USERʼS MANUAL
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Model No. WLCCEX31910.0
Serial No.
Write the serial number in the
space above for reference.
www.weslo.com
QUESTIONS?
If you have questions, or if parts
are damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-936-4266
Mon.–Fri., 7:30 until 16:30 ET
(excluding holidays)
OR E-MAIL US:
[email protected]

2
TABLE OF CONTENTS
WARNINGDECA P ACEMENT ..............................................................2
IMPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
ASSEMB Y ...............................................................................5
HOWTOUSETHEEXERCISEBIKE .........................................................11
MAINTENANCEANDTROUB ESHOOTING ...................................................18
EXERCISEGUIDE INES ...................................................................19
PART IST ..............................................................................22
EXP ODEDDRAWING ....................................................................23
ORDERINGREP ACEMENTPARTS ..................................................BackCover
IMITEDWARRANTY ..............................................................BackCover
WARNING DECAL PLACEMENT
This drawing shows the location(s) of
the warning decal(s). If a decal is
missing or illegible, call the tele-
phone number on the front cover of
this manual and request a free
replacement decal. Apply the decal
in the location shown. Note: The
decal(s) may not be shown at actual
size.

3
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your exercise bike before using your exercise bike.
ICON assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. Use the exercise bike only as described in
this manual.
3. It is the responsibility of the owner to ensure
that all users of the exercise bike are ade-
quately informed of all precautions.
4. The exercise bike is intended for home use
only. Do not use the exercise bike in a com-
mercial, rental, or institutional setting.
5. Keep the exercise bike indoors, away from
moisture and dust. Place the exercise bike
on a level surface, with a mat beneath it to
protect the floor or carpet. Make sure that
there is at least 2 ft. (0.6 m) of clearance
around your exercise bike.
6. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
7. Keep children under age 12 and pets away
from the exercise bike at all times.
8. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the exercise bike. Always wear
athletic shoes for foot protection.
9. The exercise bike should not be used by
persons weighing more than 250 lbs.
(113 kg).
10. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
11. The exercise bike does not have a free
wheel; the pedals will continue to move until
the flywheel stops. Reduce your pedaling
speed in a controlled way.
12. Always keep your back straight while using
the exercise bike; do not arch your back.
13. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
IMPORTANT PRECAUTIONS

4
Thank you for selecting the new WES O PRO™
10.8X exercise bike. Cycling is an effective exercise
for increasing cardiovascular fitness, building
endurance, and toning the body. The 10.8X exercise
bike provides a selection of features designed to make
your workouts at home more effective and enjoyable.
For your benefit, read this manual carefully before
you use the exercise bike. If you have questions
after reading this manual, please see the front cover
of this manual. To help us assist you, note the product
model number and serial number before contacting
us. The model number and the location of the serial
number decal are shown on the front cover of this
manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Seat
Adjustment Knob
Pedal/Strap
Console
Pulse Sensor
Wheel
Fan
Handlebar
BEFORE YOU BEGIN

5
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise bike in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver and an
adjustable wrench .
As you assemble the exercise bike, use the drawings below to identify small parts. The number in parentheses
below each drawing is the key number of the part, from the PART IST near the end of this manual. The number
following the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check
to see if it has been preassembled.
M10 Locknut
(63)–4
M8 Locknut
(60)–4
M8 Split
Washer (59)–5
M6 Washer
(55)–8
M8 x 25mm Button
Screw (33)–3
M8 x 70mm Button
Bolt (54)–2
M6 Locknut
(72)–4
M10 x 75mm Carriage Bolt (51)–4
M6 x 42mm Button
Screw (49)–4
M6 x 38mm Patch
Screw (48)–4
M6 x 38mm Button
Bolt (69)–4
M4 x 16mm
Screw (52)–4

6
1.
While another person lifts the front of the Frame
(1), attach the Front Stabilizer (3) to the Frame
with two M10 x 75mm Carriage Bolts (51) and
two M10 ocknuts (63).
3
51
1
1
3. Attach the Wheels (18) to the Rear Stabilizer (4)
with two M8 ocknuts (60). Then, press a
Wheel Cap (19) onto each Wheel.
Attach the Rear Stabilizer (4) to the Rear Frame
(2) with two M10 x 75mm Carriage Bolts (51)
and two M10 ocknuts (63).
2. Slide the Rear Frame (2) partway out of the
Frame (1), and then tighten the Adjustment
Knob (17) into the Frame.
51
18
4
18
19
63
63
60
2
63
17
2
1
To make assembly easier, read the
information on page 5 before you begin.
2
3

7
5. Attach the Backrest (5) to the Seat Frame (7)
with four M6 x 38mm Patch Screws (48) and
four M6 Washers (55). Do not tighten the
Patch Screws yet.
5
5
7
55
55
48
48
4. Attach the Seat Frame (7) to the Handlebar (6)
with two M8 x 70mm Button Bolts (54), two M8
Split Washers (59), and two M8 ocknuts (60).
Do not tighten the Button Bolts yet.
7
6
60
54
59
59
4

8
7
Battery Cover
Batteries
16
7. The Console (16) can use four 1.5V D batteries
(not included); alkaline batteries are recom-
mended. IMPORTANT: If the Console has
been exposed to cold temperatures, allow it
to warm to room temperature before insert-
ing batteries. Otherwise, you may damage
the console displays or other electronic
components. Remove the battery cover, insert
the batteries into the battery compartment, and
then reattach the battery cover. Make sure to
orient the batteries as shown by the diagram
inside the battery compartment.
To purchase an optional power adapter, call
the telephone number on the cover of this
manual. To avoid damaging the console, use
only a manufacturer-supplied power adapter.
Plug one end of the power adapter into the jack
on the console; plug the other end into an outlet
installed in accordance with all local codes and
ordinances.
12
55
55
55
7
6
49
2
49
6. Have another person hold the Seat Frame (7)
under the Rear Frame (2) as shown.
Attach the Seat Frame (7) and the Seat (12) to
the Rear Frame (2) with four M6 x 42mm Button
Screws (49) and four M6 Washers (55).
See step 4. Tighten the two M8 x 70mm Button
Bolts (54).
See step 5. Tighten the four M6 x 38mm Patch
Screws (48).

9
9. While another person holds the Console (16)
near the Upright (13), connect the console wire
to the Upper Wire Harness (36). Then, connect
the console pulse wires to the Pulse Wires (71).
Insert the excess wire downward into the
Upright (13).
Tip: Do not pinch the wires. Attach the
Console (16) to the Upright (13) with four M4 x
16mm Screws (52).
9
16
Console
Wire
Pulse Wires
52
13
36
71
8. Identify the eft Pulse Bar (65), which is marked
with a “ eft” sticker.
Have another person hold the eft Pulse Bar
(65) near the left side of the Upright (13). Make
sure that the hexagonal holes are in the indi-
cated location.
Insert the left Pulse Wire (71) into the Upright
(13), and pull it upward out of the top of the
Upright.
Tip: Do not pinch the wires. Slide the eft
Pulse Bar (65) onto the Upright (13). Attach the
eft Pulse Bar with two M6 x 38mm Button
Bolts (69) and two M6 ocknuts (72). Make
sure that the Locknuts are in the hexagonal
holes.
Repeat this step for the Right Pulse Bar (66).
8
65
13
66
69
71
71
36
72
Avoid pinching
the wires
Avoid pinching
the wires
Hexagonal
Holes

10
11
25
24
Tab
31
11. Identify the eft Pedal (24), which is marked
with a “ eft” sticker. Firmly tighten the eft
Pedal counterclockwise into the left arm of the
Crank (31).
Tighten the Right Pedal (not shown) clockwise
into the right arm of the Crank. IMPORTANT:
Tighten both pedals as firmly as possible.
After using the exercise bike for one week,
retighten the pedals. For best performance,
keep the pedals tightened.
Adjust the eft Pedal Strap (25) to the desired
position, and press the end of the eft Pedal
Strap onto the tab on the eft Pedal (24).
Adjust the Right Pedal Strap (not shown) in
the same way.
12. Make sure that all parts are properly tightened before you use the exercise bike. Note: Some hardware
may be left over after assembly is completed. Place a mat beneath the exercise bike to protect the floor.
13
36
10
10. While another person holds the Upright (13)
near the Frame (1), connect the Upper Wire
Harness (36) to the ower Wire Harness (8).
Tip: Do not pinch the wires. Slide the Upright
(13) onto the Frame (1).
Attach the Upright (13) with three M8 x 25mm
Button Screws (33) and three M8 Split Washers
(59).
8
33
33
59
59
1
Avoid pinching
the wires
