Western Digital WD10000E035 - Elements Desktop Installation instructions

Portable Hard Drives
WD Elements™
Portable Hard Drives
Simply Affordable
Easy to Use
USB Powered
Portable USB 2.0 drives are
simple, easy-to-use, light and
easy to carry.
Simply affordable,
easily portable.
A simple, high quality portable drive that is light and easy to carry.
Simply plug it in to any USB port and start saving your photos,
music, video, and files.
WD quality inside and out –Designed with the same
commitment to quality that made WD external drives the number
one drives in the world.
Plug-and-play simplicity –Just plug it into a USB port and
you’re up and running instantly.
USB powered – These drives require no power adapter – they
are powered directly through the USB cable.*
Compact design –Weighing in at only a few ounces, these
small drives fit easily into a pocket or purse.
Preformatted for PCs – Designed for use with Windows-
based computers. Can be easily reformatted for use with Macs.
*An optional cable is available for the few computers that limit power to the USB port.
•
•
•
•
•

Portable Hard Drives
WD Elements Portable Hard Drives
Interface
USB 2.0
Dimensions
Height: 0.60 in (15 mm)
Length: 5.00 in (126 mm)
Width: 3.10 in (78 mm)
Weight: 0.44 lb (0.2 kg)
System Compatibility
Windows® XP, Windows Vista®,
Windows 7
Mac®OS®X Tiger®or Leopard®
Compatibility may vary depending on user’s hardware
configuration and operating system.
Capacities and Model Numbers
250 GB WDBAAR2500
320 GB WDBAAR3200
500 GB WDBAAR5000
Limited Warranty
Americas 1 year
EMEA 2 years
APAC 3 years
Kit Contents
USB 2.0 portable hard drive
USB cable
Quick Install Guide
Product Specifications
Data transfer rate:1 480 Mb/s (maximum)
Operating temperature: 5°C to 40°C
Non-op. temperature: –40°C to 65°C
A USB 2.0 host and USB 2.0 certified cable are required to obtain
Hi-Speed USB performance.
Western Digital, WD, the WD logo, and Put Your Life On It are registered trademarks in the U.S. and other countries; WD Elements is a trademark of Western Digital
Technologies, Inc. Other marks may be mentioned herein that belong to other companies. Pictures shown may vary from actual product. Not all products may be
available in all regions of the world. All product and packaging specifications subject to change without notice. The term of the limited warranty depends on the country
in which the product was purchased. Visit our web site at support.wdc.com/warranty/policy.asp for the detailed terms and conditions of our limited warranty and for a
list of the specific countries in these regions.
© 2009 Western Digital Technologies, Inc. All rights reserved.
As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total
accessible capacity varies depending on operating environment. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per
second,and gigabit per second (Gb/s) = one billion bits per second.
4178-705046-A00 June 2009
Examples of the number of photos, songs, videos and any other files that can be stored on a hard drive are
provided for illustrative purposes only. Your results will vary based on file size and format, settings, features,
software and other factors.
What it Holds
250 GB 50,000 or 30 or 62,000
320 GB 64,000 or 38 or 80,000
500 GB 100,000 or 60 or 125,000
Photos
up to
Hours
up to
Songs
up to
1
