Watts Lf919-qt-fs Operating instructions

RP-IS-LF919-FS

Installation, Maintenance, and Repair Manual

Series LF919-FS

Reduced Pressure Zone Assembly

1⁄2" – 2"

WARNING

Read this Manual BEFORE using this equipment.

Failure to read and follow all safety and use information

can result in death, serious personal injury, property

damage, or damage to the equipment.

Keep this Manual for future reference.

Need for Periodic Inspection/Maintenance: This prod-

uct must be tested periodically in compliance with local

codes, but at least once per year or more as service condi-

tions warrant. All products must be retested once mainte-

nance has been performed. Corrosive water conditions and/

or unauthorized adjustments or repair could render the prod-

uct ineffective for the service intended. Regular checking and

cleaning of the product’s internal and external components

helps assure maximum life and proper product function.

WARNING

Local building or plumbing codes may require modifications

to the information provided. You are required to consult the

local building and plumbing codes prior to installation. If

the information provided here is not consistent with local

building or plumbing codes, the local codes should be

followed. This product must be installed by a licensed

contractor in accordance with local codes and ordinances.

WARNING

NOTICE

For Australia and New Zealand, line strainers should be

installed between the upstream shutoff valve and the inlet of

the backflow preventer.

If installed on a fire sprinkler system, all mechanical checks,

such as alarm checks and backflow preventers, should be flow

tested and inspected internally in accordance with NFPA 13

and NFPA 25.

Testing

For field testing procedure, refer to Watts installation sheets

IS-TK-DL, IS-TK-7, IS-TK-9A, IS-TK-99D, and IS-TK-99E at

www.watts.com.

For other repair kits and service parts, refer to the Backflow

Prevention Products Repair Kits & Service Parts price list

PL-RP-BPD at www.watts.com.

For technical assistance contact your local Watts representative.

LF919-QT-FS

Series LF919-FS is equipped with an integrated flood sensor that,

when activated, triggers notification of potential flood events from

excessive relief valve discharges.

NOTICE

An add-on connection kit is required to activate the integrated

flood sensor. Without the connection kit, the flood sensor is a

passive component that has no communication with any other

device. (A retrofit sensor connection kit is also available for exist-

ing installations. See “Add-on and Retrofit Sensor Connection

Kits,” for ordering details.)

NOTICE

Use of the integrated flood sensor does not replicate the need

to comply with all required instructions, codes, and regulations

related to installation, operation, and maintenance of this product,

including the need to provide proper drainage in the event of a

discharge.

Watts®is not responsible for the failure of alerts due to connectiv-

ity or power issues.

NOTICE

The information contained herein is not intended to replace the

full product installation and safety information available or the

experience of a trained product installer. You are required to

thoroughly read all installation instructions and product safety

information before beginning the installation of this product.

Inquire with governing authorities for local installation requirements.

DRAFT

Need for Periodic Inspection/Maintenance:

DRAFT

Need for Periodic Inspection/Maintenance:

This prod-

DRAFT

This prod-

uct must be tested periodically in compliance with local

DRAFT

uct must be tested periodically in compliance with local

codes, but at least once per year or more as service condi-

DRAFT

codes, but at least once per year or more as service condi-

tions warrant. All products must be retested once mainte-

DRAFT

tions warrant. All products must be retested once mainte-

nance has been performed. Corrosive water conditions and/

DRAFT

nance has been performed. Corrosive water conditions and/

or unauthorized adjustments or repair could render the prod-

DRAFT

or unauthorized adjustments or repair could render the prod-

uct ineffective for the service intended. Regular checking and

DRAFT

uct ineffective for the service intended. Regular checking and

cleaning of the product’s internal and external components

DRAFT

cleaning of the product’s internal and external components

helps assure maximum life and proper product function.

DRAFT

helps assure maximum life and proper product function.

DRAFT

Local building or plumbing codes may require modifications

DRAFT

Local building or plumbing codes may require modifications

to the information provided. You are required to consult the

DRAFT

to the information provided. You are required to consult the

local building and plumbing codes prior to installation. If

DRAFT

local building and plumbing codes prior to installation. If

the information provided here is not consistent with local

DRAFT

the information provided here is not consistent with local

building or plumbing codes, the local codes should be

DRAFT

building or plumbing codes, the local codes should be

followed. This product must be installed by a licensed

DRAFT

followed. This product must be installed by a licensed

contractor in accordance with local codes and ordinances.

DRAFT

contractor in accordance with local codes and ordinances.

DRAFT

For Australia and New Zealand, line strainers should be

DRAFT

For Australia and New Zealand, line strainers should be

installed between the upstream shutoff valve and the inlet of

DRAFT

installed between the upstream shutoff valve and the inlet of

the backflow preventer.

DRAFT

the backflow preventer.

If installed on a fire sprinkler system, all mechanical checks,

DRAFT

If installed on a fire sprinkler system, all mechanical checks,

such as alarm checks and backflow preventers, should be flow

DRAFT

such as alarm checks and backflow preventers, should be flow

LF919-QT-FS

DRAFT

LF919-QT-FS

DRAFT

Series LF919-FS is equipped with an integrated flood sensor that,

DRAFT

Series LF919-FS is equipped with an integrated flood sensor that,

when activated, triggers notification of potential flood events from

DRAFT

when activated, triggers notification of potential flood events from

excessive relief valve discharges.

DRAFT

excessive relief valve discharges.

DRAFT

NOTICE

DRAFT

NOTICE

An add-on connection kit is required to activate the integrated

DRAFT

An add-on connection kit is required to activate the integrated

flood sensor. Without the connection kit, the flood sensor is a

DRAFT

flood sensor. Without the connection kit, the flood sensor is a

passive component that has no communication with any other

DRAFT

passive component that has no communication with any other

Installation Guidelines

Indoors

For indoor installation, make sure Series LF919-FS is accessible

to facilitate testing and servicing. Do not install the assembly

in a concealed location. If the location is parallel and close to

the wall, make sure the test cocks are accessible and the drain

line can discharge water if required. An air gap and drain line

are piped from the relief valve connection, allowing evidence of

discharge to be visible and preventing the occurrence of water

damage. (Refer to ES-AG/EL/TC at watts.com.)

Outdoor, Above Ground

For outdoor installations, install Series LF919 where there are no

freezing conditions and above ground whenever possible.

Install the assembly in an accessible location to facilitate test-

ing and servicing. The installation must also allow for adequate

drainage from the air gap and the discharge line if needed.

WARNING

Do not allow the drain line to empty directly into a drainage

ditch, sewer system, or sump.

Do not install the assembly in any location where any part of the

unit could become submerged in standing water.

Now available, Wa ttsBox Insulated Enclosures,

for more information, send for literature ES-WB.

FIBERGLASS WattsBox

Min. 12"

WattsBox Insulated Enclosure

For more information download ES-WB.

Parallel

For parallel installations, two or more small-sized assemblies

can be installed (when approved) to serve a large supply pipe

main. Use this type of installation in an application where

increased capacity beyond that provided by a single valve is

required. Additionally, this type of installation permits testing

and/or servicing of a single valve without shutting down the

complete line.

The number of units installed in parallel should be determined

by the engineer’s judgment, based on the operating conditions

of a specific application.

NOTICE

The total capacity of all the units installed in the application

should equal or exceed that required by the system.

A. Shutoff Valves: If you remove the shutoff valves from the

assembly, reassemble the shutoff valve with the test cock

mounted on the inlet side of the unit.

B. Check state and local codes to ensure the assembly is

installed in compliance with the codes, such as proper

height above the ground.

C. Recommended: Install a strainer ahead of the assembly to

protect the internal components from unnecessary fouling.

CAUTION

Do not install the assembly with a strainer in rarely used

water lines, such as a fire sprinkler system which is only

deployed during emergencies.

Start Up: Close the downstream shutoff. Open the

upstream slowly and fill the valve. When the valve is filled,

open the downstream shutoff slowly, and fill the water sup-

ply system. This is necessary to avoid water hammer and/or

shock damage.

D. Vent the air gap and drain line from the relief valve in

accordance with code requirements. Terminate discharge

approximately 12" above the ground or through an air gap

piped to a floor drain.

WARNING

Do not allow the drain line to empty directly into a drainage

ditch, sewer system, or sump.

NOTICE

Relief Valve Discharge Rates. The air gap and drain line

terminating above a floor drain can accommodate any mod-

erate discharge or nuisance spitting through the relief valve.

However, to prevent water damage in the case of a cata-

strophic failure, design the floor drain size to accommodate

the increased discharge. (See table on typical flow rates as

sized by floor drain manufacturers, page 3.)

Air Gap

Strainer

Meter

12" Minimum

(refer to local codes)

DRAFT

For outdoor installations, install Series LF919 where there are no

DRAFT

For outdoor installations, install Series LF919 where there are no

freezing conditions and above ground whenever possible.

DRAFT

freezing conditions and above ground whenever possible.

Install the assembly in an accessible location to facilitate test-

DRAFT

Install the assembly in an accessible location to facilitate test-

ing and servicing. The installation must also allow for adequate

DRAFT

ing and servicing. The installation must also allow for adequate

drainage from the air gap and the discharge line if needed.

DRAFT

drainage from the air gap and the discharge line if needed.

DRAFT

Do not allow the drain line to empty directly into a drainage

DRAFT

Do not allow the drain line to empty directly into a drainage

ditch, sewer system, or sump.

DRAFT

ditch, sewer system, or sump.

Do not install the assembly in any location where any part of the

DRAFT

Do not install the assembly in any location where any part of the

unit could become submerged in standing water.

DRAFT

unit could become submerged in standing water.

The total capacity of all the units installed in the application

DRAFT

The total capacity of all the units installed in the application

should equal or exceed that required by the system.

DRAFT

should equal or exceed that required by the system.

DRAFT

Shutoff Valves: If you remove the shutoff valves from the

DRAFT

Shutoff Valves: If you remove the shutoff valves from the

assembly, reassemble the shutoff valve with the test cock

DRAFT

assembly, reassemble the shutoff valve with the test cock

mounted on the inlet side of the unit.

DRAFT

mounted on the inlet side of the unit.

DRAFT

Check state and local codes to ensure the assembly is

DRAFT

Check state and local codes to ensure the assembly is

DRAFT

NOTICE

Do not reduce the size of the drain line from the air gap fit-

ting. The drain line must remain at full line size.

E. After the initial installation of the assembly, a discharge from

the relief valve may occur due to dirt and pipe compounds.

This may be caused by inadequate initial flushing of the pipe-

lines. If flushing the valve does not clear the unit, remove the

first check valve and clean thoroughly, using the procedures

in “Servicing the First and Second Check Valves.”

NOTICE

Periodic relief valve discharge may occur on dead end

service applications, such as boiler feed lines or cooling

tower makeup lines. This may be due to fluctuating supply

pressure during a static or no flow condition. To avoid this

discharge, install a spring-loaded, rubber seated check valve

ahead of the backflow assembly.

F. Avoid placing the assembly in a pit or at a depth below the

ground level, unless absolutely necessary. If an installa-

tion requires below ground level installation, a modified pit

installation is recommended, as well as the approval of local

codes. In such cases, provision should be made to always

vent the drain line above the flood level. In the case of a pit

drain, ensure an adequate air gap exists between the bottom

of the drain line and the bottom of the pit.

G. Periodically inspect the assembly to check for any discharge

from the relief valve. This discharge is a visual indication that

the valve needs cleaning or repair. Also test the valve peri-

odically in compliance with local codes to ensure its proper

operation.

The relief vent discharges water during no-flow periods in the

following instances:

• The first check valve is fouled.

• The inlet pressure to the check valve drops sufficiently due

to upstream pressure fluctuations. This affects the required

operating differential between the inlet pressure and the

reduced pressure zone.

• The second check is fouled during emergency backflow or

resulting from a water hammer condition.

For more information download Troubleshooting Guide S-TSG.

NOTICE

When installing the assembly on fire prevention systems, special

considerations are required.

Fire Protection System Installations: The National Fire Protection

Agency (NFPA) Guidelines require a confirming flow test to be

conducted by a certified tester whenever a “main line” valve is

installed, such as a shutoff valve or a backflow preventer.

1/2"

3/4" M2

1" M2

1⁄2" – 1" LF919

0 10 20 30 40 50 60 70 80 90 100 110

Flow Rate gpm

Zone Pressure psi

1⁄2" 3⁄4" X 1"

0 10 20 30 40 50 60 70 80 90 100 110

Zone Pressure psi

0 11⁄4"–11⁄2" 2"

Flow Rate gpm

350

300

250

200

150

100

11⁄4" – 2" LF919

TYPICAL FLOW RATES AS SIZED BY FLOOR DRAIN MANUFACTURERS

2" 55 gpm 5" 350 gpm

3" 112 gpm 6" 450 gpm

4" 170 gpm 8" 760 gpm

DRAFT

installation is recommended, as well as the approval of local

DRAFT

installation is recommended, as well as the approval of local

codes. In such cases, provision should be made to always

DRAFT

codes. In such cases, provision should be made to always

vent the drain line above the flood level. In the case of a pit

DRAFT

vent the drain line above the flood level. In the case of a pit

drain, ensure an adequate air gap exists between the bottom

DRAFT

drain, ensure an adequate air gap exists between the bottom

Periodically inspect the assembly to check for any discharge

DRAFT

Periodically inspect the assembly to check for any discharge

from the relief valve. This discharge is a visual indication that

DRAFT

from the relief valve. This discharge is a visual indication that

the valve needs cleaning or repair. Also test the valve peri-

DRAFT

the valve needs cleaning or repair. Also test the valve peri-

odically in compliance with local codes to ensure its proper

DRAFT

odically in compliance with local codes to ensure its proper

The relief vent discharges water during no-flow periods in the

DRAFT

The relief vent discharges water during no-flow periods in the

The first check valve is fouled.

DRAFT

The first check valve is fouled.

The inlet pressure to the check valve drops sufficiently due

DRAFT

The inlet pressure to the check valve drops sufficiently due

to upstream pressure fluctuations. This affects the required

DRAFT

to upstream pressure fluctuations. This affects the required

operating differential between the inlet pressure and the

DRAFT

operating differential between the inlet pressure and the

reduced pressure zone.

DRAFT

reduced pressure zone.

The second check is fouled during emergency backflow or

DRAFT

The second check is fouled during emergency backflow or

resulting from a water hammer condition.

DRAFT

resulting from a water hammer condition.

For more information download Troubleshooting Guide S-TSG.

DRAFT

For more information download Troubleshooting Guide S-TSG.

DRAFT

When installing the assembly on fire prevention systems, special

DRAFT

When installing the assembly on fire prevention systems, special

considerations are required.

DRAFT

considerations are required.

Fire Protection System Installations: The National Fire Protection

DRAFT

Fire Protection System Installations: The National Fire Protection

Agency (NFPA) Guidelines require a confirming flow test to be

DRAFT

Agency (NFPA) Guidelines require a confirming flow test to be

DRAFT

0 10 20 30 40 50 60 70 80 90 100 110

DRAFT

0 10 20 30 40 50 60 70 80 90 100 110

DRAFT

0 10 20 30 40 50 60 70 80 90 100 110

DRAFT

⁄

DRAFT

⁄

1⁄

DRAFT

1⁄

DRAFT

⁄2⁄

DRAFT

⁄2⁄

DRAFT

Flow Rate gpm

DRAFT

Flow Rate gpm

350

DRAFT

350

DRAFT

350

300

DRAFT

300

DRAFT

300

250

DRAFT

250

DRAFT

250

200

DRAFT

200

DRAFT

200

150

DRAFT

150

DRAFT

150

100

DRAFT

100

DRAFT

100

DRAFT

⁄

DRAFT

⁄

1⁄

DRAFT

1⁄

DRAFT

⁄4⁄

DRAFT

⁄4⁄

" – 2" LF919

DRAFT

" – 2" LF919

DRAFT

TYPICAL FLOW RATES AS SIZED BY FLOOR DRAIN MANUFACTURERS

DRAFT

TYPICAL FLOW RATES AS SIZED BY FLOOR DRAIN MANUFACTURERS

Servicing the Relief Valve

WARNING

!Depressurize valve before servicing.

No special tools are required to service the assembly.

Before servicing, turn off the water or close the shutoff valves.

Remove the flood sensor and activation module if the relief

valve outlet needs to be cleaned of debris.

The following procedures provide information for replacing

the diaphragm, the relief valve disc, and the relief valve seat.

Visually inspect these parts to determine if a replacement or

cleaning is required.

Disassembling the Relief Valve

1. Remove the relief valve cover bolts while holding the cover

down.

2. Turn the cover counterclockwise by one quarter, and lift it

straight off while still applying pressure to the cover with

your hand.

WARNING

Apply pressure to the cover as you lift it straight off. Due to

the release of pressure when removing the cover, the relief

valve spring may eject quickly.

3. Remove the relief valve assembly (includes cover O-ring,

stem and diaphragm assembly).

4. Remove the relief valve spring.

5. Remove the pressed-in relief valve seat and seat O-ring.

Replacing the Diaphragm

1. Using a wrench, loosen the diaphragm assembly by turning

the hex bolt counterclockwise.

2. Remove the diaphragm and replace with a new diaphragm

if required, or clean the existing diaphragm. The molded

step of the diaphragm should point down toward the relief

valve stem.

3. Using a wrench, reassemble the diaphragm assembly

by turning the hex bolt clockwise to tighten.

Replacing the Relief Valve Disc and Seat

1. Using a Phillips screwdriver, remove the screw in the relief

valve disc and replace the disc if required, or clean the

existing disc.

2. Place the screw back into the relief valve disc and tighten.

3. Replace the relief valve seat with a new seat if required, or

clean the existing seat.

Quad-Ring

Relief Valve Cover O-ring

Diaphragm Nut

Relief Valve Diaphragm

Relief Valve Stem

Relief Valve Disc

Relief Valve

Disc Screw

Relief Valve Seat

Body

Relief Valve Seat O-ring

Relief

Valve

Spring

Relief

Valve

Cover

Bolts

Reassembling the Relief Valve

1. Place the relief valve seat back into the chamber bore.

2. Slide the diaphragm assembly into the relief valve seat.

3. Place the spring onto the diaphragm assembly.

4. Place the cover O-ring on the diaphragm assembly.

5. Line up the grooves on the relief valve cover with the

grooves in the relief valve body, and turn the cover clock-

wise by one quarter to seat the cover.

6. Using a wrench, place the bolts back into the cover and

tighten.

CAUTION

If the cover does not lie flat against the relief valve body, the

diaphragm assembly is not installed properly and damage

can result. Remove the bolts and cover, realign the dia-

phragm assembly, and place the cover back on the relief

valve body.

7. Reinstall the flood sensor and activation module if removal

was required.

8. Open the shutoff valves.

DRAFT

5. Remove the pressed-in relief valve seat and seat O-ring.

DRAFT

5. Remove the pressed-in relief valve seat and seat O-ring.

1. Using a wrench, loosen the diaphragm assembly by turning

DRAFT

1. Using a wrench, loosen the diaphragm assembly by turning

2. Remove the diaphragm and replace with a new diaphragm

DRAFT

2. Remove the diaphragm and replace with a new diaphragm

if required, or clean the existing diaphragm. The molded

DRAFT

if required, or clean the existing diaphragm. The molded

step of the diaphragm should point down toward the relief

DRAFT

step of the diaphragm should point down toward the relief

3. Using a wrench, reassemble the diaphragm assembly

DRAFT

3. Using a wrench, reassemble the diaphragm assembly

by turning the hex bolt clockwise to tighten.

DRAFT

by turning the hex bolt clockwise to tighten.

Replacing the Relief Valve Disc and Seat

DRAFT

Replacing the Relief Valve Disc and Seat

1. Using a Phillips screwdriver, remove the screw in the relief

DRAFT

1. Using a Phillips screwdriver, remove the screw in the relief

valve disc and replace the disc if required, or clean the

DRAFT

valve disc and replace the disc if required, or clean the

existing disc.

DRAFT

existing disc.

2. Place the screw back into the relief valve disc and tighten.

DRAFT

2. Place the screw back into the relief valve disc and tighten.

3. Replace the relief valve seat with a new seat if required, or

DRAFT

3. Replace the relief valve seat with a new seat if required, or

clean the existing seat.

DRAFT

clean the existing seat.

DRAFT

Quad-Ring

DRAFT

Quad-Ring

Relief Valve Cover O-ring

DRAFT

Relief Valve Cover O-ring

Reassembling the Relief Valve

DRAFT

Reassembling the Relief Valve

1. Place the relief valve seat back into the chamber bore.

DRAFT

1. Place the relief valve seat back into the chamber bore.

2. Slide the diaphragm assembly into the relief valve seat.

DRAFT

2. Slide the diaphragm assembly into the relief valve seat.

3. Place the spring onto the diaphragm assembly.

DRAFT

3. Place the spring onto the diaphragm assembly.

4. Place the cover O-ring on the diaphragm assembly.

DRAFT

4. Place the cover O-ring on the diaphragm assembly.

5. Line up the grooves on the relief valve cover with the

DRAFT

5. Line up the grooves on the relief valve cover with the

grooves in the relief valve body, and turn the cover clock-

DRAFT

grooves in the relief valve body, and turn the cover clock-

wise by one quarter to seat the cover.

DRAFT

wise by one quarter to seat the cover.

6. Using a wrench, place the bolts back into the cover and

DRAFT

6. Using a wrench, place the bolts back into the cover and

Servicing the First and Second Check Valves

WARNING

!Depressurize valve before servicing.

No special tools are required to service the series.

Before servicing, make sure the water is turned off or shutoff

valves are closed.

1. Close shutoff valves up and downstream of the valve.

2. Using an appropriately sized wrench, loosen the check

valve cover. Unscrew the check valve cover and lift it off.

3. Remove the spring.

4. Lift out the disc holder assembly from the body of the valve.

5. To reverse the seat disc, unscrew the disc screw and dis-

assemble the disc washer and disc rubber from the disc

holder assembly. Reverse the disc rubber so the opposite

face is showing.

6. Assemble the disc screw through the disc washer and disc

rubber, and screw it into the disc holder.

7. To replace the seat module, pull the seat module out of the

body by gripping at the reinforcement ring. Replace the seat

module with the new seat by placing it into the body seat

bore.

NOTICE

When the cover is tightened in step 12, the cover is

engaged with the seat module properly.

8. Insert the disc holder assembly back into the seat module.

9. Replace the spring ensuring that it seats properly on the

disc holder.

WARNING

The first check valve has a heavyweight spring. The second

check valve has a lighter-weight spring. When reassembling

the check valves, install the correct spring into the correct

check valve.

10.Place the cover onto the spring with the internal guide on

the cover positioned inside the end coil.

11.Screw the cover onto the valve body.

12.Tighten the cover using the appropriately sized wrench.

13.Service the second check valve using steps 2 to 12.

14.Slowly open shutoff valves.

Check Disc Washer

Check Disc Screw

Check Seat

O-ring

Cover

Cover O-ring

Check Spring

Check Disc Rubber

Check Disc Holder Check Assembly

Troubleshooting

SYMPTOM CAUSE SOLUTION

Check valve fails to hold

1.0 PSID minimum

Debris on check disc sealing surface Disassemble and clean

Leaking gate valve Disassemble and clean or repair

Damaged seat disc or seat O-ring Disassemble and replace

Damaged guide holding check open Disassemble and clean or replace

Weak or broken spring Disassemble and replace spring

Chatter during flow conditions Worn, damaged or defective guide Disassemble and repair or replace guide

Low flows passing through

mainline valve

Mainline check fouled Disassemble and clean

Meter strainer plugged

Damaged mainline seat disc or seat Disassemble and replace

Broken mainline spring

DRAFT

10.Place the cover onto the spring with the internal guide on

DRAFT

10.Place the cover onto the spring with the internal guide on

12.Tighten the cover using the appropriately sized wrench.

DRAFT

12.Tighten the cover using the appropriately sized wrench.

13.Service the second check valve using steps 2 to 12.

DRAFT

13.Service the second check valve using steps 2 to 12.

Troubleshooting

DRAFT

Troubleshooting

DRAFT

CAUSE

DRAFT

CAUSE

Check valve fails to hold

DRAFT

Check valve fails to hold

1.0 PSID minimum

DRAFT

1.0 PSID minimum

Debris on check disc sealing surface

DRAFT

Debris on check disc sealing surface

Leaking gate valve

DRAFT

Leaking gate valve

Damaged seat disc or seat O-ring

DRAFT

Damaged seat disc or seat O-ring

Damaged guide holding check open

DRAFT

Damaged guide holding check open

Weak or broken spring

DRAFT

Weak or broken spring

Chatter during flow conditions

DRAFT

Chatter during flow conditions

Worn, damaged or defective guide

DRAFT

Worn, damaged or defective guide

Add-on and Retroﬁt Sensor Connection Kits for Building Management Systems

ORDERING CODE ADD-ON/REPLACEMENT KIT DESCRIPTION

88009418 FP-BF-BMS-1/2-10

BMS Sensor Connection Kit

Series LF919-FS

Sizes ½" to 2"

Includes sensor activation module with cable, power adapter,

and ground wire. Use this kit to activate the integrated flood

sensor and enable flood detection capabilities on the relief

valve of a new installation in a BMS configuration.

88009423 FP-RFK-BF-BMS-CFS-1/2-2

BMS Sensor Retrofit Connection Kit

Series LF919

Sizes ½" to 2"

Includes flood sensor (2), sensor activation module with cable,

power adapter, and ground wire. Use this kit to add flood

detection capabilities to the relief valve of an existing installation

in a BMS configruation.

Add-on and Retroﬁt Sensor Connection Kits for Cellular Communication

ORDERING CODE ADD-ON/REPLACEMENT KIT DESCRIPTION

88009420 FP-BF-CFS-1/2-10

Cellular Sensor Connection Kit

Series LF919-FS

Sizes ½" to 2"

Includes sensor activation module with cable, Cellular Gateway

with mounting kit, power adapter, and ground wire. Use this kit

to activate the integrated flood sensor and enable flood detection

capabilities as well as e-mail, text, and voice notifications.

88009424 FP-RFK-BF-CFS-1/2-2

Cellular Sensor Retrofit Connection Kit

Series LF919

Sizes ½" to 2"

Includes flood sensor (2), sensor activation module with cable,

Cellular Gateway with mounting kit, power adapter, and ground

wire. Use this kit to add flood detection capabilities to the relief

valve of an existing installation and enable e-mail, text, and voice

notifications.

Limited Warranty: Watts (the “Company”) warrants each product to be free from defects in material and workmanship under normal usage for a period of one year from the date of original shipment.

In the event of such defects within the warranty period, the Company will, at its option, replace or recondition the product without charge.

THE WARRANTY SET FORTH HEREIN IS GIVEN EXPRESSLY AND IS THE ONLY WARRANTY GIVEN BY THE COMPANY WITH RESPECT TO THE PRODUCT. THE COMPANY MAKES NO OTHER

WARRANTIES, EXPRESS OR IMPLIED. THE COMPANY HEREBY SPECIFICALLY DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for breach of warranty, and the Company shall not be responsible for any incidental, special

or consequential damages, including without limitation, lost profits or the cost of repairing or replacing other property which is damaged if this product does not work properly, other costs resulting

from labor charges, delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions, chemical, or any other circumstances over which the Company has no

control. This warranty shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or alteration of the product.

Some States do not allow limitations on how long an implied warranty lasts, and some States do not allow the exclusion or limitation of incidental or consequential damages. Therefore the above

limitations may not apply to you. This Limited Warranty gives you specific legal rights, and you may have other rights that vary from State to State. You should consult applicable state laws to

determine your rights. SO FAR AS IS CONSISTENT WITH APPLICABLE STATE LAW, ANY IMPLIED WARRANTIES THAT MAY NOT BE DISCLAIMED, INCLUDING THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO ONE YEAR FROM THE DATE OF ORIGINAL SHIPMENT.

USA: T: (978) 689-6066 • Watts.com

Canada: T: (888) 208-8927 • Watts.ca

Latin America: T: (52) 55-4122-0138 • Watts.com

DRAFT

power adapter, and ground wire. Use this kit to add flood

DRAFT

power adapter, and ground wire. Use this kit to add flood

detection capabilities to the relief valve of an existing installation

DRAFT

detection capabilities to the relief valve of an existing installation

in a BMS configruation.

DRAFT

in a BMS configruation.

Add-on and Retroﬁt Sensor Connection Kits for Cellular Communication

DRAFT

Add-on and Retroﬁt Sensor Connection Kits for Cellular Communication

DRAFT

DESCRIPTION

DRAFT

DESCRIPTION

Cellular Sensor Connection Kit

DRAFT

Cellular Sensor Connection Kit

Series LF919-FS

DRAFT

Series LF919-FS

Sizes ½" to 2"

DRAFT

Sizes ½" to 2"

Includes sensor activation module with cable, Cellular Gateway

DRAFT

Includes sensor activation module with cable, Cellular Gateway

with mounting kit, power adapter, and ground wire. Use this kit

DRAFT

with mounting kit, power adapter, and ground wire. Use this kit

to activate the integrated flood sensor and enable flood detection

DRAFT

to activate the integrated flood sensor and enable flood detection

capabilities as well as e-mail, text, and voice notifications.

DRAFT

capabilities as well as e-mail, text, and voice notifications.

FP-RFK-BF-CFS-1/2-2

DRAFT

FP-RFK-BF-CFS-1/2-2

Cellular Sensor Retrofit Connection Kit

DRAFT

Cellular Sensor Retrofit Connection Kit

Series LF919

DRAFT

Series LF919

Sizes ½" to 2"

DRAFT

Sizes ½" to 2"

Includes flood sensor (2), sensor activation module with cable,

DRAFT

Includes flood sensor (2), sensor activation module with cable,

DRAFT

This manual suits for next models

Table of contents

Other Watts Control Unit manuals

Watts

Watts 775 Series Installation and user guide

Watts

Watts 007 Series Instruction Manual

Watts

Watts AMES 920GD-01-15 User manual

Watts

Watts 1717 User manual

Watts

Watts LFM110-AS Owner's manual

Watts

Watts AMES 960GD-15-17 Installation and operating instructions

Watts

Watts AMES Deringer 20G User manual

Watts

Watts tekmar tekmarNet 2 User manual

Watts

Watts LF919 User manual

Watts

Watts AMES 930GD-01 User manual

Watts

Watts Series 709 User manual

Watts

Watts LFM115-74 Owner's manual

Watts

Watts LFM113-29 Installation and operating instructions

Watts

Watts LFM110-10 User manual

Watts

Watts LFU5B-Z3 User manual

Watts

Watts LFM513-AK Installation and operating instructions

Watts

Watts Ames 986GD User manual

Watts

Watts 980GD-16-19 User manual

Watts

Watts bar PZDS Operational manual

Watts

Watts Ames 910GD-17 Owner's manual

Watts

Watts AMES 2000SS Series Operating instructions

Watts

Watts Ames 920GD-15 Owner's manual

Watts

Watts 957 Series User manual

Watts

Watts Lync DigiTemp Jr V23 User manual

Popular Control Unit manuals by other brands

ADTRAN

ADTRAN Octal E&M user manual

Woodward

Woodward easYgen-1000 Applications manual

Eclipse

Eclipse 200 LT Series instruction manual

KSB

KSB ECOLINE GTF Series operating manual

Kitz

Kitz SGE Operation manual

Ross

Ross HBB Series operating instructions

PNI

PNI ECH01 user manual

Siemens

Siemens SINUMERIK 828D Turning Function manual

Pilz

Pilz mc1p coated operating instructions

Campbell

Campbell CR10 PROM Operator's manual

APARIAN

APARIAN A-TSM user manual

HF HF-BL200A user manual

Harman

Harman AMX HPX-AV102-MDP-R quick start guide

artisan

artisan ITC8 Series Operation manual

ELCOM

ELCOM TBM-300 Operating and assembly instructions

Campbell

Campbell TEMP 120 product manual

Smartgen

Smartgen CMM365A-2G user manual

Mitsubishi

Mitsubishi MELSEC-A user manual

Watts LF919-QT-FS Operating instructions

Popular Control Unit manuals by other brands
