CAUTIO
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Model o. 831.15907.0
Serial o.
Write the serial number in the
space above for reference.
• Assembly
• Operation
• Maintenance
• Part List and Drawing
Sears, Roebuck and Co.
Hoffman Estates, IL 60179
WEIGHT BE CH EXERCISER
Userʼs Manual
Serial Number Decal
(under the seat)
2
WAR I G DECAL PLACEME T
TABLE OF CO TE TS
WARNINGDECALPLACE ENT ..............................................................2
I PORTANTPRECAUTIONS .................................................................3
BEFOREYOUBEGIN .......................................................................4
PARTIDENTIFICATIONCHART ...............................................................5
ASSE BLY ...............................................................................6
ADJUST ENT ............................................................................11
EXERCISEGUIDELINES ...................................................................13
PARTLIST ...............................................................................14
EXPLODEDDRAWING .....................................................................15
ORDERINGREPLACE ENTPARTS ..................................................BackCover
90DAYFULLWARRANTY ..........................................................BackCover
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, call
1-877-992-5999 and request a free replacement
decal. Apply the decal in the location shown.
Note: The decal(s) may not be shown at actual
size.
WEIDER PRO is a trademark of ICON IP, Inc.
3
WAR I G: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your weight bench before using your weight bench.
Sears assumes no responsibility for personal injury or property damage sustained by or through
the use of this product.
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of the weight bench are ade-
quately informed of all precautions.
3. The weight bench is intended for home use
only. Do not use the weight bench in a
commercial, rental, or institutional setting.
4. Keep the weight bench indoors, away from
moisture and dust. Place the weight bench
on a level surface, with a mat beneath it to
protect the floor or carpet. Make sure that
there is enough clearance around the weight
bench to mount, dismount, and use the
weight bench.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. The weight bench is designed to support a
maximum user weight of 300 lbs. (136 kg)
and a maximum total weight of 410 lbs. (186
kg). Do not place more than 110 lbs. (50 kg),
including a barbell and weights, on the
weight rests. Do not place more than 50 lbs.
(23 kg) on the leg lever. ote: The weight
bench does not include a barbell or weights.
7. Always keep children under age 12 and pets
away from the weight bench.
8. Always keep hands and feet away from mov-
ing parts.
9. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the weight bench. Always wear
athletic shoes for foot protection.
10. Do not use a barbell that is longer than 6 ft.
(1.8 m) with the weight bench.
11. Always place the same amount of weight on
both ends of your barbell. Always keep
some weight on both ends of the barbell
while adding or removing weights to prevent
the barbell from tipping.
12. Before using the leg lever, place a barbell
with the same amount of weight on the
weight rests to balance the weight bench.
13. Always exercise with a partner. When you
are performing bench press exercises, your
partner should stand behind you to catch
the barbell if you cannot complete a repeti-
tion.
14. Before using the backrest in the level posi-
tion or in an inclined position, make sure
that the backrest support is properly insert-
ed (see ADJUSTI G THE BACKREST on
page 11).
15. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
16. Use the weight bench only as described in
this manual.
IMPORTA T PRECAUTIO S
4
Backrest
Weight Rest
Upright
Backrest Support
Curl Pad
Seat
Curl Knob
Leg Lever
Weight Tube
BEFORE YOU BEGI
ASSE BLED DI ENSIONS:
Height: 3 ft. 11 in. (119 cm)
Width: 2 ft. 6 in. (76 cm)
Depth: 5 ft. 2 in. (157 cm)
Thank you for selecting the new WEIDER PRO™
270 L weight bench. The 270 L weight bench offers a
selection of exercises designed to develop the major
muscle groups of the body. Whether your goal is to
tone your body, build dramatic muscle size and
strength, or improve your cardiovascular system, the
weight bench will help you to achieve the specific
results you want.
For your benefit, read this manual carefully before
using the weight bench. If you have questions after
reading this manual, please see the back cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please look at the drawing
below and familiarize yourself with the parts that are
labeled.
5
M8 x 45mm Bolt (28)
M6 Washer
(22)
M10 x 135mm Bolt (23)
M10 x 60mm Bolt (25) M10 x 68mm Bolt (27)
M10 x 35mm
Carriage Bolt (37)
M6 x 16mm
Screw (24)
M6 x 40mm Screw (32)
M8 Locknut
(38) M10 Locknut (31)
M8 Washer (39) M10 Washer (30)
PART IDE TIFICATIO CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. IMPORTA T: If you cannot
find a part in the hardware kit, check to see if it has been preassembled. If a part is missing, please call
1-877-992-5999. To avoid damaging parts, do not use power tools for assembly.
6
1
27
35
35
41
41
1
10
31
1.
Orient one of the Uprights (1) so that the
Upright Cover (10) is on the side shown.
Next, identify one Joint Plate A (35) and one
Joint Plate B (41); the Joint Plates have “A” and
“B” stickers. Orient the Joint Plates as shown,
with the diamond patterns facing away from the
Upright (1).
Attach the Joint Plates (35, 41) to the Upright
(1) with two 10 x 68mm Bolts (27) and two
10 Locknuts (31). Do not tighten the
Locknuts yet.
Orient the other Upright (1) and the other
Joint Plates (35, 41) as shown; attach the
Joint Plates as described above.
1
To make assembly easier, read the
assembly tips at the top of this page
before beginning.
ASSEMBLY
• Assembly requires two persons.
• Because of its size and weight, assemble the
weight bench in the location where it will be
used. Make sure that there is enough clear-
ance to walk around the weight bench as you
assemble it.
• Place all parts in a cleared area and remove
the packing materials. Do not dispose of the
packing materials until you complete all
assembly steps.
• To identify small parts, see page 5.
• The following tools (not included) may be
required for assembly:
two adjustable wrenches
one rubber mallet
one standard screwdriver
one Phillips screwdriver
Assembly will be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.
7
3
4
31
31
37
33
2. Attach one end of the Crossbar (2) to two Joint
Plates (35, 41) with two 10 x 68mm Bolts (27)
and two 10 Locknuts (31). Do not tighten the
Locknuts yet.
Attach the other end of the Crossbar (2) in
the same way.
3. Orient the Base (33) so that the warning decals
are in the positions shown.
Attach the Base (33) to the Front Leg (4) with
two 10 x 35mm Carriage Bolts (37) and two
10 Locknuts (31).
2
27
35
41
2
Warning
Decals
31
4. Attach the Front Leg (4) to the Frame (3) with
two 8 x 45mm Bolts (28), two 8 Washers
(39), and two 8 Locknuts (38). Make sure that
the Locknuts are in the indicated hexagonal
holes; do not tighten the Bolts yet.
4
4
3
38
Hexagonal
Holes
28 39
8
5. Attach the Frame (3) to the Crossbar (2) with
two 10 x 68mm Bolts (27) and two 10
Locknuts (31). Do not tighten the Locknuts
yet.
5
6. Insert the Backrest Support (14) from the direc-
tion shown into one of the three sets of holes in
the Uprights (1). Rotate the Backrest Support
so that the locking pin is wrapped around
the Upright (see the inset drawing).
See steps 1, 2, and 5. Tighten the M10
Locknuts (31).
See step 4. Tighten the M8 x 45mm Bolts
(28).
6
1
1
14
Locking
Pin
3
2
31
27
7. Apply a small amount of the included grease to
an 10 x 60mm Bolt (25).
Attach the Leg Lever (6) to the Front Leg (4) with
the 10 x 60mm Bolt (25) and an 10 Locknut
(31). Do not overtighten the Locknut; the Leg
Lever must pivot easily.
7
25
31
Grease
6
4
Locking
Pin
9
8. Insert a Pad Tube (12) through the Leg Lever
(6).
Slide a Foam Pad (13) onto each end of the
Pad Tube (12).
Press a Pad Cap (34) into each end of the Pad
Tube (12).
Repeat this step with the other Pad Tube
(12), Foam Pads (13), and Pad Caps (34).
8
9. Insert a Weight Rest (15) into an Upright (1).
Rotate the Weight Rest so that the locking
pin is wrapped around the Upright.
Repeat this step with the other Weight Rest
(15). Make sure that both Weight Rests are
at the same height.
9
15
15
Locking
Pin
1
1
6
13
13
13
13
12
12
34
34
34
34
10. Orient the Backrest Tubes (7) so that the indi-
cated holes are in the position shown.
Attach the Backrest Tubes (7) to the Backrest
(8) with four 6 x 40mm Screws (32) and four
6 Washers (22). Do not tighten the Screws
yet.
10
8
7
Holes
22
32
32
22
10
11. Apply grease to an 10 x 135mm Bolt (23).
Attach the Backrest Tubes (7) to the welded
tube on the Frame (3) with the 10 x 135mm
Bolt (23), two 10 Washers (30), and an 10
Locknut (31). Do not overtighten the Locknut;
the Backrest Tubes must pivot easily.
See step 10. Tighten the M6 x 40mm Screws
(32).
11
31 30
7
3
Tube 23
Grease
30
12. Orient the Seat (9) as shown.
Attach the Seat (9) to the Frame (3) with four
6 x 16mm Screws (24).
9
3
24 24
12
14. Make sure that all parts are properly tight-
ened before you use the weight bench. The
use of all remaining parts will be explained in
ADJUST ENT, beginning on page 11.
13. Orient the Curl Pad (5) as shown.
Attach the Curl Pad (5) to the Curl Post (11)
with two 6 x 16mm Screws (24).
5
11
24
13
