WeiderPro Pro 4300 User manual

• Assembly
• Adjustment
• Troubleshooting
• Part List and Drawing
Model o. 831.14622.1
Serial o.
Write the serial number in the
space above for future reference.
Serial umber Decal (under seat)
WEIGHT SYSTEM EXERCISER
Userʼs Manual
CAUTIO
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Sears, Roebuck and Co.
Hoffman Estates, IL 60179

WAR I GDECALPLACEME T ..............................................................2
IMPORTA TPRECAUTIO S ................................................................3
BEFOREYOUBEGI ......................................................................4
PARTIDE TIFICATIO CHART ..............................................................5
ASSEMBLY ..............................................................................8
ADJUSTME T ...........................................................................25
WEIGHTRESISTA CECHART..............................................................27
CABLEDIAGRAM.........................................................................28
MAI TE A CE ..........................................................................29
EXERCISEGUIDELI ES ...................................................................30
PARTLIST ..............................................................................33
EXPLODEDDRAWI G ....................................................................34
ORDERI GREPLACEME TPARTS ..................................................BackCover
90DAYFULLWARRA TY ..........................................................BackCover
TABLE OF CO TE TS
2
The decal shown here has been applied to
the weight system. If the decal is missing
or illegible, call 1-877-992-5999 and
request a free replacement decal. Apply
the decal in the location shown. ote: The
decal may not be shown at actual size.
WAR I G DECAL PLACEME T

3
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. Use the weight system only as described in
this manual.
3. It is the responsibility of the owner to ensure
that all users of the weight system are ade-
quately informed of all precautions.
4. The weight system is intended for home use
only. Do not use the weight system in any
commercial, rental, or institutional setting.
5. Keep the weight system indoors, away from
moisture and dust. Place the weight system
on a level surface, with a mat beneath it to
protect the floor or carpet. Make sure that
there is enough clearance around the weight
system to mount, dismount, and use the
weight system.
6. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
7. Keep hands and feet away from moving
parts.
8. Keep children under age 12 and pets away
from the weight system at all times.
9. Always wear athletic shoes for foot protec-
tion while exercising.
10. Make sure that the cable remains on the pul-
leys at all times. If the cable binds as you
are exercising, stop immediately and make
sure that the cable is on the pulleys. Replace
all cables at least every two years.
11. The weight system is designed to be used
only with the included weight. Do not use
the weight system with dumbbells or any
other type of weight to increase the resist-
ance.
12. The weight system is designed to support a
maximum user weight of 300 lbs. (136 kg).
13. Always make sure that the weight pin is
inserted fully into the weight stack before
exercising.
14. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
WAR I G: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your weight system before using your weight sys-
tem. Sears assumes no responsibility for personal injury or property damage sustained by or
through the use of the weight system.
IMPORTA T PRECAUTIO S

4
Backrest
Curl Pad
Shroud
Weight
Backrest
Adjustment Knob
Seat Adjustment Knob
Ankle Strap
Handle
Curl Adjustment Knob
Frame
Butterfly Arm
Seat
Right Side Left Side
ote: The terms “right
side” and “left side”
are determined relative
to a person facing
away from the weight
system; they do not
correspond to right
and left on the draw-
ings in the manual.
Leg Lever
Foam Pad
Chain
Press Arm
Lat Bar
BEFORE YOU BEGI
Thank you for selecting the versatile WEIDER®PRO
4300 weight system. The weight system offers a selec-
tion of weight stations designed to develop every
major muscle group of the body. Whether your goal is
to tone your body, build dramatic muscle size and
strength, or improve your cardiovascular system, the
weight system will help you to achieve the specific
results you want.
For your benefit, read this manual carefully before
using the weight system. If you have questions after
reading this manual, please see the back cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.
ASSEMBLED DIME SIO S:
Height: 6 ft. 11 in. (210 cm)
Width: 3 ft. 7 in. (109 cm)
Depth: 3 ft. 5 in. (196 cm)

M10 Locknut (77)
M8 Washer (103)
M8 Locknut
(78) M6 Washer
(114)
OM4 Washer
(104)
M4 x 12mm
Self-tapping
Screw (102)
M4 x 16mm
Self-tapping
Screw (110)
M6 x 16mm
Screw (88) M8 x 22mm
Shoulder Bolt (90)
M10 x 75mm Button Screw (118)
M10 x 20mm
Button Screw (96)
19mm
Spacer (67)
21mm Steel
Spacer (108)
56.5mm Spacer (69) 89.5mm Spacer (59)
M10 Washer (80) M10 Large Washer (105) M12 Large Washer (98)
M10 x 70mm Bolt (113)
11mm
Spacer (99)
13mm Steel
Spacer (109)
7mm
Spacer (111)
M12 Nut (112)
M6 Locknut
(107)
PART IDE TIFICATIO CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. ote: Some small parts
may have been preattached. If a part is missing, call 1-877-992-5999.
5

M6 x 32mm Screw (89)
M6 x 28mm
Bolt (94)
M6 x 60mm Button Screw (91)
M8 x 75mm Carriage Bolt (83)
M8 x 80mm Bolt (100)
M8 x 65mm Bolt (101)
M10 x 120mm Bolt (115)
M10 x 82mm Button Screw (92)
M10 x 61mm Bolt Set (116)
M8 x 69mm Shoulder Bolt (87)
M10 x 60mm Bolt (79)
M10 x 85mm Bolt (81)
M10 x 75mm Bolt (82)
M10 x 80mm Bolt (84)
M10 x 65mm Bolt (85)
M10 x 45mm Bolt (86)
M10 x 50mm Bolt (97)
M10 x 110mm Bolt (93)
M10 x 65mm Button Bolt (106)
6

7
Backrest Adjustment Knob (53)
Curl Adjustment Knob (58)
Seat Adjustment Knob (52)

8
The Four Stages of the Assembly Process
Frame Assembly—You will begin by assembling
the base and the uprights that form the skeleton
of the weight system.
Arm Assembly—During this stage you will
assemble the arms and the leg lever.
Cable Assembly—During this stage you will
attach the cables and pulleys that connect the
arms to the weights.
Seat Assembly—During the final stage you will
assemble the seats and the backrests.
ASSEMBLY
To make assembly easier, carefully read the
following information and instructions:
•Assembly requires two persons.
• Because of its size, the weight system should be
assembled in the location where it will be used.
Make sure that there is enough clearance to walk
around the weight system as you assemble it.
• To make assembly as easy as possible, we have
divided the assembly process into four stages.
The parts needed for each stage are found in
individual hardware kits. Place all parts of the
weight system in a cleared area and remove the
packing materials. Do not dispose of the packing.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until assembly is completed.
• For help identifying small parts, use the PART
IDE TIFICATIO CHART on pages 5 and 6.
• As you assemble the weight system, make sure
all parts are oriented as shown in the drawings.
•Tighten all parts as you assemble them, unless
instructed to do otherwise.
• Assembly requires the included hex key and
grease and the following tools (not included):
two adjustable wrenches
one rubber mallet
one standard screwdriver
one Phillips screwdriver
Assembly may be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.

9
2. Orient the two Weight Guides (18) so that the
indicated holes are closer to the floor, and
insert the Weight Guides into the Stabilizer (3).
Attach the Stabilizer (3) and the Weight Guides
(18) to the Base (1) with two M10 x 85mm Bolts
(81), two M10 Washers (80), two 21mm Steel
Spacers (108), and two M10 Locknuts (77). Do
not tighten the Locknuts yet.
ext, attach the Weight Guides (18) to the
Stabilizer (3) with two M10 x 20mm Button
Screws (96). Then, attach the Stabilizer to the
Base (1) with an M8 x 75mm Carriage Bolt (83)
and an M8 Locknut (78). Do not tighten the
Locknut yet.
Attach the Upright (2) to the Base (1) with the two
indicated M8 x 75mm Carriage Bolts (83) and two
M8 Locknuts (78). Do not tighten the Locknuts
yet.
2
3
10
78
75
104
110
78
1
18
83
1
81
80
80
108
78
78
83
83
96
78
2
3
77
Holes
1
3. Attach the Front Leg (10) to the Base (1) with the
two M8 x 75mm Carriage Bolts (83) and two M8
Locknuts (78). Do not tighten the Locknuts yet.
Attach the Leg Lever Bumper (75) to the Front
Leg (10) with an M4 x 16mm Self-tapping Screw
(110) and an M4 Washer (104). Make sure that
the end of the Leg Lever Bumper is pointing
up.
1.
Insert four M8 x 75mm Carriage Bolts (83) up
through the Base (1). ote: It may be helpful to
place a piece of tape over each Bolt head to
hold it in place.
Before beginning assembly, make sure
that you understand the information in the
box on page 8.
Frame Assembly
83
83
1

10
4. Attach the Frame (9) to the Upright (2) with two
M8 x 80mm Bolts (100), two M8 Washers (103),
and two M8 Locknuts (78). Do not tighten the
Locknuts yet.
Attach the Frame (9) to the Front Leg (10) with
two M8 x 65mm Bolts (101), two M8 Washers
(103), and two M8 Locknuts (78). Do not tighten
the Locknuts yet.
4
5
100
100
2
103
103
78
78
78
78
9
101
103 10
102
21
1
5. Attach the bottom of the Left Shroud (21) to the
Base (1) with two M4 x 12mm Self-tapping
Screws (102).
Repeat this step for the Right Shroud (not
shown).
6
6. ote: Some parts have been removed to show
this step clearly.
Slide the two Weight Bumpers (71) onto the
Weight Guides (18). Orient nine Weights (19) with
the pin holes on the bottom as shown. Slide the
Weights onto the Weight Guides.
Insert the Weight Tube into the nine Weights (19).
Make sure that the pin on the Weight Tube is
oriented as shown.
Lubricate the indicated holes in a Weight (19)
with the included grease packet. Slide the Weight
onto the Weight Guides (18).
19
71
19
20
18
Pin
Pin
Hole
Grease

11
9. Attach a Shroud Cover (23) to the Left and Right
Shrouds (21, 22) with two M6 x 28mm Bolts (94),
four M6 Washers (114), and two M6 Locknuts
(107).
Attach the Shroud Cover (23) to the Top Frame
(4) with four M4 x 16mm Self-tapping Screws
(110) and four M4 Washers (104).
See the inset drawing. Attach the other
Shroud Cover (23) in the same manner.
7
4
2
80
18
103
100
78
78
96
8. Attach the top of the Left Shroud (21) to the Top
Frame (4) with two M4 x 12mm Self-tapping
Screws (102).
Repeat this step for the Right Shroud (22).
8
9
23
7. Attach the Top Frame (4) to the Upright (2) with
two M8 x 80mm Bolts (100), two M8 Washers
(103), and two M8 Locknuts (78). Do not tighten
the Locknuts yet.
Attach the Weight Guides (18) to the Top Frame
(4) with two M10 x 20mm Button Screws (96) and
two M10 Washers (80).
102 21
23
21
94
94 114
107
110 110
104
114
22 4
22 4

12
10. Attach the Butterfly Frame Brace (6) to the
Upright (2) with two M8 x 80mm Bolts (100), two
M8 Washers (103), and two M8 Locknuts (78).
Do not tighten the Locknuts yet.
11. Apply grease in the locations shown. Insert a
56.5mm Spacer (69) into the indicated hole in the
Leg Lever (12). Attach the Leg Lever to the Front
Leg (10) with an M10 x 61mm Bolt Set (116).
Make sure that the indicated rod is oriented as
shown.
See the left inset drawing. Attach the Lock Plate
(14) to the Front Leg (10) with the M8 x 69mm
Shoulder Bolt (87), an M8 Washer (103), and an
M8 Locknut (78).
See the right inset drawing. Insert the Lock
Plate Pin (95) through the Lock Plate (14) and the
Leg Lever (12). Attach the tether on the Lock
Plate Pin to the Front Leg (10) with an M4 x
12mm Self-tapping Screw (102).
12. Attach the Butterfly Frame (5) to the Top Frame
(4) with two M8 x 80mm Bolts (100), two M8
Washers (103), and two M8 Locknuts (78). Do
not tighten the Locknuts yet.
Attach the Butterfly Frame (5) to the Butterfly
Frame Brace (6) with an M10 x 75mm Button
Screw (118).
10
11
10
Rod
12
Hole
116
78
6
2
103
100
100
12
103
78
118
103
100
4
5
6
102
103
87
14
10
78
95
10
14
12
Arm Assembly
69
116
Grease
Grease

13
13. Apply grease to the locations shown and attach
the Left Butterfly Bracket (28) to the Butterfly
Frame (5) with an M10 x 80mm Bolt (84) and an
M10 Locknut (77).
Repeat this step for the Right Butterfly
Bracket (29).
See steps 2–13. Tighten the Locknuts (77, 78,
107).
14. Attach a Butterfly Handle (27) to the Left Butterfly
Arm (25) with an M10 x 65mm Button Bolt (106),
two M10 Washers (80), two 13mm Steel Spacers
(109), and an M10 Locknut (77).
Secure the Left Butterfly Arm (25) with an M10 x
82mm Button Screw (92) and an M10 Large
Washer (105).
Repeat this step for the Right Butterfly Arm
and Butterfly Handle (26, 27).
15. Apply grease in the locations shown and attach
the Right Butterfly Arm (26) to the Right Butterfly
Bracket (29) with an M10 x 75mm Bolt (82) and
an M10 Locknut (77). Press a Bolt Cap (44) onto
the end of the Bolt. Do not overtighten the Bolt;
the Butterfly Arm must be able to pivot easily.
Repeat this step for the Left Butterfly Arm (25).
13
14
26
27
77
80
27
80
106
109
109
5
84
77
29
28
105
92
25
15
25
29
77
82
26
44
Grease
Grease

14
16. Orient a Press Arm Handle (17) with the 90° bend
at the top as shown in the inset drawing. Attach a
Press Arm Handle (17) to the Right Press Arm
(16) with two M10 x 65mm Button Bolts (106),
four M10 Washers (80), four 11mm Spacers (99),
and two M10 Locknuts (77).
Repeat this step for the Left Press Arm (not
shown).
17. Attach the Left Press Arm (15) to the Right Press
Arm (16) with an M10 x 110mm Bolt (93), an
89.5mm Spacer (59) and an M10 Locknut (77).
Finish attaching the Press Arms with two M10 x
65mm Bolts (85), two M10 Washers (80), and two
M10 Locknuts (77). Do not tighten the
Locknuts yet.
18. Attach the Left and Right Press Arms (15, 16) to
the Base (1) with an M10 x 110mm Bolt (93), an
89.5mm Spacer (59), and an M10 Locknut (77).
Do not over tighten the Locknut; the Press
Arms (15, 16) must be able to pivot freely.
See step 17. Tighten the Locknuts (77).
17
16
15
77
77
59
93
80 85
18
16 15
77
1
106
16
99
99
99
80
80
77
99
80
80
17
16
90° Bend
90°
Bend
Grease
59 93

15
19. See the CABLE DIAGRAMS on page 28 to iden-
tify the cables as you assemble them.
Identify the Butterfly Cable (50). Grease an
M8 x 22mm Shoulder Bolt (90). Attach the Cable to
the Left Butterfly Bracket (28) with the Shoulder Bolt
and an M8 Locknut (78). Make sure that the flat
edge of the Cable is against the Butterfly Arm.
Do not overtighten the Shoulder Bolt; the Cable
must pivot easily.
20. Wrap the Butterfly Cable (50) over a V-pulley
(47). Attach the V-pulley, a Long Cable Trap (57),
an M10 Washer (80), and two Guards (54) to the
Upright (2) with an M10 x 60mm Bolt (79) and an
M10 Locknut (77).
21. Wrap the Butterfly Cable (50) under a 90mm
Pulley (48). Attach the Pulley and two Half
Guards (55) to the Double “U”-bracket (61) with
an M10 x 45mm Bolt (86) and an M10 Locknut
(77). Make sure that the Half Guards are ori-
ented as shown.
19
20
54 50
47
2
80
54
57
79
77
50
78
90 Grease
28
21
48
50
77
55
55 61
86
Cable Assembly
Flat Edge

16
22. Wrap the Butterfly Cable (50) over a V-pulley
(47). Attach the V-pulley, a Long Cable Trap (57),
an M10 Washer (80), and two Guards (54) to the
Upright (2) with an M10 x 60mm Bolt (79) and an
M10 Locknut (77).
23. Grease an M8 x 22mm Shoulder Bolt (90). Attach
the Butterfly Cable (50) to the Right Butterfly Arm
(29) with the Shoulder Bolt and an M8 Locknut
(78). Make sure that the flat edge of the Cable
is against the Butterfly Arm.
24. Identify the Lat Cable (49). Route the Cable up
through the Top Frame (4) and over a 90mm
Pulley (48). Attach the Pulley inside the Top
Frame with an M10 x 80mm Bolt (84), two M10
Washers (80), two 19mm Spacers (67), and an
M10 Locknut (77).
22
23
90 50
29
78
57
50
2
77
54
54
47
80
79
24
84 80
80
77
67
67
48 4
49
Flat Edge
Grease

17
25. Route the Lat Cable (49) over a Thin Pulley (24)
and down through the Top Frame (4). Hold the
Thin Pulley inside the Top Frame. Insert an M10 x
80mm Bolt (84) through an M10 Washer (80), a
19mm Spacer (67), the Top Frame, and the Thin
Pulley.
26. Wrap the Lat Cable (49) under a 90mm Pulley
(48). Attach the Pulley, a Cable Trap (56), and
two Half Guards (55) at the second hole from the
top of the two Pulley Plates (60) with an M10 x
50mm Bolt (97) and an M10 Locknut (77). Make
sure that the Cable Trap and the Half Guards
are oriented as shown.
27. Route the Lat Cable (49) up through the Top
Frame (4) and wrap the Cable over a Thin Pulley
(24). Pull the M10 x 80mm Bolt (84) out of the
Top Frame until it is flush with the first Thin Pulley
from step 24. Do not remove the Bolt com-
pletely from the Top Frame.
Hold the second Thin Pulley (24) inside the Top
Frame (4) and attach it with the M10 x 80mm Bolt
(84), a 19mm Spacer (67), an M10 Washer (80),
and an M10 Locknut (77).
25
26
77
55 55
49
97
4
24
84
80
67
49
60
56 48
60
27
67 77
80
84
49
24
113

18
28. Wrap the Lat Cable (49) around a 90mm Pulley
(48) and route the Cable down through the Top
Frame (4). Attach the Pulley to the Top Frame
with an M10 x 80mm Bolt (84), two M10 Washers
(80), two 19mm Spacers (67), and an M10
Locknut (77).
29. Set an M12 Large Washer (98) on top of the
Weight Tube (20). Thread the M12 ut (112) all
the way onto the Lat Cable (49).
Thread the Lat Cable (49) into the Weight Tube
(20) two turns. Tighten the M12 ut (112)
against the M12 Large Washer (98).
30. Identify the Leg Lever Cable (51). Route the
Cable through the Leg Lever (12) and the Front
Leg (10).
Insert a 90mm Pulley (48) into the Leg Lever (12)
from behind it as shown. Attach the 90mm Pulley
with an M10 x 65mm Bolt (85), two M10 Washers
(80), two 13mm Steel Spacers (109), and an M10
Locknut (77).
28
29
112
98
20
49
80
80
77
48
4
49
67
67
84
30
85
80
12
109
51
77
109
80
48
10

19
31. Attach a 90mm Pulley (48) to the Front Leg (10)
with an M10 x 65mm Bolt (85), two M10 Washers
(80), two 13mm Steel Spacers (109), and an M10
Locknut (77). Make sure that the Leg Lever
Cable (51) is under the Pulley.
32. Route the Leg Lever Cable (51) under the
89.5mm Spacer (59), through the Upright (2), and
under the indicated rod in the Base (1). Wrap the
Leg Lever Cable around a 90mm Pulley (48).
Attach the Pulley to the Base with an M10 x
45mm Bolt (86), two Half Guards (55), and an
M10 Locknut (77).
33. Wrap the Leg Lever Cable (51) over a 90mm
Pulley (48). Attach the Pulley, a Cable Trap (56),
and two Half Guards (55) to the second hole from
the bottom of the Pulley Plates (60) with an M10
x 50mm Bolt (97) and an M10 Locknut (77).
Make sure that the Cable Trap and the Half
Guards are oriented as shown.
31
32
55
59
177
51
85 80
80
77
10
109
109
48
51
Rod
33
77
55
56
55
97
60
51
48
86
55
48

20
34. Wrap the Leg Lever Cable (51) under a 90mm
Pulley (48). Attach the Pulley to the Base (1) with
an M10 x 45mm Bolt (86), two Half Guards (55),
and an M10 Locknut (77).
35. Wrap the Leg Lever Cable (51) over a 90mm
Pulley (48). Attach the Pulley to the Double “U”-
bracket (61) with an M10 x 45mm Bolt (86), two
Half Guards (55), and an M10 Locknut (77).
36. Wrap the Leg Lever Cable (51) under a 90mm
Pulley (48). Attach the Pulley to the Upright (2)
with an M10 x 120mm Bolt (115), two Half Guards
(55), an M10 Washer (80), and a Cable Trap (56).
34
35
77 61
55
55 86
51
48
1
48
55
55
77
51
86
36
115
80 48
56
2
55
55
51
