Version UM.G5.CDZ.174.FX6.E23 Manufactured under ISO 9001
USER MANUAL
DOOR DETECTOR CDZ SERIES
03.G5.CDZ.174.FX6
INSTALLATION INSTRUCTIONS
Ensure that both the receiver and the transmitter are at the same level.
Securely fix the transmitter and receiver to the car/car doors through the fixing
holes with the bolts provided, ensuring that the labels are pointing outwards.
Connect the power supply to the input terminals. Connect the output signals to the
output terminals.
Connect the cables from the receiver and the transmitter to the input terminals of the
door controller. Ensure both cables can be easily and smoothly bent. Tightly lock both
sides of the intermediate connectors.
Switch on the power.
The yellow LED in the receiver will light up.
The red LED in the receiver will light up when the light beams are interrupted.
1.
2.
Fix the power supply on the car top. Ensure that the steel cover is grounded.
3.
4.
5.
6.
[email protected] www.wecoeurope.com
· Keep connection cables away from high voltage and/or high current wires.
· Keep connection cables away from door motor and door drive.
· Avoid exposing the receiver (RX) lens to direct sunlight or other infrared sources.
· Prior to power-on, clean the lenses with a soft, damp cloth.
· Do not bend or twist the edges, and do not scratch the lenses.
PLANNED MAINTENANCE PROCEDURE
· Ensure that the yellow LED is lit (system functioning), then clean the lenses with a
soft, damp cloth.
· Check all plug and terminal connections.
· Perform a detection test by inserting an object greater than 50mm between the TX
and RX.
· The red LED status indicator will light to confirm object detection.
SAFETY INSTRUCTIONS
Neither LED in the receiver is lit.
Both the yellow and red LEDs of the door
detector are lit without interruption
between the RX and TX.
The plastic filter is too dirty.
Other infrared equipment is nearby.
The ambient light is stronger than allowed.
There is a system fault.
The LEDs of the door detector are lit
correctly when interrupted, but
the car door doesn’t open.
Wrong connection with NC/NO contacts.
The output relay is broken.
Check the wiring.
The green LED in the power supply
is not lit.
The power supply wires are broken or
incorrectly connected.
The terminal connection is too loose.
The power supply is broken and needs
to be replaced.
The cable is broken or not connected.
Power Supply LEDs Door Detector
LEDs in RX
Yellow
Power indicator
TROUBLESHOOTING
Red
Status indicator
POWER SUPPLY SETTING AND WIRING
Input voltage: 15-30VDC or 220VAC±15%, 50/60Hz
K4
AC
DC
RelayBJT
ON
OFF
K3
PNPNPN
Buzzer
K1
K2
1 2 3 45 6 7
K2
Select relay output
K3
Select transistor NPN or PNP output
K1
Select either AC or DC input
AC AC in DC DC in
K4
Select buzzer ON or OFF
ON Buzzer on OFF Buzzer off
NC NO
1
COM STATUS -AC/DC
2 3 4567
+
Output model
Relay output
Relay output
Transistor NPN
Transistor PNP
K1
AC
DC
DC
DC
K2
Relay
Relay
BJT
BJT
K3
N/A
N/A
NPN
PNP
ITEMS
Cables
Transmitter (TX)
Receiver (RX)
QTY
2 cables
1 piece
1 piece
ITEMS
Operation manual
Mounting accessories
Power supply
QTY
1 copy
1 set
1 piece
PACKING LIST
Please check if anything is missing
from the packing list.
Contents may vary slightly according
to the customers specific
requirements.
Transistor output model only works when 'DC in' is selected!
