USER’S MANUAL
QUESTIONS?
As a manufacturer, we are com-
mitted to roviding com lete
customer satisfaction. If you have
questions, or find there are miss-
ing or damaged arts, we will
guarantee you com lete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will rovide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 .m. MST
Model No. WESY19720
Serial No.
Write the serial number in the space
above for reference.
Serial Number Decal
CAUTION
Read all recautions and instruc-
tions in this manual before using
this equi ment. Save this manual
for future reference.
Visit our website at
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!

2
TABLE OF CONTENTS
IMPORTANT PRE AUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
TROUBLESHOOTING AND MAINTENAN E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
ABLE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
ORDERING REPLA EMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back over
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back over
Note: A PART IDENTIFI ATION HART is attached to the center of this manual. Remove the PART
IDENTIFI ATION HART before beginning assembly.
WEIDER is a registered trademark of I ON Health & Fitness, Inc.

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following im ortant recautions
before using the weight system.
1. Read all instructions in this manual and in
the accom anying literature before using the
weight system.
2. It is the res onsibility of the owner to ensure
that all users of the weight system are ade-
quately informed of all recautions.
3. The weight system is intended for home use
only. Do not use the weight system in any
commercial, rental, or institutional setting.
4. Use the weight system only on a level sur-
face. Cover the floor beneath the weight sys-
tem to rotect the floor.
5. Make sure all arts are ro erly tightened
each time you use the weight system.
Re lace any worn arts immediately.
6. Kee children under 12 and ets away from
the weight system at all times.
7. Kee hands and feet away from moving arts.
8. Always wear athletic shoes for foot rotection.
9. The weight system is designed to su ort a
a maximum user weight of 300 ounds.
10. Always stand on the foot late when er-
forming an exercise that could cause the
weight system to ti .
11. Never release the ress arm, butterfly arms,
leg lever, lat bar, or nylon stra while weights
are raised. The weights will fall with great
force.
12. Always disconnect the lat bar from the
weight system when performing an exercise
that does not use the lat bar.
13. Make sure that the cables remain on the ul-
leys at all times. If the cables bind while you
are exercising, sto immediately and make
sure that the cables are on all of the ulleys.
14. If you feel ain or dizziness at any time while
exercising, sto immediately and begin cool-
ing down.
15. The decals shown
here have been
laced on the
weight system in the
locations shown on
age 4. If a decal is
missing or illegible,
lease call our
Customer Service
De artment toll-free
at 1-800-999-3756,
Monday through
Friday, 6 a.m. until 6
.m. Mountain Time,
to order a free
re lacement decal.
A ly the re lace-
ment decal in the
location shown.
WARNING:Before beginning this or any exercise rogram, consult your hysician. This
is es ecially im ortant for ersons over the age of 35 or ersons with re-existing health roblems.
Read all instructions before using. ICON assumes no res onsibility for ersonal injury or ro erty
damage sustained by or through the use of this roduct.
Keep hands and
fingers clear of
this area.
Decal 1
Decal 2

4
BEFORE YOU BEGIN
ASSEMBLED
DIMENSIONS:
Height: 76 in.
Width: 38 in.
Length: 53 in.
Foot Plate Low Pulley Station
High Pulley Station
Lat Bar
Leg Lever
Butterfly Arm
Press Arm
Weight Stack
Seat
Backrest
Warning
Decal 1
Warning
Decal 2
Weight Pin
Thank you for selecting the versatile WEIDER®8515
weight system. The WEIDER®8515 weight system
offers a selection of weight stations designed to devel-
op every major muscle group of the body. Whether
your goal is to tone your body, build dramatic muscle
size and strength, or improve your cardiovascular sys-
tem, the WEIDER®8515 weight system will help you to
achieve the specific results you want.
For your benefit, read this manual carefully before
using the weight system. If you have additional
questions, please call our ustomer Service
Department toll-free at 1-800-999-3756, Monday
through Friday, 6 a.m. until 6 p.m. Mountain Time
(excluding holidays). To help us assist you, please
note the product model number and serial number
before calling. The model number is WESY19720. The
serial number can be found on a decal attached to the
weight system (see the front cover of this owner's
manual).
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.

5
ASSEMBLY
1
56
High Side of
Bracket
3
5
51
51 14
127
4
Before beginning assembly, carefully read the
following information and instructions:
•Place all parts of the weight system in a cleared
area and remove the packing materials; do not
dispose of the packing materials until assembly is
completed.
• The assembly is divided into four stages: 1)
frame assembly, 2) press and butterfly arm
assembly, 3) cable and pulley assembly, and 4)
seat and backrest assembly. The hardware for
each stage is packaged separately.
• Wait until you begin each assembly stage to open
that parts bag.
•For help identifying the small parts used in
assembly, use the PART IDENTIFICATION
CHART located in the center of this manual.
Note: Some small parts may have been pre-
attached for shipping. If a part is not in the parts
bag, check to see if it has been pre-attached.
•As you assemble the weight system, be sure that
all parts are oriented as shown in the drawings.
•Tighten all parts as you assemble them, unless
instructed to do otherwise.
THE FOLLOWING TOOLS (NOT INCLUDED) ARE
REQUIRED FOR ASSEMBLY:
• Two (2) adjustable wrenches
• One (1) standard screwdriver
• One (1) hilli s screwdriver
• One (1) rubber mallet
• Lubricant, such as grease or etroleum jelly,
and soa y water will also be needed.
Assembly will be more convenient if you have the
following tools: A socket set, a set of open-end or
closed-end wrenches, or a set of ratchet wrenches.
1. Before beginning assembly, be sure that
you have read and understand the infor-
mation in the box above.
Press a 2” Square Outer ap (51) onto each
end of the Stabilizer (5). Press a 2” Square
Inner ap (27) into the end of the Base (4).
Insert two M8 x 67mm arriage Bolts (14)
up through the Stabilizer (5). Insert two M8 x
63mm arriage Bolts (1) up through the
Base (4).
Slide the indicated end of the Base (4) onto
the M8 x 67mm arriage Bolts (14) in the
Stabilizer (5). Slide the Rear Upright (56)
onto the arriage Bolts. Hand tighten a M8
Nylon Locknut (3) onto each arriage Bolt.
The high side of the bracket on the Rear
U right must be on the side shown. Do
not tighten the Nylon Locknuts yet.
FRAME ASSEMBLY

6
FRAME ASSEMBLY
2. Slide the Front Upright (42) onto the M8 x
63mm arriage Bolts (1) in the Base (4).
Hand tighten an M8 Nylon Locknut (3) onto
each arriage Bolt. Do not tighten the
Nylon Locknuts yet.
Press a 1” Square Inner ap (65) into the
Front Upright (42).
3. Press a 2” Square Inner ap (27) into each
end of the Top Frame (55). Press a 1 3/4”
Square Inner ap (44) into each end of the
crossbar on the Top Frame. Press two 1”
Round Inner aps (49) into the top of the
crossbar.
Attach the Top Frame (55) to the Front Upright
(42) and the Rear Upright (56) with four M8 x
65mm Bolts (11), four 5/16” Flat Washers (8),
and four M8 Nylon Locknuts (3).
Tighten all Nylon Locknuts used in ste s 1
through 3.
4. Set two Weight Bumpers (19) onto the brack-
et on the Base (4) as shown.
Stack six Weights (25) on the Weight
Bumpers (19). Be sure that all of the Weights
are turned so the pin grooves are on the
same side. Be careful not to ti the stack
of Weights.
4
2
3
42
65
3
1
4
11 11
49
8
44
44
27
27
55
56 42
3
rossbar
25
Pin Groove
19
4—Bracket
3
8

7
FRAME ASSEMBLYARM ASSEMBLY
5. Press the Weight Tube Bumper (64) into the
end of the Weight Tube (63). Insert the
Weight Tube into the stack of Weights (25).
Be sure that the pins on the Weight Tube are
aligned with the pin grooves in the upper
Weight.
Lubricate the insides of the holes in the Top
Weight (76). Set the Top Weight onto the
stack of Weights (25).
Insert both Weight Guides (62) into the stack
of Weights (25). Be sure that the holes in
the Weight Guides are at the to , as
shown.
6. Attach the upper ends of the Weight Guides
(62) to the Top Frame (55) with the m8 x
150mm Bolt (60), two 1/2” x 3/4” Spacers
(61), and an M8 Nylon Locknut (3).
Be sure that the Pulley Bracket (20) is in
front of the right Weight Guide (62) as
shown.
7. Press a 1” x 7/8” Plastic Bushing (75) onto
each welded spacer on the Press Frame (17).
Slide the Press Frame into place on the Base
(4). Note: This will be a tight fit. The
Plastic Bushings should fit onto each end
of the indicated tube in the Base. Be sure
that the ulleys are on the indicated side.
Lubricate the M10 x 195mm Bolt (59). Attach
the Press Frame (17) to the Base (4) with the
M10 x 195mm Bolt and an M10 Nylon
Locknut (21).
7
5
6
55
76
63
64
25
62
Lubricate
60 20
62
3
4—Tube Welded
Spacers
17
Lubricate
59
Pulleys
21
75
61
Holes

8
ARM ASSEMBLY
8. Press a 1 3/4” Square Inner ap (44) into the
top of a Press Arm (46). Press a 1” Round
Inner ap (49) into each end of the handle on
the Press Arm. Attach the Press Arm to one
side of the Press Frame (17) with two M8 x
62mm Bolts (22) and two M8 Nylon Locknuts
(3).
Assemble the other Press Arm (46) in the
same manner.
9. Identify the Right Arm (48) and the Left Arm
(47). Note the position of the welded bracket
on each Arm. Arm identification is very
im ortant for ste 10.
Note: The “V”-Pulleys (6), Long able Traps
(50), M10 x 60mm Bolts (7), and M10 Nylon
Locknuts (21) are pre-attached. These have
been shown disassembled for easy part iden-
tification.
10. Lubricate both axles on the Top Frame (55).
Slide a 1/8” x 2 1/2” Plastic Bushing (74) onto
the right axle.
Slide the Right Arm (48) onto the right axle.
Note: Be careful not to confuse the Right
Arm with the Left Arm (47); refer to ste 9
to identify the Right Arm. Be sure that the
u er end of the Right Arm is behind the
indicated bracket on the To Frame (55).
Tap two 1” Retainers (69) and a 1” Round
over ap (70) onto the right axle. Be sure
that the teeth on the Retainers bend
toward the Cover Ca , as shown in the
inset drawing.
Attach the Left Arm (47) in the same manner.
Press 1 3/4” Square Inner aps (44) into the
lower ends of the Right and Left Arms (47,
48). Wet the lower end of each Arm with
soapy water. Slide a 10” Pad (45) onto the
lower end of each Arm.
10
50
50
46
3
22
46
49
49
44
17
7
44
49
Bracket
Lubricate Axle
45
47
55
48
45
44
69
70
6
6
48
47
Welded
Brackets 21
74
8
9
69
55
70

9
CABLE ASSEMBLY
11. During steps 11 through 25, refer to the
ABLE DIAGRAM on page 20 of this manual
to verify proper cable routing. Before begin-
ning this section, identify the Long able (23)
and the Short able (58) by comparing the
lengths of the cables.
IMPORTANT: While assembling the cables,
do not overtighten the bolts and nuts
securing the ulleys. The ulleys must be
able to turn freely.
12. Locate the Long Cable (23). Route the Long
able around the indicated 3 1/2” Pulley (15)
attached to the Top Frame (55). Be sure that
the end of the Cable with the ball is on the
indicated side of the Pulley and that the
Cable is between the Pulley and the hook.
Tighten the M10 x 90mm Bolt (77) and the
M10 Nylon Locknut (not shown).
13. Wrap the Long able (23) around a “V”-Pulley
(6). Attach the “V”-Pulley and a Long able
Trap (50) to the indicated bracket on the
Front Upright (42) with a M10 x 60mm Bolt
(7) and an M10 Nylon Locknut (21). Be sure
that the Long Cable Tra is ositioned to
hold the Cable in lace.
14. Route the Long able (23) around the “V”-
Pulley (6) on the Left Arm (47). Be sure that
the Cable is in the groove of the Pulley
and that the Long Cable Tra (50) is osi-
tioned to hold the Cable in lace. Tighten
the M10 x 60mm Bolt (7) and the M10 Nylon
Locknut (not shown).
14
11
12
13
58
23
55
77
Hook
Ball 15
50
23
7
47
23
7
21
650
23
6
42

10
15. Route the Long able (23) around the “V”-
Pulley (6) on the Right Arm (48). Be sure
that the Cable is in the groove of the “V”-
Pulley and that the Long Cable Tra (50) is
turned to hold the Cable in lace. Tighten
the M10 x 60mm Bolt (7) and the M10 Nylon
Locknut (not shown).
16. Route the Long able (23) around the 3 1/2”
Pulley (15) attached to the Pulley Bracket
(20). Be sure that the Cable is in the
groove of the Pulley and that the Cable
Tra (66) is turned to hold the Cable in
lace. Tighten the M10 x 45mm Bolt (78) and
the M10 Nylon Locknut (not shown).
Be sure that the M8 x 115mm Bolt (68) is
properly tightened and that the Pulley Bracket
(20) can move freely.
17. See the inset drawing. Attach a 3 1/2” Pulley
(15) and a able Trap (66) to the indicated
hole in the Long “U”-Bracket (57) with a M10
x 50mm Bolt (12) and an M10 Nylon Locknut
(21). Be sure that the Cable Tra is inside
the “U”-Bracket. Note: This may come re-
assembled.
Route the Long able (23) around the 3 1/2”
Pulley (15) and through the Long “U”-Bracket
(57). Be sure that the Cable is in the
groove of the Pulley and that the Cable
and Pulley move smoothly.
18. Note: The Pulley (15) in this drawing is
re-assembled. It is shown disassembled
for easy art identification.
Route the Long able (23) around the 3 1/2”
Pulley (15) attached to the bracket on the Top
Frame (55). Tighten the M10 x 45mm Bolt
(78) and the M10 Nylon Locknut (21). Be
sure that the Cable is in the groove of the
Pulley and that the Cable and Pulley move
smoothly.
18
15
16
17
CABLE ASSEMBLY
48
50 76
23
66
15
78
20
68
23
21 12
15
23
57
66
78
15
23
Bracket
55
21
23

11
CABLE ASSEMBLY
19. Loosen the M10 Nylon Locknut (21) on the
lower 3 1/2” Pulley (15) on the Press
Frame (17).
Locate the Short Cable (58). Route the
Short able (58) under the 3 1/2” Pulley (15).
Be sure that the end of the Cable with the
ball is on the indicated side of the Press
Frame (17) and that the Cable is between
the Pulley and the crossbar on the Press
Frame. Tighten the M10 Nylon Locknut (21)
and the M10 x 90mm Bolt (77).
20. Route the Short able (58) around the 3 1/2”
Pulley (15) attached to the lower hole in the
Front Upright (42). See the inset drawing.
Be sure that the Cable Tra (66) is turned
to hold the Cable in lace and that the
Cable is routed around the Pulley as
shown. Tighten the M10 Nylon Locknut (21)
and the M10 x 95mm Bolt (71).
19
20
58 rossbar
Ball
15
17
77
21
58
21
42
15
71
58
This view is from
the o osite side
42
66
15

12
21. Route the Short able (58) around the 3 1/2”
Pulley (15) attached to the upper hole in the
Press Frame (17). Be sure that the Cable
Tra (66) is turned to hold the Cable in
lace and that the Cable is routed around
the Pulley as shown. Tighten the M10 Nylon
Locknut (21) and the M10 x 80mm Bolt (not
shown).
22. Route the Short able (58) around the 3 1/2”
Pulley (15) attached to the upper hole in the
Front Upright (42). See the inset drawing.
Be sure that the Cable Tra (66) is turned
to hold the Cable in lace and that the
Cable is routed around the Pulley as
shown. Tighten the M10 Nylon Locknut (21)
and the M10 x 95mm Bolt (71).
22
21
CABLE ASSEMBLY
58
15 66
21
17
71
58
Inset shows view
from other side
42
66
15
42
58
15
21

23. Attach the end of the Short able (58) to the
Long “U”-Bracket (57) with an M8 Nylon Lock-
nut (3) and a 5/16” Flat Washer (8). Do not
com letely tighten the Nylon Locknut. It
should be threaded onto the end of the
Cable so only a cou le of threads are
showing above the nut, as shown in the
inset drawing.
24. Attach the Long able (23) to the Small “U”-
Bracket (67) with an M8 Nylon Locknut (3)
and a 5/16” Flat Washer (8). Do not com-
letely tighten the Nylon Locknut. It
should be threaded onto the end of the
Cable only a cou le of turns, as shown in
the inset drawing.
Attach the Small “U”-Bracket (67) to the
Weight Tube (63) with the M8 x 45mm Bolt
(72) and an M8 Nylon Locknut (3).
23
24
CABLE ASSEMBLY
57
3
8
58
63
72
67
3
83
23
13
23
67
3
8
58
57
3
8

14
25. Attach the Backrest (41) to the Front Upright
(42) with two M6 x 65mm Screws (43) and
two 1/4” Flat Washers (10).
26. Press a 1 1/2” Square Inner ap (32) into the
Seat Frame (36).
Insert the M6 x 50mm arriage Bolt (38) into
the center hole in the Seat Plate (37). Attach
the Seat Plate to the Seat (13) with two M6 x
16mm Screws (18).
Insert the M6 x 50mm arriage Bolt (38) into
the indicated hole in the Seat Frame (36).
Tighten an M6 Nylon Locknut (2) with a 1/4”
Flat Washer (10) onto the arriage Bolt.
Attach the other end of the Seat (13) to the
Seat Frame (36) with a 1/4” Flat Washer (10)
and the M6 x 50mm Screw (24).
27. Press a 1 1/2” Square Inner ap (32) into the
Leg Lever (29).
Lubricate the M8 x 57mm Bolt (33). Attach the
Leg Lever (29) to the Seat Frame (36) with
the M8 x 57mm Bolt and an M8 Nylon
Locknut (3). Do not overtighten the Nylon
Locknut. The Leg Lever must be able to
ivot freely.
Insert the M8 x 50mm Eyebolt (35) into the
Leg Lever (29) from the direction shown.
Tighten an M8 Nylon Locknut (3) with a 5/16”
Flat Washer (8) onto the Eyebolt.
25
26
27
SEAT ASSEMBLY
41
42
10 2
24
36
36
3
Lubricate–33
29
83
32
35
2
13
38
37 32
18
10
43

15
28. Rest the Seat Frame (36) on the indicated pin
in the Front Upright (42). Attach the Seat
Frame to the Front Upright with a M8 x 67mm
arriage Bolt (14) and the Seat Knob (40).
29. Press 3/4” Round Inner aps (34) into the
ends of both 12 1/2” Pad Tubes (28).
Insert one 12 1/2” Pad Tube (28) into the
Seat Frame (36). Slide a 5 1/2” Pad (30) onto
each end of the Pad Tube.
Insert the other 12 1/2” Pad Tube (28) into the
Leg Lever (29). Slide a 5 1/2” Pad (30) onto
each end of the Pad Tube.
28
29
36
40
30
34
28
34
29
30
36
SEAT ASSEMBLY
Pin
42
14

16
30. Remove the decals from the decal sheet (not shown) and apply them to the weight system in the locations
shown below.
HIGH PULLEY
BUTTERFLY
8515
BEN H PRESS
LOW PULLEY
LEG URL
LEG EXTENSION
30
31. Make sure that all parts have been properly tightened. The use of the remaining parts will be explained in
ADJUSTMENTS, beginning on page 17 of this manual.
Before using the weight system, pull each cable a few times to be sure that the cables move smoothly over
the pulleys. If one of the cables does not move smoothly, find and correct the problem. IMPORTANT: If the
cables are not ro erly installed, they may be damaged when heavy weight is used. See the CABLE
DIAGRAM on age 20 of this manual for ro er cable routing. If there is any slack in the cables, you
will need to remove it by tightening the cables. See TROUBLESHOOTING AND MAINTENANCE on
age 19.

17
ADJUSTMENTS
The instructions below describe how each part of the weight system can be adjusted. Refer to the exercise
guide accompanying this manual to see how the weight system should be set up for each exercise. IMPOR-
TANT: When attaching the lat bar or nylon stra , make sure that the attachments are in the correct start-
ing osition for the exercise to be erformed. If there is any slack in the cables or chain as an exercise
is erformed, the effectiveness of the exercise will be reduced.
54
53
52
23
25 26
54
58
52
53
CHANGING THE WEIGHT SETTING
To change the weight setting of the weight stack,
insert a Weight Pin (26) under the desired Weight
(25). Be sure to insert the Weight Pin until the bent
end of the Weight Pin is touching the Weights, and
turn the bent end downward. The weight setting of the
weight stack can be changed from 6.5 pounds to 81.5
pounds, in increments of 12.5 pounds. Note: Due to
the cables and ulleys, the actual amount of
resistance at each exercise station may vary from
the weight setting. Use the WEIGHT RESISTANCE
CHART on age 18 to find the actual amount of
resistance at each weight station.
ATTACHING THE LAT BAR OR NYLON STRAP TO
THE HIGH PULLEY STATION
Attach the Lat Bar (54) to the Long able (23) with a
able lip (53). For some exercises, the hain (52)
should be attached between the Lat Bar and the Long
able with two able lips. Adjust the length of the
Chain between the Lat Bar and the Long Cable so
the Lat Bar is in the correct starting osition for
the exercise to be erformed.
The Nylon Strap (39) (not shown) can be attached in
the same manner.
ATTACHING THE LAT BAR OR NYLON STRAP TO
THE LOW PULLEY STATION
Attach the Lat Bar (54) to the Short able (58) with a
able lip (53). For some exercises, the hain (52)
should be attached between the Lat Bar and the
Pulley able with two able lips. Adjust the length
of the Chain between the Lat Bar and the Short
Cable so the Lat Bar is in the correct starting
osition for the exercise to be erformed.
The Nylon Strap (39) (not shown) can be attached in
the same manner.

18
ATTACHING AND REMOVING THE SEAT
Set the bracket on the Seat Frame (36) onto the indi-
cated pins on the Front Upright (42). Attach the Seat
Frame to the Front Upright with the M8 x 67mm
arriage Bolt (14) and the Seat Knob (40).
For some exercises, the Seat (13) must be removed.
First, be sure that the chain is not attached to the leg
lever. Next, remove the Seat Knob (40) and the M8 x
67mm arriage Bolt (14) from the Seat Frame (36).
Lift the Seat Frame off the Front Upright (42).
ATTACHING THE LEG LEVER TO THE LOW
PULLEY STATION
To use the Leg Lever (29), the seat must be attached
to the front upright (see ATTA HING AND REMOV-
ING THE SEAT above).
Attach one end of the hain (52) to the Short able
(58) with a able lip (53). Attach the other end of
the hain to the Eyebolt (35) with a able lip.
40 36
42
13
14
52
53
58
29
35
WEIGHT PRESS ARM BUTTERFLY ARM LEG LEVER HIGH PULLEY LOW PULLEY
PLATES (lbs.) (lbs.) (lbs.) (lbs.) (lbs.)
Top 20 10 15 14 24
145 22 36 28 54
270 33 54 44 82
399 42 75 60115
4 128 48 96 72 147
5 153 60 115 90 175
6 184 69 137 103 209
WEIGHT RESISTANCE CHART
This chart shows the approximate weight resistance at each station. “Top” refers to the 6.5 lb. top weight. The
other numbers refer to the 12.5 lb. weight plates. The weight resistance shown for the butterfly arm station is for
each butterfly arm.
The actual resistance at each weight station may vary due to differences in individual weight plates, as well as
friction between the cables, pulleys, and weight guides.

19
TROUBLESHOOTING AND MAINTENANCE
Make sure all parts are properly tightened each time the weight system is used. Replace any worn parts immedi-
ately. The weight system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents.
TIGHTENING THE CABLES
Woven cable, the type of cable used on the weight
system, can stretch slightly when it is first used. If
there is slack in the cables before resistance is felt,
the cables should be tightened. Slack can be
removed from the cables by tightening the M8 Nylon
Locknuts (3) at the end of the Long able (23) (see
drawing 1) and at the end of the Short able (58)
(see drawing 2). To do this you may need to remove
the Small “U”-Bracket (67) from the Weight Tube (not
shown) or remove the 3 1/2” Pulley (15) from the
Long “U”-Bracket (57). Make sure that the cables are
not too tight, or the Top Weight (76) will be lifted off
the weight stack.
Additional slack can be removed by moving the 3 1/2”
Pulley (15) to the other hole in the Long “U”-Bracket
(57). Remove the M10 Nylon Locknut (21) and the
M10 x 50mm Bolt (12) from the able Trap (66),
Pulley, and “U”-Bracket. Re-attach the Pulley and
able Trap. Be sure that the able trap is in the prop-
er position and that the able and Pulley move
smoothly.
Note: If a cable tends to sli off the ulleys often,
the cable may have become twisted. Remove the
cable and re-install it.
If the cables need to be replaced, see ORDERING
REPLA EMENT PARTS on the back cover of this
manual.
57
67
76
66
15
3
3
58
12
23
1
2
23
21

20
CABLE DIAGRAM
The cable diagram below shows the proper routing of the Short able (58) and the Long able (23). Use the
diagram to be sure that the two cables and the cable traps have been assembled correctly. If the cables have
not been correctly routed, the weight system will not function properly and damage may occur. The numbers
show the correct route for each cable. The starting and ending points of each cable are labeled. Be sure that
the cable tra s do not touch or bind the cables.
4
3
2
7
6
5
4
3
2
Weight Stack—8
1—Low Pulley
1—High Pulley
Long Cable (23)
5—Long “U”-Bracket
Short Cable (58)
TOP VIEW
