Westlab 664-812 User manual

1
PRODUCT MANUAL
Product Manual
Floor Mounted, Emergency Shower,
Head & Eye Wash
Code 664-812

PLEASE READ THESE INSTRUCTIONS BEFORE USE.
TABLE OF CONTENT
1. Product Description
1.1 Introduction
1.2 Features
2. TechnicalSpecications
3. Operating Instructions
- Shower
4. Operating Instructions
- Eye Shower
1. Product Description
1.1 Introduction
Westlab’s Premium Emergency Shower has a maximum working pressure of 5 Bars,
the emergency shower is engineered for a quick response to injuries.
Manufactured in Italy – world leaders in quality.
1.2 Features
• Floor Fixed Emergency Shower
• ABS Showerhead & Eyewash Bowl
• Epoxy Powder Coated Surface Protection
• Hand & Foot Operated
• 100% Italian Made
2. Technical Specications
Application Floor Fixed
Test Pressure 9 bars/air
Working Pressure Max. 5 bars
Flow Rate 30L/min at 1 bar
Surface Protection Epoxy Powder Coated
Materials Brass
ABS
Stainless Steel
Headwork Sealing PTFE Temperature Working Range
of 0 to 70°C
Tap Connection G1” Female
Compliance DIN12899
DIN12918
ISO0228/1
EN15154
Weight 21,150g
PRODUCT CODE
664-812
M
a
d
e
i
n
I
t
a
l
y
2
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

Dimensions
285
1120
2150
165
OUT 1-1/4ÓF
1630
IN 1-1/4ÓF
3. Operating Instructions - Shower
1. Standards and regulations
The FAR safety showers comply with all aspects of DIN 12899-3:2009, DIN EN 15154-1:2006,
ANSI Z358.1-2009, TRGS 526 and the BG Chemie BGI/GUV-I 850-0 guidelines. This operating
manual serves as a supplement to the valid rules and regulations. Please take note of the DIN
12899-3:2009, DIN EN 15154-1:2006, ANSI Z358.1-2009, TRGS 526 and the BG Chemie BGI/
GUV-I 850-0 guidelines.
2. Operating pressure
The FAR safety showers are designed for an operating pressure of a maximum of 10 bar
(PN10).Theowrateisdependentontheavailablewaterpressureaswellasthecross
section of the connecting pipes. FAR safety showers with high-performance shower head
withoutintegratedowregulationhaveanaveragevolumeowofatleast60liters/minute
at 1 bar dynamic water pressure.
3
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

2.1 FAR–high-performanceshowerheadwithintegratedowregulation50l/min(classI
acc.toDIN12899-3:2009)Theowrateis45to55liters/minute.Thisvolumeowisset
automaticallybyaowregulatorintegratedinthehigh-performanceshowerheadirrespective
of the existing operating pressure.
2.2 FAR–high-performanceshowerheadwithintegratedowregulation70l/min(classII
acc.toDIN12899-3:2009)Theowrateis63to77liters/minute.Thisvolumeowisset
automaticallybyaowregulatorintegratedinthehigh-performanceshowerheadirrespective
of the existing operating pressure.
2.3 FAR–high-performanceshowerheadwithoutintegratedowregulation(classIIIacc.to
DIN12899-3:2009)Theowrateisunlimitedanddependentontheavailablewaterpressure
aswellasthecrosssectionoftheconnectingpipes.Thevolumeowisupto120liters/
minute with appropriate water pressure and cross section of the connecting pipes.
3. Construction
Where possible, the safety showers are to be stored and delivered in the transport packaging
(box/pallet) supplied and kept in dry and frost-free conditions.
The surface must be level and be able to hold the weight of the safety shower when installed
andlled.Wallsandspecialstructuresmustbeabletoholdtheweightofthesafetyshower
and the piping.
Any water leaking from the safety shower during use should not be able to cause any
consequential damage. Leaking water is to be safely drained away using barriers and drain
trays if necessary.
3.1 Water connection
The connections for the various safety showers have a ¾” to 1 ¼” thread. We recommend
attaching the safety shower to at least a ¾ inch pipe. The water pressure should be at least
1 bar. The water supply for the safety shower should be situated near the system and have a
stop valve for maintenance and repair work that no one can tamper with.
3.2 Necessary space / installation height of body safety showers.
There must be a free space with a radius of 400 mm underneath the body safety shower.
The installation height in accordance with DIN EN 15154-1:2006 of the lower edge of the
shower head (body safety shower) must be 210–230 cm.
3.3 Necessary space / installation height of eye showers.
There must be a free space with a radius of 150 mm around the eye shower. The installation
height in accordance with DIN EN 15154-2:2006 of the upper edge of the spray head (eye
shower) must be 80–120 cm.
3.4 Installation height of safety shower valve / release button.
The safety shower valve / release button should be mounted in a maximum height of 175 cm
abovetheoorintheimmediatevicinityofthesafetyshower.
3.5 Self-draining between valve and shower head.
For an installation in accordance with DIN EN 15154-1:2006 it must be ensured, that the
safety shower installation is self-draining between valve and shower head.
4
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

4. Installation
4.1 Installation of wall/ceiling mounted versions
Wall or ceiling mounted versions must be securely fastened to the wall/ceiling or other
special structure. The technique required to fasten the shower depends on the construction
and is to be decided by the installation company.
4.2 Installation of over-door mounted versions
The over-door models are delivered with an already attached valve adapter (type A) for
installation of the rod-operated valve to the right of the door. If an installation to the left of the
door is required, then the attached valve adapter (type A) must be replaced by another valve
adapter (type B), which is also included in the delivery. The specialist tool (C31), which is also
included in the delivery, must be used to attach the valve adapter to the ball cock. The nut of
the ball cock must be tightened with a standard screw locking device.
4.3 Installation of freestanding body safety showers
Freestanding body safety showers must be securely fastened to the surface using the base
plate. The technique required to fasten the shower depends on the construction and is to be
decided by the installation company.
4.4 Installation of safety shower cubicles
Safetyshowercubiclesmustbesecurelyscrewedtothesuboorbymeansofthebase
plates. The technique required to fasten the shower depends on the construction and is to be
decided by the installation company.
4.5 Models with eye showers
4.5.1 Models with safety eye showers combine the eye shower and body safety shower using
the provided adapter
4.5.2 Models with hand-held eye showers mount the bracket of the hand-held eye shower
at a height of approximately 900 mm. Connect the hand-held eye shower to the body
safety shower with the hose using the double adapter.
4.5.3 Models with eye/face wash units remove the base of the eye shower. Drill the holes for
the pipe clamps using the template provided. Place the eye shower at a height of 970
mm on the body safety shower and fasten it using the pipe clamps, screws and nuts.
Install the base. Connect the eye shower to the body safety shower with the hose using
the double adapter.
4.6 Models with optional platform actuation
Platformactuatorsmustbesecurelyscrewedtotheoor.Whichtypeoffastenersare
required must be determined at the installation site by installation personnel depending upon
the type of foundation.
The actuating chain is cut to length at the factory. During setup at the installation site, it
must be assured that the actuating chain opens the valve all the way when the platform is
subjected to full loading, but it must also have a small amount of remaining free play. If there
is no free play, for example due to an out-of-level foundation, the chain must be lengthened
because the shower valve will otherwise be damaged.
5
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

The return spring is also preset at the factory. During setup at the installation site, it must be
assured that the spring holds the platform up, and that the actuating chain to the valve is not
subjected to any load.
4.7 Models with eye shower and optional foot lever actuation
The actuating chain is cut to length at the factory. During setup at the installation site, it
must be assured that the actuating chain opens the valve all the way when the platform is
subjected to full loading, but it must also have a small amount of remaining free play. If there
is no free play, for example due to an out-of-level foundation, the chain must be lengthened
because the shower valve will otherwise be damaged.
4.8 Models with optional catch basin
Thewateroutletisequippedwitha2”maledrainpipe.Waterdisposalxturesrequired
forfurthertransportofwastewatermustbeclariedattheinstallationsite.Asaresult
of the shower’s design, splash water will also fall outside of the catch basin, especially in
consideration of the fact that the user causes additional dispersion. If the possibility exists
that this may result in danger, please make use of our housings.
5. Water supply
The FAR body safety showers must be connected to drinking water. The drinking water
network must be set up in accordance with DIN 1988 and DIN EN 1717.
CAUTION! For new installations the water supply system must be rinsed out before
connecting the shower in order to prevent dirt damaging the valve. The high-performance
shower head must be deinstalled during this process. It must be reinstalled after the
rinsing process. The high-performance shower head can be fastened and tightened
using a pin type face wrench (item no. BR 010 100).
6. Electrical Connection
All heated safety showers and safety showers with optional electrical accessories must be
connected to the available electricity supply system of the factory.
If the safety shower is equipped with electrically operated options, supply power must be
protected with an appropriately dimensioned fuse, as well as an RCCB (residual current
circuit breaker) with a maximum tripping current of 30 mA. All of the shower system’s
metallic components must be electrically connected to equipotential bonding included in
the existing electrical system. Any special building requirements (such as Ex zones, EMC,
corrosion protection etc.) must be examined on-site and taken into consideration as required.
Inspection and testing of all safety equipment (safety measures) for correct functioning must
be executed and documented. All applicable VDE and other overriding requirements must
be observed and adhered to. Safety shower systems can be ordered for use in potentially
explosiveatmospheres.Makesurethatthesystemisappropriatelyidentiedforuseinthe
required environment before initial start-up in hazardous areas!
7. Safety labelling
The enclosed safety label (self-adhesive label) is to be attached near the FAR body safety shower.
6
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

8. Location
The location is to be chosen in accordance with the BG Chemie BGI/GUV-I 850-0 guidelines.
Access must always be kept clear. Special care must also be taken at the installation location
that the safety shower:
• cannot be damaged by vehicles.
• is readily accessible to users at all times.
• is less than 10 meters away from the potential danger zone and can be reached within
10 seconds.
• For highly corrosive substances, a distance between 3-6 meters is recommended. The area
aroundtheshowermustbewell-litandtheshoweritselfmustbeclearlyidentiedbyeasily
visible signs.
9. Operating
9.1 Body safety showers with pull rods
Pull the handle until the valve arm stops. Once showering begins, remove all contaminated
items of clothing that are not stuck to the skin and rinse all affected areas with clean and cold
water. Push the lever upwards until the valve closes to turn off the shower.
9.2 Body safety showers operated using a rocker arm
Pull the rocker arm forward until it stops. Once showering begins, remove all contaminated
items of clothing that are not stuck to the skin and rinse all affected areas with clean and cold
water. Push the lever back towards the wall until the valve closes to turn off the shower.
9.3 Models with safety eye showers
In order to start the eye shower press the big PUSH lever. This locks the PUSH lever in the
open position. The eyewash should not make direct contact with the contaminated eye or any
surrounding areas. Ideal rinsing is assured at a distance of approximately 150 mm. In order to
stop the shower, pull back the PUSH lever.
9.4 Models with eye-/face wash units
In order to start the eyewash pull the eyewash lid towards yourself. The eyewash valve is
opened and the eyewash is activated. The eyewash should not make direct contact with
the contaminated eye or any surrounding areas. Ideal rinsing is assured at a distance of
approximately150mm.Aowcontrolvalveisintegratedintotheeyewash.Theheightofthe
water jet can thus be adjusted as desired with the help of a hex key depending upon on-site
water pressure. In order to stop the shower, push the lid up until the valve is closed.
10. Maintenance / Problems
The safety shower must be checked for visible damage or faults after installation and before
being put into use and subsequently at the intervals stated and after any alterations or
maintenance.
7
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

10.1 Maintenance
The FAR safety showers must be checked for operation at least once a month. This is also
set out in the BGI/GUV-I 850-0 guidelines from BG Chemie. For this purpose, the shower must
be turned on for approximately 5 seconds. This not only checks the operation of the shower
itself but also replaces the water in the shower with fresh water (contamination protection).
During the course of this test, the shower is to also be inspected visually to see how it closes
and if any leaks or dirt, such as dust or lime scale, are apparent. Faulty parts must be replaced
immediately.
10.2 Problems
Problem
Theamountofwatercomingoutoftheshowerdoesnotappeartobesucient.
Thevolumeofwaterwhichowsfromtheeyewashdoesnotappeartobeadequate.
The shower drips continuously.
The shower drips continuously.
The body safety shower does not automatically switch itself off after use.
Possible cause
Water pressure or cross section of the connecting pipes is too low.
Water pressure is too low, supply line cross-section is too small or the jet regulator is
contaminated.
The valve does not close properly.
The valve seal is damaged.
This is NOT a fault. This is a requirement according to DIN standards.
Possible solution
Check the piping. Ensure that the piping has a minimum diameter of ¾ inches and that the
water pressure is at least 1bar.
Unscrew the jet regulator and clean the regulator and sieve (blue). If water pressure is too low,
low-pressure diffusers
are available as accessories.
Check the valve for damage and ensure that the valve is pushed back into a fully-closed position.
Replace the valve.
This is NOT a fault. This is a requirement according to DIN standards.
11. Disposal
The safety shower can be fully dismantled. The individual parts, e.g. metal, insulation etc,
can be recycled separately.
Please note the national and international disposal regulations.
8
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

4. Operating Instructions - Eye Shower
1. Standards and regulations
The FAR eye showers correspond in all respects to DIN EN 15154-2:2006, the ANSI Z358.1-
2009, the Technical Rules for Hazardous Substances (TRGS) 526 and the regulation of
the BG Chemie (professional association for chemistry) BGI/GUV-I 850-0. These operating
instructions are intended as a supplement to the statutory regulations and provisions. Please
comply with DIN EN 15154-2:2006, the ANSI Z358.1-2009, the TRGS 526 and the BG Chemie
regulation BGI/GUV-I 850-0.
2. Operating pressure
The FAR eye showers are designed for an operating pressure of a maximum of 10 bar (PN10).
2.1. Eye showers with one high-performance spray head:
Toguaranteecorrectoperation,theowpressuremustbeatleast1.5bar.Theowrateis
6 to 8 liters per minute.
Thisowratespeciedbythestandardissetautomaticallybyaowregulatorintegratedin
the eye shower irrespective of the existing operating pressure.
2.2. Eye showers with two high-performance spray heads:
Toguaranteecorrectoperation,theowpressuremustbeatleast2bar.Theowrateis
13 to 15 liters per minute.
Thisowratespeciedbythestandardissetautomaticallybyaowregulatorintegrated
in the eye shower
irrespective of the existing operating pressure.
3. Installation
3.1 Items supplied:
• Eye shower consisting of hand-held piece / valve body and spray head / spray heads
• Stainless steel coated hose with tapered end and connection nut (only hand-held eye
showers)
• Tablebracket,wallbracket,45°wallbracketorwallange
• Eye shower emergency sign
3.2 Installation:
Toavoiddamagetofurnitureandtheoortheshowershouldbeinstallednearadrainsothat
water from the shower can be channeled away.
9
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

3.2.1 Table mounted eye showers:
Install using the table mounting accessories M28x80mm. A hole of 30 mm diameter should
be made in the table top at a suitable point.
The table mounting accessories will be mounted with the plastic rosette and the counter nut
below the table surface.
3.2.2 Wall mounted eye showers:
Installusingthewallange.Thewallangeshouldbeinstalledwithasuitablefastening
systemonaatsurface(wall).
Installing using the male thread: Remove the bottom of the eye shower. Drill the embossed
holes and arrange the eye shower and mark the mounting holes.
3.2.3 Wall-/table mounted hand-held eye showers:
Install using the combined wall and table bracket. When using the combined bracket as a
wall bracket, the brass pipe must be unscrewed by hand - ensure that work gloves are worn
for this. The wall bracket should be mounted on an even surface (wall) using a suitable
xingsystem.Toachieveawallspacingof150mmaccordingtoDINEN15154-2:2006,an
additional spacer (article number: BR 710 255) is available as an accessory. When using as a
table bracket, refer to the points under 4.2.1.
3.2.4 Wall mounted hand-held eye showers, 45° wall mounted:
Install using the 45° wall bracket. The wall bracket should be mounted on an even surface
(wall)usingasuitablexingsystem.
3.2.5 25°-table mounted hand-held eye shower:
Install using the 25° table mounting accessories M28x80mm. A hole of 30 mm diameter
should be made in the table top at a suitable point. The table mounting accessories will be
mounted with the plastic rosette and the counter nut below the table surface.
3.3 Position of strainer and gasket (Hand-held eye showers)
The strainer must be mounted between the eye shower and the hose; the gasket must be
mounted between the water inlet and the hose.
4. Water supply
The FAR eye shower should be connected to drinking water. The drinking water system
should be constructed in accordance with DIN 1988 and DIN EN 1717.
CAUTION! For new installations the water supply system must be rinsed out before
connecting the shower in order to prevent dirt damaging the valve.
4.1 Water supply for hand-held eye showers
The FAR hand-held eye shower is connected to the water supply using the ½ inch connection
nutonthehose.TheFARhand-heldeyeshowersarettedwithabackowpreventer
accordingtoDIN1988protectionclass2(3forshortperiods).Inaddition,asecondbackow
preventer can be obtained from specialized traders to achieve a higher protection class.
10
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

4.2 Water supply for eye showers
TheFAReyeshowersareconnectedwiththewallange,thetablemountingaccessoriesor
the water supply, which is provided for it.
5. Safety labelling
Theenclosedsafetylabel(self-adhesiveinformationsign)shouldbeaxedbesidetheFAR
eye shower.
6. Location
The location must be selected in accordance with regulation BGI/GUV-I 850-0 of the BG
Chemie. Access must be kept free at all times. Special attention should be given to selecting
a place which can be reached quickly from hazard areas. The injured person must be able
to reach the shower within a maximum of 10 seconds. This necessitates installation at a
distance of no more than 10 meters from the work place.
7. Operating
7.1 Operating of hand-held eye showers
Commissioning the FAR hand-held eye shower is carried out by pressing the button on the
handle. This locks the button in the open position. To switch off the shower, press the button
again while pulling down the locking device.
When suitably mounted, the FAR hand-held eye shower can be operated both in and out of
the bracket (table feed-through, wall bracket). Operating the shower in the holder makes it
possible to hold open the lids of the contaminated eyes with both hands at the same time.
The shower can also be removed from the bracket. This allows other body parts or an injured
personontheoortobetreated.
7.2 Operating of eye showers
Commissioning the FAR eye shower is carried out by pressing the big PUSH lever. This locks
the PUSH lever in the open position. To switch off the shower, pull back the PUSH lever.
7.3 Eyewash in First-Aid-Case
The eye shower should not come into direct contact with the contaminated eye or its
surroundings. The black rubber cup on the shower is only intended to prevent impact injuries.
Optimum rinsing is achieved at a distance of approx. 150 mm. At this distance, the diameter
of the spray cone is approx. 80 mm. To use the shower, it is advisable to hold the eye open
with both hands.
7.4 Self-draining of spray heads
The spray head / spray heads must be emptied each time after use by holding the shower
with the head pointing downwards. This avoids standing water remaining in the spray head
and minimizes the likelihood of microbial contamination.
11
PRODUCT MANUAL
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada

8. Maintenance
FAR eye showers must undergo a function test at least once a month. This is set down in
regulation BGI/GUV-I 850-0 of the BG Chemie. To do this, activate the shower for approx.
5 seconds. This ensures not only that correct function is tested but that any standing water
in the shower is replaced by fresh water (protection against microbial contamination).
As part of this function test, the shower should be checked visually for signs of wear and tear
and any possible leaks and dirt such as e.g. dust or scale deposits. Inspect the hose for any
twisted, bent or otherwise damaged places. Faulty parts must be replaced immediately.
9. Procedure for leaking hand-held eye showers
After connecting to the cold water system, the hand-held eye shower may have started to
leak. This is generally due to dirt from the water supply which collects in front of the valve.
If this has happened, disconnect the handheld eye shower from the supply. Operate the
shower a few times without pressure and rinse the pipe thoroughly before reconnecting. If the
faultcannotberemediedbythismeanstheenclosedmeshltermustbettedinfrontofthe
stainless steel hose.
12
PRODUCT MANUAL
ORDERING WITH
WESTLAB IS EASY
Online
www.westlab.com.au
Order online with our easy
Express Order form for fast,
secure ordering.
Phone
1800 385 101
Speak to one of our friendly,
ecientstafffrom
8.00am - 5.00pm (Mon/Fri)
Email
24 hours, 7 days a week
convenience.
1800 358 101
sales.au@westlab.com
www.westlab.com.au
09 972 7682
sales.nz@westlab.com
www.westlab.co.nz
646 568 5391
sales.us@westlab.com
www.westlab.com
1 877 822 1455
sales.ca@westlab.com
www.westlab.com
Australia New Zealand United StatesCanada
Table of contents
