Wellcare FE-4611 User manual

AIR PRESSURE
EYE CARE MASSAGER
E209
Model Number FE-4611
USER MANUAL

2
2
Contents
03 Important Safety Instructions
06 Product Overview
07 Operation
08 Specifications

3
3
Important Safety Instructions
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with this
type of product. The safety precautions enclosed herein reduce the risk of fire,
electric shock and injury when correctly adhered to. Make sure you understand
all instructions and warnings. Keep the manual in a safe place for future
reference, along with any warranty information, your purchase receipt and the
original packaging carton. If you sell or transfer ownership of this product, pass
on these instructions to the new owner of the product.
Always follow basic safety precautions and accident prevention
measures, including the following:
Usage conditions and restrictions
• This product is intended for private use by adults only. It is not suitable for
commercial or trade use. Do not use it for anything other than its intended
purpose, and only use it as described in this manual.
• CAUTION: Avoid leaving your device in direct sunlight, near to heat or
boiling water.
• Do not use the device if you have swelling, or have had surgery, sunburn or
other skin problems.
• Take glasses, false eyelashes and contact lenses off before using.
• Do not share the same device.
• Do not power it on when charging.
• Do not disassemble the device by yourself.
• Do not immerse the device in water.
• This product is not a medical device and should not be used to treat
medical conditions
• If at any time you feel discomfort or skin irritation, please immediately
stop using the product.
• If you experience any pain or side effects after using the product, please
immediately see a doctor.
• This product must only be used indoors

4
4
Important Safety Instructions (Cont.)
Care, cleaning and storage
• Before cleaning or maintaining, make sure it is disconnected.
• Only clean the housing with a soft, dry or slightly damp cloth. Do
not use liquid or aerosol cleaners. Do not use solvent or oil-based
vibration ball.
• Do not use chemical, steel wool or abrasive cleaners to clean the
outside as these chemicals may damage the silicon head.
• Store the appliance in a cool and dry indoor area, disconnected from
the power supply and out of direct sunlight.
Electrical safety (charging)
• WARNING: Only use the supplied USB cable to charge the
appliance. Using the wrong charger can cause fire or explosion of the
battery.
• Connection/disconnection: To connect the battery charger,
insert the power plug rmly into an appropriate mains socket. To
disconnect, grip the power plug rmly and remove it from the outlet,
do not pull on the cord.
• Do not leave the adaptor plugged in when the device is fully
charged. When unplugging, grab the plug, do not pull the cord. Do
not use or charge the product if you notice anything wrong with the
battery.
• The battery is not exchangeable
• Charging: When charging the appliance, place it on a at surface,
away from hot surfaces and close to a power point so no one trips
over the cord. Do not leave the appliance charging or operating
unsupervised. Do not attempt to use the device while it is being
charged.
• Protect the USB charging cable: Do not kink, strain or damage
the charging cable and protect it from sharp edges and heat. A
damaged charging cable must be replaced by a new one.

5
5
Important Safety Instructions (Cont.)
• Note: Supervision is necessary if you are using your device around
children or infants.
• Do not use on children and keep out of reach of children.
• This device is not suitable for use by persons with reduced
physical, sensory or mental capabilities.
• Ensure to adjust the elastic to a suitable tightness to secure the
product.
• It is suggested to sit or lie on a chair or sofa during use for
maximum comfort.
• Use this device a maximum of once or twice per day, for no longer
than 10-20 minutes.
• Do not open your eyes while the device is in use.
• Always charge the device after use.
• Clean the surface of the device with a towel or cotton ball, using
75% medical alcohol.
• Do not place or use the device near a fire, corrosive liquids, or other
adverse environments.
It is recommended to consult your doctor before using this device if you:
• Are pregnant
• Are short-sighted over -6.00 dioptres
• Have serious glaucoma or cataracts
• Are under 7 years old
• Have a sequela of apoplexy
• Have an eye injury, or are in the period of rehabilitation from any serious
eye surgery.
• Are suffering from serious eye inflammation.

6
6
Product Overview
1 2 3
5
4
6
7
1 Power/Mode button: press and hold to turn on/off. Press to switch
modes.
2 USB-C charging port: connect the supplied USB-C charging cable
and the other to a 5V power adaptor (not included) to charge the
device.
3 Pressure indicator
4 Music indicator
5 Battery status indicator: LED will flash and a voice notifiation will
be heard when there is no battery. LED will flash slowly when
charging and the LED will light up when fully charged.
6 Vibration indicator
7 Hot compress indicator

7
7
Operation
Charging the device
• Connect the supplied USB-C charging cable to the USB-C charging
port on the device, and the other end to a 5V power adaptor (not
included).
• When charging, the battery status indicator will flash slowly. The
indicator will light up white once fully charged.
• Press and hold the Power/Mode button to turn on the device.
• Press the Power/Mode button repeatedly to select between
the different modes to best suit your needs. There are 4 modes
available.
Mode Pressure Hot Compress Vibration Internal Music Time (min)
Vitality Yes Ye s Yes Yes 10
Relaxation Yes Yes No Yes 15
Soothing Yes Yes No No 15
Sleep Yes No No Ye s 20
Note: the device will automatically power off when the operation time is
finished.
Troubleshooting
If the device does not work, check and ensure that it is fully charged. If
the product is still not working, please call our after sales support centre.
Do not attempt to open and repair the product yourself.

8
8
Compliance
This appliance has been fully tested and meets all requirements as set
out by standards AS/NZS 60335.2.32 for electrical safety.
The RCM Mark (Regulatory Compliance Mark) indicates that the product
complies with the relevant guidelines of the ACMA as well as corresponding
government requirements for the safety of electrical devices.
E209
Specifications
Battery Lithium 3.7V, 1200mAh
Charging voltage and current DC 5V, 1A
Max. power consumption 5W
Hot compression temperature (C) 42+/-2
Weight 275g (approx.)
Dimensions (W x H x D) (mm) 210 x 75 x 130
For Technical and Warranty Support
1300 886 649
tempo.org/support
Distributed by Tempo (Aust) Pty Ltd,
PO Box 132, Frenchs Forest NSW 1640

9
9
Responsible disposal
WARNING! This product contains a rechargeable lithium-ion battery.
Never throw the appliance into a fire and do not subject it to high
temperatures. There is a risk of explosion!
At the end of its working life, do not throw this appliance out with
your household rubbish. Electrical and electronic products contain
substances that can have a detrimental effect on the environment and
human health if disposed of inappropriately.
Cut the power cord of the battery charger and remove the lithium-
ion battery pack from the appliance before disposal. Dispose of the
appliance and the battery pack responsibly, observing any local
regulations regarding the disposal of consumer goods and batteries.
Contact your local authorities for advice on battery disposal and
recycling facilities for electrical consumer goods.

10
10
Notes

11
11
Notes

12
Warranty returns
Should you for any reason need to return this product for a warranty
claim, make sure to include all accessories with the product.
Product does not work?
If you encounter problems with this product, or if it fails to perform to your
expectations, make sure to contact our After Sales Support Centre on
(AU) 1300 886 649 or (NZ) 0800 836 761 for advice.
Distributed by Tempo (Aust) Pty Ltd ABN 70 106 100 252
PO BOX 132 Frenchs Forest, Australia NSW 1640
Customer Helpline:
(AU) 1300 886 649 (NZ) 0800 836 761
Email: tempo.org/support
