Westinghouse WHSM03K User manual

INSTRUCTION MANUAL
STICK MIXER
WHSM03K220~240V

SAFETY INFORMATION
Important Safety Instructions ........................ 1-2
Electrical Requirements ................................ 3
SETUP AND USE
Installation Guide ...................................... 3
Parts and Features ..................................... 4
Stick Mixer Operation .................................. 5
CLEANING AND CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
TROUBLESHOOTING .............................. 7
WARRANTY ..................................... 8-9
CONTENTS
Figures and illustrations in this User Manual are provided
for reference only and may differ from actual product appearance.
Product design and ations may be changed without notice.

© 2018 RVM Australia Pty Ltd. All Rights Reserved 1
IMPORTANT SAFETY INSTRUCTIONS
***WARNING***


1. Read all instructions carefully before using your new stick mixer. Keep these
instructions in a safe place.
2. Always use this stick mixer with a power outlet of the voltage (A.C. only) marked
on the back of the appliance.
3. DANGER Do not operate stick mixer if:
i) the cord or plug is split, melted or damaged.
ii) the appliance has malfunctioned.
iii) the appliance has been damaged in any manner.
If any of the above incidents occur, return the stick mixer to the nearest authorised
service center for examination, repair or adjustment.
4. DANGER Do not under any circumstances immerse the power cord, mains
plug or stick mixer body in water or any other liquid.
5. WARNING Incorrect operation and improper use may damage the stick mixer
or parts thereof, and cause severe personal injury.
6. WARNING When operating the stick mixer, use handle and buttons only as
outer surfaces may become hot whilst the stick mixer is in use.
7. WARNING Do not blend hot or boiling foods or liquids as there is a risk of
burns or scalding.
8. WARNING The stick mixer blades are very sharp, avoid touching them and
handle with care.
9. WARNING Do not plug the appliance to mains before it is fully assembled.
10. WARNING Exercise caution when removing the attachments from the
attachments.
stick mixer and ensure the appliance is turned off and unplu
11. WARNING
WARNING
Keep hands and utensils out of the blending container while
blending to reduce the risk of severe injury. A scraper may be used but must only
be used when the stick mixer is not running.
12. Do not handle the appliance with wet hands.
13. CAUTION The stick mixer should not be left unattended while in operation.
14. CAUTION Keep the stick mixer and its cord out of reach of children younger
than 8 years old.
15. CAUTION It is not recommended to run the stick mixer continuously for more
than 1 minute at a time for light substances. Do not mix dry, thick or heavy
mixtures continuously for more than 15 seconds. Stop the operation and stir the
ingredients before continuing.
DANGER - Immediate hazards
which WILL result in severe
personal injury or death.
DANGER
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death.
WARNING
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury.
CAUTION

2
16. CAUTION Do not use this stick mixer with any attachment other than the
one supplied.
as this may cause damage to the stick mixer.
17. CAUTION Do not chop extremely hard food items, such as ice cubes, nutmeg
18. All stick mixers are designed to operate only when the power buttons remain
depressed.
19. Always ensure hands are dry before handling the plug or switching on the
appliance.
Ensure the stick mixer is switched off and unplugged from the power source
20.
prior to cleaning.
21. This stick mixer is not intended for use by persons (including children) with
reduced physical, sensory or metal capabilities or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the stick mixer in a safe way by the person responsible for their safety, and
understand the hazards involved.
22. Children should be supervised not to play with the stick mixer.
Always turn off the power at the power outlet before you insert or remove the
23.
power plug. Remove by grasping the plug - do not pull on the cord.
24. This appliance is intended for non-commercial, indoor use only. Do not use this
appliance for anything other than its intended use.
25. Always hold the stick mixer  and upright while using it.
26. Always use the appliance on a stable, secure, dry and level surface.
27. This stick mixer is not intended to be operated by means of an external timer or
separate remote-control system.
28. Wait for the stick mixer to cool before moving. Carry only by the handle.
29. Pay close attention when using this appliance near children.
30. Do not place your stick mixer on or near a hot gas e, electric element, heated
oven or any hot surface.
31. Do not place the stick mixer on top of any other appliance.
32. Do not permit the mains supply cord or plug to touch hot objects, or allow the
power cord to lay across the stick mixer body or blades.
33. Do not allow the power cord of this appliance to hang over the edge of a table or
bench top.
34. Do not use harsh or abrasive cleaning agents or any sharp instruments for cleaning
the appliance. When the appliance is cool to touch, the outside surface may be
wiped clean with a soft, damp cloth and then dried thoroughly. If necessary, a
mild dishwashing detergent may be applied to the cloth but not directly applied
to the stick mixer.
35. Immediately unplug the stick mixer from mains power if malfunction occurs.
36. If the appliance has been dropped or damaged, it should not be used until
examined by an authorised service center.
37. If the mains supply cord is damaged, it must be replaced by the manufacturer,
void a hazard.
IMPORTANT SAFETY INSTRUCTIONS

© 2018 RVM Australia Pty Ltd. All Rights Reserved 3
POWER SUPPLY CORD
1. Do not attempt to modify the power cord or plug in any way.
2. A short power supply cord is provided to reduce the risk of entanglement or
tripping over.
3. If the power supply cord is too short, do not use an extension cord. Have a
ceman install an outlet near the appliance.
NOTE: Neither Westinghouse nor the retailer can accept any liability for damage
to the product or personal injury resulting due to failure to observe the electrical
connection procedures.
ELECTRICAL REQUIREMENTS
INSTALLATION GUIDE
1. Carefully unpack your electric stick mixer.
2. Carefully remove packaging around the stick mixer and straighten the power
cord. Do not remove warning labels.
3. Wash blender blade attachment and allow to dry before use.
DANGER Do not under any circumstances immerse the power cord, mains plug or
stick mixer body in water or any other liquid.
WARNING The stick mixer blades are very sharp, avoid touching them and handle
with care.
ing attachments.
WARNING Exercise caution when removing the attachments from the stick mixer

4
4. Easy release mechanism for
blender blade attachment.
twin blades.
5. Blender blade attachment with
PARTS AND FEATURES
3
4
5
DESCRIPTION:
1
2
1. Pressure operated Power ON
button.
2.
3. Powerful motor chops, purees
and liquifies with ease.
Pressure operated Turbo
button. (Short powerful burst)

© 2018 RVM Australia Pty Ltd. All Rights Reserved 5
STICK MIXER OPERATION
1. Before st use, the blender blade accessory must be cleaned. Wash the blades
with warm water and mild detergent. Rinse with fresh water and allow to dry.
Your stick mixer is now ready for use.
2. Ensure unit is unplugged from wall power outlet.
3. Insert blender blade attachment into stick mixer body until it locks.
4. Ensuring your  are not pressing either of the buttons on the front of the
unit, plug the power cord into the power outlet and switch on.
5. Add ingredients into an appropriate mixing container.
6. Press the on/off or turbo button to start the mixer.
7. After use, unplug from the wall power outlet.
8. Press the easy release buttons either side of the stick mixer body simultaneously
to release the blender blade attachment.
WARNING The stick mixer and chopper blades are very sharp, avoid touching
them and handle with care.
ing attachments.
WARNING Do not plug the appliance into power before it is fully assembled.
WARNING Exercise caution when removing the attachments from the stick mixer
NOTE: All stick mixers are designed to operate only when the power buttons remain
depressed.
WARNING Do not blend hot or boiling foods or liquids as there is a risk of burns
or scalding.
CAUTION It is not recommended to run the stick mixer continuously for more
than 1 minute at a time for light substances. Do not mix dry, thick or heavy mixtures
continuously for more than 15 seconds. Stop the operation and stir the ingredients
before continuing. Allow the motor to rest for 1 minute between each use.

6
CLEANING & CARE
1. After use, unplug from the wall power outlet then press the release buttons on
either side of the stick mixer body simultaneously to release the attachment.
2. Do not use harsh or abrasive cleaning agents. The outside surface of the stick
mixer body may be wiped clean with a soft, damp cloth and dried thoroughly.
If necessary, a mild dishwashing detergent may be applied to the cloth but not
directly applied to the stick mixer.
3. Do not soak or immerse the stick mixer body in water or any other liquid.
4. to remove
most food substances. Do not immerse.
5. When washing, non-abrasive cloths and plastic bristle kitchen brushes may be
used to remove stubborn food particles from the accessories. Do not use abrasive
cloths and cleaning materials as they will damage the surface.
6. Ensure all components are dried thoroughly after cleaning, before placing into
storage.
7. Store in a dry place away from steam and humidity where possible.
DANGER Do not under any circumstances immerse the power cord, mains plug or
stick mixer body in water or any other liquid.
WARNING The stick mixer blades are very sharp, avoid touching them and handle
with care.
the stick mixer.
WARNING Exercise caution when removing the blender blade attachment from
NOTE: Parts are not dishwasher safe.

© 2018 RVM Australia Pty Ltd. All Rights Reserved 7
TROUBLESHOOTING
BEFORE CALLING FOR SERVICE
If the stick mixer fails to operate:
1. Check to make sure the stick mixer is plugged in correctly and securely. If it is not,
remove the plug from the outlet, wait 10 seconds and plug it back in securely.
2. Check for a blown or tripped circuit breaker in your home. If these seem to be
working correctly, test another appliance in the same outlet to ensure the outlet
is working correctly.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, DO NOT TRY TO ADJUST OR
REPAIR THE STICK MIXER YOURSELF.
CUSTOMER SERVICE
In the event you believe your stick mixer to be defective, please return it along with
your sales receipt to the place of purchase for resolution.
For any enquiries, please call our service center on: Tel: [phone]
TROUBLESHOOTING
Troubleshoot your problem by using the chart below. If the stick mixer still does not
operate correctly, it may be defective.
TROUBLE POSSIBLE CAUSE
Stick mixer does
not turn on.
Stick mixer is not
plugged in.
Check that stick mixer is
plugged into a working
power outlet and turned on.
POSSIBLE REMEDY
Motor slowing down
and appears to be
struggling while in use.
Foods are too dense
or too much food in
your container.
Reduce quantity of food
and try again.

8
LIMITED WARRANTY
1.
Consumer Law. The  o  Consumer under  Warr are  
Nohng n h warran affeche Consumer’s rgh under he Ausralan
o   and r of  buer under an Consumer Guaranees. The
AusrConsumer Law rrawe ca
Our goods come  guaranees a  be excluded under  Ausr
Consumer Law. You are  o a replac or refund for a major fre
and for compensa for an  r foreseeable loss or damage. You
are also  o have  goods rred or replaced   goods f o be of
accfro a major fre.
2.  o Clause 1,  Seller warr a Wes branded pr 
be free of manuf def and  perform o  Seller’s a
follo!
3. The  of  Warr exends  o  owner of  pr  
 Pr manufred or  b  Seller are s and used b 
owner fraWarrP!
4. The Warr commences on  dae of  purchase of  pr and
c for   of  Owner for  Warr P! If  
Warr P a manuf def  covered   Pr" or 
Pr f o perform o  Seller’s a as a r of some def 
noercsdnwosallwrelleSehneh,cudorPehnphsnamkrowrola
ream
a.) R or replace  Pr a  cos of  Seller,   
ed o labour and ravel cos! Goods rred or replaced under 
Warrwarraned frWarr.
b.) Rrcbconsumer.
5. The Warro Pra
a.) Has f due o excesve wear and ear beond wha  cred o be
reasonable.
b!#$ed.
c.) Has been damaged ac or b  of God  re and !
d.) Has been used or operaed cr o opera or enance s!
e.) Has been damaged b  Consumer or a rd   o  for 
crrsore Consumer.
6. In order o make a  under  Warr,  Owner mus" where pos
r  goods o  Seller’s sore a  Owner’s cos! Proof of purchase mus
!
7. The seller  ex an r Pr and   Seller de a
rrfrough no f%r"
a.) Make noe of  Owner’s c    Owner’s elephone
number   owner can be ced  ss hours, pos
addres&ress.

© 2018 RVM Australia Pty Ltd. All Rights Reserved 9
b.) Make note of the defects reported by the Owner.
c.) Take back the defective goods from the owner and determine within a
reasonable time through dialogue with the Seller whether the goods are
defective.
d.) Advise the owner within a reasonable time frame whether it accepts or
rejects the Product claim.
e.) If the Seller accepts the return of the Product, the Seller must arrange to have
i) The Product repaired or,
ii) Replace the damaged or faulty Product or,
iii) Refund the purchase price.
8. The Seller will not accept any returned Product which has not been returned
strictly in accordance with this Warranty.
9. For the purpose of this Warranty:
a.) Australian Consumer Law means the law as set out in Schedule 2 of the
Competition and Consumer Act 2010 (Cth).
b.) Consumer means the Purchaser of goods from the seller.
c.) Consumer means a Consumer as that term is set out in section 3 of the
Australian Consumer Law.
d.) Consumer Guarantees means the guarantees under the Australian Consumer
Law.
e.) Implied terms means any guarantees, conditions, warranties or other terms
implied by any Australian Commonwealth, State or Territory laws, (excluding
the Australian Consumer Law) or the law of any other jurisdiction.
f.) Owner has the meaning set out in clause 3.
g.) Warranty means this warranty.
h.) Product means the Product/s bought by the Owner from the Seller that fall
under this warranty.
i.) Warranty Period means:
i) In relation to Cast Iron Cookware: 3 Year Limited Warranty.
ii) In relation to Non-Stick Cookware: 3 Year Limited Warranty
iii) In relation to Cooking Utensils: 3 Year Limited Warranty
iv) In relation to Knives/Knife Block Sets: 3 Year Limited Warranty
v) In relation to Stainless Steel Cookware: 10 Year Limited Warranty
vi) In relation to Chopping boards: 1 Year Limited Warranty
vi) In relation to Small Appliances: 1 Year Limited Warranty

14
CUSTOMER SERVICE - 1300 883 109
IMPORTED AND DISTRIBUTED BY RVM AUSTRALIA PTY LTD.
11 Tamara Drive, Cockburn Central, WA 6164
MADE IN CHINA
© 2018 RVM AUSTRALIA PTY LTD. ALL RIGHTS RESERVED.
, WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF
are trademarks of Westinghouse Electric Corporation.
Used under license by RVM AUSTRALIA PTY LTD. ALL RIGHTS RESERVED.
