WESTECH S6 User manual

www.westechmediatechnologies.com
User Manual
User Manual

2
Table of
Contents
Basics
4Read me first
5Package contents
6Device layout
8 SIM or USIM card
10 Battery
14 Turning the device on and
off
15 Touchscreen
18 Home screen
24 Lock screen
25 Notification panel
28 Entering text
31 Screen capture
31 Opening apps
32 Multi window
37 Device and data management
41 Connecting to a TV
43 Sharing files with contacts
44 Emergency mode
Applications
45 Installing or uninstalling
apps
46 Phone
49 Contacts
51 Messages
53 Internet
54 Email
55 Camera
71 Gallery
73 Smart Manager
75 S Planner
76 S Health
79 S Voice
81 Music
82 Video
83 Voice Recorder
85 My Files
86 Memo
86 Clock
88 Calculator
89 Google
apps
Settings
91 Introduction
91 Wi-Fi
93 Bluetooth
95 Flight mode
95 Mobile hotspot and
tethering
96 Data usage
97 Mobile networks
97 NFC and payment
100 More connection settings

3
102 Sounds and
notifications
103 Display
103 Motions and gestures
Table of Contents
104 Applications
104 Wallpaper
105 Themes
105 Lock screen and security
110 Privacy and safety
113 Easy mode
113 Accessibility
114 Accounts
115 Backup and reset
115 Language and input
116 Battery
116 Storage
117 Date and
time 117
User manual
117 About
device
Appendix
118 Accessibility
133 Troubleshooting
138 Removing the battery (non-removable
type)

4
Basics
Read me first
Please read this manual before using the device to ensure safe and proper use.
•Descriptions are based on the device’s default settings.
•Some content may differ from your device depending on the region, service
provider, model specifications, or device’s software.
•Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work
properly depending on the device’s specifications and the environment that it is
used in.
•WESTECH is not liable for performance issues caused by apps supplied by providers
other than WESTECH.
•WESTECH is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise
the operating system may cause the device or apps to work improperly.
•Software, sound sources, wallpapers, images, and other media provided with this
device are licensed for limited use. Extracting and using these materials for
commercial or other purposes is an infringement of copyright laws. Users are
entirely responsible for illegal use of media.
•You may incur additional charges for data services, such as messaging, uploading
and downloading, auto-syncing, or using location services depending on your data
plan. For large data transfers, it is recommended to use the Wi-Fi feature.
•Modifying the device’s operating system or installing softwares from unofficial
sources may result in device malfunctions and data corruption or loss. These actions
are violations of your WESTECH licence agreement and will void your warranty.

Basics
5
•Depending on the region or model, some devices are required to receive
approval from the Federal Communications Commission (FCC). If your device is
approved by the FCC, you can view the FCC ID of the device. To view the FCC ID, tap
Apps →Settings →About device.
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information
Package contents
Check the product box for the following items:
•Device
•Quick start guide
•The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•The supplied items are designed only for this device and may not be
compatible with other devices.
•Appearances and specifications are subject to change without prior notice.
•You can purchase additional accessories from WESTECH. Make sure they are
compatible with the device before purchase.
•Use only WESTECH-approved accessories. Using unapproved accessories may
cause the performance problems and malfunctions that are not covered by
the warranty.
•Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories,
refer to the WESTECH website.

Basics
6
Device layout

Basics
7
•Do not cover the antenna area with your hands or other objects. This may
cause connectivity problems or drain the battery.
•Using a WESTECH-approved screen protector is recommended. Unapproved
screen protectors may cause the sensors to malfunction.
•Do not allow water to contact the touchscreen. The touchscreen may
malfunction in humid conditions or when exposed to water.
Keys
Key
Function
Power
•Press and hold to turn the device on or off.
•Press to turn on or lock the screen.
Recents
•Tap to open the list of recent apps.
•Tap and hold to launch the split screen view.
Home
•Press to turn on the screen while the screen is locked.
•Press to return to the Home screen.
•Press and hold to launch Google.
Back
•Tap to return to the previous screen.
Volume
•Press to adjust the device volume.
SIM or USIM card
Installing the SIM or USIM card
Insert the SIM or USIM card provided by the mobile telephone service provider.
•Only nano-SIM cards work with the device.
•Some LTE services may not be available depending on the service provider. For more
information about service availability, contact your service provider.

Basics
8
1 Insert the ejection pin into the hole on the SIM card tray to loosen the tray.
Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device
may be damaged.
2 Pull out the SIM card tray gently from the SIM card tray slot.
3 Place the SIM or USIM card on the SIM card tray with the gold-coloured contacts
facing downwards.
Use caution not to lose or let others use the SIM or USIM card. WESTECH is not
responsible for any damages or inconveniences caused by lost or stolen cards.
4 Insert the SIM card tray back into the SIM card tray slot.
Removing the SIM or USIM card
1 Insert the ejection pin into the hole on the SIM card tray to loosen the tray.
2 Pull out the SIM card tray gently from the SIM card tray slot.

Basics
9
3 Remove the SIM or USIM card.
4 Insert the SIM card tray back into the SIM card tray slot.
Battery
Charging the battery
Charge the battery before using it for the first time or when it has been unused for
extended periods.
Use only WESTECH-approved chargers, batteries, and cables. Unapproved
chargers or cables can cause the battery to explode or damage the device.
•When the battery power is low, the battery icon appears empty.
•If the battery is completely discharged, the device cannot be turned on
immediately when the charger is connected. Allow a depleted battery to
charge for a few minutes before turning on the device.
•If you use multiple apps at once, network apps, or apps that need a
connection to another device, the battery will drain quickly. To avoid
disconnecting from the network or losing power during a data transfer, always
use these apps after fully charging the battery.
•Using a power source other than the USB power adaptor, such as a computer,
may result in a slower charging speed due to a lower electric current.
Connect the USB cable to the USB power adaptor, and then plug the end of the USB
cable into the multipurpose jack.

Basics
10
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
•The device can be used while it is charging, but it may take longer to fully
charge the battery.
•If the device receives an unstable power supply while charging, the
touchscreen may not function. If this happens, unplug the charger from the
device.
•While charging, the device and the charger may heat up. This is normal and
should not affect the device’s lifespan or performance. If the battery gets
hotter than usual, the charger may stop charging.
•If the device is not charging properly, contact WESTECH.
After fully charging, disconnect the device from the charger. First unplug the charger
from the device, and then unplug it from the electric socket.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not
in use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
Reducing the battery consumption
Your device provides various options that help you conserve battery power.
•Optimise the device using the Smart manager.
•When you are not using the device, switch to sleep mode by pressing the Power key.
•Activate power saving mode.
•Close unnecessary apps.

Basics
11
•Deactivate the Bluetooth feature when not in use.
•Deactivate the Wi-Fi feature when not in use.
•Deactivate auto-syncing of apps.
•Decrease the backlight time.
•Decrease the screen brightness.
Power saving mode
Save the battery power by limiting the device’s functions.
On the Home screen, tap Apps →Settings →Battery →Power saving mode, and then
tap the switch to activate it.
To automatically activate power saving mode when the remaining battery power
reaches the preset level, tap Start power saving and select an option.
Ultra power saving mode
Use this mode to extend the device’s battery power. In ultra power saving mode, the
device performs the following:
•Displays colours on the screen as grey tones.
•Restricts the available apps to essential and selected apps only.
•Deactivates the mobile data connection when the screen turns off.
•Deactivates the Wi-Fi and Bluetooth features.
On the Home screen, tap Apps →Settings →Battery →Ultra power saving mode, and
then tap the switch to activate it.
To deactivate ultra power saving mode, tap MORE →Disable ultra power saving mode.
The usage time left shows the time remaining before the battery power runs
out. Usage time left may vary depending on your device settings and
operating conditions.
Turning the device on and off
Press and hold the Power key for a few seconds to turn on the device.
When you turn on your device for the first time or after performing a data reset, follow
the onscreen instructions to set up your device.
To turn off the device, press and hold the Power key, and then tap Power off.

Basics
12
•If your device is frozen and unresponsive, press and hold the Power key and
the Volume key down simultaneously for more than 7 seconds to restart it.
•Follow all posted warnings and directions from authorised personnel in areas
where the use of wireless devices is restricted, such as aeroplanes and
hospitals.
Touchscreen
•Do not allow the touchscreen to come into contact with other electrical
devices. Electrostatic discharges can cause the touchscreen to malfunction.
•To avoid damaging the touchscreen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.
•The device may not recognise touch inputs close to the edges of the screen,
which are outside of the touch input area.
•Leaving the touchscreen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touchscreen when you do not use
the device.
•It is recommended to use fingers when you use the touchscreen.
Tapping
To open an app, to select a menu item, to press an on-screen button, or to enter a
character using the keyboard on the screen, tap it with your finger.
Tapping and holding
Tap and hold an item or the screen for more than 2 seconds to access available options.

Basics
13
Dragging
To move an item, tap and hold it and drag it to the target position.
Double-tapping
Double-tap on a webpage or image to zoom in. Double-tap again to return.
Swiping
Swipe to the left or right on the Home screen or the Apps screen to view other panels.
Swipe upwards or downwards to scroll through a webpage or a list of items, such as
contacts.

Basics
14
Spreading and pinching
Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom
out.
Home screen
Home screen
The Home screen is the starting point for accessing all of the device’s features. It
displays widgets, shortcuts to apps, and more.
To view other panels, swipe to the left or right, or tap one of the screen indicators at the
bottom of the screen.

Basics
15
Screen indicators
Home screen options
On the Home screen, tap and hold an empty area, or pinch your fingers together to
access the available options. Customise the Home screen by adding, deleting, or
rearranging Home screen panels. You can also set the Home screen wallpaper, add
widgets to the Home screen, and more.
•Wallpapers: Change the wallpaper settings for the Home screen and the locked
screen.
•Widgets: Add widgets to the Home screen. Widgets are small apps that launch
specific app functions to provide information and convenient access on your Home
screen.
•Themes: Change the device’s theme. Visual elements of interface, such as colours,
icons, and wallpapers, will change depending on the selected theme.
•Screen grid: Change the size of the grid to display more or less items on the Home
screen.

Basics
16
Flipboard Briefing
View the latest articles in various categories. You can get up to date on news that
interests you using this feature.
On the Home screen, tap or swipe to the right to open Flipboard Briefing. Swipe
upwards or downwards to browse articles in each news category.
To deactivate Flipboard Briefing, tap and hold an empty area on the Home screen. Then,
swipe to the right and deselect the tick box at the top of the Flipboard Briefing panel.

Basics
17
Adding items
Tap and hold an app or a folder from the Apps screen, and then drag it to the Home
screen.
To add widgets, tap and hold an empty area on the Home screen, tap Widgets, tap and
hold a widget, and then drag it to the Home screen.
Moving and removing an item
Tap and hold an item on the Home screen, and then drag it to a new location.
To move the item to another panel, drag it to the side of the screen.
You can also move frequently used apps to the shortcuts area at the bottom of the
Home screen.
To remove an item, tap and hold the item. Then, drag it to Remove at the top of the
screen.
Creating folders
1 On the Home screen, tap and hold an app, and then drag it over another
app. 2 Drop the app when a folder frame appears around the apps.
A new folder containing the selected apps will be created.

Basics
18
3 Tap Enter folder name and enter a folder
name. To change the folder colour, tap .
To add more apps to the folder, tap and hold another app, and then drag it to the
folder.
Managing panels
On the Home screen, tap and hold an empty area to add, move, or remove a panel.
To add a panel, swipe to the left, and then tap .
To move a panel, tap and hold a panel preview, and then drag it to a new location.
To remove a panel, tap and hold a panel preview, and then drag it to Remove at the top
of the screen.
To set a panel as the main Home screen, tap .
Apps screen
The Apps screen displays icons for all apps, including newly installed apps.
On the Home screen, tap Apps to open the Apps screen. To view other panels, swipe to
the left or right, or select a screen indicator at the bottom of the screen.
Moving items
On the Apps screen, tap EDIT. Tap and hold an item and drag it to a new
location. To move the item to another panel, drag it to the side of the screen.
Creating folders
1 On the Apps screen, tap EDIT.
2 Tap and hold an app, and then drag it over another app.
3 Drop the app when a folder frame appears around
the apps.
A new folder containing the selected apps will be created.

Basics
19
4 Tap Enter folder name and enter a folder name.
To change the folder colour, tap .
To add more apps to the folder, tap and hold another app, and then drag it to the
folder.
Indicator icons
Indicator icons appear on the status bar at the top of the screen. The icons listed in the
table below are most common.
The status bar may not appear at the top of the screen in some apps. To display
the status bar, drag down from the top of the screen.
Icon
Meaning
No signal
Signal strength
Roaming (outside of normal service area)
GPRS network connected
EDGE network connected

Basics
20
UMTS network connected
HSDPA network connected
HSPA+ network connected
/
LTE network connected (LTE-enabled models)
Wi-Fi connected
Bluetooth feature activated
GPS activated
Call in progress
Missed call
New text or multimedia message
Alarm activated
Mute mode activated
Vibration mode activated
Icon
Meaning
Flight mode activated
Error occurred or caution required
Battery power level
Lock screen
Pressing the Power key turns off the screen and locks it. Also, the screen turns off and
automatically locks if the device is not used for a specified period.
To unlock the screen, press the Power key or the Home key and swipe in any direction.
