WEBTEC FI750 Series User manual

FI750 Flow Indicators
user manual
Bedienungsanleitung
FI750 Durchussanzeiger
Manuel d’utilisation des FI750
Indicateurs de débit
Manual de usuario de los
indicadores de caudal FI750
www.webtec.com

English
Introduction
Flow Indicators are designed for continuous monitoring or intermittent use commissioning and servicing hydraulic systems up to 420 bar
(6000 psi). The large clear 63 mm (2.5”) diameter dial ensures that quick checks can be made to determine pump performance and setting
of ow control valves. They can be used on mobile and industrial hydraulic circuits, also lubrication and coolant systems using oil. These
direct acting ow indicators can be installed in hazardous areas or on applications where no power is available. The ow indicator design
ensures good reliability and minimises the effects of contamination.
The FI range of products is divided into two families:
1. FI750
2. FI1500
This manual covers the FI750 range of products.
Before rst operating the equipment read the whole of these instructions. Safety may be impaired if they are not followed.
Webtec have been designing and manufacturing ow meters and hydraulics components for over 50 years. We operate within a Quality
Management System that complies with the requirements of BS EN ISO 9001:2000 which is externally audited and certicated each year.
Beyond compliance to the standard, Webtec is committed to continually improving in everything we do; with particular emphasis on
understanding what matters to our customers and suppliers, and designing our systems and work to meet their needs. We are always keen
to hear from customers who may have special requirements not covered by our standard ranges
1

English
Basic operation
The ow indicator consists of a sharp edged
orice and tapered metering piston. The piston
movement is directly proportional to the ow
rate and the sharp edge orice minimises the
effects of viscosity. The piston is magnetically
coupled to the rotary pointer assembly which
registers on a clear 63 mm (2.5”) scale
displayed in lpm and USgpm. The FI750 ow
indicators should not be installed in circuits
where the ow is reversed.
See our RFI series for reverse ow capability.
2

English
Specication
lAmbient temperature: -10 to 50°C (14 to 122°F)
lFluid temperature:
Continuous: 20 to 80°C (65 - 176°F)
Intermittent use (less than 10 minutes) > 80 to 110°C (> 176 - 230°F)
lHumidity: 10 - 90 % RH
lFluid: see model conguration
lSeals: FKM as standard (EPDM available on request)
lAccuracy: 4% of full scale (calibrated at 28 cSt)
lPressure: 420 bar (6000 psi)
lFlow range: see model conguration
lDimensions: 146 x 74 x 49 mm (5.75” x 2.9” x 1.92”)
lWeight: Aluminium: 1.4 kg (3 lbs), Brass: 3.8 kg (8.4 lbs)
3

English
Installation guidance
The unit can be installed in any position, horizontal, vertical or anywhere in between. The unit is designed to panel mount or pipe mount.
When panel mounting ensure that rear and bottom faces of the unit are at least 12 mm (1/2”) from any ferrous material such as an iron panel
or base. The piston contains a magnet that can be affected by close proximity of ferrous material. The front face can be mounted directly to
ferrous panels. Two 9 mm (0.35”) diameter holes are provided for this purpose.
The indicator can be connected into pressure or return lines, however, do not reverse ow; the ow indicator may be damaged and will act
as a non return valve.
Problems are generally few but debris from contaminated oil sometimes adheres to the piston or lodges between the piston and seat. This
jams the piston partially open, causing the ow needle to fail to return to zero. For recalibration or repair please contact the service centre
listed on the rear cover of this manual. Care should be taken to ensure that the ow indicator is installed in a position which is not subjected
to excessive pulsation as this can cause incorrect readings. Connections can be by exible hoses or steel pipes.
For heavy-duty applications, for example installation close to a piston pump, consult the Webtec Products sales ofce.
4

Model conguration
English
FI750 16 A B O T
--
Flow range
16 0 - 16 lpm 0 - 4 USgpm
30 0 - 30 lpm 0 - 8 USgpm
60 0 - 60 lpm 0 - 16 USgpm
120 0 - 120 lpm 0 - 32 USgpm
180 0 - 180 lpm 0 - 48 USgpm
FI750 product type
* Pressure gauge ports follow main port - ‘B’ main port - 1/4” BSPP pressure port
‘S’ or ‘N’ Main port - 1/4” NPTF pressure port
** Units on ‘W’ uid type follow main port - Scale in litres for BSPP main ports
Scale in US gallons for main ports in UN or NPSF
Main ports threads*
‘B’ = 3/4” BSPP
‘N’ = 3/4” NPSF
‘S’ = 1-1/16” UN
#12 SAE ORB
Fluid type and units**
‘O’ = Oil in both Litres
and US gallons
‘W’= Water and Oil in either
Litres or US gallons
Temperature option
‘T’ = with temperature
‘ ‘ = no temperature
Body material
‘A’ = Aluminium
‘B’ = Brass
5

Models available as standard
English
FI 750-16-ABO
FI 750-30-ABO
FI 750-60-ABO
FI 750-120-ABO
FI 750-180-ABO
FI 750-16-ABOT
FI 750-30-ABOT
FI 750-60-ABOT
FI 750-120-ABOT
FI 750-180-ABOT
FI 750-16-ANO
FI 750-30-ANO
FI 750-60-ANO
FI 750-120-ANO
FI 750-180-ANO
Model number
FI 750-16-ANOT
FI 750-30-ANOT
FI 750-60-ANOT
FI 750-120-ANOT
FI 750-180-ANOT
FI 750-16-ASO
FI 750-30-ASO
FI 750-60-ASO
FI 750-120-ASO
FI 750-180-ASO
FI 750-16-ASOT
FI 750-30-ASOT
FI 750-60-ASOT
FI 750-120-ASOT
FI 750-180-ASOT
FI 750-30-BBW
FI 750-60-BBW
FI 750-120-BBW
FI 750-30-BBWT
FI 750-60-BBWT
FI 750-120-BBWT
FI 750-30-BNW
FI 750-60-BNW
FI 750-120-BNW
FI 750-30-BNWT
FI 750-120-BNWT
FI 750-120-BNWT
Webtec are always happy to hear from customers who have unique requirements please contact Webtec or your local distributor to discuss
your requirements
6

Technical Information
Typical pressure drop curves. Oil viscosity 25 centistokes. (1 bar = 14.5 psi, 10 lpm = 2.64 USgpm)
English
Flow (lpm)
Pressure Drop (bar)
10 20 30 40 50 60
0.2
0.4
0.6
0.8
1.0 FI 750 - 16 FI 750 - 30
FI 750 - 60
Flow (lpm)
Pressure Drop (bar)
30 60 90 120 150 180
2.0
4.0
6.0
8.0
FI 750 - 120
FI 750 - 180
Maintenance and service
For calibration please return the ow indicator to Webtec or your local distributor.
Calibration
The FI750 is calibrated at a mean viscosity of 28 cSt using ISO32 hydraulic mineral oil to ISO11158 category HM.
Recommended period between calibrations is 12 months. Maximum period between calibrations is 36 months. Unit accuracy may be affected by
operating cycle, uid condition or extended periods between recalibrations.
Accessories
Optional 63 mm (2.5”) diameter glycerine lled pressure gauge tted directly into a connection in the block or remotely connected by micro bore hose
and test point. External load valve to enable a system to be tested under load.
For accessories specications please consult Webtec or your local distributor. 7

English
2 Holes Ø9 (0.35) thro’
8 (0.31) typ
146 (5.75) 49 (1.93)
30 (1.18)
7 (0.28) typ
74 (2.91)
38.6 (1.52)
Installation
Dimensions in Millimetres (Inches)
8

Manufacturer’s Limited Warranty
Webtec Products Ltd. warrants to the original purchaser, for the period of one year from the date of purchase, that the product is free from defect in materials and workmanship. This warranty does not cover any part of
the product that has been damaged due to abuse or operation beyond the specications stated by Webtec Products Ltd. in the associated literature. Webtec Products Ltd. sole obligation under the warranty is limited
to the repair or the replacement of parts, at no charge, found to be defective after inspection by Webtec Products Ltd. or one of its divisions. Repair or replacement of parts will be at Webtec Products Ltd. discretion.
Authorisation from Webtec Products Ltd. is required before any product can be returned under warranty. Cost of shipping and handling is covered during the rst 12 months from the date of purchase. Webtec Products
Ltd. is not liable for any consequential damages or any contingent liabilities arising out of the failure of the product, component part or accessory. The above warranty supersedes and is in place of all other warranties,
either expressed or implied and all other obligation or liabilities. No agent, or representative or distributor has any authority to alter the terms of this warranty in any way.
Begrenzte Garantie des Herstellers
Webtec Products Ltd. garantiert an den Erstkäufer, über einen Zeitraum von einem Jahr ab Verkaufsdatum, dass das Produkt frei von Fehlern in Material und Verarbeitung ist. Diese Garantie erstreckt sich nicht auf Teile
des Produkts, welche durch Missbrauch, fehlerhafter Bedienung oder Bedienung über die Grenzen der Spezikationen (wie von Webtec Products Ltd in der Literatur angegeben) hinaus, entstanden sind. Die einzige
Verpichtung von Webtec Products Ltd. unter dieser Garantie, ist beschränkt auf die kostenlose Reparatur oder den Ersatz von Teilen, welche für defekt befunden wurden, nach einer Inspektion von Webtec Products
Ltd, oder einer ihrer Divisionen. Reparatur oder Ersatz von Teilen erfolgt nach Ermessen von Webtec Products Ltd. Eine Ermächtigung durch Webtec Products Ltd ist notwendig, bevor ein Produkt unter Garantie
retourniert werden darf. Versand-und Bearbeitungsgebühren sind, während den ersten 12 Monaten ab Verkaufsdatum, gedeckt. Nach 12 Monaten ab Verkaufsdatum sind Versand und Bearbeitungsgebühren nicht
durch die Garantie gedeckt. Webtec Products Ltd. ist nicht haftbar für Folgeschäden oder Folgekosten, welche durch einen Ausfall oder einer Fehlfunktion des Produkts, Zubehörs, Teile davon oder Komponententeile
entstehen könnten. Obige Garantie ersetzt und ist anstelle aller anderen Garantien, welche angeführt oder angedeutet wurden und anstelle aller anderen Verpichtungen und Verbindlichkeiten. Kein Wiederverkäufer,
Agent oder Distributor hat ein Recht die Konditionen dieser Garantie in irgendeiner Weise zu ändern.
Garantie limitée du fabricant
Webtec Products Ltd. garantit à l’acheteur original, pendant un an à compter de la date d’achat, que le produit est libre de tout défaut dans les matériaux ou défaut de fabrication. La présente garantie ne couvre aucune
partie du produit ayant été endommagée suite à tout usage abusif ou non conforme aux spécications formulées par Webtec Products Ltd. dans la documentation associée. La seule obligation de Webtec Products Ltd.
aux termes de la garantie est limitée à la réparation ou au remplacement, à titre gratuit, des pièces défectueuses après inspection par Webtec Products Ltd. ou l’une de ses divisions. La réparation ou le remplacement
des pièces est décidé à la discrétion de Webtec Products Ltd. Une autorisation de Webtec Products Ltd. est requise avant qu’un produit puisse être retourné sous garantie. Les frais d’expédition et de manutention sont
couverts pendant les 12 premiers mois à compter de la date d’achat. Webtec Products Ltd. n’est pas tenue pour responsable de tous dommages indirects et dénie toute responsabilité contingente qui résulterait de toute
panne du produit, de ses composantes ou de ses accessoires. La garantie annule et remplace toutes les autres garanties, explicites ou implicites, et toute autre obligation ou responsabilité. Aucun agent, représentant
ou distributeur n’est autorisé à modier de quelque façon que ce soit les conditions de la présente garantie.
Garantía limitada del fabricante
Webtec Products Ltd. garantiza al comprador original, por un período de un año a partir de la fecha de compra, que el producto carece de defectos de materiales y mano de obra. Esta garantía no cubre ninguna pieza
del producto que se haya dañado debido a abuso u operación fuera de las especicaciones indicadas por Webtec Products Ltd. en los folletos relacionados. La única obligación de Webtec Products Ltd. de acuerdo a
esta garantía se limita a la reparación o sustitución de piezas, sin cargo alguno, que se hallen defectuosas tras inspección por parte de Webtec Products Ltd. o una de sus divisiones. La decisión de reparar o sustituir
piezas será a discreción de Webtec Products Ltd. Antes de que se pueda devolver bajo garantía cualquier producto se requerirá autorización de Webtec Products Ltd. Está cubierto el coste de transporte y manipulación
durante los primeros 12 meses a partir de la fecha de compra. Webtec Products Ltd. no es responsable de ningún daño consecuencial ni de pasivos contingentes que se ocasionen debido al fallo del producto, de una
pieza componente o de un accesorio. Esta garantía anula y sustituye cualquier otra garantía, bien explícita o implícita, y cualesquiera otras obligaciones o responsabilidades. Ningún agente, representante o distribuidor
posee autoridad para modicar las condiciones de esta garantía de ninguna forma.

Certicate No.8242
Webtec reserve the right to make improvements and changes to the specication without notice.
Webtec behält sich das Recht vor, Verbesserungen oder Änderungen der Spezikationen ohne Ankündigung vorzunehmen.
Webtec se réserve le droit d’améliorer et de changer ses spécications sans préavis.
Webtec se reserva el derecho de realizar mejoras y cambios a las especicaciones sin previo aviso.
Designed and produced by Webtec - Entwickelt und hergestellt von Webtec - Conçu et produit par Webtec - Diseñado y producido por Webtec
FI750-MA-MUL-2274.pdf - FT10144 - Issue E - 01/17
