Weco TINY-24 User guide

TINY Series
Water Engineering Corporation
Long Beach, CA U.S.A
1 [phone]
[email protected]
WECO Reverse Osmosis
Drinking Water Filter
System Manual
www.wecofilters.com

Inspect the System before Installation:
Please inspect the System and all connection fittings carefully, and make sure there is no damage
during shipping. If you find a damaged or broken part, please DO NOT proceed with the installation,
and contact us for a replacement, broken part or assistance via 1 [phone]
General Installation and Maintenance Requirements:
• Please make sure that the installation complies with State and local laws and regulations.
• Do not use with the water that is microbiologically unsafe or of unknown quality without
adequate disinfection before or after system.
• System must be installed indoor.
• It is recommended that installation of the water filter be done by a professional plumber.
Important !
1
TINY-SET-2
It is recommended to change the 2 pre-filters at least every
3-5 months. It is advised to change them on time to avoid any
damages to the RO System. It is advised to use WECO replacement
filters. Using ‘non-WECO’ and poor quality filters may clog the
RO system and will also damage the membrane.
Visit us on www.wecofilters.com or call us at 1 [phone]
TINY Manual
© 2017 Water Engineering Corporation

TINY Manual
© 2017 Water Engineering Corporation
2
CARBON
PRE-FILTER
SEDIMENT
PRE-FILTER
3rd Stage
MEMBRANE
AUTO SHUT-OFF
VALVE
ALKALINE OR
UV SYSTEMS ONLY
5th Stage Filter PRODUCT
WATER TANK
4th Stage Filter
2nd Stage 1st Stage
MAIN SUPPLY
WATER
FILTERED
WATER
BRINE
Feed Water
IN OUT
Product Water
Flow Restrictor Check Valve
INLET
Water supply adapter valve
Cold water shut-off valve
Auxiliary faucet
Garbage disposal
Carbon Filters
Drain Saddle
Storage tank with valve in open Position
Sediment Filter
Membrane
Inline GAC Filter
Alkaline/UV Filter (optional)
A
B
C
D
A
E
F
G
H
I
J
A
K
A
B
C
D
E
F
G
H
I
J
K
Reverse Osmosis System Tubing Diagram
Fig. #1

3
Water supply adapter valve
Cold water shut-off valve
Auxiliary faucet
Garbage disposal
Carbon Filters
Drain Saddle
Storage tank with valve in open Position
Sediment Filter
Membrane
Inline GAC Filter
Alkaline/UV Filter (optional)
CARBON
PRE-FILTER
SEDIMENT
PRE-FILTER
3rd Stage
GRO MEMBRANE
PUMP
ALKALINE OR
UV SYSTEMS ONLY
5th Stage Filter
PRODUCT
WATER TANK
4th Stage Filter
2nd Stage 1st Stage
MAIN SUPPLY
WATER
FILTERED
WATER
BRINE
Feed Water
Product Water
INLET
Low-Pressure
Switch
Inlet Water
Solenoid Valve
High-Pressure
Switch Flow Restrictor
Check Valve
A
B
C
D
E
F
G
H
I
J
K
A
B
C
D
F
G
H
I
J
K
E
Reverse Osmosis System Electric Booster Pump Tubing Diagram
Electrical Diagram
Fig. #2
Fig. #3
TINY Manual
© 2017 Water Engineering Corporation
Transformer
Solenoid
PUMP
110V-240V
AC
24V
DC
High-Pressure
Switch
Low-Pressure
Switch

4
CARBON
PRE-FILTER
SEDIMENT
PRE-FILTER
3rd Stage
GRO MEMBRANE
AUTO SHUT-OFF
VALVE
ALKALINE OR
UV SYSTEMS ONLY
5th Stage Filter PRODUCT
WATER TANK
4th Stage Filter
2nd Stage 1st Stage
MAIN SUPPLY
WATER
FILTERED
WATER
BRINE
Feed Water
IN OUT
PERMEATA
IN
PERMEATA
OUT
BRINE
OUT
Product Water
Flow Restrictor
Check Valve
INLETINLET
BRINE
IN
Water supply adapter valve
Cold water shut-off valve
Auxiliary faucet
Garbage disposal
Carbon Filters
Drain Saddle
Storage tank with valve in open Position
Sediment Filter
Membrane
Inline GAC Filter
Alkaline/UV Filter (optional)
Permeate Pump
L
L
Reverse Osmosis System Electric Diagram with Permeate Pump
Fig. #4
A
B
C
D
A
E
F
G
H
I
J
A
K
A
B
C
D
F
G
H
I
J
K
E
TINY Manual
© 2017 Water Engineering Corporation

Tapping into the cold water line
(Using the water supply adapter model FW 1)
Drilling the hole for the faucet
1. For best results, a ½” carbide-tipped drill bit should be used to drill a hole into your sink for the
auxiliary faucet.
2. Carefully select the faucet location making sure it will have a neat water fall pattern and that
the faucet stud will be accessible from below once the hole is completed.
3. For Porcelain Sink: Before starting the drill motor, apply firm downward pressure on the bit until
a crunching occurs. This will help keep the drill bit from moving.
4. For Stainless Steel Sink: Before using a ½” carbide drill bit, an indent should be made with a
center punch to keep the drill bit from moving. A small pilot hole will also aid the ½” drill bit.
5. For best results, keep steady firm pressure during the start of the hole will cause excess wear
on the bit and progress will be slow.
6. Once the hole is complete, clean the area of metal chips and roughness around the hole.
Metal chips will stain Porcelain.
5
NOTE: The drinking water system must be connected to the COLD
water supply only.
1. Turn off the cold water supply to the sink faucet
by locating the Round or oblong handle on the
right side of the sink cabinet and Turning clockwise
until the water supply is off.
NOTE: If the cold water shut-off valve fails to turn off the water, the
house water supply can be turned off at the main water supply.
2. The water supply adapter can be installed at the faucet Connection (A of Fig. #5) of the cold
water line or at the shut-off Valve connection (B of Fig. #5).
3. Disconnect the threaded nut at the connection and thread the water supply adapter, with
the flat washer in place, onto the connection and tighten. Connect the white tubing to the
water supply adapter with the treaded nut and tighten.
4. Thread the needle valve into the adapter tightly and turn the handle clockwise all the way in.
Turn on cold water supply to the sink faucet and check for leaks.
NOTE: Safety glasses should be worn to protect your eyes while drilling the faucet hole.
INSTALLATION INSTRUCTIONS
NEEDLE VALVE
WATER SUPPLY
ADAPTER
Fig. #5
TINY Manual
© 2017 Water Engineering Corporation

Mounting the faucet
Your unit comes complete with a long reach faucet.
Drain clamp installation
1. The drain clamp assembly should be installed above the trap and on the vertical or horizontal
tailpiece (Fig. #7)
6
NOTE: Air gap option installation instructions are available upon
request. The following instructions is for non-air gap option.
1. Slide chrome cover plate and rubber gasket onto
stem of faucet and place faucet onto sink with the
stem going through the hole.
2. Place metal washer and lock washer over threaded
stem of faucet and tighten nut from under the
counter surface to lock the faucet into place.
DO NOT OVER TIGHTEN.
3. Connect the blue tube to the faucet stem under
the counter and tighten.
Fig. #6
2. Mark the hole position on the pipe and drill a ¼” hole through one side of the pipe (Fig. #8).
Fig. #7
Fig. #8
Chrome Washer
Rubber Gasket
Star Lock Washer
Plastic Inlet Nipple
Plastic Sleeve
Compression Nut
Inlet Line
Brass Nut
Washer
Mount Drain
Saddleat Either
Location
Never
Mount
Here
TINY Manual
© 2017 Water Engineering Corporation

Positioning the system
1. The head assembly will stand up in the sink cabinet or can be hung on screws provided.
2. The storage tank may be laid on its side.
3. The head assembly and/or storage tank maybe placed up to 15 feet from the point of use
with nominal pressure loss.
7
3. Make sure to align drain saddle to drilled hole.
Attach drain clamp to drain pipe and tighten
the two screws evenly. (Fig. # 9)
NOTE: The center hole on the sponge must be removed.
4. Connect the Black tubing to the drain clamp.
Fig. #9
CONNECTING THE SYSTEM
Use the color coded tubing to make the following connections:
• The white tubing connects the water supply adapter to the inlet side.
• The blue tubing connects the faucet to the outlet side.
• The Black tubing connects to the drain clamps.
• Tha yellow tubing connects the storage tank to the inlet side of the post
carbon.
Fig. #10
TINY Manual
© 2017 Water Engineering Corporation

1. Check to see all connections are made
2. Check that the pre-filter and pre-carbon sumps are secure using the housing wrench provided.
3. Slowly turn on the water by turning the needle valve counterclockwise.
4. The valve handle on top of the tank should be in the open position, parallel to the valve body
5. The handle of the faucet should be perpendicular to the spigot (closed).
6. Check for leaks.
7. The RO/NF ro drinking water system makes 2 gallons of drinking water per hour and requires
1 to 2 hours before water is readily available.
8. During this initial fill period, you will hear water being discharged through the black drain line.
This is normal as the contaminated water is being rejected by the reverse osmosis membrane.
8
START-UP PROCEDURE
DO NOT DRINK THE WATER FROM THE FIRST TANK PRODUCED BY THE SYSTEM.
DISCHARGE THE WATER FROM THE STORAGE TANK BY OPENING THE FAUCET.
DISCHARGING MIGHT TAKE UP TO 15 MINUTES.
If you have any difficulties with the installation, or require additional information on your unit,
please consult with our factory technicians.
We thank you for purchasing our Reverse Osmosis / Nanofiltration unit for your high quality processed drinking
water. In order to maintain this high quality water, it is important that scheduled maintenance be followed.
To properly maintain your WECO drinking water system, please use
only genuine WECO water replacement filters at
www.wecofilters.com or call us at 1 [phone]
RECOMMENDED SYSTEM MAINTENANCE
TINY Manual

9
Sediment Pre-filter: The pre-filter protects the system and should be
maintained regularly, a clear housing has been provided for your
convenience. The show-white pre-Filter should be changed when the
outside discolors to a cardboard brown color and before the inner
surface discolors. The life of the pre- filter will depend upon the
condition of your water supply and should be checked at 3-month
intervals until a filter life is established (average life 6 months).
Carbon Block: Designed to remove chlorine form the water supply, as
well as organic and inorganic substance before entering the TFC
membrane (average life 12 months).
Post-Carbon: The post-filter should be changed
when you experience an unusual taste and/or
odor to the water and has a nominal life of
1 year.
Membrane: The high quality Thin Film
Composite membrane should last between
2 to 4 years depending on the quality of your
local water.
Drain your storage tank twice each month to extend the membrane and have the freshest water
in the storage tank. Drain the storage tank by lifting the faucet handle into the parallel position
with the spigot until water flow stops from the tank. Return the faucet handle to the closed position
and the tank will refill in 2 hours. It is best to drain the system before retiring for the evening.
TINY-24 R30-478 C2 T300-24-OMN GS-6RO -
TINY-36 R30-478 C2 T300-36-OMNI GS-6RO -
TINY-50 R30-478 C2 T300-50-OMNI GS-6RO -
TINY-150 R30-478 C2 T300-150-OMNI GS-6RO -
TINY-150UV R30-478 C2 T300-150-OMNI GS-6RO GL10SE4P
TINY-150ALK R30-478 C2 T300-150-OMNI GS-10CAL/RO -
TINY-150ALKUV R30-478 C2 T300-150-OMNI GS-10CAL/RO GL10SE4P
Reverse Osmosis Systems Replacement Cartridges
System Stage 1 Filter Stage 2 Filter Stage 3 Filter Stage 4 Filter Stage 5 Filter
TINY Manual
© 2017 Water Engineering Corporation

10
1. Turn OFF cold water supply to RO system. Turn OFF tank’s ball-valve. Lift up RO faucet lever
briefly to relief the built-up pressure inside the RO system. This will make opening the housings
easier.
2. Open housing: Have the RO standing upright. Slip the plastic wrench onto the #1 housing.
Looking down from a top view, you should open the housing turning clockwise. If necessary,
lay RO down on the floor to get a better leverage. If the housing is too tight, use a hammer
and tap on the wrench handle to help turn the wrench.
3. Discard 3 used filters, wash housings with mild soap, rinse off. Put 3 new filters into their
respective housings: sediment filter in stage-1, carbon block filters in stages 2 & 3.
4. Close up the housings. Make sure each housing has a black O-ring in the thread groves. Use
wrench to tighten each housing.
5. Remember: Turn ON the cold water supply and OPEN the tank valve after finished changing
filters!
6. Check for leaks!
CHANGING THE PRE-FILTERS
1. Shut off the feed water to the system by turning the saddle valve on the water supply adapter
clockwise until it stops.
2. Close the storage tank ball valve by turning the handle perpendicular to the valve body.
3. Open the drinking water faucet relive pressure.
4. Allow 3-5 minutes for pressure in the system to drop.
5. Disconnect the tubing from the membrane cap by pushing in and holding down the end
collar ring surrounding the quick connect elbow fitting while gently pulling back on the tubing.
6. Remove the membrane housing cap by turning counter-clockwise.
7. Using a pair of needle nose pliers, remove and discard the used membrane.
8. Rinse the inside of membrane housing with warm water.
9. Using pliers, insert the new membrane all the way into the housing (double o-ring end first),
making sure it is properly seated.
10. Replace and hand-tighten the membrane housing cap by turning clockwise.
11. Reconnect the removed tubing by pushing it into the elbow fitting in the housing cap.
12. Gently pull back on the tubing to insure a leak free connection.
CHANGING THE MEMBRANE
CAUTION: ANY REPLACEMENT FILTERS OR MEMBRANE NOT RECOMMENDED BY THE
FACTORY CAN CAUSE SEVERE DAMAGE TO THE SYSTEM AND VOIDS ALL WARRANTIES.
TINY Manual
© 2017 Water Engineering Corporation

11
OPERATING LIMITS
Max. TDS Water
Temperature pH Range Water Pressure
Standard
RO System
RO with
Booster Pump
2000 ppm 40 - 85 F 2 - 11 45 - 85 PSI
o
2000 ppm 40 - 85 F 2 - 11 45 - 85 PSI
o
TINY Manual
© 2017 Water Engineering Corporation
For replacements cartridges and accessories shop
CONTACT US
www.wecofilters.com
For questions and concerns, please feel free to
contact our support staff.
Phone: [phone]
Email: [email protected]
Water Engineering Corporation
1037 Stanley Ave, Long Beach,
CA 90804, USA
CUSTOMER SATISFACTION IS OF PRIMARY CONCERN,
PLEASE CALL IN THE EVENT THERE IS A SERVICE PROBLEM.
Notice: Your RO system has been thoroughly tested and inspected for production, rejection,
leaks and shut-off functions at our factory. Therefore, it might have some water in it.
Warning: Do not use this system if feed water has biological contamination or of unknown
source. For operating parameters, please contact our technical support department.

12
TINY Manual
© 2017 Water Engineering Corporation
This page is intentionally left blank

WECO TINY Series
Reverse Osmosis
Drinking Water Filter
System Manual
Water Engineering Corporation
Long Beach, CA U.S.A
1 [phone]
[email protected]
WECO
www.wecofilters.com
