Wellclima WellSmart User manual

Modalità
Mode Status
Temperatura
Temperature
Direzione dell’aria
Wind Direction
Livello carica Batteria
Battery level
Luce
Light
Modo
Mode
Alimentazione 2
Power port 2
Regolazone Direzione Aria
Manual Wind Direction
DirezioneAutomaticaAria
Automatic Wind Direction
Blocco Codici
Child lock
Fahrenheit
Celsius
Velocità dell’aria
Air speed
Codice selezionato
Present code
On/Off
Controllo VelocitàAria
Air Speed Control
Tasto SET
SET button
Indicazione WiFi
WiFi Status
Temperatura +
Temperature +
Temperatura +
Temperature +
Power On/Off
Posizionare il telecomandosulla base di alimentazione.
Place the remote control on the power base.
Collegare il cavo di alimentazione alla base.
Plug the power cord into the base power inlet.
Collegare il cavo di alimentazione alla presa di corrente.
Plug the power adaptor into the power outlet.
Per caricare il telecomando - To charge the remote control
Accendere il telecomando con il cursore sul lato destro e collegare il cavo di alimentazione alla base per caricare la batteria.
Please switch on the Power on the right side of the remote control and connect the power cord according to the above diagram to charge
the battery.
Telecomando universale per condizionatori
Universal air conditioner remote control
1

AUTOMATIC CODE SEARCH
1. Connected to www.wellclima.com website, nd air conditioner brand in the‘CODE LIST’of SMART
model and check the rst set of codes.
2. Press and hold SET button, then press POWER button and hold them down. Release the two buttons
when the model code ashes on the screen window (bottom right). Press ‘TEMP▲’or ‘TEMP▼’ until the
code found in Step 1 appears on the screen window (you can keep the TEMP keys pressed to scroll the
codes faster).
3. Press the SET button to exit, check the button functions. If the device respond correctly the setting
is nished, if not, please repeat steps 2 and 3 with next set of codes.
LOOK OUT: when the codes are separated by a - sign it means all the numbers between the rst and the
last (es LG 600-609 you have to test codes 600, 601, 602.....>609). If none of the codes work with your air
conditoner or if your brand is not in the list don’t worry, proceed with the Automatic Code Search.
1. Aim the remote towards the air conditioner receiver window.
2. Press and hold SET button, about 6 seconds later the model code (bottom right) starts to ash, do not
release the button until the air conditioner switches on automatically.
3. Release the SET button immediately when the conditioner turns on and check the button functions.
If the buttons work correctly, the code setting is eective. If not, please repeat steps 2 and 3.
4. A complete scan of all codes takes about 30 minutes. Do not stop the search before, or before the air
conditioner switches on.
The remote control can be set to 3 dierent modes. Choose mode 1 if the brand of your
air conditioner is among those in the image below, or modes 2 or 3 for all other brands.
▲
SETTING REMOTE CONTROL 2

DOWNLOAD AND INSTALL THE REMOTE CONTROL APP
We use the Genius Remote app to manage the remote control by smartphone.
Remember that the SMART remote control connects to the Wi-Fi network when it is placed
in its own base and / or connected to the power supply.
1. Find "Genius Remote" in the App Store or in Google Play or scan the QR code to download and
install the app.
2. Register your account in the Welcome screen (REGISTER link at the bottom right).
3. Choose your account name and password, enter your email address and register.
The e-mail address is only for password recovery.
4. Make sure that your mobile phone is connected to the Wi-Fi network and connect the remote control to the power supply base.
5. Tap on Add Device > A/C Remote Control.
6. Press and hold the remote control “On/O” button (for about 5s) and release it when
appears on the screen. After some time, the Wi-Fi icon ( ) will ash rapidly (bottom left), and the remote control will enter the
conguration mode.
7. At the next step you should see the name of your network. Enter the network password and touch [conguration]. After a few seconds the
remote control code will appear with the word ON LINE on. If you want to change and customize the name of the remote control, tap on
EDIT. To enter the screen, tap on the name of the remote control, now you can control the air conditioner with the APP.
8. TIMER - Entering the TIMER function and touching the +(top right) it is possible to add dierent ON / OFF programs for each day of the week.
3

Q: Cannot configure or no response during the configuration?
A: PleasecheckiftheWi-Firoutercanaccessthenetwork. Pleaseplacetheremotecontrolintothepowersupplybase; theremotecontrolcanbeonlyusedasauniversalremote
controlifitisnotplacedintothepowersupplybase;Wi-Fi remotecontrolfunctionisavailableonlyaftertheremotecontrolisplacedintothepowersupplybase.
Q: Failed-Config?
A: PleasechecktherouterWi-Fisignalstrengthandifnetworkspeedisnormal,thentrytoreconfigure.Pleaseplacetheremotecontrolintothepowersupplybase,andcheckifthe
remotecontrolscreendisplaysWi-Fiicon.
Q: Cannot control the A/C with remote control after successful configuration?
A: Pleasesetthecodeontheremotecontrolagain.ConfirmthattheremotecontrolcancontroltheA/Candthatthecodedisplayedintheremotecontrolmatcheswiththatdisplayedin
theAPP(lowerleft). Ifnotwork youmayneedtosettheremotecontrolagain;
Q: The APP displays device offline?
A: Pleaseplacetheremotecontrolintothepowersupplybase,andcheckiftheremotecontrolscreendisplaysWi-Fiicon( ).PIeasecheckiftheconnectedWI-FIrouterworks
normally.
Q: How can you know if the remote control is successfully connected to Wi-Fi?
A: TheAPPwilldisplaydeviceonlineandtheWi-Fiicon( )ontheremotecontrolscreenwillstayonwhentheremotecontrolsuccessfullyconnectstotheWi-Firouter.Wi-Fi
functionwillbeautomaticallydisabled(Wi-Fi icononremotecontrolscreenwilldisappear)whentheremotecontrolisdisconnectedfromthepowersupplybase.Wi-Ffunctionwill
beautomaticallyenabled(Wi-Fi icononremotecontrolscreenwillappear)whentheremotecontrolisconnectedtothepowersupplybase.
Q: Can the SMART remote control work without the power supply station?
A: TheSMARTremotecontrolcancontroltheairconditionerwithoutusingthesupportbase,butitconnectstothewi-finetwork (andtoyoursmartphone)onlywhenitispoweredby
thebase.Ifyouhavedifficultyplacingthebaseinasuitablepositionorwanttouseanothersupporttype,youcaninsertthechargermicrousbconnectordirectlyontheleftsideof
theSMARTremotecontrol.
Q: How long is the automatic code search?
A: itdependsontheairconditionerbrandandmodel,oftenjustafewminutesareneeded,butafullscanofallthecodestakesabout30minutes.Donotstopthesearchbeforeor
beforetheairconditionerturnson.
Tips:
Afterreplacingtherouterorrestoringtheroutertofactorysettings,youmustreconfigurethedevicebyfollowingtheAdddevicestepontheAPP.
1-3sdelayduringremotecontroloperationbymobilephoneisnormal.Ifthereisaprolongeddelayorthereisnoresponse,pleasetestiftheWi-Rnetworkconnectionspeed
ofthemobilephoneandrouterarenormal.
YoumustpointtheremotecontrolattheA/Creceiverwindow.
PleasedonotdisassembletheremotecontrolbyyourselforthrowitinfireasithasaninbuiltIithiumbattery.
Pleasekeeptheremotecontrolawayfromheatandfire,andpleasedonotletchildrenusethechargerwithoutadultsupervision,astheremaybepotentialsafetyhazards.
Itisrecommendedtochargewithambienttemperaturebelow40°CThebatterywillslightlyheatupwhenfullycharged,whichisnormal.
PleaseswitchoffthePowerontherightsideoftheremotecontroIifyoudonotplantousetheremotecontroIforalongtime.
Thisremote controlis compatible with 99% of brand ofair conditioners,we performcompatibility testswith thevarious brands and thecodes areconstantly updated. It can
operateonly ifthe air condiotioner receiver works well. Tocheck ifthe newremote works(or eventhe old one) we suggest you to do this test: frame the ledthat youfind on
thetop edgewith a digital camera or a smartphone(not iphone),press theon-off buttonseveral times,through the camera you will seethe LED light up slightly. If theled
turnson theremote control transmits, if you have triedthe varioussetup methodsand theair conditionerhas never turned on it isprobable that the problem is in thereceiver
insidethe controlunit, in this case you must contactthe service.If youfind anyother problemsor remote control cannot be usedappropriately, pleasevisit HELP and FAQs
pageon ourwebsite www.wellclima.com or contact us and we willprovide ourbest servicefor you.
4

Puoi visualizzare o scaricare le istruzioni in Italiano di questo
prodotto all’indirizzo: https://wellclima.com/manuali/
o con la scansione di questo QRcode
You can view or download english instructions
for this product at: https://wellclima.com/en/manuals/
or by scanning this QR code
Vous pouvez afficher ou télécharger les instructions
en français concernant ce produit à l'adresse suivante:
https://wellclima.com/fr/manuels/
ou en scannant ce QRcode
Puedes visualizar o descargar las instrucciones en español de
este producto en la dirección:
https://wellclima.com/es/manuales/ o con el barrido de este QRcode
Eine Anleitung in deutscher Sprache zu diesem Produkt
können Sie unter der folgenden Adresse:
https://wellclima.com/de/handbuecher/
oder durch Scannen dieses QR-Codes einsehen oder
herunterladen
IT
EN
FR
ES
DE
Ai sensi della direttiva 2012/19/EU D.L. N°49/2014 Multiservizi (proprietaria del marchio wellclima) in qualità di fornitore del prodotto da la seguente informativa: è fatto obbligo di non smaltire i RAEE come rifiuti urbani e di
effettuare una raccolta separata. Alla riconsegna dell’apparecchio per l’acquisto di uno nuovo il produttore stesso provvederà al reimpiego, riciclaggio od altre forme di recupero a mezzo delle misura adottate dalla pubblica
amministrazione. Tale informativa è data al fine di evitare gli effetti potenziali sull’ambiente e sulla salute umana dovuti alla presenza di sostanze pericolose nelle apparecchiature elettroniche o ad un uso improprio delle stesse;
pertanto ogni apparecchio venduto è soggetto alla presente informativa e sarà contrassegnato dai simboli sotto indicati.
In compliance with directive 2012/19/EU D.L. N°49/2014 Multiservizi (owner of wellclima brand) being the suppliers of this products issues the following information: it is mandatory not to dispose of the RAEE as if they were
urban waste, but to carry out a separate collection of them. When delivering the equipment upon purchase of a new one, the same manufacturer shall provida in re-using, recycling it or other forms of recycle through measures
implemented and approved by the public administrations. Such information is supplied in order to prevent potential effects on the enviroment and human healt due to the presence of dangerous substances in electronic
equipments or due to an improper use of the same. Therefore every electronic equipment sold shall subject to this directive and shall be marked with the symbol shown here below.
Tutti i diritti riservati - Copyright Multiservizi
Vietata la riproduzione parziale o totale di questo manuale.
Importato da Multiservizi - Capriano del Colle - BS - Italy
Disegni ed informazioni possono variare senza preavviso.
All rights reserved - Copiright Multiservizi
Unauthorized reproduction of all or part of this guide are prohibited.
Imported by Multiservizi - Capriano del Colle - BS – Italy
Design and techincal parameters may vary without notice.
