Weslo Pro Crosswalk 7.8 Treadmill User manual

Model No. WLTL37308.1
Serial No.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. f you have
questions, or if parts are missing,
DO NOT CONTACT THE STORE;
please contact Customer Care.
IMPORTANT: You must note the
product model number and ser-
ial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-866-699-3756
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.wesloservice.com
Serial Number
Decal
www.weslo.com
USER'S MANUAL
Write the serial number in the space
above for future reference.

TABLE OF CONTENTS
WARNNGDECALPLACEMENT ..............................................................2
MPORTANTPRECAUTONS .................................................................3
BEFOREYOUBEGN .......................................................................5
ASSEMBLY ...............................................................................6
OPERATONANDADJUSTMENT ............................................................14
HOWTOFOLDANDMOVETHETREADMLL ..................................................20
TROUBLESHOOTNG ......................................................................22
EXERCSEGUDELNES ...................................................................25
PARTLST ...............................................................................26
EXPLODEDDRAWNG .....................................................................28
ORDERNGREPLACEMENTPARTS ..................................................BackCover
LMTEDWARRANTY...............................................................BackCover
2
This drawing shows the locations of the warning
decals. If a decal is missing or illegible, call the
telephone number on the front cover of this
manual and request a free replacement decal.
Apply the decal in the location shown. Note:
The decals may not be shown at actual size.
WARNING DECAL PLACEMENT

3
IMPORTANT PRECAUTIONS
1. Before beginning any exercise program, con-
sult your physician. This is especially impor-
tant for persons over age 35 or persons with
pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
3. Use the treadmill only as described.
4. Place the treadmill on a level surface, with at
least 8 ft. (2.4 m) of clearance behind it and 2
ft. (0.6 m) on each side. Do not place the
treadmill on any surface that blocks air open-
ings. To protect the floor or carpet from dam-
age, place a mat under the treadmill.
5. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
6. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
7. Keep children under age 12 and pets away
from the treadmill at all times.
8. The treadmill should not be used by persons
weighing more than 250 lbs. (113 kg).
9. Never allow more than one person on the
treadmill at a time.
10. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended for
both men and women. Always wear athletic
shoes; never use the treadmill with bare feet,
wearing only stockings, or in sandals.
11. When connecting the power cord (see page 14),
plug the power cord into a surge suppressor
(not included) and plug the surge suppressor
into a grounded circuit capable of carrying 15
or more amps. No other appliance should be on
the same circuit. Do not use an extension cord.
12. Use only a single-outlet surge suppressor that
meets all of the specifications described on
page 14. To purchase a surge suppressor, see
your local WESLO dealer or call the telephone
number on the front cover of this manual and
order part number 146148, or see your local
electronics store.
13. Failure to use a properly functioning surge
suppressor could result in damage to the con-
trol system of the treadmill. If the control sys-
tem is damaged, the walking belt may slow,
accelerate, or stop unexpectedly, which may
result in a fall and serious injury.
14. Keep the power cord and the surge suppres-
sor away from heated surfaces.
15. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See TROU-
BLESHOOTING on page 22 if the treadmill is
not working properly.)
16. Read, understand, and test the emergency
stop procedure before using the treadmill (see
HOW TO TURN ON THE POWER on page 16).
17. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails or crosswalk arms while using the
treadmill.
18. The pulse sensor is not a medical device.
Various factors, including your movement,
may affect the accuracy of heart rate readings.
The pulse sensor is intended only as an exer-
cise aid in determining heart rate trends in
general.
WARNING: To reduce the risk of serious injury, read all important precautions and in-
structions in this manual and all warnings on your treadmill before using your treadmill. ICON as-
sumes no responsibility for personal injury or property damage sustained by or through the use of
this product.

4
19. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
20. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord, and switch the reset/off cir-
cuit breaker to the off position when the
treadmill is not in use. (See the drawing on
page 5 for the location of the circuit breaker.)
21. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6 and HOW TO FOLD
AND MOVE THE TREADMILL on page 20.)
You must be able to safely lift 45 lbs. (20 kg)
to raise, lower, or move the treadmill.
22. When folding or moving the treadmill, make
sure that the frame is held securely in the
storage position.
23. Do not change the incline of the treadmill by
placing objects under the treadmill.
24. Inspect and properly tighten all parts of the
treadmill regularly.
25. Never drop or insert any object into any
opening on the treadmill.
26. This treadmill is intended for in-home use
only. Do not use this treadmill in a commer-
cial, rental, or institutional setting.
27. DANGER: Always unplug the power
cord immediately after use, before cleaning
the treadmill, and before performing the main-
tenance and adjustment procedures de-
scribed in this manual. Never remove the
motor hood unless instructed to do so by an
authorized service representative. Servicing
other than the procedures in this manual
should be performed by an authorized service
representative only.
SAVE THESE INSTRUCTIONS

5
Thank you for selecting the new WESLO PRO™
CROSSWALK 7.8 treadmill. The CROSSWALK 7.8
treadmill offers a selection of features designed to make
your workouts at home more effective and enjoyable.
And when youʼre not exercising, the treadmill can be
folded up, requiring less than half the floor space of
other treadmills.
For your benefit, read this manual carefully before
using the treadmill. f you have questions after read-
ing this manual, please see the front cover of this man-
ual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
To avoid a registration fee for any service needed
under warranty, you must register the treadmill at
www.wesloservice.com/registration.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
BEFORE YOU BEGIN
Handrail
Storage Latch
Console
Key/Clip
Reset/Off
Circuit Breaker
Power Cord
Walking Belt
Hood
Wheel
Foot Rail
dler Roller
Adjustment Bolts
Accessory Tray
Fan
Crosswalk Arm
Pulse Sensor
Resistance Knob

ASSEMBLY
To hire an authorized service technician to assemble the treadmill, call 1-800-445-2480.
Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking
belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to
the top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor-
mance. f there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild,
non-abrasive cleaner.
Assembly requires the included hex keys and your own Phillips screwdriver ,
adjustable wrench , scissors , needlenose pliers , and rubber mallet .
Use the drawings below to identify the assembly hardware. The number in parentheses below each drawing is
the key number of the part, from the PART L ST near the end of this manual. The number after the parentheses
is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it is preattached
to one of the parts to be assembled. To avoid damaging plastic parts, do not use power tools for assem-
bly. Extra hardware may be included.
6
M10 Flat Washer
(14)–2
M8 x 15mm
Bolt (8)–6
M10 Star
Washer (9)–6
M8 Star
Washer (5)–6
M4.2 x 19mm
Screw (10)–4
M5 Star
Washer (7)–2
M10 x 75mm Bolt (2)–4
M10 x 60mm Patch Bolt (1)–2
M5 x 16mm
Screw (85)–2
M4 x 10mm Ground
Screw (84)–1
#10 x 1" Tek Screw
(112)–2
#8 x 1" Tek Screw
(26)–6
M8 Flat
Washer (32)–4
Base Extension Nut
(43)–4
M8 x 58mm Bolt (13)–4
1/4" Flat Washer
(114)–4
1/4" x 3" Bolt (111)–4

7
2. Have a second person hold the Base (52) in the
position shown.
dentify the Left Upright (53) (the Right Upright
[54] has a square hole near the lower end).
Hold the Left Upright (53) so the two round
holes are on top as shown. Attach the Left
Upright to the Base (52) with two M10 x 75mm
Bolts (2) and two M10 Star Washers (9). Do not
fully tighten the Bolts yet.
Attach the Right Upright (54) to the Base (52)
in the same way.
2
52
53
2
2
9
9
54
Square
Hole
Round Holes
Round Holes
1. Make sure that the power cord is unplugged.
Position the Base (52) and the Base Extensions
(45) upside-down as shown.
Attach six Base Feet (63) to the Base (52) and
the Base Extensions (45) with six #8 x 1" Tek
Screws (26).
1
52 26
26 63
63
63
26
63
26
63
26
45
63
26
45

8
4. Position the Base (52) as close to the front of the
treadmill as possible, as shown.
See the upper inset drawing. Locate the wire
tie in the lower end of the Right Upright (54). Tie
the wire tie securely around the end of the Wire
Harness (39). Then, locate the other end of the
wire tie in the upper end of the Right Upright.
Pull the upper end of the wire tie until the Wire
Harness is extending from the upper end of the
Right Upright. Secure the Wire Harness to the
Right Upright so that it will not fall inside.
See the lower inset drawing. Press the indi-
cated Grommet (49) into the Right Upright (54).
54
54
49
39
52
Wire Tie
39
52
4
39
54
3. Attach each Base Extension (45) to the Base
(52) with two M8 x 58mm Bolts (13), two M8 Flat
Washers (32), and two Base Extension Nuts
(43). Note: The heads of the Bolts should be
on the outside of the Base Extensions.
Lower the Base (52) so that it is flat on the floor.
3
52
32
45
13 43
Bolt Head
13
32
45
43

9
6. See the left inset drawing in step 5. dentify
the outer side of the remaining Frame Spacer
(11).
Hold the Frame Spacer (11) between the Left
Upright (53) and the Lift Frame (23), with the
outer side of the Frame Spacer facing the
Left Upright. Attach the Left Upright to the Lift
Frame with an M10 x 60mm Patch Bolt (1), an
M10 Flat Washer (14), and an M10 Star Washer
(9); do not fully tighten the Patch Bolt yet.
6
53
14 11
9
23
1
114
9
53
11
23
5. See the left inset drawing. dentify the two
Frame Spacers (11). Open the included packet
of grease, and apply grease to both sides of both
Frame Spacers. Then, identify the outer side of
each Frame Spacer.
Hold a Frame Spacer (11) between the Right
Upright (54) and the Lift Frame (23), with the
outer side of the Frame Spacer facing the
Right Upright.
With the help of a second person, lift the front of
the treadmill. Attach the Lift Frame (23) to the
Right Upright (54) with an M10 x 60mm Patch
Bolt (1), an M10 Flat Washer (14), and an M10
Star Washer (9); do not fully tighten the Patch
Bolt yet.
5
54
1
1
11
23
14
54
14
9
23
11
9
11
Grease
Outer Side

10
8. Remove the plastic ties from the Right Handrail (33)
and the Left Handrail (not shown). f necessary,
press the Cage Nuts (105) back into place. With the
help of a second person, hold the Console
Assembly (91) near the Right Upright (54).
Connect the Wire Harness (39) to the console
wire. See the inset drawing. The connectors
should slide together easily and snap into
place. f they do not, turn one connector and try
again. IF THE CONNECTORS ARE NOT CON-
NECTED PROPERLY, THE CONSOLE MAY BE
DAMAGED WHEN THE POWER IS TURNED
ON. Next, insert the connectors and the excess
wire downward into the Right Upright (54). Then,
remove the wire tie from the Wire Harness.
8
91
54
39
39
33
Wire
Tie
105 Console
Wire
Console
Wire
7. Set the Console Assembly (91) face down on a
soft surface to avoid scratching the Console
Assembly. Hold the Right Handrail (33), which
has a large hole in one side, near the Console
Assembly.
Next, insert the console wire and the tie into the
large hole in the side of the Right Handrail (33).
Using needlenose pliers, pull the console wire
out of the hole near the bracket on the Right
Handrail.
Then, set the Right Handrail (33) on the Console
Assembly (91). Make sure that no wires are
pinched. Start an M5 x 16mm Screw (85) with
an M5 Star Washer (7) into the Right Handrail,
and then start two M4.2 x 19mm Screws (10)
into the Right Handrail. Tighten the M5 x 16mm
Screw and then tighten the two M4.2 x 19mm
Screws; do not overtighten the Screws.
Attach the Left Handrail (not shown) to the
Console Assembly (91) in the same way.
Note: There are no wires on the left side.
7
Console
Wire
Large
Hole
33
Bracket
85
7
10
91
Tie
