Waterpik WF-13 Series User manual

Waterpik®Water Flosser
Model WF-13 Series
Hydropulseur WaterpikMD
Modèle WF Série 13
I
O
II
I
www.waterpik.com

IMPORTANT
SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE USING.
• This product is for household use.
When using electrical products, especially when children are present, basic
safety precautions should always be followed, including the following:
DANGER:
To reduce the risk of electrocution:
• Do not handle the USB charger* with wet hands.
• Do not place USB charger* in or drop charger into water
or other liquid.
• Do not use this product while bathing.
• Do not place or store this product where it can fall or be pulled
into a tub or sink.
• Do not reach for this product if it has fallen into water. Unplug from
electrical outlet immediately.
• Check the USB charger* and cord for damage before the rst use
and during the life of the product.
IMPORTANT SAFEGUARDS
WARNING:
To reduce the risk of burns, electrocution, ire,
or injury to persons:
• Use this product only as indicated in these instructions or as
recommended by your dental professional.
• Use only the USB charger provided. If a USB charger is not provided, a
user supplied USB charger with the following specications is required
to charge this product: USB Type-A, Rated Output: 5.0 VDC, 1.0 A.
• Do not plug this device into a voltage system that is dierent from the
voltage system specied on the device or charger.
• Keep the charging cord and USB charger* away from heated surfaces.
• Do not use the Water Flosser for more than 5 minutes in each
two hour period.
• Do not direct water under the tongue, into the ear, nose or other
delicate areas. This product is capable of producing pressures that may
cause serious damage in these areas. The potentially deadly amoeba,
Naegleria fowleri, may be present in some tap water or unchlorinated
well water and may be fatal if directed into the nose or ear.
*The USB charger is not included in all product congurations.
2

• Fill reservoir with warm water or other dental professional
recommended solutions only.
• Do not use iodine, saline (salt solution), or water insoluble concentrated
essential oils in this product. Use of these can reduce performance and
will shorten the life of the product.
• Only use tips and accessories that are recommended by Water Pik, Inc.
• If the Pik Pocket™ tip (not included in all models) separates from the
sha for any reason, discard tip and sha and replace with a new Pik
Pocket™ tip.
• Do not drop or insert any foreign object into any opening on
the product.
• Do not use this product outdoors or operate where aerosol (spray)
products are being used or where oxygen is being administered.
• Remove any oral jewelry prior to use of this product.
• Do not use if you have an open wound on your tongue or in your mouth.
• There are no consumer serviceable parts in this product and it does
not require maintenance.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with
the appliance.
• If the supply cord is damaged, it must be replaced by a special cord or
assembly available from the manufacturer or its service agent.
• Do not use this product if it has a damaged cord or plug, if it is not
working properly, if it has been dropped or damaged, or dropped
into any liquid. Contact Water Pik, Inc. at 1-800-525-2774 or visit
www.waterpik.com.
SAVE THESE
INSTRUCTIONS
3
ENGLISH
ORIGINAL INSTRUCTIONS

Product Description 5
Getting Started 6
Cleaning and Troubleshooting Your Waterpik® Water Flosser 8
Battery Removal 9
Service and Maintenance 10
Limited Two Year Warranty 11
TABLE OF CONTENTS
SYMBOLS
The following symbols may appear on your product and/or packaging. Some of these symbols may not be relevant in your region and are listed for information purposes only.
Symbol Deinition Symbol Deinition Symbol Deinition Symbol Deinition
Refer to instruction manual Detachable Power Supply Do not use this device in a shower, bathtub
and do not immerse in any liquid. Regulatory Compliance Mark
Manufacturer Direct Current (DC) Voltage Authorized Representative in the
European Community
Separate collection for waste electrical
and electronic equipment.
IPX7 or IPX4 Ingress Protection Code Alternating Current (AC) Voltage CE marking of conformity
IEC Class II Equipment Do not immerse this device in any liquid. UK Conformity Assessed
EC
REP
4

1. Tip rotator
2. Power switch
3. Pressure control knob
4. Power handle
5. Charger inlet
6. Tip
7. Tip eject button
8. Flip top water inlet
9. Reservoir
10. USB Charger*
I
O
II
I
TIPS
A. Orthodontic Tip*
- Braces/General Use
B. Pik Pocket™ Tip*
- Periodontal Pockets/
Furcations
C. Plaque Seeker™ Tip*
- Implants/Crowns/
Bridges/Retainers/
General Use
NOT ALL TIPS INCLUDED IN ALL MODELS
A
D
B
E
C
F
*Replace Every 3 months **Replace Every 6 months
Replacement tips/attachments may be purchased online
at www.waterpik.com or by phone from Water Pik, Inc.
at 1-800-525-2774. To nd detailed information about
tips, other accessories, and product usage please visit our
website at www.waterpik.com.
PRODUCT DESCRIPTION
D. Toothbrush Tip*
- General Use
E. Classic Jet Tip**
- General Use
F. Tongue Cleaner**
- Fresher Breath
1
5
7
8
9
6
4
3
2
USB charging cord
Water Pik PN 20031307-1 (White)
Water Pik PN 20031307-2 (Black)
USB Charger*
Water Pik PN 20024470-36 (White)
Water Pik PN 20024470-4 (Black)
10
*The USB charger is not included in all product congurations
5
ENGLISH

66
I
O
II
I
Insert
Charging Unit Prior to First Use
Charge Unit For 24 Hours Prior To First Use. Use only the USB charger provided. If a USB charger is not provided, a user supplied
USB charger with the following specications is required to charge this product: USB Type-A, Rated Output: 5.0 VDC, 1.0 A. Plug the
USB charger into a wall outlet and connect the charging cord to the unit. Make sure you slide the switch into the OFF (0) position before
charging. The unit will not charge if the switch is in the ON (I) position. See “Cleaning and Troubleshooting Your Waterpik® Water Flosser”
for guidance on how to look aer your battery. The Waterpik® Water Flosser will stay charged for up to 2 weeks depending on use.
Filling the Reservoir
Li ip top on reservoir and ll the reservoir with lukewarm water.
Inserting and Removing Tips
Insert tip into the center of the knob at the top of the Water Flosser handle. The colored ring will be ush with the end of the knob if the
tip is correctly locked into place. To remove the tip from the handle, press the tip eject button and pull tip from the handle.
CAUTION: Do not press tip eject button while unit is running.
Adjusting the Pressure Setting
You can adjust the pressure setting on your Water Flosser by simply sliding the pressure switch on the handle.
Recommended Technique
Lean low over sink and place the tip in mouth. Aim the tip toward teeth, and turn the unit ON (|).
For best results, start with the back teeth and work toward the front teeth. Glide tip along gumline and pause briey between teeth.
Continue until you have cleaned the inside and outside of both the upper and lower teeth.
Direct the jet stream at a 90-degree angle to your gumline. Slightly close lips to avoid splashing but allow water to ow freely from
mouth into the sink. Keep unit upright during use for best results.
When Finished
Turn the unit OFF (O). Empty any liquid le in the reservoir.
If desired, the reservoir may be removed from the power handle by pulling the reservoir release latch (1) while sliding the reservoir down
towards the base of the unit. (2) To replace the reservoir on the power handle, simply slide it up towards the top of the unit. The reservoir will
snap into place when fully engaged.
Eject
Fill
I
O
II
I
Pressure
Setting
1.
2.
Remove
GETTING STARTED
I
O
II
I
Charge

77
NOTE: NOT ALL TIPS INCLUDED WITH ALL MODELS.
TIP USAGE
Pik Pocket™ Tip
The Pik Pocket™ tip is specically designed to deliver water or anti-bacterial solutions deep into periodontal pockets.
To use the Pik Pocket™ tip, set the unit to the lowest pressure setting. Place the so tip against a tooth at a 45-degree angle and gently
place the tip under the gumline, into the pocket.
Tongue Cleaner Tip
Set to lowest pressure setting, place tip in the center/middle of your tongue about half way back. Pull forward with light pressure.
Increase pressure as you prefer.
Orthodontic Tip
To use the orthodontic tip, gently glide tip along gumline, pausing briey to lightly brush area between teeth and all around orthodontic
bracket, before proceeding to the next tooth.
Toothbrush Tip
Place the toothbrush tip in mouth with the brush head on the tooth at the gumline. The toothbrush tip can be used with or
without toothpaste.
Using a light pressure (bristles should not bend) massage the brush back and forth with very short strokes – much like you would
with a manual toothbrush.
Plaque Seeker™ Tip
To use the Plaque Seeker™ tip, place the tip close to the teeth so that the bristles are gently touching the teeth. Gently glide tip along
gumline, pausing briey between teeth to gently brush and allow the water to ow between the teeth.
ENGLISH

88
Using Mouthwash and Other Solutions
Your Waterpik® Water Flosser can be used to deliver mouthwash and antibacterial solutions. Aer using any special solution, rinse
unit to prevent clogging by partially lling reservoir with warm water and running unit with tip pointed into sink until unit is empty.
Cleaning
Never immerse unit in water. Before cleaning, unplug from the electrical outlet. Clean the product when necessary by using a so
cloth and mild non-abrasive cleanser to wipe exterior.
The water reservoir is removable for easy cleaning and is top rack dishwasher safe. It is recommended that the reservoir is removed
and cleaned weekly.
Removing Hard Water Deposits / General Cleaning
Hard water deposits may build up in your unit, depending on the mineral content of your water. If le unattended,
it can hinder performance.
Cleaning internal parts: add 1 tablespoon of white vinegar to a full reservoir of warm water. Point the handle and tip into sink.
Turn unit ON (I) and run until reservoir is empty. Rinse by repeating with a full reservoir of clean warm water.
This process should be done every 1 to 3 months to ensure optimal performance.
Battery Care and Disposal
The unit will not charge if the switch is in the ON(|) position. If you use your Water Flosser once a day or less, it is recommended you
charge it overnight, once a week. If you use it twice a day or more, charge the unit more frequently. Do not run the batteries down
completely as this may shorten the lifespan of the batteries and will require charging the unit for 24 hours to obtain a full charge.
If the Water Flosser is to be stored for an extended period of time (six months or more), be sure to fully charge it prior to storage.
The unit contains a Nickel Metal Hydride battery.
CLEANING AND TROUBLESHOOTING YOUR WATERPIK® WATER FLOSSER

99
Battery Removal
The product contains a rechargeable battery and/or recyclable electronic waste. In order to protect the
environment, please do not dispose along with household waste. When battery life ends, please dispose
or recycle according to local administrative regulations.
Please contact local waste administrative department for any questions.
If you intend to dispose of the Nickel Metal Hydride on your own, for example, for WF-13 models, please
discharge battery fully before removal and follow below steps to remove battery:
1. Power o the device, pull the reservoir release latch and take out the reservoir.
2. Remove the rear cover by breaking the joints at the handle (both sides) and top cover.
3. Remove 6 screws to remove chassis from unit to gain access to battery.
4. Remove tip rotator by prying it o with a at blade screwdriver
5. Remove chassis from Unit.
6. Flip chassis over to expose battery. Remove two screws
7. Cut these two wires and pry battery out of chassis.
The removed battery should be disposed safely by special recycling center
WARNING: The battery of this product is not replaceable. Please do not disassemble the product
unless you want to dispose it. Otherwise the warranty service will be void..
1.
2.
3.
4.
5.
6.
7.
I
O
II
I
O
II
I
1.
2.
3.
4.
5.
6.
7.
I
O
II
I
O
II
I
cut
BATTERY REMOVAL
ENGLISH

Service Maintenance
Waterpik® Water Flossers have no consumer-serviceable electrical items and
do not require routine service maintenance.
For all parts and accessories go to www.waterpik.com. You may also call our
toll-free customer service number at 1-800-525-2774 (USA) or 1-888-226-3042
(CANADA). Refer to the serial and model numbers in all correspondence. These
numbers are located on the bottom of your unit.
Still have questions? Go to www.waterpik.com.
Water Pik, Inc. warrants to the original consumer of this new product that it
is free from defects in materials and workmanship for 2 years from the date
of purchase. Consumer will be required to submit the original purchase receipt
as proof of purchase date and if requested, the entire product, to support a
warranty claim. Water Pik, Inc. will replace at its discretion the product, which
in its opinion is defective, provided the product has not been abused, misused,
altered or damaged aer purchase, was used according to instructions, and
was used only with accessories or consumable parts approved by Water Pik,
Inc. This limited warranty excludes accessories or consumable parts such as
tips, etc.
This warranty gives you specic legal rights. You may also have other rights
that vary, depending on the law in your place of residence.
SERVICE AND MAINTENANCE
WATER PIK, INC. DISCLAIMS ALL OTHER EXPRESS OR IMPLIED WARRANTIES
TO THE EXTENT PERMITTED BY LAW INCLUDING, BUT NOT LIMITED TO,
ALL WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. ALL IMPLIED WARRANTIES ARE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY. SOME STATES OR PROVINCES MAY NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
MAY NOT APPLY TO YOU.
10
