Weber Q 120 Guide

ELECTRONIC IGNITER MODULE
REPLACEMENT INSTRUCTIONS
1) Remove both of the ignition wires attached to the terminals
(1) on the ignition module.
2) Inside the front cradle assembly: Using a small screwdriver, apply
upward pressure to the bottom locking clip. At the same time
pulling the igniter module back and slightly up until the igniter
module begins to loosen from the cradle assembly.
TOOLS NEEDED:
3) While holding onto the igniter module, apply downward pressure to
the upper locking clip (on the opposite side of igniter module) until it
completely releases from the front cradle.
4) Replace with new igniter module. Make sure new igniter module is
securely snapped into the cradle assembly.
Follow steps in reverse order for compete installation.
5) Check the electronic igniter module for proper operation and spark
(should be able to hear a clicking noise and see a spark).
56308 01/15/08
2) Remove the battery and igniter
button from the front of the
ignition module by turning it
counter clockwise.
Bottom locking clip
Locking
Clips
THIS PROCEDURE SHOULD ONLY BE PERFORMED BY AN AUTHORIZED
WEBER-STEPHEN PRODUCTS CO. SERVICE TECHNICIAN
DANGER: BEFORE PERFORMING ANY WORK MAKE SURE THE GAS SUPPLY IS TURNED OFF AT THE SOURCE.
FAILURE TO FOLLOW DANGERS, WARNINGS AND CAUTIONS CONTAINED IN THIS INSTRUCTION SHEET MAY CAUSE A
FIRE OR AN EXPLOSION RESULTING IN SERIOUS PERSONAL INJURY OR DEATH AS WELL AS DAMAGE TO PROPERTY.
WARNING: GENUINE WEBER-STEPHEN REPLACEMENT PARTS MUST BE USED FOR ANY REPAIR OR REPLACEMENT.
YOUR ACTIONS, IF YOU FAIL TO FOLLOW THIS PRODUCT WARNING, MAY CAUSE A FIRE, AN EXPLOSION, OR
STRUCTURAL FAILURE RESULTING IN SERIOUS PERSONAL INJURY OR DEATH AS WELL AS DAMAGE TO PROPERTY.
(WILL VOID ALL WARRANTY PROTECTION.)
NOTE:The grills illustrated may have slight differences than the model purchased.
IMPORTANT NOTE: If it has been close to a year since
the battery was changed, this would be a good time to
replace it.

 WARNING: Make sure that all parts are assembled and hardware is fully tightened before operating the grill.Your
actions, if you fail to follow this Product Warning, may cause a fire, an explosion, or structural failure resulting in
serious personal injury or death as well as damage to property.
 WARNING: Make sure that all control knobs are turned to the OFF position before reconnecting the gas supply
and operating the grill. Your actions, if you fail to follow this Product Warning, may cause a fire, an explosion, or
structural failure resulting in serious personal injury or death as well as damage to property.
WEBER-STEPHEN PRODUCTS CO.
Customer Service Center
1890 Roselle Road, Suite 308
Schaumburg, IL 60195
1-800-446-1071 (USA ONLY)
www.weber.com®
 WARNING: All repairs to gas carrying, gas burning, ignition components or structural components
should be performed by a authorized Weber-Stephen Products Co. service technician.
These parts may be gas carrying, gas burning components, ignition components or structural components. Please contact Weber-
Stephen Products Co., Customer Service Department for Genuine Weber-Stephen Products Co. Replacement Part(s) information.
 WARNING: Do not attempt to make any repair to gas carrying, gas burning, igniter components
or structural components without contacting Weber-Stephen Products Co., Customer Service
Department. Your actions, if you fail to follow this Product Warning, may cause a fire, an explosion,
or structural failure resulting in serious personal injury or death as well as damage to property.
