Webasto Thermo Top C Manual

Ident-Nr. 9000814B 5/2002
Operating and
maintenance instructions
Thermo Top C
Telestart
Thermo Top E
General information
Maintenance and safety instructions
Dear Webasto user
We presume that the principle and mode of operation of your new heater has been
explained to your complete satisfaction by the workshop / service centre which
installed the heater. This manual summarizes the main points of importance for using
the heaters Thermo Top C and Thermo Top E, as well as the handheld transmitter
Telestart T70/T80.
The water heaters Thermo Top C and Thermo Top E have been type-tested and
approved in accordance with Directives 2001/56/EC (heaters) and 72/245/EEC (EMC)
within the territory governed by European Directive 70/156/EEC.
The units must be installed in accordance with the enclosed installation instructions.
n
n
n
In filling stations and tank farms.
In places where explosive vapours or dust may build up
(e.g. near fuel, coal, wood dust or cereal stores).
In enclosed rooms (e.g. garages), not even via the timer
or Telestart.
n
n
be exposed to temperatures of more than 120 °C
(storage temperature), otherwise the electronics may
suffer permanent damage.
be operated without at least 20% brandname anti-freeze
in the water of the heating circuit.
The heater :must not be operated
Danger of explosion
and suffocation!
The heater must not:
D
!
Action in the event of faults
To cancel the fault interlock
If a fault occurs, check that the fuses and plug connections are in perfect condition
and secure.
When a fault occurs, the heater switches to the fault interlock; an error is not indicated
on the clock display.
Always try to cancel the fault interflock before calling a
Webasto service centre.
The following faults can be remedied directly by the user:
Please contact a Webasto service centre if the fault cannot be remedied in this way.
Interrupt power
supply by
removing the 20 A
fuse (yellow) in the
heater cable
harness
Interrupt power
supply by
removing the 20 A
fuse (yellow) in the
heater cable
harness
Refit the fuse Refit the fuse.
The heater
switches on
again.
Briefly press ON button
on transmitter on left or
press button on
timer
Note:
The heater switches on again when the fuse is refitted.
!
or
Wait
approx.
Wait
approx.
Wait
approx.
3s
3s 3s
Fault description Possible cause Remedy
Heater switches off
automatically
(= fault lock-out).
No combustion after
starting and restarting.
Flame goes out
during operation.
Heater does not switch on. Heater is without
electric power.
Check power supply
to heater and ground
connections.
Switch off heater and
switch on again
(not more than twice).
Heater switches off
during operation
(= fault lock-out).
Heater has overheated
due to lack of coolant.
Refill coolant as directed
by manufacturer.
ON
ON
1
2
3
SET
20
A
1
A
25
A
20
A
1
A
25
A
20
A
1
A
25
A
20
A
1
A
25
A
Webasto Thermosysteme International GmbH
Postfach 80 - D-82132 Stockdorf - Hotline [phone]
Hotfax (0395) 55 92-353 - http://www.webasto.de

Operation of the heater
The heater can be started via the timer or Telestart unit, depending on its configuration.
Before switching on the heater, the vehicle heating must be set to "warm". The heater
fan in the vehicle should be set to the 1st speed in the case of a 3-speed fan and to the
2nd speed in the case of a 4-speed fan. Fans with infinitely variable speed should be set
to at least 1/3 of the fan performance.
NOTE:
We recommend that the heating time be set in accordance with the driving time.
Heating time = driving time
Example: For a journey lasting approx. 20 minutes (one way), the duty period
should not exceed 20 minutes.
!
n
n
be operated with the fuel specified on the rating plate and
at the nominal voltage specified on the rating plate.
be taken out of operation by removing the fuse if smoke
develops, if unusual burning noises are heard or if there
is a smell of fuel. The heater must not be restarted until
the unit has been checked by personnel duly trained by
Webasto.
be operated for 10 minutes at least once per month, with
the engine cold and the fan set to the minimum setting.
The heater must be inspected by a specialist at the
beginning of the heating season or earlier.
n
nNon-compliance with the installation instructions and the
warnings contained therein will lead to the exclusion of all
liability by Webasto. The same also applies if repairs are
not undertaken by professionals or without using genuine
spare parts. This invalidates the type approval for the
heater and its homologation / EC type permit.
The heater must:
Liability:
G
Setting the duty period
Restore default setting
Check batteries
Press the ON or OFF button. or
Batteries LED Action
OK Lights up red
(heating) or green
(ventilation) for
0.5 seconds after
1 second
Low Flashes orange
for 3 seconds after
1 second
-
-
Heat batteries to over 0 °C
Replace batteries
as soon as possible
Empty Lights up orange
for 5 seconds after
1 second
-
-
Heat batteries to over 0 °C
Replace batteries
The next duty period is called up by
pressing the OFF button.
To save the setting:
No button pressed for 10 seconds or
press the ON button.
-
-
Simultaneously press both the ON and the OFF button for
approx. 10 seconds, until the LED goes out.
Default setting: Heating mode, 30 minutes.
If the optional summer / winter switch has been installed for the heater, it must be set in
accordance with the time of year. In this case, the heater will heat the interior of the
vehicle when set to the winter position and merely operate the vehicle fan to
ventilate the interior of the vehicle when set to the summer position .

The Webasto heaters – Thermo Top, Thermo Top T, Thermo Top C and Thermo Top E –
as well as the vehicle fan can be switched on and off under remote control from a
distance of up to 600 metres with the Webasto Telestart T70/T80.
A mode change must be made on the transmitter in order to switch on the vehicle fan
(ventilation of the vehicle).
The duty period after switching on via the transmitter is limited by the receiver. The
maximum range can be reached in open country. A shorter range must be expected in
built-up areas.
OFF OFF
ON ON
LED LED
NOTE:
A minimum distance of 2 metres must be maintained between the
handheld Telestart transmitter and the vehicle antenna
or
the antenna on the handheld transmitter must be shielded with the other
hand when
- learning the Telestart handheld transmitter,
- switching the heater on and off,
- switching the vehicle fan on and off.
!
Min. 2 m
Antenna
Telestart T70 Telestart T80
General
Learning the Telestart transmitter
Check mode
Change mode
Simultaneously press ON and OFF buttons twice within
one second.
The selected mode (heating or ventilation) is only set in the
receiver when the next signal is transmitted.
The LED changes colour when the buttons are pressed
for the second time and remains lit until the buttons are
released.
Press and hold ON and OFF buttons simultaneously.
LED lights up:
LED goes out:
when the buttons are released or
after 10 seconds.
Heating mode
Ventilation mode
red
green
=
=
-
-
2x
1.
2.
3.
4.
5.
Place batteries in the battery compartment of the transmitter.
Remove 1 A fuse (black) from the heater fuse holder (interrupt power supply).
Wait for at least 5 seconds.
Refit fuse in heater fuse holder and press OFF button on transmitter for
at least 1 second within the next 5 seconds.
Learning is complete.
A second or third handheld transmitter can be learned in the same way.
Min. 1 s
OFF
1A 1A
25A
15A1A
25A
15A1A
Min. 5 s Max. 5 s

Hold handheld transmitter with antenna pointing straight
upwards and press the ON button for 1 or 2 seconds.
NOTE:
In heating mode, the vehicle heating must be set to
"warm" before leaving the vehicle.
In both heating and ventilation modes, the vehicle fan
must be set to the 1st speed in the case of a 3-speed
fan and to the 2nd speed in the case of a 4-speed fan.
Fans with infinite adjustment must be set to at least
1/3 of the fan performance.
Via handheld transmitter:
Via timer:
Hold handheld transmitter with antenna pointing straight
upwards and press the OFF button for 1 or 2 seconds.
Press the direct heating button twice.
!
Switch heater or ventilation on
Switch heater or ventilation off
Check and set duty period
Check duty period
NOTE:
The duty period must be set to 20 or 30 minutes in heating mode for the
Thermo Top and Thermo Top T heaters.
The heating time should correspond to the driving time for Thermo Top C and
Thermo Top E heaters.
For instance, if the vehicle is used for driving to and from work.
We recommend that the duty period be set to 30 minutes for a journey lasting
approx. 30 minutes (one way).
The duty period of the heater or vehicle fan can be set on the transmitter in
10-minute increments. The duty period is set to 30 minutes as the manufacturer's default
setting.
NOTE:
The first flashing pulse output simultaneously with
the third actuation of the two buttons must also be
counted.
The LED flashes in accordance with the set duty period.
Simultaneously press the ON and OFF buttons three times
briefly in succession within one second.
Number of flashes
Duty period
1
10 min.
4
40 min.
2
20 min.
5
50 min.
3
30 min.
6
60 min.
3x
!
!
3-program timer
Direct heating Return Program selection Forward
Symbol
for set /
view time
Program
number
indication
Time
button
Heating
indication
Display illumination
General
Switching on
Set time
View time
Program start
of heating
Delete
program
Select
programmed
time
Switching off
1
2
3
SET
SET
SET
SET
SET
Note
changeover
from summer
to winter time
(and vice versa)
!
The time at which heating starts can be set precisely between
“1 minute" and "24 hours". Three switch-on times can be
programmed, but only one can be activated at any one time.
Maximum duty period: 60 minutes.
Manually: by pressing the direct heating button
Automatically: by preprogramming the time at which heating starts
The program number appears in the display and the
display lights up.
Manually: by pressing the direct heating button
Automatically: by limitation of the duty period.
The display lighting goes out.
Press the time button and then forward or back .
Press the time button .
Press button.
Within 10 seconds, press either forward until the time
at which heating is to start appears on the display.
If a different program number is required, press the button within
10 seconds in each case.
or back
Briefly press the button.
Press the button within 10 seconds in each case until the program
number with the required time is displayed.
