Weco UPF Series User manual

Version UM.UPF
USER MANUAL
UPF SERIES DOOR DETECTOR

INSTALLATION INSTRUCTIONS
Please ask us about our range of fixings clips and brackets.
Ensure that both the receiver and the transmitter are at the same level.
Securely fix the transmitter and receiver to the car/car doors through
the fixing holes with the bolts provided, ensuring that the labels are
pointing outwards.
1.
2.
Connect the cables from the receiver and the transmitter to the input
terminals of the door controller.
Ensure that both cables can be easily and smoothly bent.
Tightly lock both sides of the intermediate connectors.
Switch on the power.
The yellow LED in the receiver will light up.
The red LED in the receiver will light up when the light beams are
interrupted.
3.
4.
5.

WIRING
· Keep connection cables away from high voltage and/or high current wires.
· Keep connection cables away from the door motor and door drive.
· Avoid direct sunlight or other infrared ingress to the receiver (RX).
· Prior to power-on, clean the lenses with a soft, damp cloth.
· Do not bend or twist the edges, and do not scratch the lenses.
PLANNED MAINTENANCE PROCEDURE
· Ensure that the yellow LED is lit (system functioning), then clean
the lense with a soft, damp cloth.
· Check all plug and terminal connections.
· Perform a detection test by inserting an object greater than 50mm
between the TX and RX.
· The red LED status indicator will light to confirm object detection.
NOTES AND ADVICE
DIRECT CONNECTION TO DOOR CONTROLLER
RX
TX
To door open
To power
supply
To diagnostic
COM2 (purple)
NC (orange)
COM1 (blue)
NC1 (green)
NO1 (yellow)
24V (red)
0V (black)
NO NC
NPN
PNP
Yellow to black
Green not connected
Blue is output
Green to black
Yellow not connected
Blue is output
Yellow to red
Green not connected
Blue is output
Green to red
Yellow not connected
Blue is output
1.
NPN & PNP WIRING
2.
Door Detector LEDs

Neither LED in the receiver is lit.
Both the yellow and red LEDs of the door
detector are lit without interruption
between the RX and TX.
The plastic filter is too dirty.
Other infrared equipment is nearby.
The ambient light is stronger than allowed.
There is a system fault.
The LEDs of the door detector are lit
correctly when interrupted, but
the car door doesn’t open.
Wrong connection with NC/NO contacts.
The output relay is broken.
Check the wiring.
The cable is broken or not connected.
TROUBLESHOOTING
ITEMS
Cables
Transmitter
Receiver
Operation manual
Mounting accessories
QTY
2 cables
1 piece
1 piece
1 copy
1 set
ITEMS
Cable clip
M3 spring washer
M3x25 bolt
M3 nut
M4 plastic washer
3x100mm cable tie
M4x10 self-drilling screw
QTY
6 pieces
10 pieces
10 pieces
10 pieces
10 pieces
20 pieces
8 pieces
PACKING LIST
DOOR DETECTOR SET PACKING LIST MOUNTING ACCESSORIES LIST
[email protected] www.wecoitaly.com
MADE IN P.R. CHINA
WARNING ADVICE
· This equipment should be installed only by qualified technicians.
· Please closely follow all instructions in this manual.
· Do not drill the PCB.
