Westinghouse WP2500 User manual

2
DISCLAIMERS:
All information, illustrations and specifications in this manual are based on the latest information available at
the time of publishing. The illustrations used in this manual are intended as representative reference views only.
Moreover, because of our continuous product improvement policy, we may modify information, illustrations and/or
specifications to explain and/or exemplify a product, service or maintenance improvement. We reserve the right to
make any change at any time without notice.
ALL RIGHTS RESERVED:
No part of this publication may be reproduced or used in any form by any means – graphic, electronic or
mechanical, including photocopying, recording, taping or information storage and retrieval systems – without the
written permission of Westpro Power Systems, LLC.
California
Proposition 65 Warning
Certain components in this product and its
related accessories contain chemicals
known to the state of California to cause
cancer, birth defects or other reproductive
harm. Wash hands after handling.
California
Proposition 65 Warning
The engine exhaust from this product
contains chemicals known to the state of
California to cause cancer, birth defects
or other reproductive harm.

CONGRATULATIONS ON OWNING A WESTINGHOUSE
PRESSURE WASHER
!DANGER
!This manual contains important instructions for operating this pressure washer. For your safety
and the safety of others, be sure to read this manual thoroughly before operating the pressure
washer. Failure to properly follow all instructions and precautions can cause you and others to
be seriously hurt or killed.
For Your Records
Date of Purchase: Pressure Washer Model Number:
Purchased from Store/Dealer: Pressure Washer Serial Number:
Purchase Receipt: (retain your purchase receipt to ensure trouble-free warranty coverage)
Product Registration
To ensure trouble-free warranty coverage, it is important you register your Westinghouse pressure washer.You can
register your pressure washer by either:
1. Filling in the product registration form below and mailing to:
Product Registration
Westpro Power Systems, LLC
W237 N2889 Woodgate Road, Unit B
Pewaukee, WI 53072
2. Registering your product online at www.westpropower.com
To register your pressure washer you will need to locate the following information:
Model Number Serial Number
Product Registration Form
PERSONAL INFORMATION PRESSURE WASHER INFORMATION
First Name: Model Number:
Last Name: Serial Number:
Street Address: Date Purchased:
Street Address: Purchased From:
City, State, ZIP:
Country:
Phone Number:
E-Mail:

5
TABLE OF CONTENTS
CONGRATULATIONS ON OWNING A WESTINGHOUSE PRESSURE WASHER ...........................................3
For Your Records ..........................................................................................................................................3
Product Registration.....................................................................................................................................3
Product Registration Form............................................................................................................................3
SAFETY ....................................................................................................................................................................7
SAFETY DEFINITIONS ......................................................................................................................................7
SAFETY SYMBOL DEFINITIONS ......................................................................................................................7
GENERAL SAFETY RULES ...............................................................................................................................8
SAFETY LABELS AND DECALS .....................................................................................................................10
WP2500......................................................................................................................................................10
WP2800......................................................................................................................................................11
WP3000Z....................................................................................................................................................12
UNPACKING ...........................................................................................................................................................13
UNPACKING THE PRESSURE WASHER........................................................................................................13
COMPONENTS ................................................................................................................................................13
ASSEMBLY.............................................................................................................................................................15
ASSEMBLY – WP2500 AND WP2800 ..............................................................................................................15
ASSEMBLY – WP3000Z ...................................................................................................................................18
FEATURES .............................................................................................................................................................22
GENERAL PRESSURE WASHER FEATURES................................................................................................22
WP2500 and WP2800 ................................................................................................................................22
WP2500 and WP2800 ................................................................................................................................23
WP3000Z....................................................................................................................................................24
WP3000Z....................................................................................................................................................25
OPERATION ...........................................................................................................................................................26
BEFORE STARTING THE PRESSURE WASHER ...........................................................................................26
ADDING / CHECKING ENGINE FLUIDS AND FUEL.......................................................................................26
Checking and / or Adding Engine Oil..........................................................................................................26
Adding Gasoline to the Fuel Tank...............................................................................................................27
CONNECTING THE WATER SUPPLY..............................................................................................................27
STARTING THE PRESSURE WASHER – WP2500 AND WP2800 ..................................................................28
Stopping the Pressure Washer...................................................................................................................30
STARTING THE PRESSURE WASHER – WP3000Z .......................................................................................30
Stopping the Pressure Washer...................................................................................................................32
SELECTING NOZZLES ....................................................................................................................................33
Changing the Nozzle ..................................................................................................................................34
SPRAYING TIPS...............................................................................................................................................34
SPRAYING SOAP.............................................................................................................................................34
RINSING ...........................................................................................................................................................35
CLEANING SOAP SIPHON HOSE...................................................................................................................35
MAINTENANCE......................................................................................................................................................36
MAINTENANCE................................................................................................................................................36
Maintenance Schedule...............................................................................................................................36
ENGINE OIL MAINTENANCE – WP2500 AND WP2800 .................................................................................37
Engine Oil Specification..............................................................................................................................37
Checking Engine Oil...................................................................................................................................37
Adding Engine Oil.......................................................................................................................................38
Changing Engine Oil...................................................................................................................................38
ENGINE OIL MAINTENANCE – WP3000Z ......................................................................................................39
Engine Oil Specification
..............................................................................................................................39
Checking Engine Oil...................................................................................................................................39
Adding Engine Oil.......................................................................................................................................40
Changing Engine Oil...................................................................................................................................40
AIR FILTER MAINTENANCE – WP2500 AND WP2800...................................................................................40
Cleaning the Air Filter.................................................................................................................................40
AIR FILTER MAINTENANCE – WP3000Z.......................................................................................................42
SPARK PLUG MAINTENANCE ........................................................................................................................43

6
TABLE OF CONTENTS
PRESSURE WASHER COMPONENTS...........................................................................................................44
Water Filter Screen.....................................................................................................................................44
High-Pressure Hose and Spray Gun ..........................................................................................................45
High-Pressure Hose.............................................................................................................................45
Spray Gun ............................................................................................................................................45
Soap Siphon Hose......................................................................................................................................45
Nozzle.........................................................................................................................................................45
AFTER EACH USE...........................................................................................................................................45
LONG-TERM STORAGE ..................................................................................................................................46
Storage Procedure for 1 – 3 Months...........................................................................................................46
Storage Procedure for Greater Than 3 Months ..........................................................................................46
WINTER STORAGE..........................................................................................................................................46
Remove and Install the Pump – WP2500 and WP2800 .............................................................................46
Remove and Install the Pump – WP3000Z.................................................................................................47
TROUBLESHOOTING ............................................................................................................................................48
TROUBLESHOOTING ......................................................................................................................................48
WARRANTY............................................................................................................................................................50
WESTPRO POWER SYSTEMS “THREE YEAR” LIMITED WARRANTY.........................................................50
WESTPRO’S RESPONSIBILITY................................................................................................................50
OWNER’S RESPONSIBILITY ....................................................................................................................50
PRODUCT WARRANTY APPLICATIONS AND PRODUCT WARRANTY PERIODS ................................50
CONSUMER APPLICATION................................................................................................................50
COMMERCIAL APPLICATION ............................................................................................................50
EXCLUSIONS......................................................................................................................................51
DISCLAIMER OF IMPLIED WARRANTIES................................................................................................51
EMISSIONS CONTROL WARRANTY ....................................................................................................................52
FEDERAL AND/OR CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT....................................52
YOUR WARRANTY RIGHTS AND OBLIGATIONS ....................................................................................52
MANUFACTURER’S WARRANTY COVERAGE: .......................................................................................52
OWNER’S WARRANTY RESPONSIBILITIES:...........................................................................................52
DEFECTS WARRANTY REQUIREMENTS................................................................................................52
WARRANTED PARTS: ...............................................................................................................................53
QUESTIONS:..............................................................................................................................................54

7
SAFETY
SAFETY DEFINITIONS
The words DANGER, WARNING, CAUTION and
NOTICE are used throughout this manual to highlight
important information. Be certain that the meanings of
these alerts are known to all who work on or near the
equipment.
!
This safety alert symbol appears
with most safety statements. It
means attention, become alert, your
safety is involved! Please read and
abide by the message that follows
the safety alert symbol.
!DANGER
Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
!WARNING
Indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
!CAUTION
Indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE
Indicates a situation which can cause damage to
the pressure washer, personal property and/or the
environment, or cause the equipment to operate
improperly.
OTE:NIndicates a procedure, practice or condition that
should be followed in order for the pressure
washer to function in the manner intended.
SAFETY SYMBOL
DEFINITIONS
Symbol Description
!Safety Alert Symbol
Asphyxiation Hazard
Burn Hazard (Chemical)
Symbol Description
Burn Hazard
Burst/Pressure Hazard
Don’t leave tools in the area
Electrical Shock Hazard
Explosion Hazard
Fall Hazard
Fire Hazard
High-Pressure Hazard
Lifting Hazard
Pinch-Point Hazard
Read Manufacturer’s Instructions
Read Safety Messages Before
Proceeding
Wear Personal Protective Equipment
(PPE)

8
SAFETY
GENERAL SAFETY RULES
!DANGER
NEVER operate the pressure washer
in an enclosed area. Engine exhaust
contains carbon monoxide. Only
operate the pressure washer outside
and away from windows, doors and
vents.
!WARNING
Gasoline and gasoline vapors are
extremely flammable and explosive
under certain conditions.
• ALWAYS refuel the pressure washer
outdoors, in a well-ventilated area.
• NEVER remove the fuel cap with the
engine running.
• NEVER refuel the pressure washer
while the engine is running. Always
turn engine off and allow the
pressure washer to cool before
refueling.
• Only fill fuel tank with gasoline.
• Keep sparks, open flames or other
form of ignition (such as match,
cigarette, static electric source) away
when refueling.
• NEVER overfill the fuel tank. Leave
room for fuel to expand. Overfilling
the fuel tank can result in a sudden
overflow of gasoline and result in
spilled gasoline coming in contact
with HOT surfaces. Spilled fuel
can ignite. If fuel is spilled on the
pressure washer, wipe up any
spills immediately. Dispose of rag
properly. Allow area of spilled fuel
to dry before operating the pressure
washer.
• Wear eye protection while refueling.
• NEVER use gasoline as a cleaning
agent.
• Store any containers containing
gasoline in a well-ventilated area,
away from any combustibles or
source of ignition.
• Check for fuel leaks after refueling.
Never operate the engine if a fuel leak
is discovered.
!WARNING
This equipment produces a stream
of water with enough high pressure
to penetrate skin and its underlying
tissues, which could result in
amputation or other serious injury.
Spray gun traps high-pressure water,
even when engine is stopped and
water is disconnected. Leaks caused
by loose fittings or worn or damaged
hoses can result in injection injuries.
DO NOT TREAT FLUID INJECTION
AS A SIMPLE CUT! See a physician
immediately!
• NEVER aim spray gun at people,
animals or plants. Direct spray away
from self and others.
• NEVER place hands in front of nozzle.
• ALWAYS point spray gun in safe
direction while spraying and when
relieving retained high pressure after
stopping engine.
• DO NOT allow CHILDREN to operate
pressure washer.
• NEVER leave spray gun unattended
while machine is running.
• NEVER secure spray gun in open
position.
• DO NOT twist nozzle while spraying.
• NEVER repair a high-pressure hose.
ALWAYS replace it.
• NEVER repair leaking connections
with sealant of any kind. ALWAYS use
factory-recommended repair parts.
• NEVER hold onto the hose or fittings
during operation.
• DO NOT allow high-pressure hose to
contact muffler or other extremely
hot surfaces.
• ALWAYS be certain spray gun,
nozzles and hoses are correctly
attached and in working order.
• NEVER use spray gun if trigger lock
is not in working order.
• ALWAYS use spray gun, hoses and
connections rated for pressure
higher than your pressure washer’s
psi.
• NEVER attach or remove spray gun,
nozzles or hoses while system is
pressurized.

9
SAFETY
!WARNING
• NEVER modify spray equipment.
• ALWAYS wear protective clothing to
protect eyes and skin from contact
with sprayed materials.
NEVER aim spray in the direction of
power source. Contact with power
source can cause electric shock or
burn.
Unexpected kickback while spraying
can cause you to fall.
• Use of pressure washer can create
slippery surfaces and puddles.The
operating area of this equipment
should have adequate drainage to
reduce the possibility of a fall due to
slippery surfaces.
• Be extremely careful if necessary
to use the pressure washer from
a ladder, scaffolding or any other
similar location.
• Use both hands to firmly gasp the
spray gun while in use to avoid injury
from high-pressure kickback.
NEVER use acids, toxic or corrosive
chemicals, poisons, insecticides, or
any kind of flammable solvent with
this equipment. Only use detergents,
cleaners and degreasers recommended
for use in this pressure washer.
ALWAYS wear chemical splash safety
goggles that comply with ANSI Z87.1
when operating or in the vicinity of this
equipment.
ALWAYS remove any tools or other
service equipment used during
maintenance from the pressure washer
before operating.
NOTICE
NEVER operate pressure washer with damaged or
missing parts.
NEVER modify any feature or component of pressure
washer.
NEVER spray at glass when using the high-pressure
nozzle (red). High-pressure spray may damage fragile
items including glass.
DO NOT exceed rated pressure when operating
pressure washer.
NEVER move pressure washer by pulling on any
hoses. Always use handle to move pressure washer.
Check components for ice forming on components
when operating in cold weather.
Remove the protective shipping caps from the pump’s
water inlet and outlet.
Be sure the water supply is connected and turned
on before starting the engine. Damage to the pump
could occur and will void the warranty.
Water supply must deliver a minimum of 3.8 gal
(14.3 L) per minute and at least 30 psi (2 bar). Do
not siphon standing water for the water supply. Water
temperature must not exceed 100°F (37.7°C).
DO NOT install a one-way valve, vacuum breaker or
check valve at the pump’s water inlet. Installing one of
these devices at the pump’s water inlet could cause
damage to the pump and will void the warranty. Allow
at least 10 feet (3 m) of unrestricted hose length
between the pump’s water inlet and a one-way valve,
vacuum breaker or check valve.

10
SAFETY
SAFETY LABELS AND DECALS
WP2500
Figure 1

11
SAFETY
WP2800
Figure 2

12
SAFETY
WP3000Z
Figure 3

13
UNPACKING
UNPACKING THE PRESSURE
WASHER
!CAUTION
Always have assistance when lifting
the pressure washer.The pressure
washer is heavy; lifting it could cause
bodily harm.
!Avoid cutting on or near staples to
prevent personal injury.
The following tools are required:
 Box cutter or similar device
 8 mm wrench
 17 mm wrench (WP2500)
 13 mm wrench (WP3000Z)
1. Carefully cut the packing tape on top of the carton.
2. Fold back top flaps to reveal the owner’s manual.
Remove owner’s manual and save it for reference.
3. Carefully cut two sides of the carton to remove the
pressure washer.
COMPONENTS
Verify the contents against the list below. If any
parts are missing, please locate an authorized
Westinghouse dealer at www.westpropower.com or call
1-855-WHHELP1 (1-855-944-3571).
124
5
6
7
8
3
Figure 4 – Unpacking
1 - High-Pressure
Hose (1)
2 - Spray Wand (1)
3 - Upper Handle
(1)
4 - Nozzles (5)
5 - Soap Hose (1)
6 - Spray Gun (1)
7 - Wheels (2)
WP2500
8 - Wheels (2)
WP2800 and
WP3000Z
OTE:N A 0.6-liter bottle of SAE 10W30 oil is also
included. Soap reservoir is not included.

14
UNPACKING
1234
5
8
9
10
11
12
13
6
7
14
16
15
Figure 5 – Hardware
1 - Hose Bracket (1)
2 - Spray Gun
Bracket Bolts
M6 x 45 mm (2)
3 - Spray Gun
Bracket Nuts
M6 (2)
4 - Handle Knobs (2)
5 - Wheel Axle Flange
Bolts M12 x
105 mm (2)
WP2500
6 - Hose Bracket Bolts
M5 x 10 mm (2)
7 - Hose Bracket Nuts
M5 (2)
8 - Serrated Flange
Nut M12 (4)
WP2500
9 - Wheel Axle Pin
16 mm x 105
mm (2) WP2800
and WP3000Z
10 - Wheel Axle
Lock Pin (2)
WP2800 and
WP3000Z
11 - Spray Gun
Bracket
12 - Upper Handle
Bolts (2)
13 - Spare Parts:
High-Pressure
Hose O-Rings (2)
Inlet Screens (2)
14 - Nuts M8 (2)
WP3000Z
15 - Axle Washers (4)
WP2800 and
WP3000Z
16 - Front Support
WP3000Z

15
ASSEMBLY
ASSEMBLY – WP2500 AND
WP2800
Before assembling the pressure
washer, review Safety on page 7
and the following safety messages.
!CAUTION
Never lift the pressure washer without
assistance. The pressure washer is
heavy and lifting without assistance
could result in personal injury.
!Never use the handles as a lifting point
to support the entire weight of the
pressure washer. Only use the handles
to move the pressure washer by lifting
the handles and using the wheels to
move the pressure washer.
Use caution when collapsing the
handles. Hands and fingers could get
caught and pinched.
NOTICE
Assembling the pressure washer will require tipping
the unit. Make sure all engine oil and fuel are drained
from the unit prior to assembling.
Once assembled, the wheels are not intended for
on-road use. The wheels are designed for use on this
pressure washer only.
Never tip the pressure washer after it has been fully
assembled and filled with oil and fuel.
1. Place pressure washer on a flat surface.
2. Place a piece of cardboard or other soft material to
tip the pressure washer onto, to protect the frame
paint and prevent the pressure washer from sliding.
Tip the pressure washer onto the front as shown in
Figure 6.
Figure 6 – Tip the Pressure Washer onto the Front
3. WP2500 only: Install the M12 x 105 mm wheel axle
flange bolt through the wheel (see Figure 7).
1
2
Figure 7 – Installing Outside Serrated Flange Nut
WP2500
1 - Wheel Axle
Flange Bolt 2 - Serrated Flange Nut
4. WP2500 only: Thread the M12 serrated flange nut
onto the bolt with serrated edges facing away from
the wheel. Tighten the nut (see Figure 7).

16
ASSEMBLY
5. WP2500 only: Install the wheel with bolt through the
spacer and the frame (see Figure 8).
1
2
Figure 8 – Assemble Wheels to Frame WP2500
1 - Spacer 2 - Serrated Flange
Nut
6. WP2500 only: Install the serrated flange nut and
tighten (see Figure 8).
7. WP2800 only: Slide the wheel axle washer onto the
wheel axle pin (see Figure 9).
1
2
Figure 9 – Installing Wheel Axle Washer WP2800
1 - Wheel Axle
Washer 2 - Wheel Axle Pin
8. WP2800 only: Install the axle pin through the axle
bracket, and secure with lock pin (see Figure 10).
1
2
Figure 10 – Installing Wheel Axle
1 - Wheel Axle Pin 2 - Wheel Axle
Lock Pin
9. Install the hose bracket to the handle using the M5
bolts and nuts (see Figure 11).
1
2
Figure 11 – Installing Hose Bracket
1 - Hose Bracket 2 - M5 Bolts and
Nuts

17
ASSEMBLY
10. Install the upper handle to the frame using the
handle bolts and knobs (see Figure 12).
23
1
Figure 12 – Installing Upper Handle
1 - Upper Handle
2 - Handle Bolt
3 - Knob
11. Install the spray gun bracket using the M6 bolts and
nuts (see Figure 13).
1
2
Figure 13 – Installing Spray Gun Bracket
1 - Spray Gun
Bracket 2 - M6 Bolts and Nuts
12. Connect the wand to the spray gun and turn the
fitting counterclockwise to tighten (see Figure 14).
Do not overtighten. The fitting only needs to be
hand-tight.
2
1
Figure 14 – Connecting Spray Wand
1 - Spray Wand 2 - Fitting
13. Inspect the O-rings on both sides of the high-
pressure hose. Moisten the O-rings with water (see
Figure 15).
Figure 15 – High-Pressure Hose O-Rings

18
ASSEMBLY
14. Connect the high-pressure hose to the pump and
tighten the hose fitting (see Figure 16). Do not
overtighten. The fitting only needs to be hand-tight.
12
Figure 16 – Installing High-Pressure Hose WP2500
Shown
1 - Soap Hose 2 - Hose Fitting
15. Connect the soap hose to the barbed fitting if you
are going to be using soap (see Figure 16).
16. Flip the trigger lock up to lock the trigger in the OFF
position (see Figure 17).
1
2
Figure 17 – Trigger Lock in OFF Position
1 - Trigger Lock 2 - Hose Fitting
17. Install the high-pressure hose to the spray gun
and tighten the hose fitting (see Figure 17). Do not
overtighten. The fitting only needs to be hand-tight.
ASSEMBLY – WP3000Z
Before assembling the pressure
washer, review Safety on page 7
and the following safety messages.
!CAUTION
Never lift the pressure washer without
assistance. The pressure washer is
heavy and lifting without assistance
could result in personal injury.
!Never use the handles as a lifting point
to support the entire weight of the
pressure washer. Only use the handles
to move the pressure washer by lifting
the handles and using the wheels to
move the pressure washer.
Use caution when collapsing the
handles. Hands and fingers could get
caught and pinched.
NOTICE
Assembling the pressure washer will require tipping
the unit. Make sure all engine oil and fuel are drained
from the unit prior to assembling.
Once assembled, the wheels are not intended for
on-road use. The wheels are designed for use on this
pressure washer only.
Never tip the pressure washer after it has been fully
assembled and filled with oil and fuel.
1. Place pressure washer on a flat surface.
2. Install the upper handle to the frame using the
handle bolts and knobs (see Figure 18).

19
ASSEMBLY
1
2
3
Figure 18 – Installing Upper Handle
1 - Handle Bolt
2 - Upper Handle
3 - Knob
3. Slide the wheel axle washer onto the wheel axle pin
(see Figure 19).
1
2
Figure 19 – Installing Wheel Axle Washer
1 - Wheel Axle
Washer 2 - Wheel Axle Pin
4. Install the pin into the wheel assembly.
5. Install the pin through the axle mounting holes.
Install a washer on the axle pin (see Figure 20).
12
3
Figure 20 – Installing Wheel Axle Washer
1 - Wheel Axle Pin
2 - Wheel Axle
Washer
3 - Wheel Axle
Lock Pin
6. Secure the wheel axle pin in position with the wheel
axle lock pin (see Figure 20).
7. Install the front support using the two front support
nuts (M8). Tighten the nuts securely (see Figure
21).
2
1
Figure 21 – Installing Front Support
1 - Front Support 2 - Front Support
Nuts (M8)

20
ASSEMBLY
8. Install the spray gun bracket using the two spray
gun bracket nuts and bolts (M6). Tighten securely
(see Figure 22).
21
6
3
4
5
Figure 22 – Installing Spray Gun Bracket and Hose
Bracket
1 - Spray Gun
Bracket
2 - Spray Gun
Bracket Nuts
(M6)
3 - Spray Gun
Bracket Bolts
(M6 x 45 mm)
4 - Hose Bracket
5 - Hose Bracket
Nuts M6
6 - Hose Bracket
Bolts (M6 x
10 mm)
9. Install the hose bracket using the two hose bracket
nuts and bolts (M6). Tighten securely (see Figure
22).
10. Connect the wand to the spray gun and turn the
fitting counterclockwise to tighten (see Figure 23).
Do not overtighten. The fitting only needs to be
hand-tight.
1 2
Figure 23 – Connecting Spray Wand
1 - Fitting 2 - Spray Wand
11. Inspect the O-rings on both sides of the high-
pressure hose. Moisten the O-rings with water (see
Figure 24).
Figure 24 – High-Pressure Hose O-Rings
12. Connect the high-pressure hose to the pump and
tighten the hose fitting (see Figure 25). Do not
overtighten. The fitting only needs to be hand-tight.
