Weider 9900i User manual

CAUT ON
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Model No. WEEVSY49810.0
Serial No.
Write the serial number in the
space above for reference.
Serial Number
Decal
USERʼS MANUAL
www.iconeurope.com
QUEST ONS?
If you have questions, or if there are
missing parts, please contact us:
UK
Call: 08457 089 009
From reland: 053 92 36102
Website: www.iconsupport.eu
E-mail: [email protected]
Write:
CON Health & Fitness, Ltd.
c/o H Group PLC
Express Way
Whitwood, West Yorkshire
WF10 5QJ
UK
AUSTRAL A
Call: 1-800-237-173
E-mail:
[email protected]

2
WARN NG DECAL PLACEMENT
TABLE OF CONTENTS
WARNINGDECA P ACEMENT ..............................................................2
IMPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
PARTIDENTIFICATIONCHART ..............................................................5
ASSEMB Y ...............................................................................7
ADJUSTMENT ...........................................................................34
WEIGHTRESISTANCECHART..............................................................37
CAB EDIAGRAM.........................................................................38
MAINTENANCE ..........................................................................39
EXERCISEGUIDE INES ...................................................................40
PART IST ..............................................................................43
EXP ODEDDRAWING ....................................................................45
ORDERINGREP ACEMENTPARTS ..................................................BackCover
This drawing shows the location(s)
of the warning decal(s). f a decal
is missing or illegible, see the
front cover of this manual and
request a free replacement
decal. Apply the decal in the
location shown. Note: The
decal(s) may not be shown at
actual size.
WEIDER is a registered trademark of ICON IP, Inc.

3
MPORTANT PRECAUT ONS
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. Use the weight system only as described in
this manual.
3. t is the responsibility of the owner to ensure
that all users of the weight system are ade-
quately informed of all precautions.
4. The weight system is intended for home use
only. Do not use the weight system in a com-
mercial, rental, or institutional setting.
5. Keep the weight system indoors, away from
moisture and dust. Do not put the weight
system in a garage or covered patio, or near
water.
6. Place the weight system on a level surface,
with a mat beneath it to protect the floor or
carpet. Make sure that there is enough clear-
ance around the weight system to mount,
dismount, and use the weight system.
7. nspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
8. Keep children under age 12 and pets away
from the weight system at all times.
9. The weight system should not be used by
persons weighing more than 300 lbs.
(136 kg).
10. Wear appropriate exercise clothes while
exercising; do not wear loose clothes that
could become caught on the weight system.
Always wear athletic shoes for foot protec-
tion.
11. Keep hands and feet away from moving
parts.
12. Always secure the weight stack with the lock
pin and the lock after exercising to prevent
unauthorized use of the weight system (see
LOCK NG THE WE GHT STACK on page 36).
13. Make sure that the cables remain on the pul-
leys at all times. f the cables bind while you
are exercising, stop immediately and make
sure that the cables are on the pulleys.
14. Always stand on the foot plate when per-
forming an exercise that could cause the
weight system to tip.
15. Never release the arms, leg lever, lat bar,
handle, ankle strap, or double strap while
weights are raised. The weights will fall with
great force.
16. Always disconnect the lat bar from the
weight system when performing an exercise
that does not require the lat bar.
17. Over exercising may result in serious injury
or death. f you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
WARN NG: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your weight system before using your weight sys-
tem. CON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.

4
Assembled Dimensions:
Height: 6 ft. 11 in. (211 cm)
Width: 4 ft. 1 in. (124 cm)
Depth: 7 ft. 1 in. (216 cm)
Shroud
High Pulley Station
ow Pulley Station
Ankle Strap
Double Strap
Right Side
Left Side
Backrest
Ab Station
at Bar
Weight
Weight Pin
eg ever
Cable Clip
Chain
Foot Plate
Seat
Butterfly Arm
Burn Band
BEFORE YOU BEG N
Thank you for selecting the versatile WEIDER®9900 I
weight system. The weight system offers a selection of
weight stations designed to develop every major mus-
cle group of the body. Whether your goal is to tone
your body, build dramatic muscle size and strength, or
improve your cardiovascular system, the weight sys-
tem will help you to achieve the specific results you
want.
For your benefit, read this manual carefully before
using the weight system. If you have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.
Press Handle
Handle
Note: The terms “right side” and “left side” are used relative to a person sitting on the seat; they
do not correspond to right and left on the drawings in this manual.

5
M10 Locknut (74)
M10 Washer (88)
12.7mm
Spacer (73)
M10 Curved
Washer (86)
14.8mm
Spacer (95)
6.35mm
Spacer (94)
M10 Jam Nut (99)M6 Locknut (87)
ST4.2 x 19mm
Screw (90)
M4 Locknut
(108)
PART DENT F CAT ON CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART IST near the end of this manual. MPORTANT: f you cannot
find a part in the hardware kit, check to see if it has been preassembled. To avoid damaging parts, do
not use power tools for assembly.
Continued on page 6

6
M10 x 95mm Bolt (78)
M10 x 68mm Bolt (66)
M10 x 57mm Bolt Set (80)
M10 x 93mm Bolt (63)
M10 x 45mm Bolt (98)
M10 x 97mm Bolt (100)
M10 x 125mm Bolt (83)
M10 x 130mm Bolt (11)
M10 x 65mm Bolt (75)
M10 x 47mm
Bolt (91)
M10 x 55mm
Bolt (79)
M10 x 57mm
Bolt (93)
M10 x 63mm Bolt (89)
M10 x 43mm Bolt (65)
M10 x 40mm Bolt (97)
M10 x 117mm Bolt (64)
M6 x 45mm Bolt (85)
M10 x 20mm
Screw (84)
M6 x 16mm
Screw (62)
M10 x 50mm
Button Bolt (76) M8 x 65mm Button Screw (82)
M
M4 x 12mm
Bolt (107)

7
ASSEMBLY
To make assembly easier, carefully read the
following information and instructions:
• Assembly requires two persons.
• Because of its weight and size, assemble the
weight system in the location where it will be
used. Make sure that there is enough clearance
to walk around the weight system.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until assembly is completed.
• For help identifying small parts, use the PART
IDENTIFICATION CHART on pages 5 and 6.
• The following tools (not included) may be required
for assembly:
two adjustable wrenches
one rubber mallet
one standard screwdriver
one Phillips screwdriver
Assembly may be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.
1.
Orient the Base (1) and the Side Stabilizers (2)
as shown.
Attach the Side Stabilizers (2) to the Base (1)
with two M10 x 95mm Bolts (78) and two M10
ocknuts (74). Do not fully tighten the
Locknuts yet.
1
1
2
78
78
74
74
Warning
Decal
2
To make assembly easier, read the
assembly tips in the box above.
2. Orient the U-stabilizer (3) and the Foot Plate (4)
as shown. Make sure that the textured side of
the Foot Plate is facing upward.
Attach the Foot Plate (4) to the U-stabilizer (3)
with two M8 x 65mm Button Screws (82). Do
not overtighten the Screws; the Foot Plate
must pivot easily.
2
82
82
3
4

8
3. Attach the U-stabilizer (3) to the Base (1) with
two M10 x 68mm Bolts (66), two M10 Washers
(88), and two M10 ocknuts (74).
3
88
88
3
74
74
1
4
4. Orient the Upright (5) as shown.
Attach the Upright (5) to the Base (1) and the
Side Stabilizers (2) with four M10 x 55mm Bolts
(79), four M10 Washers (88), and four M10
ocknuts (74). Do not fully tighten the
Locknuts yet.
74
5
74
74
1
2
2
79 79
88
88
66

9
5. Orient the eg (10) as shown.
Attach the eg (10) to the Base (1) with two
M10 x 55mm Bolts (79), two M10 Washers (88),
and two M10 ocknuts (74). Do not fully
tighten the Locknuts yet.
5
74
10
88
88
79
1
74
6
8
5
74
6. Orient the Seat Tube (8) as shown.
Attach the eg (10) to the Seat Tube (8) with
two M10 x 68mm Bolts (66), two M10 Washers
(88), and two M10 ocknuts (74). Do not fully
tighten the Locknuts yet.
Attach the Seat Tube (8) to the Upright (5) with
two M10 x 93mm Bolts (63), two M10 Washers
(88), and two M10 ocknuts (74). Do not fully
tighten the Locknuts yet.
See steps 1, 4, 5, and 6. Tighten the M10
ocknuts (74).
63
88
74
10
74
74
88
88
66

10
7. Apply some of the included grease to an M10 x
57mm Bolt Set (80).
Orient the eg ever (13) so that the high end of
the bracket is in the location shown.
Attach the eg ever (13) to the eg (10) with
the M10 x 57mm Bolt Set (80). Make sure that
the barrel of the Bolt Set is inserted through
both sides of the bracket on the Leg.
780
13
80
10
Grease
High
End
8
8. See the CABLE D AGRAM on page 38 to
identify the cables as you assemble them.
dentify the Burn Cable (45).
dentify the four Burn Pulleys (68), the three
V-pulleys (not shown), and the twenty
Pulleys (not shown).
Route the threaded end of the Burn Cable (45)
through the bracket on the Base (1) as shown.
Attach a Burn Pulley (68) over the Burn Cable
(45) inside the bracket on the Base (1) with an
M10 x 63mm Bolt (89), two 12.7mm Spacers
(73), and an M10 ocknut (74).
89
73
73
74
Threaded
End
1
68
45
9. Attach a second Burn Pulley (68) over the Burn
Cable (45) inside the bracket on the Base (1)
with an M10 x 63mm Bolt (89), two 12.7mm
Spacers (73), and an M10 ocknut (74).
9
89
73
73
74
1
68
45

11
10
31
Holes
10. Orient the Weight Guides (31) so that the indi-
cated holes are closer to the floor.
Insert the Weight Guides (31) into the holes in
the Base (1). Attach each Weight Guide with an
M10 x 63mm Bolt (89) and an M10 ocknut
(74).
89
74
74
1

12
11
11. Orient the Bottom Cover (28) so that the notch
is in the indicated location.
Slide the Bottom Cover (28) downward over the
Weight Guides (31) and the Burn Cable (45).
Make sure that the Burn Cable is routed as
shown and is inserted into the notch in the
Bottom Cover.
28
45
31
Notch
12. Make sure that the Burn Cable (45) is routed
as shown.
Attach the Bottom Cover (28) to the Base (1)
with two ST4.2 x 19mm Screws (90).
28
1
90
45
12

13
13. Slide a Bumper (40) onto each Weight Guide
(31).
Orient a Weight (30) so that the pin hole is in
the indicated location.
Then, slide the Weight (30) onto the Weight
Guides (31). Route the end of the Burn Cable
(45) upward through the center of the Weight.
Repeat these actions with the other eleven
Weights.
13
31
30
Pin Hole
40
45
14
14. Orient the Top Frame (6) and the Top Cover
(27) as shown. Slide the Top Cover onto the
Top Frame. 27
6
15. Attach the Top Frame (6) to the Upright (5) with
two M10 x 93mm Bolts (63), two M10 Washers
(88), and two M10 ocknuts (74). Do not fully
tighten the Locknuts yet.
15
5
63
63
88
74
6

14
16. Attach the Top Frame (6) to the Weight Guides
(31) with two M10 x 43mm Bolts (65), two M10
Curved Washers (86), and two M10 ocknuts
(74).
See step 15. Tighten the M10 ocknuts (74).
16
74
65 65
86 86
31
6
17. Note: For clarity, the Top Cover (27) is not
shown.
Route the Burn Cable (45) over two Burn
Pulleys (68).
Attach each Burn Pulley (68) to the right side of
the Top Frame (6) with an M10 x 40mm Bolt
(97) and an M10 ocknut (74).
17
6
68 68
74
45
97

15
18. Apply grease to an M10 x 130mm Bolt (11).
Identify the eft and Right Press Arms (17, 18)
and orient them as shown.
Insert the Press Arm Spacer (42) between the
eft and Right Press Arms (17, 18) as shown.
Attach the eft and Right Press Arms (17, 18) to
the Base (1) with the M10 x 130mm Bolt (11)
and an M10 ocknut (74). Do not overtighten
the Locknut; the Press Arms must pivot eas-
ily.
Attach the eft and Right Press Arms (17, 18)
with two M10 x 20mm Screws (84), two M10
Washers (88), and the Press Arm Spacer (42).
19. Identify the Butterfly Frame (7), the eft
Butterfly Pulley Bracket (20), and the eft
Butterfly Arm (15) and orient them as shown.
Apply grease to an M10 x 130mm Bolt (11).
Attach the eft Butterfly Arm (15) to the Butterfly
Frame (7) with the M10 x 130mm Bolt (11), an
Upper Butterfly Bushing (52), the eft Butterfly
Pulley Bracket (20), and an M10 ocknut (74).
Do not overtighten the Locknut; the Butterfly
Arm must pivot easily.
Repeat this step to attach the Right Butterfly
Arm (16) and the Right Butterfly Pulley
Bracket (21).
18
19
84
18
17
88
74 88
42
1
84
11
15
20
21 52
74
11
7
16
Grease
Grease

16
20. Attach the Butterfly Frame (7) to the Top Frame
(6) with two M10 x 93mm Bolts (63), two M10
Washers (88), and two M10 ocknuts (74). Do
not fully tighten the Locknuts yet.
Insert a Ball Detention Assembly (96) into the
eft and Right Butterfly Arms (15, 16).
20
21. Finish attaching the Butterfly Frame (7) to the
Top Frame (6) with two M10 x 117mm Bolts
(64), four M10 Washers (88), and two M10
ocknuts (74).
See step 20. Tighten the M10 ocknuts (74).
21
63
88
74 88
88
64
74
6
6
7
96
96
16
7
15

17
22. dentify the Low Cable (43). Route the ow
Cable through the bracket on the eg ever
(13).
Attach a Pulley (69) inside the eg ever (13)
over the ow Cable (43) with an M10 x 63mm
Bolt (89), two 12.7mm Spacers (73), and an
M10 ocknut (74).
23. Route the ow Cable (43) over a Pulley (69)
and through the eg (10).
Attach the Pulley (69) inside the eg (10) with
an M10 x 65mm Bolt (75), two M10 Washers
(88), two 12.7mm Spacers (73), and an M10
ocknut (74).
22
23
13
74
73
69
69
43
10
43
73
89
74
73
73
75
88
88
24. See drawing 24a. Route the ow Cable (43)
under the Press Arm Spacer (42).
See drawing 24b. Attach a Pulley (69) to the
bracket on the Base (1) over the ow Cable
(43) with an M10 x 45mm Bolt (98) and an M10
Jam Nut (99).
24b
42
1
43
69
43
98
24a
99

18
26. Route the ow Cable (43) around a Pulley (69)
and then route it through the bracket in the
Base (1) as shown.
Attach the Pulley (69) and a Cable Trap (71) to
the bracket on the Base (1) with an M10 x
47mm Bolt (91) and an M10 ocknut (74). Make
sure that the Cable Trap is oriented to hold
the Low Cable in the groove of the Pulley.
25. Route the ow Cable (43) over a Pulley (69).
Attach the Pulley (69) and a Cable Trap (71)
inside the eft and Right Press Arms (17, 18)
with an M10 x 125mm Bolt (83) and an M10
Washer (88). Make sure that the Cable Trap
is oriented to hold the Low Cable in the
groove of the Pulley.
25
26
43
43
74
69
83
17
18
69
71
88
91
71
1
27. Route the ow Cable (43) over a Pulley (69).
Attach the Pulley (69) and a Cable Trap (71)
inside the eft and Right Press Arms (17, 18)
with the M10 x 125mm Bolt (83) used in step
25, an M10 Washer (88), and an M10 ocknut
(74). Make sure that the Cable Trap is ori-
ented to hold the Low Cable in the groove of
the Pulley.
Route the ow Cable (43) through the left side
of the Upright (5). Set the ow Cable aside until
step 38.
27
69
83
18
71
88
74
17
543

19
29. Route the High Cable (44) over a Pulley (69).
Attach the Pulley (69) and a Cable Trap (71) to
the right side of the Top Frame (6) with an M10
x 93mm Bolt (63), an M10 Washer (88), and an
M10 ocknut (74). Make sure that the Cable
Trap is oriented to hold the High Cable in
the groove of the Pulley.
28
29
74
74 71
69
69
88
44
44
6
95
95
66
6
28. dentify the High Cable (44). Route the High
Cable through the bracket on the Top Frame (6)
and over a Pulley (69).
Attach the Pulley (69) inside the Top Frame (6)
with an M10 x 68mm Bolt (66), two 14.8mm
Spacers (95), and an M10 ocknut (74).
63
30. Route the High Cable (44) under a V-pulley
(67).
Attach the V-pulley (67) and a Cable Trap (71)
to the Upright (5) with an M10 x 57mm Bolt (93)
and an M10 ocknut (74). Make sure that the
Cable Trap is oriented to hold the High
Cable in the groove of the V-pulley.
30
93
74
71
5
67
44

20
31. Route the High Cable (44) around a Pulley (69).
Attach the Pulley (69) and a Cable Trap (71) to
the Right Butterfly Pulley Bracket (21) with an
M10 x 47mm Bolt (91) and an M10 ocknut
(74). Make sure that the Cable Trap is ori-
ented to hold the High Cable in the groove
of the Pulley.
31
74
71
69
21
44
91
32. Route the High Cable (44) around a Pulley (69).
Attach the Pulley (69) to the Upright (5) with an
M10 x 43mm Bolt (65) and an M10 ocknut
(74).
32
5
65
74
44
69
33
74
71
44
69
20
91
33. Route the High Cable (44) around a Pulley (69).
Attach the Pulley (69) and a Cable Trap (71) to
the eft Butterfly Pulley Bracket (20) with an
M10 x 47mm Bolt (91) and an M10 ocknut
(74). Make sure that the Cable Trap is ori-
ented to hold the High Cable in the groove
of the Pulley.
