Waterpik WP-490 Series User manual

Waterpik
®
Water Flosser
Model WP-490 Series
I
O
II
I
www.waterpik.co.uk
DO NOT PRINT
DATE: 06.30.22
CLIENT: WATERPIK
FILENAME: 20031739-F AA_WP-490SeriesUK_IM_R7.indd
DESCRIPTION: WP-490 Series UK Instruction Manual
LANGUAGES: 1 (Eng)
FILE TYPE: Adobe InDesign CC
SCD JOB# / PREPARED BY: 22WPOH7309 / JS
CLIENT ROUND: 7
SCALE: 100%
UPC: N/A
SIZE: Flat: 14.0”x 4.5”; Folded: 7.0”x 4.5”
FORM NUMBER: 20031739-F AA
INK: Process Black
NOTES:

22
IMPORTANT SAFEGUARDS
SAFEGUARD
STATEMENTS
READ ALL INSTRUCTIONS BEFORE USING.
• This product is for household use.
When using electrical products, especially when children are present,
basic safety precautions should always be followed, including the
following:
DANGER:
To reduce the risk of electrocution:
• Do not handle the user supplied USB charger with wet hands.
• Do not place or drop the user supplied USB charger into water or
other liquid.
• Do not use this product while bathing.
• Do not place or store this product where it can fall or be pulled into
a tub or sink.
• Do not reach for this product if it has fallen into water. Unplug from
electrical outlet immediately.
• Check the charging cord and user supplied USB charger for damage
before the rst use and during the life of the product.
WARNING:
To reduce the risk of burns, electrocution, ire,
or injury to persons:
• Use this product only as indicated in these instructions or as
recommended by your dental professional.
• A user supplied USB charger with the following specications is
required to charge this product: USB Type-A, Output: 5.0 VDC, 1.0 A.
• Do not plug this device into a voltage system that is dierent from the
voltage system specied on the device or charger.
• Keep the charging cord and user supplied USB charger away from
heated surfaces.
• Do not use the Water Flosser for more than 5 minutes in each two
hour period.
• Do not direct water under the tongue, into the ear, nose or other
delicate areas. This product is capable of producing pressures that
may cause serious damage in these areas. The potentially deadly
amoeba, Naegleria fowleri, may be present in some tap water or
unchlorinated well water and may be fatal if directed into the nose
or ear.
• If your physician advised you to receive antibiotic premedication
before dental procedures, you should consult your dental professional
before using this product or any other oral hygiene aid.

33
• Fill reservoir with warm water or other dental professional
recommended solutions only.
• Do not use iodine, saline (salt solution), or water insoluble
concentrated essential oils in this product. Use of these can reduce
performance and will shorten the life of the product.
• Only use tips and accessories that are recommended by
Water Pik, Inc.
• If the Pik Pocket™ tip (not included in all models) separates from the
sha for any reason, discard tip and sha and replace with a new
Pik Pocket™ tip.
• Do not drop or insert any foreign object into any opening on
the product.
• Do not use this product outdoors or operate where aerosol (spray)
products are being used or where oxygen is being administered.
• Remove any oral jewelry prior to use of this product.
• Do not use if you have an open wound on your tongue or in
your mouth.
• There are no consumer serviceable parts in this product and it does
not require maintenance.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
• If the supply cord is damaged, it must be replaced
by a special cord or assembly available from the
manufacturer or its service agent.
• Do not use this product if it has a damaged cord or plug, if it is not
working properly, if it has been dropped or damaged, or dropped
into any liquid. Contact Water Pik, Inc. at [phone] or
visit www.waterpik.co.uk.
SAVE THESE
INSTRUCTIONS
ENGLISH
ORIGINAL INSTRUCTIONS

TABLE OF CONTENTS
Product Description 5
Getting Started 6
Cleaning and Troubleshooting Your Waterpik® Water Flosser 9
Battery Removal 10
Limited Two Year Warranty 12
SYMBOLS
The following symbols may appear on your product and/or packaging. Some of these symbols may not be relevant in your region and are listed for information purposes only.
Symbol Deinition Symbol Deinition Symbol Deinition Symbol Deinition
Refer to instruction manual Detachable Power Supply Do not use this device in a shower, bathtub
and do not immerse in any liquid. Regulatory Compliance Mark
Manufacturer Direct Current (DC) Voltage Authorized Representative in the European
Community
Separate collection for waste electrical
and electronic equipment.
IPX7 or IPX4 Ingress Protection Code Alternating Current (AC) Voltage CE marking of conformity
IEC Class II Equipment Do not immerse this device in any liquid. UK Conformity Assessed
EC
REP
4

1. Tip knob
2. Power switch
3. Pressure control
4. Power handle
5. Charger inlet
6. Tip
7. Tip eject button
8. Flip top water inlet
9. Reservoir
USB charging cord
Waterpik® p/n 20031307-1 (White)
Waterpik® p/n 20031307-2 (Black)
TIPS
A. Orthodontic Tip*
- Braces/General use
B. Pik Pocket™ Tip*
- Periodontal pockets/
Furcations
C. Plaque Seeker™ Tip*
- Implants/Crowns/Bridges/
Retainers/General use
NOT ALL TIPS INCLUDED IN ALL MODELS
A
D
B
E
C
F
*Replace Every 3 months **Replace Every 6 months
PRODUCT DESCRIPTION
Replacement/attachments may be purchased directly from
Water Pik, Inc. UK Customer Service Centre at +44 (0) 333
123 5677 or from www.waterpik.co.uk. To nd detailed
information about tips, other accessories, and product
usage please visit our website at www.waterpik.co.uk.
I
O
II
I
1
5
7
8
9
6
4
3
2
D. Toothbrush Tip*
- General use
E. Classic Jet Tip**
- General use
F. Tongue Cleaner**
- Fresher breath
ENGLISH
5

66
Charging Unit Prior to First Use
Charge Unit For 24 Hours Prior To First Use. A user supplied USB carger with the following specications is required to charge this product:
USB Type-A, Rated Output: 5.0 VDC, 1.0 A. Plug the USB charger into a wall outlet and connect the charging cord to the unit. Make sure
you slide the switch into the OFF (0) position before charging. The unit will not charge if the switch is in the ON (I) position. See “Cleaning
and Troubleshooting Your Waterpik® Water Flosser” for guidance on how to look aer your battery.
Filling the Reservoir
Li ip top on reservoir and ll the reservoir with lukewarm water.
Inserting and Removing Tips
Insert tip into the center of the knob at the top of the Water Flosser handle. The colored ring will be ush with the end of the knob if the
tip is correctly locked into place. To remove the tip from the handle, press the tip eject button and pull tip from the handle.
CAUTION:DO NOT PRESS TIP EJECT BUTTON WHILE UNIT IS RUNNING.
Adjusting the Pressure Setting
You can adjust the pressure setting on your Water Flosser by simply sliding the pressure switch on the handle.
GETTING STARTED
Fill
I
O
II
I
Pressure
Setting
I
O
II
I




I
O
II
I
Eject
Insert

ENGLISHENGLISH
77
1.
2.
Remove
Recommended Technique
Lean low over sink and place the tip in mouth. Aim the tip toward teeth, and turn the unit ON (|).
For best results, start with the back teeth and work toward the front teeth. Glide tip along gumline and pause briey between teeth.
Continue until you have cleaned the inside and outside of both the upper and lower teeth.
Direct the jet stream at a 90-degree angle to your gumline. Slightly close lips to avoid splashing but allow water to ow freely from
mouth into the sink. Keep unit upright during use for best results.
When Finished
Turn the unit OFF (0). Empty any liquid le in the reservoir.
If desired, the reservoir may be removed from the power handle by sliding the reservoir release latch to the unlock position(1) and then
sliding the reservoir down towards the base of the unit(2).
To replace the reservoir on the power handle, simply slide it up towards the top of the unit. The reservoir will snap into place when
fully engaged.
I
O
II
I

88
NOTE: NOT ALL TIPS INCLUDED WITH ALL MODELS.
TIP USAGE
Pik Pocket™ Tip
The Pik Pocket™ tip is specically designed to deliver water or anti-bacterial solutions deep into periodontal pockets.
To use the Pik Pocket™ tip, set the unit to the lowest pressure setting. Place the so tip against a tooth at a 45-degree angle and
gently place the tip under the gumline, into the pocket.
Tongue Cleaner Tip
Set to lowest pressure setting, place tip in the center/middle of your tongue about half way back. Pull forward with light pressure.
Increase pressure as you prefer.
Orthodontic Tip
To use the orthodontic tip, gently glide tip along gumline, pausing briey to lightly brush area between teeth and all around orthodontic
bracket, before proceeding to the next tooth.
Toothbrush Tip
Place the toothbrush tip in mouth with the brush head on the tooth at the gumline. The toothbrush tip can be used with or
without toothpaste. Using a light pressure (bristles should not bend) massage the brush back and forth with very short
strokes – much like you would with a manual toothbrush.
Plaque Seeker™ Tip
To use the Plaque Seeker™ tip, place the tip close to the teeth so that the bristles are gently touching the teeth. Gently glide tip along
gumline, pausing briey between teeth to gently brush and allow the water to ow between the teeth.

ENGLISHENGLISH
99
CLEANING AND TROUBLESHOOTING YOUR WATERPIK® WATER FLOSSER
Using Mouthwash and Other Solutions
Your Waterpik® Water Flosser can be used to deliver mouthwash and antibacterial solutions. Aer using any special solution, rinse unit
to prevent clogging by partially lling reservoir with warm water and running unit with tip pointed into sink until unit is empty.
Cleaning
Never immerse unit in water. Before cleaning, unplug from the electrical outlet. Clean the product when necessary by using a so cloth
and mild non-abrasive cleanser to wipe exterior.
The water reservoir is removable for easy cleaning and is top rack dishwasher safe. It is recommended that the reservoir is removed
and cleaned weekly.
Removing Hard Water Deposits / General Cleaning
Hard water deposits may build up in your unit, depending on the mineral content of your water. If le unattended, it can
hinder performance.
Cleaning internal parts: add 1 tablespoon of white vinegar to a full reservoir of warm water. Point the handle and tip into sink.
Turn unit ON (I) and run until reservoir is empty. Rinse by repeating with a full reservoir of clean warm water.
This process should be done every 1 to 3 months to ensure optimal performance.
Battery Care
The unit will not charge if the switch is in the ON (I) position. If you use your Water Flosser once a day or less, it is recommended you
charge it overnight, once a week. If you use it twice a day or more, charge the unit more frequently. Do not run the batteries down
completely as this may shorten the lifespan of the batteries and will require charging the unit for 24 hours to obtain a full charge.
If the Water Flosser is to be stored for an extended period of time (six months or more), be sure to fully charge it prior to storage.
The unit contains a Nickel Metal Hydride battery.

1010
BATTERY REMOVAL
1.
2.
3.
4.
5.
6.
7.
8.
Battery Removal
The product contains battery and/or recyclable electronic waste. In order to protect the environment, please do not dispose along with
household waste. When battery life ends, please dispose or recycle according to local administrative regulations.
Please contact local waste administrative department for any questions.
If you intend to dispose of the Nickel Metal Hydride battery on your own, please discharge battery fully before removal and follow below steps
to remove battery:
1. Power o the device, pull the reservoir release latch and take out the reservoir.
2. Remove four screws.
3. Remove back handle.
4. Remove two screws.

ENGLISHENGLISH
1111
1.
2.
3.
4.
5.
6.
7.
8.
cut
5. Remove tip rotator by prying it o with a at blade screwdriver.
6. Remove chassis from Unit.
7. Flip chassis over to expose battery. Remove two screws.
8. Cut these two wires and pry battery out of chassis.
The removed battery should be disposed safely by special recycling center.
WARNING: The battery of this product is not replaceable. Please do not disassemble the product
unless you want to dispose it. Otherwise the warranty service will be void.

1212
LIMITED TWO YEAR WARRANTY
Service Maintenance
Waterpik® Water Flossers have no consumer serviceable electrical items and do not require routine service maintenance. For all your service
needs please call the Water Pik, Inc. UK Customer Service Centre at [phone]. Some replacement parts and accessories for the
Water Flosser are also available at www.waterpik.co.uk. For questions or problems please call the customer service centre before returning
the product.
Refer to the serial and model numbers in all correspondence. These numbers are located on the back of the handle and bottom
of the reservoir respectively.
Still have questions? Go to www.waterpik.co.uk.
Warranty
Water Pik, Inc. warrants to the original consumer of this new product that it is free from defects in materials and workmanship for 2 years
from the date of purchase. Consumer will be required to submit the original purchase receipt as proof of purchase date and if requested, the
entire product, to support a warranty claim. Water Pik, Inc. will replace at its discretion the product, which in its opinion is defective, provided
the product has not been abused, misused, altered or damaged aer purchase, was used according to instructions, and was used only with
accessories or consumable parts approved by Water Pik, Inc. This limited warranty excludes accessories or consumable parts such as tips, etc.
This warranty gives you specic legal rights. You may also have other rights that vary, depending on the law in your place of residence.

ENGLISHENGLISH
1313

Form No. 20031739-F AA
©2022 Water Pik, Inc.
Designed and tested in the US. Made in China.
Water Pik, Inc., a subsidiary
of Church & Dwight Co., Inc.
1730 East Prospect Road
Fort Collins, CO 80553-0001 USA
844-821-4873
www.waterpik.com
EC REP
SOFIBEL SAS
110-114 Rue Victor Hugo
92686 Levallois-Perret Cedex-France
UK Responsible Person
Church & Dwight UK Limited,
Wear Bay Road,
Folkestone,
Kent CT19 6PG
United Kingdom
