Weidmüller IE-SW-AL08M-6TX-2GT Manual

1 2 3
Hardware Installation Guide
Managed Fast/Gigabit Ethernet Switch
IE-SW-AL08M-6TX-2GT (Part No. 2682290000)
1. Introduction
Ethernet Switches from Weidmüller are designed for industrial applications and fitted with a
robust housing. To ensure reliable, error-free operation, and to prevent damage or injury, please
read the operating instructions, all safety information provided in this document and any other
safety information that were supplied with the product.
2. Safety notice
The device heats up during operation. Allow the unit to cool down or use protection
gloves when carrying out any work.
The device may only be connected to the supply voltage shown on the product label.
Higher voltage than specified will destroy the device.
The device must be supplied by a SELV source as defined in the Low Voltage
Directive 2014/35/EU and 2014/30/EU.
Installation, commissioning and maintenance may only be performed by qualified
electricians.
Observe the operating instructions.
Indoor use and pollution degree II, it must be wiped with a dry cloth for clean up
the device and label.
oUtilisation en intérieur et degré de pollution II, il faut l'essuyer avec un chiffon sec
pour nettoyer l'appareil et son étiquette.
Do not block air ventilation holes.
oNe bouchez pas les orifices de ventilation.
If the equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
oSi l’appareil est utilise d’une maniere non specifiee par le fabricant, la protection
qu’il apporte peut se voir diminuee.
Shall be mounted in the Industrial Control Panel and ambient temperature is not
exceed 75 degrees C.
oDoit être monté dans le panneau de commande industriel et la température
ambiante ne doit pas dépasser 75 degrés C.
Intended use: The device is intended for the realization of communication networks within an
industrial environment, it is intended to be used in a restricted access location. The device
may only be used within the scope of the specified technical data. The device is intended to
be mounted to a well-grounded mounting surface, such as a metal panel. Any other use may
result in unintentional malfunction and damage. Observing documentation is part of the
intended use.
Environmental conditions: This equipment is intended to be used in a restricted access
location. When planning the installation site make sure that the ambient temperature during
operation will not exceed the temperature given in the technical data. Also make sure that the
air flow will not be compromised by other devices. Ensure that the mounted and wired device
is not exposed to any mechanical stress.
FCC compliance: This device complies with part 15 of FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
3. Package Checklist
Your Ethernet Switch is shipped with the following items:
Ethernet Switch
Hardware Installation Guide (printed)
7-Pin Terminal connector
Serial console cable
Protective caps for RJ45 ports
4. Panel Layouts
1. Power Input LEDs (PWR1 / PWR2)
2. Ring Master Status LED
3. Ring Status LED
4. Fault LED (PWR1/PWR2 fault or port link
loss)
5. Serial Console Port
6. Reset Button
7. 10/100BASE-T(X) Ports
8. Article Number
9. 10/100/1000BASE-T(X) Port
10. Port Speed LEDs 10/100/1000BASE-T(X)
ports
11. Link/Activity LEDs 10/100/1000BASE-T(X)
ports
12. Link/Activity LED 10/100BASE-T(X) port
13. Duplex mode LED 10/100BASE-T(X) port
(Amber = Full Duplex, OFF=Half Duplex,
Blinking = Collisions)
14. Terminal block for power input PWR1 /
PWR2 and failure relay for power and port
link loss (output)
15. DIN-Rail kit
5. DIN-Rail Mounting
Slide the switch onto a DIN-rail and make sure that the switch’s Din-rail clip clicks into
the rail firmly.
STEP 1: Place the mounting clip
from above onto the mounting rail.
STEP 2: Press the device against
the DIN rail until the fastening
element engages on the mounting
rail.
To remove the Ethernet Switch from
the DIN-rail pull down the latch with
a screwdriver then move the device away from the DIN rail and lift it up.
6. Mounting Dimensions (units = mm)
7. Grounding Ethernet Switch
ATTENTION
- Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI).
- the ground connection from the ground screw to the grounding surface
prior to connecting devices.
- This product is intended to be mounted to a well-grounded mounting
surface, such as a metal panel.
- The shielding ground of the RJ45 ports are electrically connected to the
ground connection (screw).
8. Wiring Redundant Power Inputs and Fault Alarm
Relay
The switch supports redundant power supply inputs and provides a fault alarm relay for
detecting the user-configurable failure events
Interruption of Power 1 or Power 2 and
Link Loss of Ethernet Ports.
Refer to illustration below for correct wiring.
Warning / Avertissement
Take into consideration the following guidelines before wiring the device.
oTenez compte des directrices suivantes avant de câbler l’appareil.
Terminal block is mating with Plug and suitable for 12-24AWG. Torque
value 4.5 lb-in.
oLe bornier est compatible avec les connecteurs et convient pour 12-
24AWG. Valeur de couple 4,5 lb-in.
The temperature rating of the input connection cable should higher than
105°C.
oLa température de service nominale du câble d’entrée doit être supérieure
à 105 °C.
Supplied by SELV source evaluated by UL 61010-1 or 61010-2-
201 power
supply only.
oFourni par la source SELV évaluée uniquement par l'alimentation UL
61010-1 or 61010-2-201.

4 5 6 V1.1 / 2020-12-29
Behavior of fault alarm relay (can be triggered by configurable events power
failure or port link down):
Relay contact is closed if the device is powered-off.
Relay contact is open if the device is powered-on and no alarm conditions exist
(neither Power Failure Alarms nor Port Link Loss Alarms are activated (Web menu
Warnings Fault Relay Alarm).
Relay contact closes if any of an activated alarm condition happens.
9. Communication Connections
Switch IE-SW-AL08M-6TX-2GT is equipped with:
6 x 10/100BASE-T(X) Ethernet ports (Auto MDI-X)
2 x 10/100/1000BASE-T(X) Ethernet ports (Auto MDI-X)
Please only use cables suitable for the respective type of communication and ensure
that signals are protected from possible interference.
9.1 10/100BASE-T(X) and 10/100/1000BASE-T(X) RJ45 Ports
The RJ45 ports located on Ethernet Switch’s front panel are used to connect to
Ethernet-enabled devices. Below we show pinouts for both MDI (NIC-type) ports and
MDI-X (HUB/Switch-type) ports. Auto MDI-X ensures that both wiring-schemes are
supported (Automatic crossover function).
10/100BASE-T(X) RJ45 Pinouts
MDI Port Pinouts MDI-X Port Pinouts 8-pin RJ45
Pin Signal Pin Signal
1 Tx+ 1 Rx+
2 Tx- 2 Rx-
3 Rx+ 3 Tx+
6 Rx- 6 Tx-
10/100/1000BASE-T(X) RJ45 Pinouts
8-Pin RJ45
Port
10/100BASE-T(X) MDI/MDI-X 1000BASE-T MDI/MDI-X
Pin No. MDI port MDI-X port Pin No. MDI port MDI-X port
1 TD+(transmit) RD+(receive) 1 BI_DA+ BI_DB+
2 TD-(transmit) RD-(receive) 2 BI_DA- BI_DB-
3 RD+(receive) TD+(transmit) 3 BI_DB+ BI_DA+
4 Not used Not used 4 BI_DC+ BI_DD+
5 Not used Not used 5 BI_DC- BI_DD-
6 RD-(receive) TD-(transmit) 6 BI_DB- BI_DA-
7 Not used Not used 7 BI_DD+ BI_DC+
8 Not used Not used 8 BI_DD- BI_DC-
9.2 RS232 Console Port
The RS232 Interface with RJ45 connector can be used to access the switch console for
configuration.
Pinouts Serial
Console Port:
10. User Management
10.1 Device Access (Login to Web Interface)
The Web interface of the Switch can be accessed via following factory default settings:
IP address / Netmask: 192.168.1.110 / 255.255.255.0
User name: admin
Password: Detmold
Connect the PC to any Ethernet port of the managed Switch and set the PC’s IP
address to a free one of range 192.168.1.0 / 255.255.255.0
Start a web browser and enter the IP address of the connected Switch into the
browser’s address line (http://192.168.1.110). After the appearance of prompt (login)
enter the login credentials. After confirmation of your input with "OK" the home page of
the switch will be displayed.
Note: For more detailed information about configuration and use of the device features
please read the downloadable manual from Weidmüller’s website (Product catalogue 
Automation & Software Industrial Ethernet Advanced Line managed Switches 
Select Product Click and expand section „Downloads“ Download needed software
or documentation).
10.2 Reset Button
Press reset button for 2 to 3 seconds to reboot the switch (Warm Start).
Press reset button for >= 5 seconds to reset the switch to factory default settings.
11. LED Indicators
The front panel of the Ethernet Switch contains several LED indicators. The function of
each LED is described in the table below.
LED Color Status Description
PWR1 Green On Power supplied to power input PWR1.
PWR2 Green On Power supplied to power input PWR2.
R-MSTR
(Ring Master) Green On Is Ring Master of an enabled O-Ring.
Ring Green On O-Ring redundancy is enabled.
Blinking Ring structure is broken (No redundancy).
FAULT Amber On Fault Relay indication for Power failure and
Port link loss.
LNK/ACT
(Ports 1 - 6) Green
On Port’s link is active.
Off Port’s link is inactive.
Blinking Data is transmitted.
Full / Half
Duplex
(Ports 1 - 6)
Amber
On Port is set to Full Duplex Mode.
Off Port is set to Half Duplex Mode.
Blinking Packet collisions detected.
LNK/ACT
Ports G1/G2 Green
ON Port’s link is active.
OFF Port’s link is inactive.
Blinking Data is transmitted.
Speed
Indication
(OFF / ON)
Ports G1/G2
Amber
On Port speed is 100 Mbps
Off Port speed is 10 or 1000 Mbps
12. Specifications
Technology
Ethernet Standards
IEEE 802.3 for 10BASE-T
IEEE 802.3u for 100BASE-TX
IEEE 802.3ab for 1000BASE-T
IEEE 802.3x for flow control
IEEE 802.3ad for port trunk with LACP
IEEE 802.1D for STP (Spanning Tree protocol)
IEEE 802.1w for RSTP (Rapid Spanning Tree protocol)
IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol)
IEEE 802.1p for Class of Service
IEEE 802.1Q for VLAN Tagging
IEEE 802.1x for Authentication
IEEE 802.1AB for LLDP (Link Layer Discovery Protocol)
Processing Type Store and Forward
MAC Table size 8K
Packet buffer size 1 Mbit
Backplane bandwidth 5.6 Gbps
Interfaces
RJ45 Ports
6 x 10/100BASE-T(X); 2 x 10/100/1000BASE-T(X)
Each port with auto negotiation speed, F/H duplex mode
and auto MDI/MDI-X connection, F/H duplex mode and
auto MDI/MDI-X connection
RS232 Console Port RS232 Interface with RJ45 connector for console access
LED Indicators PWR1, PWR2 (Power), Fault (Relay), Ring Master/Status,
Port Link/Activity, Port Full/Half Duplex Mode
Relay Contact Max. 1A @ 24 V DC
Power
Input Voltage 24 V DC (12 - 48 V DC), 2 redundant inputs
Current Consumption 0.83 A @ 12 V DC; 0.41 A @ 24 V DC; 0.19 A @ 48 V DC
Connection One removable 7-pin terminal block, Wiring cable 12-
24AWG
Overload Current Protect. Present
Reverse Polarity Protect. Present
Physical Characteristics
Housing IP30 protection, metal
Dimension (W x H x D) 54.2 x 145.4 x 107.1 mm (2.13 x 5.72 x 4.21 inch)
Weight 789 g
Installation DIN-rail
Environmental conditions
Operating Temperature -40 to 75°C (-40 to 167°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity 5 to 95% (non-condensing)
Operating Altitude Up to 2000 m
Regulatory Approvals
Safety EN 62368-1; UL 61010-1; UL 61010-2-201
EMC
EN 55032, EN 55024, FCC Part 15 Subpart B Class A,
IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV,
IEC 61000-4-3 RS: 80 MHz to 1 Ghz: 3 V/m,
IEC 61000-4-4 EFT: Power: 0.5 kV; Signal: 0.5 kV,
IEC 61000-4-5 Surge: Power: 0.5 kV; Signal: 1 kV,
IEC 61000-4-6 CS: 3 Vrms
Shock IEC 60068-2-27
Free Fall IEC 60068-2-31
Vibration IEC 60068-2-6
MTBF
Time 798.350 hrs
Database Telcordia SR332
Warranty
Time Period 5 years
Contact Information
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 26, 32758 Detmold / Germany
Phone [phone], Fax [phone]
E-Mail [e-mail], Internet www.weidmueller.com
