1Introduction to the WMOi3: outstanding
assets
WMOi3 integrated modem provides a quick and easy way to plug in GSM
functionality to systems and terminals. Available in dual-band configurations, this
full type approved integrated modem constitutes a self-contained, fully integrated
implementation of the GSM standard.
Thanks to standard interfaces, it can be integrated into any system which offers
unlimited assets. It is ready for voice, SMS, data and fax. WMOi3 integrated
modem is a product with a sole connector, which puts together all the interface
signals in order to facilitate its integration.
It has an integrated SIM connector as well as a standard RF connector type MMCX
(Miniature Micro Connector).
For system integrators, WMOi3 is the fast track to the wireless world.
1.1 Scope of the user’s guide
This document describes the hardware interface and the technical specifications of
the WMOi3 integrated modem.
The integrated modem is referenced as WMOi3 according to the GSM 900
standard, the GSM 1800 standard and the GSM 1900 standard. This product is
based on a Dual Band WISMOTM: every integrated modem referenced WMOi3-
G900/1800 includes a GSM 900/1800 MHz module and every integrated modem
referenced WMOi3-G900/1900 includes a GSM 900/1900 MHz module. This two
dual-band modems have the same specifications unless otherwise specified.

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 8/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
1.2 General characteristics
1.2.1 General
•Dual Band GSM modem E-GSM 900/1800 or E-GSM 900/1900
•Class 4 (2W at 900MHz)
•Class 1 (1W at 1800/1900 MHz)
•Small size and low power consumption
•Voice, SMS
•fax and data transmission without extra hardware
•Tricodec (FR/EFR/HR)
•Internal 3V SIM interface
•Easy remote control by AT commands for dedicated applications
•Fully Type Approved according to GSM Phase 2+ specifications
•Fully shielded and ready-to-use
1.2.2 Electrical
•Power supply: 5 VDC +/- 5% 1A
•300 mA average in GSM 900 at Tx power max 2W
•9 mA in idle mode
1.2.3 Physical
•Absolute maximum dimension: 46 x 64 x 12 mm
•Weight: 90 g
•Volume: 36.21 cm3
•Casing: Complete shielding-stainless steel-
•Mounting: 4 screw holes
•Operating temperature range: -20°C to + 55°C
•Storage temperature: -35°C to +85°C
1.2.4 Basic Features
1.2.4.11.2.4.1 telephonytelephony
•Telephony (TCH/FS) & Emergency calls
•Full Rate, Enhanced Full Rate and Half Rate
•Dual Tone Multi Frequency function (DTMF)

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 9/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
1.2.4.21.2.4.2 Short Message ServiceShort Message Service
•Point to point MT & MO
•SMS Cell Broadcast
1.2.4.31.2.4.3 Data FeaturesData Features
•Data circuit asynchronous, transparent and non transparent up to 14,400
bits/s
•Automatic fax group 3 (Class 1 & 2)
•Alternate speech and fax
•MNP2, V.42bis
1.2.4.41.2.4.4 GSM Supplementary servicesGSM Supplementary services
•Call Forwarding
•Call Barring
•Multiparty
•Call Waiting and Call Hold
•Calling Line Identity
•Advice of Charge
•USSD
•Closed User Group
•Explicit Call Transfer
1.2.4.51.2.4.5 Other featuresOther features
•ME+SIM phone book management
•Fixed Dialling Number
•SIM Toolkit Class 2
•SIM, network and service provider locks
•Real Time Clock
•Alarm management
•Software upgrade through Xmodem protocol
•UCS2 character set management
1.2.5 Interfaces
Single antenna interface
Internal SIM interface: 3V only
External SIM interface: 3V only for engineering sample.
3V or 5V for production unit
For Data Operation:
RS-232C serial link
remote control by AT commands (GSM 07.07 and 07.05)
baud rate from 300 to 115,200 bits/s
from 300 up to 38400 bits/s with autobauding

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 10/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
1.3 Mechanical Design Overview
The WMOi3 integrated modem is encased as shown in the figure here-below. It
includes a WISMO™ module, a 50-pin connector, a SIM holder and a RF connector.
figure 1: mechanical description

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 11/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
figure 2: mechanical description II
4 screw holes allow the WMOi3 to be fixed on the mother PCB. The WMOi3 can
be mounted indifferently on both sides (top or bottom).
For further details see mechanical specifications in annex.

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 12/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
Note: Interfaces
The integrated modem has a sole 50-pin connector which gathers all the
interface signals in order to facilitate its integration.
It has an integrated SIM card holder as well as a standard RF connector type
MMCX (Miniature Micro Connector)
The concept of the integrated modem has been defined to integrate on a sole
device:
•only one standard easy to find connector (worldwide supplied) gathering
the analog and digital interfaces
•one standard easy to find RF connector. See chapter RF connector page
34
•one SIM card holder. See chapter SIM interface

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 13/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
2Safety precautions
IMPORTANTIMPORTANT
FOR THE EFFICIENT AND SAFE OPERATION OFFOR THE EFFICIENT AND SAFE OPERATION OF
YOUR GSM INTEGRATEDYOUR GSM INTEGRATED MODEMMODEM
READ THIS INFORMATION BEFORE USEREAD THIS INFORMATION BEFORE USE
2.1 RF safety
2.1.1 General
Your WMOi3 integrated modem is based on the GSM standard for cellular
technology. The GSM standard is spread all over the world. It covers Europe, Asia
and some parts of America and Africa. This is the most used telecommunication
standard.
Your modem is actually a low power radio transmitter and receiver. It sends out
and receives radio frequency energy. When you use your WMOi3 integrated
modem, the cellular system which handles your calls controls both the radio
frequency and the power level of your cellular modem.
2.1.2 Exposure to RF energy
There has been some public concern about possible health effects of using GSM
modems. Although research on health effects from RF energy has focused on the
current RF technology for many years, scientists have begun research regarding
newer radio technologies, such as GSM. After existing research had been
reviewed, and after compliance to all applicable safety standards had been tested,
it has been concluded that the product was fitted for use.
If you are concerned about exposure to RF energy there are things you can do to
minimize exposure. Obviously, limiting the duration of your calls will reduce your
exposure to RF energy. In addition, you can reduce RF exposure by operating your
cellular modem efficiently by following the below guidelines.
2.1.3 Efficient modem operation
For your modem to operate at the lowest power level, consistent with satisfactory
call quality :
If your modem has an extendible antenna, extend it fully. Some models allow you
to place a call with the antenna retracted. However your modem operates more
efficiently with the antenna fully extended.
Do not hold the antenna when the modem is « IN USE ». Holding the antenna
affects call quality and may cause the modem to operate at a higher power level
than needed.

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 14/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
2.1.4 Antenna care and replacement
Do not use the modem with a damaged antenna. If a damaged antenna comes
into contact with the skin, a minor burn may result. Replace a damaged antenna
immediately. Consult your manual to see if you may change the antenna yourself.
If so, use only a manufacturer-approved antenna. Otherwise, have your antenna
repaired by a qualified technician.
Use only the supplied or approved antenna. Unauthorized antennas, modifications
or attachments could damage the modem and may contravene local RF emission
regulations or invalidate type approval.

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 15/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
2.2 General safety
2.2.1 Driving
Check the laws and the regulations regarding the use of cellular devices in the area
where you have to drive as you always have to comply with them. When using
your modem while driving, please :
give full attention to driving,
pull off the road and park before making or answering a call if driving conditions so
require.
2.2.2 Electronic devices
Most electronic equipment, for example in hospitals and motor vehicles is shielded
from RF energy. However RF energy may affect some improperly shielded
electronic equipment.
2.2.3 Vehicle electronic equipment
Check your vehicle manufacturer representative to determine if any on-board
electronic equipment is adequately shielded from RF energy.
2.2.4 Medical electronic equipment
Consult the manufacturer of any personal medical devices (such as pacemakers,
hearing aids, etc...) to determine if they are adequately shielded from external RF
energy.
Turn your modem OFF in health care facilities when any regulations posted in the
area instruct you to do so. Hospitals or health care facilities may be using RF
monitoring equipment.
2.2.5 Aircraft
Turn your modem OFF before boarding any aircraft.
•Use it on the ground only with crew permission.
•Do not use it in the air.
To prevent possible interference with aircraft systems, Federal Aviation
Administration (FAA) regulations require you to have permission from a crew
member to use your modem while the aircraft is on the ground. To prevent
interference with cellular systems, local RF regulations prohibit using your
modem while airborne.
2.2.6 Children
Do not allow children to play with your modem. It is not a toy. Children could hurt
themselves or others (by poking themselves or others in the eye with the antenna,
for example). Children could damage the modem, or make calls that increase your
modem bills.

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 16/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
2.2.7 Blasting areas
To avoid interfering with blasting operations, turn your unit OFF when in a
«blasting area » or in areas posted : « turn off two-way radio ». Construction
crew often use remote control RF devices to set off explosives.
2.2.8 Potentially explosive atmospheres
Turn your modem OFF when in any area with a potentially explosive atmosphere.
It is rare, but your modem or its accessories could generate sparks. Sparks in such
areas could cause an explosion or fire resulting in bodily injuries or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly
marked. They include fueling areas such as petrol stations ; below decks on
boats ; fuel or chemical transfer or storage facilities ; and areas where the air
contains chemicals or particles, such as grain, dust, or metal powders.
Do not transport or store flammable gas, liquid, or explosives, in the compartment
of your vehicle which contains your modem or accessories.
Before using your modem in a vehicle powered by liquefied petroleum gas (such
as propane or butane) ensure that the vehicle complies with the relevant fire and
safety regulations of the country in which the vehicle is to be used.
2.3 Safety standards
THIS WMOi3 INTEGRATED MODEM COMPLIES WITH ALL APPLICABLE RF
SAFETY STANDARDS.
This cellular modem meets the standards and recommendations for the
protection of public exposure to RF electromagnetic energy established by
governmental bodies and other qualified organizations, such as the following :
Directives of the European Community, Directorate General V in Matters of Radio
Frequency Electromagnetic Energy
3Standard Compliance
3.1 GSM compliance
Reference regulations: TBR 19, TBR 20, TBR 31, TBR 32
Table 1 : Wavecom acceptance test
TestsTests Applied StandardApplied Standard Acceptance CriteriaAcceptance Criteria
Performance
Test ETSI recommendation for
GSM/DCS
communication.
Full conformity to the recommendation regarding the
main RF parameters.
Cooking Test -The test continues even after the Cooking Test milestone
has been reached
Stress Test Therma shocks IEC
68-2-14.
Full conformity to the recommendation regarding the
main parameters.

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 17/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
Vibration
Test
Sinusoidal vibration
IEC 68-2-6.
No performance degradation or mechanical degradation
is allowed after test.
Vibration
Test
Random vibration
IEC 68-2-36.
No performance degradation or mechanical degradation
is allowed after test.
Shock Test IEC 68-2-27. No performance degradation or mechanical degradation
is allowed after test.
Bump Test IEC 68-2-29. No performance degradation or mechanical degradation
is allowed after test.
Humidity
Test
Corrosion test IEC
68-2-3.
No visible degradation of the product, both visual and
functionnal.
The unit is tested at room temperature and must be fully
operative for the main RF parameters.
Warehouse
Test Low temperance IEC 68-2-1. Under normal condition (room temperature) after the test, the unit must behave in full conformity with the
main RF parameters specification.
Warehouse
Test
High temperature
IEC 68-2-2.
Under normal condition (room temperature) after the
test, the unit must behave in full conformity with the
main RF parameters specification.
Dust Test MIL-STD-810D,
method 510-3.
No visible dust in the visible areas. No more than 50
dust particules in the cabinet of the product. The unit,
tested at room temperature must be fully operative.
Light Test UV radiation and
temperature EDF
HN60E03.
Visual inspection on the discoloration and other
degradation effects such as cracks in the material of the
unit after the test.
Fall Test IEC 68-2-32.
Only minor casing degradation is allowed, with a
maximum dimension change of 1mm. The unit must
remain fully operative and full specification for the main
RF parameters.
Electro Static
Discharge
Test
IEC 1000-4-2. No performance degradation allowed after the test.
Salt Mist
Test IEC 68-2-11 After the test, visual inspection on the unit.
Atmosphere
Test Flowing mixed gas corrosion. IEC 68-2-
60
After the test, visual inspection on the unit and inside.
Marking
Test
EN 60 950 After the test, visual inspection on the unit. No
degradation is allowed on the marking.
3.2 FTA Compliance
The WMOi3 has received a Full-Type Approval (according to normal MS
requirements) in the configuration using the internal SIM interface.
3.2.1 IMEI Number
GSM 900/1800:
TAC: 5 000 64
FAC: 11
Serial Numbers: 000000 to 999999

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 18/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
GSM 900/1900:
TAC: 500 100
FAC: 11
Serial Number: 000000 to 999999
3.2.2 CE Label
The WMOi3 integrated modem is CE compliant which implies that the modem is
in conformity with the European Community directives and it bears the CE label
Carrying out tests:
Electro-magnetic field immunity
EN 61000-4-3
ETS 300-342—1
Radiated emission
EN 55022
ETS 300-342
ESD immunity
EN 61000-4-2
ETS 300-342-1

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 19/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
4Hardware Interfaces
This chapter describes the hardware interfaces:
•interfaces on the 50-pin general purpose connector
•RF interface
•SIM interface
4.1 Interfaces on the 50-pin general purpose connector
4.1.1 The 50-pin connector description
Table 2 : 50-pin connector description
Pin # Name I/O I/O type Description Comment
1GND GROUND High current
2GND GROUND High current
3+5V Supply High current
4+5V Supply High current
5CT109/DCD OCMOS/2X RS232-Data Carrier Detect
6GND GROUND High current
7GPIO4 I/O CMOS/2X General Purpose I/O
8SPK2N OAnalog Speaker2 negative output
9CT125/RI OCMOS/2X RS232-Ring Indicator
10 SPK2P OAnalog Speaker 2 positive output
11 Flashing LED I/O CMOS/2X Working mode indication
Led Driven by module
12 SPK1P OAnalog Speaker 1 positive output
13 CT106/CTS O1X RS232 interface Clear To
Send
14 SPK1N OAnalog Speaker 1 negative output
15 ON/~OFF IPower ON/OFF control ON = VCC(3)
16 MIC2P IAnalog Microphone 2 positive
input
17 AUXV0 IAnalog Auxiliary ADC input
18 MIC2N IAnalog Microphone 2 negative
input
19 ~RST IReset active low Open Collector
20 MIC1P IAnalog Microphone 1 positive
input
21 GND IGround
22 MIC1N IAnalog Microphone 1 negative
input
23 BOOT IBOOT Open Collector
24 GND GROUND High current
25 CT103/TX IRS232 interface - Transmit Pull up to VCC
(3)
with 100KΩwhen
not used

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential © 20/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
Pin # Name I/O I/O type Description Comment
26 GPIO0 I/O CMOS/2X General Purpose I/O
27 CT107/DSR O1X RS232 interface
Data Set Ready
28 CT104/RX O1X RS232 interface – Receive
29 CT108-2/DTR IRS232 interface
Data Terminal Ready Pull up to VCC
(3)
with 100KΩwhen
not used
30 CT105/RTS IRS232 interface
Request To Send Pull up to VCC
(3)
with 100KΩwhen
not used
31 COL3 I/O 1X Keypad column
32 COL4 I/O 1X Keypad column
33 COL1 I/O 1X Keypad column
34 COL2 I/O 1X Keypad column
35 ROW4 I/O 1X Keypad row
36 COL0 I/O 1X Keypad column
37 ROW2 I/O 1X Keypad row
38 ROW3 I/O 1X Keypad row
39 ROW0 I/O 1X Keypad row
40 ROW1 I/O 1X Keypad row
41 GND(1)
NC(2) GROUND(1) No Connected(2) High current
42 SPI_EN O1X SPI enable
43 SPI_IO I/O 1X I2 C Data or SPI Data
44 SPI_CLK O1X I2 C Clock or SPI Clock
45 SIMCLK O2X Clock for SIM Interface 3V mode
46 SIMRST O2X Reset for SIM interface 3V mode
47 SIMVCC OSIM card supply 3V mode
6mA max
48 SIMPRES1 ISIM card detect Connected to SIM
connector pin 8.
Pin 4 of SIM
connector must be
pulled down to
GND with 1 KΩ*
49 SIMDATA I/O 3X I/O for SIM interface 3V mode
50 GND(1),
GPO0(2)** See (1) and (2) High current
(1) for engineering sample
(2) for production unit.
(3) VCC = application digital power supply either 5V or 2.8V
*see SIM socket diagram 4.3 SIM interface
** GPO0 is a general purpose output for selection of external SIM 3V or 5V
