Wesper Aquanet Manual

English Français
Installation and maintenance manual
Manuel d’installation et de maintenance
Communicating Electronic Control for Fan Coil Units
Régulation électronique communicante pour ventilo-convecteurs
IOM AQN-W.1GBF
Date : April 2003 / Avril 2003
Supersedes / Annule et remplace : None / Aucun
Aqu@Net
R

II

1
English
1 - General
2 - The Aqu@Net electronic control system
Model A : For 2 pipe heating only or cooling only fan coil units
with manual changeover.
Model B : For 2 pipe reversible fan coil units with automatic
changeover (pipe work probe).
Model C : For 2 pipe / 2 wire fan coil units.
Model D : For 2 pipe reversible fan coil units with automatic
changeover (pipe work probe) and additional electrical
heating.
Model E : For 4 pipe fan coil units.
ALARM
WIN
UNOC
MIU
J1
F/L
VL2
VL1
EH2 N
VL1 N EH1 N Pump N F/N
EH2EH1
Pump
VL2 N
F/M
F/H
RAT
WPT
4321
14
16
13
12
10
11
17
15
18
19
20
21
9
8
7
5
34
6
12
2.1 - FCC controller description
F/N Fan motor neutral.
EH2 N°2 electrical resistance phase.
Pump N Condensate lift pump supply neutral.
EH1 N°1 electrical resistance phase.
EH1 N N°1 electrical resistance neutral.
Pump Condensate lift pump supply phase.
EH2 N N°2 electrical resistance neutral.
VL1 N Valve N°1 neutral (Cooling or reversible valve).
VL2 N Valve N°2 neutral (Heating valve).
VL1 Valve N°1 phase (Cooling or reversible valve).
VL2 Valve N°2 phase (Heating valve).
F/L Fan motor low speed phase.
F/M Fan motor medium speed phase.
F/H Fan motor high speed phase.
J1 Model plug configuration and location block.
MIU Connection for additional specific interface board.
UNOC Input terminal block for normally open clock dry contact
switch (open = occupation mode).
WIN Input terminal block for normally closed window dry
contact switch (open = window open).
ALARM Special terminals (supplied shunted on the fan coil units)
for connection to a condensate pump upper level contact
switch.
RAT Intake air temperature, red connector and red wire
always wired at factory.
WPT Water pipe temperature, white connector, black wire,
wired at factory for reversible systems.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
The Aqu@net electronic control system has been specifically
designed for wall mounted, ceiling mounted or cassette type fan
coil units, all with full air recycling, for the following applications :
2 pipe cooling only, 2 pipe heating only, 2 pipe / 2 wire,
2 pipe reversible with or without additional electrical heating
and 4 pipe installations.
The system comprises an FCC controller integrated in the fan coil
unit and an RCL control, capable of being fitted as an option to our
entire range of low wall mounted fan coil units.
Aqu@net is a new generation of communicating electronic control
via a proprietary bus using an easily installed additional PCB and a
monitoring module known as µBMS (refer to the manual relating
to this monitoring module).
Furthermore, in the case of small installations, this control system
enables a master / slave network to be created very easily by
means of hardwired connections, and it enables up to 15 units to be
controlled with a single RCL control.
The Aqu@net electronic control system has been designed to
achieve an optimised compromise between running costs (heating
valve for integral proportional control), ergonomics and
performance.
It is compatible with the µBMS monitoring module and
communicates via a proprietary bus, as well as being capable of
operating without a monitoring module.
The Aqu@net electronic control system can be adapted to the
following air conditioning system models :

2
2 - The Aqu@Net electronic control system (contd.)
2.2 - RCL control description
1
2
3
4
5
DIPS J1-J2 These DIP switches enable the RCL to be configured
in accordance with your system's application (Refer
to page 3 for further details). To gain access to these
DIP switches, the RCL has to be carefully removed
from its support bracket (refer to page 7).
0
J1 P4P1 P2 P3
J2
1
01
7
1
2
3
4
5
6
Dimensions : H = 11 cm, L = 6 cm, Depth = 1.5 cm.
WARNING
7
In the event of a power cut, the RCL control can retain and
display operating mode, ventilation speed and set temperature
data for 10 minutes.
Beyond 10 minutes, the digital display is cleared and the data is
lost.
As soon as the power supply is re-established, the digital display
reactivates itself in the last operating mode selected, but the
data concerning the ambient temperature is always lost.
Press the ON/OFF key twice to reactivate the complete
system and recover the ambient temperature value.
By successive presses, this key enables the ventilation
speed to be selected :
- Low speed (2 bars)
- Medium speed (4 bars)
- High speed (6 bars)
- Automatic speed (6 bars + AUTO)
By successive presses, this key enables the displayed
temperature to be selected.
A pictogram representing a house appears when
the room temperature is displayed.
If the house is not present, then the desired room
temperature is being displayed.
TEMP These keys enable the desired temperature in the
room to be raised or lowered (set temperature).
By successive presses, this key enables the fan coil
units to be started or moved into standby mode. The
standby/off status is indicated by a green LED.
GREEN LED On : Fan coil unit running.
Off : Fan coil unit stopped.
Slow flashing : Unoccupied mode activated.
Rapid flashing: Condensate level alarm.
MODE By successive presses, this key enables the desired
operating mode to be selected (according to the
settings on the mode selection block - refer to page
3).
Ventilation only mode.
Cooling mode (Summer).
Heating mode (Winter).
Automatic operating mode selection (in Heating or
Cooling mode).
Sending data to the FCC controller or blocked
keypad signal.
The RCL control has been designed specifically for use with fan coil
units equipped with the Aqu@net system.
In no event can it be used with any other type of control
system.
It operates independently on units equipped with an FCC controller,
irrespective of the configuration (A, B, C, D, E).
When the electrical connections have been made correctly, the
digital display indicates the set temperature, the operating mode
and the ventilation speed.
NOTE : When the RCL control is mounted on a panelled unit, its
blue connector is not plugged into the FCC controller.

3
English
2 - The Aqu@Net electronic control system (contd.)
YesNoYesNoYesNo0101OffCoolHeatAutoFan
Black 2 pipe / cooling only A XX XXXXX X
Blue 2 pipe / cooling only IFC (1) A XX X XX XX
Green 2 pipe / heating only A XX XX XXXX
Green 2 pipe / heating only +
PBTEE (2) AXXXX XXXX
Red 2 pipe / heating only IFC (1) A XX XX XX X
Red 2 pipe / heating only IFC (1)
+ PBTEE (2) AXX X X XX X
White 4 pipe E X X X X XX XX
White 2 pipe reversible / 2 wire D X X X X X XXXXX
Orange 2 pipe reversible B X X X X X XXXXX
Orange 2 pipe / 2 wire C X X XX X XXXXX
W/O plug 2 pipe reversible IFC (1) B XX X X X XXXXX
Accessible modesWater
probe Dip J1 Dip J2
RCL control
recommended settin
g
Action
Valve Ventilation
Model
plug
colour on
FCC
Application
System
2.3 - Configuring the various control systems
(1) IFC : Independent Fan Control. The IFC mode signifies that the system control is only performed on the ventilation function (without valve).
(2) PBTEE : Inlet Water Low Temperature Protection (the protection cuts the ventilation function when the inlet water temperature is below
35 °C and below that of the room temperature by + 5 K).
0
J1
J2
1
01
DIP switches J1 and J2
settings accessible at the
rear of the control. (Refer
to table below).
ALARM
WIN
UNOC
MIU
J1
F/L
VL2
VL1
EH2 N
VL1 N EH1 N Pump N F/N
EH2EH1
Pump
VL2 N
F/M
F/H
RAT
WPT
4321
UNOC
U
J1
Model plug location
(different colours according
to applications. (Refer to
table below).
FCC controller RCL control
Model D : For 2 pipe reversible fan coil units with automatic
changeover (pipe work probe) and electric heating.
Model E : For 4 pipe fan coil units.
Each model plug is specific to a chosen control system.
The J1 and J2 DIP switches must be set on the RCL control in
accordance with the desired configuration type.
RCL control factory settings : J1 on 0, J2 on 0 with all modes
accessible, including on unit mounted RCL control.
The model plugs supplied on the J1 block of the FCC control and
identified by different colours, enable the following control systems
to be obtained :
Model A : For 2 pipe heating only or cooling only fan coil units
with manual changeover.
Model B : For 2 pipe reversible fan coil units with automatic
changeover (pipe work probe).
Model C : For 2 pipe / 2 wire fan coil units.

4
2.4 - Other J1 configuration block settings
NOTE :
In all cases, the shunts J4, J6 and J7 are fitted at the factory.
The shunt J5 is fitted at the factory on units fitted with an RCL control.
In the case of wall mounting, it is recommended that the RCL probe is used.
The RCL control probe must be used in the case where several
fan coil units are controlled by the same RCL control.
2 - The Aqu@Net electronic control system (contd.)
2.5 - Additional functions definition
Window contact switch function :
The FCC controller has 2 terminals (5 and 6) marked WIN, intended
to be connected to an opening contact switch for activating the
window contact switch function (window closed = contact switch
closed).
The window contact switch function stops the fan coil unit (valve or
electrical resistance cut) and moves the unit into cyclical ventilation
mode with an anti-freezing heating temperature protection set at
8 °C.
IMPORTANT : In all cases, the electrical resistance post-ventilation
function is maintained.
ALARM
WIN
UNOC
MIU
J1
F/L
VL2
VL1
EH2 N
VL1 N EH1 N Pump N F/N
EH2EH1
Pump
VL2 N
F/M
F/H
RAT
WPT
4321
OC
J1
J4J6J5J7
Unoccupied function :
The FCC controller has 2 terminals (7 and 8) marked UNOC,
intended to be connected to a closing contact switch for activating
the unoccupied function (contact switch closed = function activated).
The aim of the unoccupied function is to replace the temperatures
set by the user with factory-programmed set temperatures :
- Cooling mode set temperature : 30 °C.
- Heating mode set temperature : 14 °C.
- Cyclical ventilation.
Functions obtained by dry electrical contact on the FCC controller :
ALARM
WIN
UNOC
MIU
J1
F/L
VL2 VL1
EH2 N
VL1 N EH1 N Pump N F/N
EH2EH1
Pump
VL2 N
F/M F/H
RAT WPT
4321
ALARM
WIN
UNOC
MIU
J1
F/L
VL2 VL1
EH2 N
VL1 N EH1 N Pump N F/N
EH2EH1
Pump
VL2 N
F/M F/H
RAT WPT
4321
up to 10 fan coil units
Note : For savings in costs and materials, it is possible to use a single dry contact switch for several FCC controllers (refer to example below).
Only used with RAT intake air temperature probe YES
Used with RCL internal probe NO
J6 YES
J7 NO
J6 NO
J7 YES
J6 YES
J7 YES
Shunt
presence
Functions
Cyclical fan operation on demand in heating and
continuous fan operation in cooling mode
J4
J5
Continuous fan operation (except when unit stopped)
Cyclical fan operation on demand in heating and
cooling (no fan operation in the neutral zone)
Shunt
reference
No action YES
Maximum cable length :
50 metres, Ø between 0.4
and 0.65 mm.
Shielded, twisted pair cable
SYT1 AWG26 to AWG22.

5
English
3 - Electrical power supply and connection terminal blocks
On the Aqu@Net system, the FCC controller is supplied directly
with 230 V / 1 phase / 50 Hz current and pilots the RCL control
under very low voltage.
It comprises 6 terminal blocks as described below :
1- The first terminal block, known as the power supply block enables
230 V supply to be provided to the system. Each terminal is
marked on the plastic cover with L for the phase, N for neutral
and the ground symbol for ground.
2- The second terminal block is used for connecting the fan coil
unit's constituent elements (fan, cooling mode valve, heating
mode valve, electrical resistances etc.). The terminals are
connected at the factory according to the requested application.
3- The third terminal block marked MIU is the location set aside
for an additional communication PCB.
4- The fourth terminal block is provided for connecting the RCL
control.
There are two connection possibilities for this component :
- The FCC is supplied with a ceiling type fan coil unit : In this
case the RCL control is supplied as a kit.
- The FCC is supplied with a low wall mounted type fan coil
unit : In this case the RCL control is mounted on a bracket on
the casing side opposite to the hydraulic connections side.
5- The fifth terminal block comprises 3 connectors marked as
follows on the plastic cover:
- WPT : Water temperature probe.
It is only fitted to B and D type systems. It enables mode changing
in relation to water temperature that is measured via a probe
on the pipe work. For this reason, special care must be taken
when assembling this probe.
This probe must be fitted with a 4 way valve and upstream
of the valve on the water inlet (refer to diagram below).
We recommend that the probe is fitted with an electrician's
type collar, using contact paste and thermal insulation on the
pipe work.
- RAT : Intake air temperature probe.
The intake air temperature probe enables the fan coil unit to
be controlled by the air temperature reigning around the unit.
The major advantage of this system is that several units can be
controlled with a single RCL control.
This probe is connected at the factory in all cases and is installed
on the fan air intake.
- ALARM : Condensates upper level alarm probe.
In the case of fan coil units, this connector is systematically
supplied with a shunt and it not used.
In the case of chilled water cassettes, this contact switch is
connected to the condensates tray upper level contact switch.
This switch's function is to shut down the cassette (ventilation
and valve). Its operation is visualised by a rapid flashing of the
LED on the RCL control.
6- The sixth terminal block has 4 terminals marked in pairs on the
plastic cover as follows :
- WIN : Window contact switch (contact switch closed = window
closed). For this reason, this contact is always supplied with a
shunt.
- UNOC : Enables the room unoccupied / occupied function to
be activated via a dry contact switch (contact switch closed =
unoccupied mode). For this reason this contact switch is always
left free of potential.
21
6
5
4
3
Pipe work probe
location
FCC controller terminal blocks

6
4 - Fan coil unit wiring
RCL control
230 V / 1 Ph / 50 Hz power supply
Maximum cable length (between the RCL control and the furthest slave unit) :
100 metres, with cable diameter between 0.4 and 0.65 mm.
Shielded, twisted pair cable : SYT1 AWG26 to AWG22.
This system enables a low cost master/slave control system linking several fan coil units to be installed without the need for a communication
bus and without addressing.
Max. number of
fan coil units : 15
P1P2P3P4
33
33
3Unscrew the lower screw on
the RCL control.
33
33
3Separate the RCL control
from its support bracket with
the help of a flat bladed
screwdriver.
RCL control
support bracket
230 V / 1 Ph / 50 Hz power supply
FCC
controller
Details of connection of the RCL control with the first FCC controller
Master / slave hardwire network
Maximum
length :
30 metres
Cable diameter between 0.4 and 0.65 mm.
Shielded, twisted pair cable :
SYT1 AWG26 to AWG22.
Maximum
length :
30 metres
Lower screw

7
English
5 - RCL control installation
STEP 1
Lower screw
33
33
3Unscrew the lower screw on
the RCL control.
33
33
3Separate the RCL control
from its support bracket with
the help of a flat bladed
screwdriver.
STEP 3
Checking the support bracket :
Ensure that the wall surface is completely flat at the point
where you wish to install the RCL control, as it is important that
the support bracket is not twisted on installation, because any
bending could lead to the control not clipping together properly
and result in operating difficulties.
Fitting the support bracket :
33
33
3Present the support bracket to the desired location and align
it with a spirit level.
33
33
3Mark the screw locations.
33
33
3Make a hole or install appropriate plugs according to the
material (wood, concrete, plasterboard etc.).
33
33
3Screw the support bracket to the wall, preferably with round
head screws matching the following characteristics :
- Minimum length : 15 mm,
- Maximum head diameter : 7 mm,
- Maximum thread diameter : 3.5 mm,
- Head protrusion : 3.5 mm.
STEP 2
33
33
3Make the electrical connections
between the support bracket
terminals and the FCC controller,
and terminal 1 of the blue
connector to the terminal
marked P1, and the other
terminals in turn.
33
33
3Use cable of a diameter between
0.4 and 0.65 mm of the shielded,
twisted pair type : SYT 1 AWG
26 to AWG 22. The outside cable
diameter must not exceed 5.5 mm
Warning !
33
33
3Never run the power supply
cable into the RCL control from
underneath.
33
33
3Never change the location of
the blue connector with the
outlets on the side.
STEP 4
STEP 5
Dips switches J1 and J2 for parameterisation
33
33
3Set the DIP switches marked J1
and J2 in accordance with your
configuration (2 pipe, 4 pipe,
etc..) and the modes that are
accessible.
33
33
3Refer to page 3 of this manual
for selecting the required
settings.
33
33
3Clip the RCL control onto the
support bracket.
33
33
3Replace the lower screw in such
a way that the RCL control is held
firmly in place on the support
bracket.
33
33
3The RCL control is now ready for
use after connecting the mains
power supply to the fan coil unit.
Lower screw
Support bracket
0
J1
J2
1
01

8
6 - Commissioning
Synchronising the units under master / slave control from an RCL control
This operation must be performed if the RCL control or the FCC controller has been replaced, or in the case where one
or several fan coil units have been electrically isolated.
1 -Synchronisation operations description
1.1 Press the ON / OFF key. The green LED should light up.
1-2 Press the MODE key repeatedly until the ventilation (fan)
symbol appears.
1-3 Press the ventilation key until the High Speed ventilation symbol
appears (6 bars).
1-4 Wait for 5 to 10 seconds and check that all the units connected
for master / slave control on this RCL control are effectively
running in High speed Ventilation mode.
1-5 If all the fan coil units are running in High speed ventilation
mode then the check is complete as all the units are
synchronised.
If this is not so, move on to the following paragraph.
2-3 Press the ON / OFF key. Check that the green LED goes out.
If this is not the case, refer to paragraph 3.
2-4 All the units must stop (within 5 to 10 seconds).
2-5 Re-insert the blue connectors, following the polarities 1,2,3
and 4. Refer to diagram below.
2-6 Press the ON / OFF key once again. The green LED should
light up.
Check locally that all the units change into High Speed
Ventilation mode after 5 to 10 seconds.
The fan coil units are synchronised.
If this is not the case, refer to the following step 2.7.
2-7 Shut down the mains power supply to all the fan coil units
wired in master / slave configuration to the RCL control and
restart the procedure from Step 1.1.
3 -Case where the green LED does not
light up or does not go out when the
ON/OFF key is pressed
3-1 If the green LED does not light up or does not go out, check the
points listed in Chapter 5, Page 7 " RCL control installation" :
a. Check that the RCL control is properly clipped onto the support
bracket.
b. Check the addressing of the wires between the RCL support
bracket terminal block and the FCC controller blue connector.
c. Check that the wires linking the units are not damaged or
broken.
d. Check the condition of the connection prongs marked P1 to P4
on the back of the RCL control.
FCC controller
Blue connector
2 - Case where not all units are synchronised
2-1 Identify the non-synchronised units (those without the fan
operating).
2-2 On the fan coil units that are not running, without turning
off the power supply, unplug the blue connector from the
FCC controller. (refer to diagram below).
1
2
3
4
FCC controller
Blue connector
1
2
3
4

9
English
7 - General wiring diagrams
Aqu@Net System A
COOLING ONLY valve action + VENTILATION
Aqu@Net System A
HEATING ONLY valve action + VENTILATION
Factory wiring Client wiring
POWER SUPPLY
LN
Aqu@Net
1234
WPT RAT ALARM
UNOC
WIN
NIU
J1
F/N
EH2
Pump N
EH1
EH1 N
Pump
EH2 N
VL1 NVL2 N
VL1 VL2 F/L F/M F/H
230V/1Ph/50Hz
GMV
VF
BLUE CHESNUT BROWN
NEUTRAL BLUE
RED LS VIOLET MS BLACK HS
YELLOW / GREEN
BLACK TERMINAL BLOCK REF 224
VF = Cooling valve GMV = Fan/motor unit
SR
SR = Intake air probe
RED
RED
P1
Remote
RCL
Ground to the casing
0
J1 J2
1
01
Recommended J1 and J2 DIP switch settings on RCL control
Factory wiring Client wiring
POWER SUPPLY
LN
Aqu@Net
1234
WPT RAT ALARM
UNOC
WIN
NIU
J1
F/N
EH2
Pump N
EH1
EH1 N
Pump
EH2 N
VL1 NVL2 N
VL1 VL2 F/L F/M F/H
230V/1Ph/50Hz
GMV
VC
BLUE CHESTNUT BROWN
NEUTRAL BLUE
RED LS
VIOLET MS
BLACK HS
YELLOW / GREEN
GREEN TERMINAL BLOCK REF 226
VC = Heating valve GMV = Fan/motor unit
Remote
RCL
RED
SR = Intake air probe
P1
Ground to the casing
RED
SR
0
J1 J2
1
01
Recommended J1 and J2 DIP switch settings on RCL control

10
7 - General wiring diagrams (contd.)
SR = Intake air probe GMV = Fan/motor unit
Client wiring Factory wiring
YELLOW / GREEN
GMV
NEUTRAL BLUE
VL1 N
VIOLET MS BLACK HS RED LS
VL2 N Pump N
EH2 N
EH1 N F/N
RED
Remote
RCL
P1
Aqu@Net
1432
ALARM RAT WPT
Ground to the casing
BLUE TERMINAL BLOCK REF 225
F/H F/M F/L VL2 VL1
NIU
N
Pump
EH1 EH2
L
UNOC
WIN
J1
230V/1Ph/50Hz POWER SUPPLY
RED
SR
0
J1 J2
1
01
Recommended J1 and J2 DIP switch settings on RCL control
Aqu@Net System A
COOLING ONLY + VENTILATION only
SR = Intake air probe GMV = Fan/motor unit
Client wiring Factory wiring
YELLOW / GREEN
RED LS
GMV
NEUTRAL BLUE
VL1 N
BLACK HS
VIOLET MS
VL2 N Pump N
EH2 N
EH1 N F/N
RED
4
Remote
RCL
P1
Aqu@Net
321
ALARM RAT WPT
Ground to the casing
RED TERMINAL BLOCK REF 227
F/H F/M F/L VL2 VL1
NIU
N
Pump
EH1 EH2
L
J1
WIN
UNOC
230V/1Ph/50Hz POWER SUPPLY
RED
SR
0
J1 J2
1
01
Recommended J1 and J2 DIP switch settings on RCL control
Aqu@Net System A
HEATING ONLY + VENTILATION only

11
English
7 - General wiring diagrams (contd.)
SR = Intake air probe WTP = Water temperature probe GMV = Fan/motor unit VC = Heating valve
GMV
P1
Client wiring Factory wiring
RED LS
YELLOW / GREEN
BLACK HS
VIOLET MS
CHESTNUT BROWN BLUE
Remote
RCL
Aqu@Net
VL2 N
F/H F/M F/L VL2 GREEN TERMINAL BLOCK REF 226
WIN
UNOC
ALARM WPT
43
RAT
NIU
21
J1 SR
WPT
REDBLACK
BLACK RED
VC
NEUTRAL BLUE
EH1
Pump NVL1 N
EH2 N
EH1 N
VL1
F/N
EH2
Pump
NL
Ground to the casing
230V/1Ph/50Hz
POWER SUPPLY
0
J1 J2
1
01
Recommended J1 and J2 DIP switch settings on RCL control
Aqu@Net System A
HEATING ONLY valve action + VENTILATION
+ water temperature probe
WTP = Water temperature probe SR = Intake air probe GMV = Fan/motor unit
Client wiring Factory wiring
YELLOW / GREEN
RED LS
GMV
NEUTRAL BLUE
VL1 N
BLACK HS
VIOLET MS
VL2 N Pump N
EH2 N
EH1 N F/N
RED
Remote
RCL
P1
Aqu@Net
1432
ALARM RAT WPT WPT
Ground to the casing
RED TERMINAL BLOCK REF 227
F/H F/M F/L VL2 VL1
NIU
N
Pump
EH1 EH2
L
J1
WIN
UNOC
230V/1Ph/50Hz POWER SUPPLY
RED
SR
0
J1 J2
1
01
Recommended J1 and J2 DIP switch settings on RCL control
Aqu@Net System A
HEATING ONLY + VENTILATION only
+ water temperature probe

12
7 - General wiring diagrams (contd.)
F/H F/M F/L VL2 VL1
EH1 EH2
Aqu@Net
WTP = Water temperature probe SR = Intake air probe GMV = Fan/motor unit V = Valve
Client wiring Factory wiring
YELLOW / GREEN
GMV
V
NEUTRAL BLUE
BLUE
VL1 N
VIOLET MS BLACK HS RED LS
CHESTNUT BROWN
VL2 N Pump N
EH2 N
EH1 N F/N
RED
ALARM RAT WPT
Remote
RCL
P1
4321
BLACK
WPT
BLACK
Ground to the casing
ORANGE TERMINAL BLOCK REF 229
N
NIU
L
Pump
WIN
UNOC
J1
RED
230V/1Ph/50Hz POWER SUPPLY
SR
0
J1 J2
1
01
Recommended J1 and J2 DIP switch settings on RCL control
Aqu@Net System B
2 PIPE REVERSIBLE valve action + VENTILATION
EH2 N
WTP = Water temperature probe SR = Intake air probe GMV = Fan/motor unit
Client wiring Factory wiring
YELLOW / GREEN
GMV
NEUTRAL BLUE
VL1 N
BLACK HS VIOLET MS RED LS
VL2 N Pump NEH1 N F/N
RED
Remote
RCL
P1
Aqu@Net
342
ALARM RAT WPT
1
WPT
BLACK
BLACK
Ground to the casing
F/H F/M F/L VL2 VL1
NIU
N
Pump
EH1 EH2
L
NO TERMINAL BLOCK
UNOC
WIN
J1
230V/1Ph/50Hz POWER SUPPLY
RED
SR
0
J1 J2
1
01
Recommended J1 and J2 DIP switch settings on RCL control
Aqu@Net System B
2 PIPE REVERSIBLE + VENTILATION only

13
English
SR = Intake air probe R2 = 2nd stage electrical heating resistance
R1 = 1st stage electrical heating resistance
LT = Temperature limiter GMV = Fan/motor unit VF = Cooling valve Maximum R1 and R2 output : 1500 W R2 is only available as an option (refer to price list)
RED
YELLOW / GREEN
Remote
RCL
Aqu@Net
Client wiring Factory wiring
P1
4321
ALARM WPT RAT
BLACK HS VIOLET MS RED LS
CHESTNUT BROWN
GMV
LT
NEUTRAL BLUE
VF
BLUE
VL1 N
F/M F/H F/L VL2 VL1
VL2 N
EH2 N
EH1 N
Pump
Pump N
EH1
F/N
EH2
R2 R1
ORANGE TERMINAL BLOCK REF 229
N
NIU
WIN
UNOC
J1
L
RED
SR
Ground to the casing
230V/1Ph/50Hz POWER SUPPLY
Factory wiring for 2ndelectrical
heating resistance (if present)
0
J1 J2
1
01
Recommended J1 and J2 DIP switch settings on RCL control
Aqu@Net System C
2 PIPE / 2 WIRE
7 - General wiring diagrams (contd.)
EH2 N
Pump N F/N
SR = Intake air probe R2 = 2nd stage electrical heating resistance
WTP = Water temperature probe R1 = 1st stage electrical heating resistance
LT = Temperature limiter GMV = Fan/motor unit V = Valve
Factory wiring Client wiring
YELLOW / GREEN
GMV
V
NEUTRAL BLUE
LT
BLUE
VL1 N
BLACK HS VIOLET MS RED LS
CHESTNUT BROWN
VL2 N EH1 N
R2 R1
RED
Remote
RCL
P1
Aqu@Net
342
ALARM RAT WPT
1
WPT
BLACK
BLACK
Ground to the casing
NIU
N
F/H F/M F/L VL2 VL1
Pump
EH1 EH2
L
WHITE TERMINAL BLOCK REF 228
UNOC
WIN
J1
230V/1Ph/50Hz POWER SUPPLY
SR
RED
Factory wiring for 2nd stage electrical
heating resistance (if present)
0
J1 J2
1
01
Maximum R1 and R2 output : 1500 W R2 is only available as an option (refer to price list)
Recommended J1 and J2 DIP switch settings on RCL control
Aqu@Net System D
2 PIPE REVERSIBLE / 2 WIRE

14
7 - General wiring diagrams (contd.)
F/H
F/M
F/L
VL2
VL1
EH1 EH2
Aqu@Net
SR = Intake air probe
VF = Cooling valve
GMV = Fan/motor unit
VC = Heating valve
Client wiring
Factory wiring
YELLOW / GREEEN
BLUE
CHESTNUT BROWN
RED LS
CHESTNUT BROWN
BLUE
GMV
VC
VF
NEUTRAL BLUE
VL1 N
BLACK HS
VIOLET MS
VL2 N Pump N
EH2 N
EH1 N F/N
RED
ALARM
RAT
WPT
Remote
RCL
P1
4321
Ground to the casing
WHITE TERMINAL BLOCK REF 228
N
NIU
L
Pump
WIN
UNOC
J1
RED
230V/1Ph/50Hz
POWER SUPPLY
SR
0
J1
J2
1
01
Recommended J1
and J2 DIP switch
settings on RCL
control
Aqu@Net System E
4 PIPE VALVE action + VENTILATION
NOTE
In all cases, always refer to the wiring diagram
supplied with the fan coil unit

III
Déclaration CE de conformité
Nous déclarons sous notre responsabilité que le produit désigné ci-dessous est conforme aux dispositions des directives CEE énoncées ci-après
et aux législations nationales les transposant :
Directive Basse Tension 73 / 23 / CEE
Directive Compatibilité Electromagnétique 89 / 336 / CEE
et que les paragraphes suivants des normes harmonisées ont été appliqués :
CE Compliance Declaration
Under our own responsability, we declare that the product designated below complies with the provisions of the EEC directives listed hereafter
and with the national legislation into which these directives have been transposed :
Low Voltage Directive 73 / 23 / EEC
Electro-magnetic Compatibility Directive 89 / 336 / EEC
and that the following paragraphs of the harmonised standards have been applied :
NF EN 60 335-1 / 1995
NF EN 60 335-2-40 / 1994
NF EN 55 011 / 1998
NF EN 55 014 / 1997
EG-Konformitätserklärung
Wir erklarën in eigener Verantwortung, das die in der vorliegenden Beschreibung angegebenen Produkte den Bestimungen der nachstehend
erwähnten EG-Richtlinien und den nationalen Gesetzesvorschriffen entsprechen, in denen diese Richtinien umgesetz sind :
Niederspannungsrichtlinie 73 / 23 / EG
EMV- Richtlinie 89 / 336 / EG
Und dass die folgeten Paragraphen der vereinheitlichen Noren angewandt Wurden :
Dichiarazione CE di conformità
Dichiariamo, assurmendone la responsasabilità, che i prodotti descritti nel presente manuale sono conformi alle disposizioni delle direttive
CEE di cui sott e alle lagislazionni nazionali che li recepiscono :
Direttiva Bassa Tensione 73 / 23 / CEE
Direttiva Compatibilità Elettromagnetica 89 / 336 / CEE
e sono stati applicati i seguenti pagrafi delle norme armonizzate :
Declaración CE de conformidad
Declaramos, bajo nuestra responsabilidad, que los productos designados en este manual son conformes a las disposiciones de las directivas
CEE enunuciadas a continuacion, asi como a las legislaciones nacionales que las contemplan :
Directiva Baja Tension 73 / 23 /CEE
Directiva Compatibidad Electromagnética 89 / 336 / CEE
y que se han aplicado los siguientes apartados de las normas armonizadas :
Aqu@Net
NF EN 55 022 / 1998
NF EN 61 000 / 1998

R
As part of our ongoing product improvement programme, our products are subject to change without prior notice. Non contractual photos.
Dans un souci d'amélioration constante, nos produits peuvent être modifiés sans préavis. Photos non contractuelles.
Wesper S.A.
42 cours Jean Jaurès
17800 Pons
France
✆: [phone]
: [phone] - [phone] (Export Department)
www.wesper.com
