any standard camera tripod (U1/4”).
⑧HOUSING MAIN BODY
・
・・
・his case is uses aluminum and is given alumite treatment
⑨FRON GLASS ( empered glass)
・
・・
・Dirt, water or oil deposits on the front glass will cause an unclear picture
on the monitor and scratches might become permanent damage. Do not
dismount the front glass.
Set-up and Operation
1) Ensure that the power to the WA -400D and the peripheral equipment
is turned off before making any connections.
2) Connect the BNC ④VIDEO OU /POWER IN of the WA -400D to
③BNC to the WA -400RX. When extending the cable beyond 10 meters,
use a coaxial cable with 75Ω impedance, such as an RG-58/U.
he maximum cable length is 200m using RG-58/U.
3) Connect ①VIDEO OU (MONI OR) on the WA -400RX with the
monitor, using a coaxial cable with 75Ω impedance, such as an
RG-58/U. Select a monitor with the same television system as the
WA -400D: N SC or PAL. A monitor with more than 500 V lines is
recommended.
4) Connect the attached AC adaptor (AD-156) to ②POWER IN on the
WA -400RX.
5) urn on the power to the WA -400D, monitor and all other allied
equipment. When a picture cannot be obtained on the monitor, check
and follow the procedure mentioned in the【Problems and rouble
Shooting】section.
6) When a change of installation position is required, set ⑥BRACKE
to your required position after removing ⑤BRACKE MOUN ING
SCREWS from the WA -400D, then retighten ⑤BRACKE MOUN ING
SCREWS firmly. Angular settings for ceiling and wall are also available.
< WA -400D Back view > < ⑥BRACKE >
Wiring Diagram
he following diagram is the basic connection of the WA -400D with the
AD-156 and monitor.
Spe ifi ations
Model WAT- 400D (NTSC) WAT- 400D (PAL)
Pick-up Element 1/3 inch interline transfer CCD image sensor
Number of otal Pixels
811(H)×508(V) 795(H)×595(V)
Number of
Effective Pixels 768(H)×494(V) 752(H)×582(V)
Unit Cell Size 6.4μm(H)×7.5μm(V) 6.5μm(H)×6.3μm(V)
Imaging system Ye, Cy, Mg, and G complementary
color mosaic filters on chip
Sync. System Internal
Scanning System 2:1 interlaced
Video Output Composite video, 1.0 V(p-p), 75Ω(Unbalanced)
Resolution (H) More than 450 VL (Center)
Minimum Illumination 2.0 lx. F1.6
S/N More than 50dB (AGC=3dB, γ=1.0)
A/E mode 1/60 sec. 1/50 sec.
White Balance A W
AGC 3 - 24dB
Gamma Characteristics
γ≒0.45
Back Light
Compensation ON
Power Supply DC+15V±10%
Power Consumption 2.03W (135mA)
Operating emperature
-10 - +50℃ (Without condensation)
Operating Humidity Less than 95% RH
Storage emperature
-30 - +70℃ (Without condensation)
Storage Humidity Less than 95% RH
Built-in Lens Auto-iris lens (f=2.8 F1.6)
Cable Length RG-58/U 10m
Max. Cable Length RG-58/U 200m
※
Size φ72 × 116 (mm)
Weight Approx. 900g (Including RG-58/U 10m cable)
※Maximum cable length should be 200 meters using a RG-58/U cable to ensure
an adequate electrical performance, but waterproof performance is not
guaranteed. For waterproof, please refer to the【Waterproof Conformity】
section.
■SELEC ABLE FAC ORY SE ING
1/60, 1/100 sec. 1/50, 1/120 sec.
AE mode (Fixed) 1/250, 1/500, 1/1000, 1/2000,
1/5000, 1/10000, 1/20000, 1/50000 sec.
White balance A W, Preset (3200K, 5100K, 8200K)
Mirror image ON / OFF
Conta t information
Watec Co., Ltd.
Watec Co., Ltd.Watec Co., Ltd.
Watec Co., Ltd.
Add.: 254-2 Nihonkoku, Daihoji, suruoka- Shi,
Yamagata-Ken, 997-0017 Japan
EL: [phone] FAX: [phone]
Email: [email protected]
URL: http://www.watec.net
Warni ng
Warni ng
1473Z00
-
Y2077001
Re eiver (WAT- 400RX)
