Wave ION-Z Parts list manual

INSTRUCTION &
USAGE MANUAL
100%*watersavingwith
AquaReviveTechnology

20 years of professional experience
in water purifier manufacturing.
www.wavero.com

2. Purification Stages (ION-Z) 2
6. Product Specification (5G-PRO) 7
15. Troubleshooting (PRIME+) 18
10. Troubleshooting (5G-PRO) 12
7. Purification Stages (5G-PRO) 8
1. Product Specification (ION-Z) 1
4. Instructions to use (ION-Z) 4-6
12. Purification Stages (PRIME+) 14
18. New Series of Wave Water Purifiers 21
5. Troubleshooting (ION-Z) 6
13. Panel Overview (PRIME+) 15
CONTENT
14. Instructions to use (PRIME+) 16-18
9. Instructions to use (5G-PRO) 10-12
17. Certified Components 20
11. Product Specification (PRIME+) 13
3. Panel Overview (ION-Z) 3
8. Panel Overview (5G-PRO) 9
16. Steps of Installation 19

1
Application Types: Table Top/ Wall Mounting
Finger Touch Display Panel
Available In Two Models:
1.Water purifier with RO Membrane
2.Water purifier with Ultra Filtration (for TDS less than 300 PPM)
Water Source Indicator on Display Screen
Easy to Replace 2-in-1 Pre- Filter Cartridge
Fruits & Vegetables Detoxifier through Ozone Generator
Japanese titanium plates which delivers a range of pH (4,5,7,9,11)
Child Safety Lock for Safe Water Dispensing
TDS & pH Display on the panel
Intelligent Membrane Flushing System
Input Power Supply – AC 220 Volt
SMPS DC Power Supply 24 Volt 1.7 Amp
Inbuilt 7 Ltrs. Pure Water Storage Tank
LED Screen to monitor machine status like Tank Full, Auto Flushing
Purification etc.
Power Consumption: Ionizer 150w max when in use.
Ozone Generator (5 W), RO (30 W)
RO Booster Pump 24 Volt 75 GPD
75 GPD RO Membrane
Automatic Dry Run Protection Switch
Dimensions: (W) 20" x (H) 16" x (D) 11"
Pre- Filter Cartridge Change Indicator on Display Screen
5 stage filtration along with ionizer – 2 in 1 pre filter, carbon filter, RO/UF
membrane and UV sterilised lamp.
Electronic Water Level Control Switch
PRODUCT SPECIFICATIONS - ION - Z

2
PURIFICATION STAGES
Stage 1: Built in smart Pre-filtration, a combined filtration of Polypropylene and five- micron CTO
filter. Polypropylene filter removes dirt, impurities, rust, slime, sand and grit.
Stage 2: CTO removes Chlorine and odour. A CTO filter will produce water that is much clearer in
colour with a more appealing taste.
Stage 3: Coconut shell Activated Carbon filter is a method of filtering water that uses Activated
Carbon Granules to remove contaminants and impurities using chemical absorption. Each
Granule of carbon provides a large surface area allowing contaminants the maximum possible
exposure to the active sites within the filter media, so that the water becomes sweeter in taste.
Stage 4: RO Membrane is a water treatment process that removes contaminants from water by
using pressure to force water molecules through a semipermeable membrane, which is 0.001
micron thick. It can effectively filter the small organic matter and other contaminants which are then
filtered out and flushed away, leaving you with clean and delicious drinking water.
Stage 5: UV Disinfecting our water with Ultraviolet light is exceptionally simple, effective and
environmentally safe. UV in the tank can kill up to 99.99% of harmful microorganisms without
adding chemicals or changing the taste or odour of the stagnant pure water in the tank. It also does
not let the harmful viruses or bacteria grow in our pure water tank. This makes the taste and colour
of the water remain unaltered.
Stage 6: Ionizer Chamber The Japanese titanium plates delivers the variants of pH with the help
of electrolysis process.
PURIFICATION STAGES - ION - Z
2- IN- 1 PRE-FILTER
SEDIMENT &
CARBON BLOCK
BOOSTER
PUMP
RO/ UF MEMBRANE
PRE-ACTIVATED
CARBON
LED UV INSIDE THE
WATER STORAGE TANK
IONIZER
CHAMBER
FLOAT VALVE

3
PANEL OVERVIEW - ION - Z
Full Source Service
Auto Flush
DETOXIFIER
TDS
CHILD LOCK
Filter
PP
Purifying
• Tank Full Indication
• Purifying Indication
• Service Indication
• Source Water Indication
• Auto Flush Indication
• Acidic Water
• Water pH Level
• Fruits & Vegetables Detoxifier
Pre-Filter Indication
High Alkaline Water
Pure Water TDS
Child Lock for
Safe water dispensing
•
•
•
ON/OFFHIGH
ALKALINE ACIDIC WATER
LOW
ALKALINE
ON/OFF
PURIFIED WATER
TDS
pH
• Purified Water
Low Alkaline •
•
ION - Z

Acidic Alkaline
pH Scale
0-6 Acidic
7 Neutral
8-14
NOTE: The same machine can be switched to an Ultra Filtration Water Purifier by simply installing
an Ultra Filtration (UF) Membrane when the raw water TDS is less than 300 ppm.
INSTRUCTIONS - ION - Z
HOW TO START
1. Switch on the power supply, the auto flushing procedure will begin,
making its 'Auto Flush' sign blink for 15 seconds. The same procedure
will be followed every hour for 15 seconds to clean up the membrane
automatically.
3. As soon as the water storage tank fills up. the ' Tank Full' sign on the
panel will keep blinking.
2. 'Purifying' sign will blink repeatedly until water tank is filled up. It
usually takes about 20 minutes to fill up the storage tank.
4. Inbuilt 2-in-1 Pre-filter cartridge can be changed whenever needed
only after switching off the machine. Do not open filter housing while
the machine is on.
Full
Auto Flush
Purifying
Full
Purifying
4

HOW TO DISPENSE WATER
Note : 1. This is an approximate pH value shown on the display panel.
4. To dispense acidic water press the “Acidic water” button on the top
right corner of the panel.
3. Touch the white coloured Ambient button on the right side centre to
get normal water and touch the same to stop.
2. To dispense High Alkaline water, simply touch the “High Alkaline”
button on the top left corner of the panel touch the same to stop
dispensing.
NOTE: if you have selected low pH level option for dispensing then the
machine will dispense high acidic water when you choose to dispense
acidic water. This theory will be reversed if you have selected the high
alkaline option for dispensing.
1. To dispense low alkaline water, touch the child lock button on the
bottom left corner and then touch the “Low Alkaline” button above the
child lock button touch the same “Low Alkaline” button to stop
dispensing.
2. Dispense Acidic Water twice a day for a longer life of Titanium
plates.
3. Please maintain the TDS between 50 to 150 for Ionizer to
give better results.
HOW TO DISINFECT FRUITS & VEGETABLES
3. When the service sign blinks on the panel, please call the
technician for service.
NOTE: The source tank indication will only blink when the source
water storage tank is empty.
1. Dip Fruits & Vegetables fully in a bowl filled with tap water and dip in
the ceramic ball of ozone air pipe in the bowl. Touch the Detoxifier
button at the bottom right corner of the panel. You can stop the
detoxification process manually by touching the same button again or
it will automatically get turned off after 15 mins.
2. PP filter sign will blink after 400 working hours. This indicates the
need to replace the pre- filter.
LOW
ALKALINE
HIGH
ALKALINE
ON/OFF
ACIDIC WATER
ON/OFF
AMBIENT WATER
DETOXIFIER
Filter
PP
Service
DETOXIFIER
Filter
PP
Source
5

TROUBLESHOOTING - ION - Z
Faults POSSIBLE CAUSE SOLUTION
The pump does not start
with inlet water.
The pump started normally
but no pure water is
produced.
The pump head is leaking.
Pump starts & stops when
the machine is started.
When pure tank is full, but
the machine is not
dispensing normal.
The machine is shut down
after filling the tank, but
waste water is running
continuously.
When the water tank is full
but pump is running
continuously.
Not producing Ozone gas. Ozone air pump is not working. Replace ozone assembly unit.
The power water level switch
is not working. Replace water level switch.
Inlet solenoid valve is not working. Replace the Inlet solenoid valve.
Normal water solenoid
valve is not working. Replace solenoid valve.
1. Insufficient raw water pressure.
2. Pre- filter cartridge may be
choked.
1. Fill up source water tank.
2. Replace the pre-filter
cartridge.
1. One of the filters is blocked or
air vacuum in the pipeline.
2. The reverse osmosis membrane
is blocked.
3. The pump is out of pressure.
1. The rubber seal between the
pump heads is aging.
1. Repair or replace the pump
head.
1. Replace the filter or release
air into the pipeline.
2. Replace RO membrane.
Replace the pump.
1. Insufficient raw water pressure.
2. The power (fuse) is burnt out.
3. The Pump is damaged
1. Increase the raw water in the
source water tank.
2. Check fuse or replace it.
3. Replace the pump.
When you have selected the
Low alkaline/High Alkaline
option and the Panel
displays SF (Supply Failure)
The Ionizer chamber is not
working.
Please Call the Technician.
DETACHABLE DETOXIFIER - ION - Z
Wave RO Water Purifiers comes
wi th t he d et ac ha bl e o zo ne
generator that's highly effective in
disinfecting fruits and vegetables.
if machine will not be in use for more than 1-2 days.
NOTE: Make sure to switch off all the buttons,
6

7
Power Consumption: Cooling (110 W), Heating (2100 W when in use)
Ozone Generator (5 W), RO (30 W) in 5G- Max.
Power Consumption: Cooling (60 W), Heating (550 W when in use)
Ozone Generator (5 W), RO (30 W) in 5G- Pro.
Cold Water Storage: 0.8 ltrs in 5G-Pro.
Cold Water Storage: 1.2 ltrs in 5G-Max
LED Screen to monitor machine status like Tank Full, Auto Flushing
Purification etc.
Applications : Table Top / Wall Mounting/ Under The Counter
Water Source Indicator on Display Screen
TDS & Hot Water Temperature Display
Intelligent Membrane Flushing System after every hour.
4-in-1 Filter cartridge for Balanced pH, Minerals, Negative ORP & Hydrogen-
Rich Water. UV in the tank to protect stored water.
9 -Stage Filtration: PP, CTO, GAC, RO Membrane,
UV Steriliser lamp, Bio+ AA Alkaline, Minerals + Hydrogen + ORP Filter
UV Lamp in the storage tank
Available In Two Models:
1.Water purifier with RO Membrane
2.Water purifier with Ultra Filtration (for TDS less than 300 PPM)
Pre- Filter Cartridge Change Indicator on Display Screen
Easy to Replace 2-in-1 Pre- Filter Cartridge
75 GPD RO Membrane Sheet
SMPS DC Power Supply 24 Volt 1.7 Amp
Thermo Electric Water-Cooling System
Automatic Dry Run Protection Switch
RO Booster Pump 24 Volt 75 GPD
Electronic Water Level Control Switch
Input Power Supply – AC 220 Volt
PRODUCT SPECIFICATIONS - 5G - PRO/MAX

8
PURIFICATION STAGES
Stage 4: RO Membrane is a water treatment process that removes contaminants from water by using
pressure to force water molecules through a semipermeable membrane, which is 0.001 micron thick. It
can effectively filter the small organic matter and other contaminants which are then filtered out and
flushed away, leaving you with clean and delicious drinking water.
Stage 1: Built in smart Pre-filtration, a combined filtration of Polypropylene and five- micron CTO filter
Polypropylene filter removes dirt, impurities, rust, slime, sand and grit.
Stage 2: CTO removes Chlorine and odour. A CTO filter will produce water that is much clearer in
colour with a more appealing taste.
Stage 3: Coconut shell Activated Carbon filter is a method of filtering water that uses Activated Carbon
Granules to remove contaminants and impurities using chemical absorption. Each Granule of carbon
provides a large surface area allowing contaminants the maximum possible exposure to the active
sites within the filter media, so that the water becomes sweeter in taste.
PURIFICATION STAGES - 5G - PRO/MAX
2- IN- 1 PRE-FILTER
SEDIMENT &
CARBON BLOCK
BOOSTER
PUMP
RO/ UF MEMBRANE
PRE-ACTIVATED
CARBON
4-IN-1
MINERAL
CARTRIDGE
FLOAT VALVE
LED UV INSIDE THE
WATER STORAGE TANK

PANEL OVERVIEW - 5G - PRO/MAX
5G PRO
Full Source Service
Auto Flush
DETOXIFIER
TDS
CHILD LOCK
Filter
PP
Purifying
• Tank Full Indication
• Purifying Indication
• Service Indication
• Source Water Indication
• Auto Flush Indication
• Cooling ON/OFF
• Water Temperature
• Fruits & Vegetables Detoxifier
Pre-Filter Indication
Ambient Water
Dispense
Pure Water TDS
Child Lock for
Hot Water
•
•
•
ON/OFFHIGH
ALKALINE COOLING
HOT WATER COLD WATER
TDS
• Cold Water
Hot Water •
•
5G-PRO/MAX
°C
9

Stage 5: Alkaline: Alkaline water is used for drinking and cooking and provides consumers with
several important health benefits. Alkalizing restores pH balance by reducing acidity levels in the
body. It helps to neutralize free radicals that can cause cellular and DNA damage.
Stage 7: Hydrogen: Adding hydrogen in water helps turn our cell into " an antioxidant factory".
Drinking water with more hydrogen can give us more energy, slow the aging process and even
speedy muscle recovery after a workout.
Stage 6: Negative ORP: Water with a high pH has a higher amount of reducing agents and is
designated by Negative ORP. The ORP is responsible for the antioxidant value of the water and the
micro cluster that make alkaline water more hydrating.
Stage 8: Minerals: Filtered water removes acidic wastes and toxins out of the body at the cellular
level. It also supplies essential minerals such as Calcium, Potassium, Sodium and Magnesium to
the body improving health and increasing the metabolism of the body. Improved water quality make
water taste sweet and delicious.
Stage 9: UV: Disinfecting our water with Ultraviolet light is exceptionally simple, effective and
environmentally safe. UV in the tank can kill up to 99.99% of harmful microorganisms without
adding chemicals or changing the taste or odour of the stagnant pure water in the tank. It also does
not let the harmful viruses or bacteria grow in our pure water tank. This makes the tasted and colour
of the water remain unaltered.
Acidic Alkaline
pH Scale
0-6 Acidic
7 Neutral
8-14
NOTE: The same machine can be switched to an Ultra Filtration Water Purifier by simply
installing an Ultra Filtration (UF) Membrane when the raw water TDS is less than 300.
PURIFICATION STAGES - 5G - PRO/MAX
4- IN-1- HYDROGEN RICH ALKALINE CARTRIDGE
10

INSTRUCTIONS - 5G - PRO/MAX
HOW TO START
HOW TO DISPENSE WATER
2. 'Purifying' sign will blink repeatedly until water tank is filled up. It
usually takes about 20 minutes to fill up the storage tank. As soon as
the tank fills up the purifying sign will stop blinking.
4. Inbuilt 2-in-1 Pre-filter cartridge can be changed whenever needed
only after switching off the machine. Do not open filter housing while
the machine is on.
3. As soon as the water storage tank fills up the ' Tank Full' sign on the
panel will keep blinking.
1. Switch on the power supply, the auto flushing procedure will begin,
making its 'Auto Flush' sign blink for 15 seconds. The same procedure
will be followed every hour for 15 second to clean up the membrane
automatically.
NOTE: Once the cooling button is switched on, let the button be ON,
and keep dispensing cold water by using cold water button all the time.
It takes around 40 minutes to give 0.8 litre of cold water.
1. Turn on the cooling system by switching on the cooling button above
cold water button. To dispense cold water, touch the cold water button
below the cooling ON/OFF button touch the same to stop.
2. Touch the white coloured Ambient button on the top left corner to get
normal water and touch the same to stop.
3. Touch the Child Lock button at the bottom, left corner of the panel to
open lock & dispense hot water. Press the Hot Water button above to
dispense hot water and touch the hot water button to stop it.
Full
ON/OFF
AMBIENT
Auto Flush
Purifying
Full
ON/OFF
COOLING
Purifying
COLD WATER
HOW TO DISINFECT FRUITS & VEGETABLES
CHILD LOCK HOT WATER
2. PP filter sign will blink after 400 working hours. This indicates the
need to replace the pre- filter.
1. Dip Fruits & Vegetables fully in a bowl filled with tap water and dip in
the ceramic ball of ozone air pipe in the bowl. Touch the Detoxifier
button at the bottom right corner of the panel. You can stop the
detoxification process manually by touching the same button again or
it will automatically get turned off after 15 mins.
3. When the service sign blinks on the panel, please call the technician
for service.
NOTE: The source tank indication will only blink when the source
water storage tank is empty or has very less water.
DETOXIFIER
Filter
PP
Service
DETOXIFIER
Filter
PP
Source
11

DETACHABLE DETOXIFIER
Wave RO Water Purifiers comes with the
detachable ozone generator that's
highly effective in disinfecting fruits and
vegetables.
NOTE: Make sure to switch off all the buttons,
if machine will not be in use for more than 1-2 days.
TROUBLESHOOTING - 5G - PRO/MAX
Faults POSSIBLE CAUSE SOLUTION
The pump does not start
with inlet water.
The pump started normally
but no pure water is
produced.
The pump head is leaking.
Pump starts & stops when
the machine is started.
When pure tank is full, but
the machine is not dispensing
normal, cold & hot water.
The machine is shut down
after filling the tank, but waste
water is running continuously.
When the water tank is full
but pump is running
continuously.
Not producing Ozone gas. Ozone air pump is not working. Replace ozone assembly unit.
The power water level switch
is not working. Replace water level switch.
Inlet solenoid valve is not working. Replace the Inlet solenoid valve.
Dispensing water solenoid
valve is not working.
Replace dispensing solenoid
valves.
1. Insufficient raw water pressure.
2. Pre- filter cartridge may be
choked.
1. Fill up source water tank.
2. Replace the pre-filter
cartridge.
1. One of the filters is blocked or
air vacuum in the pipeline.
2. The reverse osmosis membrane
is blocked.
3. he pump is out of pressure.
1. The rubber seal between the
pump heads is aging.
1. Repair or replace the pump
head.
1. Replace the filter or release
air into the pipeline.
2. Replace RO membrane.
Replace the pump.
1. Insufficient raw water pressure.
2. The power (fuse) is burnt out.
3. The Pump is damaged
1. Increase the raw water in the
source water tank.
2. Check fuse or replace it.
3. Replace the pump.
Hot water is not dispensing
When the water tank is full
but pump is running
continuously.
1. The child lock is not open.
2. Hot water pump is not working
in 5G- Max model only.
1. Check switch On / Off Button.
2. Mother Board failure.
Check cooling unit power supply
and cooking fan and replace it if
not working.
1. Open Child lock first and then
touch hot water button.
2. Replace Hot Water pump.
12

13
Fruits & Vegetables Detoxifier through Ozone Generator
Finger Touch Display Panel
Application Types: Table Top/ Wall Mounting
Available In Two Models:
1. RO Machine with Membrane
2. RO Machine with Ultra Filtration (for TDS less than 400 PPM)
Easy to Replace 2-in-1 Pre- Filter Cartridge
Pre- Filter Cartridge Change Indicator on Display Screen
Water Source Indicator on Display Screen
4-in-1 Filter cartridge for Balanced pH, Minerals, Negative ORP & Hydrogen-
Rich Water
Child Safety Lock for Safe Water Dispensing
Inbuilt 7 Ltrs. Pure Water Storage Tank
Power Consumption:
Ozone Generator (5 W), RO (30 W)
LED Screen to monitor machine status like Tank Full, Auto Flushing
Purification etc.
TDS Display on the panel
Intelligent Membrane Flushing System
UV Lamp
Input Power Supply – AC 220 Volt
Automatic Dry Run Protection Switch
Dimensions: (W) 20" x (H) 16" x (D) 11"
9 -Stage Filtration: PP, CTO, GAC, RO Membrane,
UV Steriliser lamp, Bio+ AA Alkaline, Minerals + Hydrogen + ORP Filter
SMPS DC Power Supply 24 Volt 1.7 Amp
RO Booster Pump 24 Volt
75 GPD 75 GPD RO Membrane Sheet
Electronic Water Level Control Switch
PRODUCT SPECIFICATIONS - PRIME+

14
PURIFICATION STAGES - PRIME+
2- IN- 1 PRE-FILTER
SEDIMENT &
CARBON BLOCK
BOOSTER
PUMP
RO/ UF MEMBRANE
PRE-ACTIVATED
CARBON
4-IN-1
MINERAL
CARTRIDGE
LED UV INSIDE THE
SATER STORAGE
TANK
FLOAT VALVE
PURIFICATION STAGES
Stage 2: CTO removes Chlorine and odour. A CTO filter will produce water that is much clearer in
colour with a more appealing taste.
Stage 4: RO Membrane is a water treatment process that removes contaminants from water by using
pressure to force water molecules through a semipermeable membrane, which is 0.001 micron thick. It
can effectively filter the small organic matter and other contaminants which are then filtered out and
flushed away, leaving you with clean and delicious drinking water.
Stage 1: Built in smart Pre-filtration, a combined filtration of Polypropylene and five - micron CTO
filter Polypropylene filter removes dirt, impurities, rust, slime, sand and grit.
Stage 3: Coconut shell Activated Carbon filter is a method of filtering water that uses Activated Carbon
Granules to remove contaminants and impurities using chemical absorption. Each Granule of carbon
provides a large surface area allowing contaminants the maximum possible exposure to the active
sites within the filter media, so that the water becomes sweeter in taste.

15
PANEL OVERVIEW - PRIME+
Full Source Service
Auto Flush
ON/OFFON/OFF
DETOXIFIER
AMBIENT
TDS
LIGHT
CHILD LOCK
Filter
PP
Purifying
Prime +
• Tank Full Indication
• Purifying Indication
• Service Indication
• Source Water Indication
• Auto Flush Indication
• Power ON/OFF
• Fruits & Vegetables Detoxifier
Pre-Filter Indication
Ambient Water
Dispense
Pure Water TDS
Child Lock for
Safe Water dispensing
•
•
•
•

PURIFICATION STAGES - PRIME +
4- IN-1- HYDROGEN RICH ALKALINE CARTRIDGE
Stage 9: UV: Disinfecting our water with Ultraviolet light is exceptionally simple, effective and
environmentally safe. UV in the tank can kill up to 99.99% of harmful microorganisms without
adding chemicals or changing the taste or odour of the stagnant pure water in the tank. It also does
not let the harmful viruses or bacteria grow in our pure water tank. This makes the tasted and colour
of the water remain unaltered.
Stage 8: Minerals: Filtered water removes acidic wastes and toxins out of the body at the cellular
level. It also supplies essential minerals such as Calcium, Potassium, Sodium and Magnesium to
the body improving health and increasing the metabolism of the body. Improved water quality make
water taste sweet and delicious.
Stage 5: Alkaline: Alkaline water is used for drinking and cooking and provides consumers with
several important health benefits. Alkalizing restores pH balance by reducing acidity levels in the
body. It helps to neutralize free radicals that can cause cellular and DNA damage.
Stage 6: Negative ORP: Water with a high pH has a higher amount of reducing agents and is
designated by Negative ORP. The ORP is responsible for the antioxidant value of the water and the
micro cluster that make alkaline water more hydrating.
Stage 7: Hydrogen: Adding hydrogen in water helps turn our cell into " an antioxidant factory".
Drinking water with more hydrogen can give us more energy, slow the aging process and even
speedy muscle recovery after a workout.
Acidic Alkaline
pH Scale
0-6 Acidic
7 Neutral
8-14
NOTE: The same machine can be switched to an Ultra Filtration Water Purifier by simply
installing an Ultra Filtration (UF) Membrane when the raw water TDS is less than 300.
16

INSTRUCTIONS - PRIME+
HOW TO START
HOW TO DISPENSE WATER
1. Switch on the power supply, the auto flushing procedure will
begin, making its 'Auto Flush' sign blink for 15 seconds. The same
procedure will be followed every hour for 15 second to clean up the
membrane automatically.
2. 'Purifying' sign will blink repeatedly until water tank is filled up. It
usually takes about 20 minutes to fill up the storage tank.
3. As soon as the water storage tank fills up. the ' Tank Full' sign on the
panel will keep blinking.
4. Inbuilt 2-in-1 Pre-filter cartridge can be changed whenever needed
only after switching off the machine. Do not open filter housing while
the machine is on.
1. To dispense water simply touch the “Child Lock” button on the
bottom left corner of the panel and then touch “Ambient W ater” button
on the top left corner of the panel touch again the same button to stop
dispensing.
Full
Auto Flush
Purifying
Full
ON/OFF
AMBIENT
Purifying
HOW TO DISINFECT FRUITS & VEGETABLES
1. Dip Fruits & Vegetables fully in a bowl filled with tap water and dip in
the ceramic ball of ozone air pipe in the bowl. Touch the Detoxifier
button at the bottom right corner of the panel. You can stop the
detoxification process manually by touching the same button again
or it will automatically get turned off after 15 mins.
2. PP filter sign will blink after 400 working hours. This indicates the
need to replace the pre- filter.
3. When the service sign blinks on the panel, please call the
technician for service.
NOTE: The source tank indication will only blink when the source
water storage tank is empty.
CHILD LOCK
DETOXIFIER
Filter
PP
Service
DETOXIFIER
Filter
PP
Source
17
