Wet Sounds VENUE Series User manual

VS-69 PRO VS-8 PRO

Wet Sounds professional audio products represent
the ultimate in high performance audio. Wet Sounds
speakers are specically engineered to withstand the
rigorous outdoor environment.
The Wet Sounds VENUE Series were designed to provide
amazing output combined with a cutting edge style.
Utilizing state of the art acoustic engineering and three
dimensional computer aided design, Venue Series
represent the most advanced outdoor speakers in the
world.
Please take a moment to read the instruction manual
before starting your installation. If you have any
questions or concerns, please contact your certied
Wet Sounds dealer or Wet Sounds:
877-WET-SPKR (1-877-938-7757)
www.wetsounds.com
CONGRATULATIONS!
Thank You for Your Wet Sounds VENUE SERIES Purchase.

1
RMS Watts 200
PEAK Watts 400
Frequency Res. 20Hz to 20KHZ
Sensitivity 92 db @1watt/1meter
Impedance 4 Ohms
Avail. Color Black, White
SPECS
H: 10.17” W: 15” D: 11. 8 6”
DIMENSIONS
VS-8 PRO

2
RMS Watts 150
PEAK Watts 300
Frequency Res. 20Hz to 20KHZ
Sensitivity 92 db @1watt/1meter
Impedance 4 Ohms
Avail. Color Black, White
SPECS
H: 8.4” W: 11. 67 ” D: 10.08”
DIMENSIONS
VS-69 PRO

Step 1 - Carefully remove the side cover panels and rear
termination panel from the speaker.
Grip here to move
VS-69 PRO
Grip here to move
VS-8 PRO
3

4
VS-8 PRO
Step 2 - Pre-thread hardware in the speaker positioning
locations based on desired mounting orientation shown
below.
A) Vertical Under Eave *VS-8 Pro
B) Horizontal *VS-8 Pro
Locking
Positioning
Positioning
Locking Positioning
Positioning

VS-69 PRO
5
*For VS-69 Pro ensure the passive radiator is oriented correctly
depending on application. In an under eave or covered
application, the passive radiator should be faced upwards to
provide optimal performance. In a landscape application, the
passive radiator should be faced downwards. The front badge
can be rotated depending on mounting orientation.
Locking
Locking
Passive
Facing Up
Passive
Facing Down
Passive
Facing Down
Positioning
Positioning
*If using optional Ground Spike, securely mount the bracket to ground spike,
place spike in desired landscape location and follow speaker mounting
instructions above.
A) Vertical Under Eave *VS-69 Pro
B) Horizontal *VS-69 Pro
C) Landscape Ground Spike *VS-69 Pro
Locking
Positioning
Positioning
Positioning
Positioning

Step 4 - Connect the speaker signal connections from
the amplier to the speaker connections (Red + / Black - ).
Terminate the safety cable to the anchor support ring.
Re-install side cover panels and rear termination panel
to the speaker.
6
VS-69 PRO/VS-8 PRO
Step 3 - Mount bracket and safety strap in desired
location and orientation (hardware and safety strap not
included). Once the bracket is securely in place, cradle
the speaker into the brackets slots and insert remaining
hardware into the locking slots. Adjust tilt angle of the
speaker and tighten all bracket hardware.

7
Optional Tap Adjustment
The default setting of the speaker is optimally adjusted for use
with Wet Sounds Venue Series Amplier (4ohm). In the instance
of using the speakers with a 70v distributed load amplier,
remove 2x Phillips head screws and tap adjustment cover.
Adjust the rear tap to the desired wattage that satises your
system requirements and reinstall the cover.
VS-69 PRO/VS-8 PRO
VS-69 PRO VS-8 PRO

LIMITED WARRANTY
WHAT THIS WARRANTY COVERS
This is a “limited” warranty. This warranty covers any defect in
materials and workmanship. This warranty only covers the original
purchaser and is not transferable. This warranty is also only valid if
the original purchase was made from an authorized Wet Sounds TM
dealer.
HOW LONG COVERAGE LASTS
This warranty extends for 2 years from the date of purchase. It is
recommended to REGISTER your warranty online within 45 days of
purchase at www.wetsounds.com – click on “warranty registration”.
WHAT IS NOT COVERED
This warranty does not cover fading or discoloration caused by
exposure to sunlight or chemicals such as ammonia, household
bleach, or any cleaning material that contains abrasive substances.
Wet Sounds, Inc. does not cover the expense for removal or re-
installation. Additionally, shipping TO Wet Sounds, Inc. must be
paid for by the purchaser. This warranty is void and inapplicable
if Wet Sounds deems that the product was abused or misused;
including but not limited to damage caused by accident,
mishandling, improper installation, removing the inline fuse on the
power connection, negligence, normal wear and tear, excessive
water or heat damage, freight/shipping damage, or products
that have been disassembled by anyone other than Wet Sounds
technical staff. Wet Sounds will not be responsible for any incidental
or consequential damages, except to the extent provided (or
prohibited) by applicable law. This warranty gives you specic rights,
and you may also have other rights which vary from state to state.
WHAT WET SOUNDS, INC. WILL DO
Wet Sounds, Inc. will repair any part of your product that proves
to be defective in materials or workmanship. In the event repair is
not possible, Wet Sounds will replace the product in question. If it is
deemed necessary Wet Sounds, Inc. will either replace the entire
product with a refurbished unit or it will be replaced with a model
that is similar in price if that model is no longer available. Labor costs
and materials needed to complete this service will be at No Charge
to the purchaser. Additionally, return shipping FROM Wet Sounds,
Inc. to the purchaser will be paid for by Wet Sounds.

WET SOUNDS INC.
www.wetsounds.com •877-938-7757
10621 S Sam Houston PKWY W •Suite 100
Houston, Texas 77071 •USA
HOW TO GET SERVICE
Contact Wet Sounds, Inc. either by phone[phone]) or
by email ([email protected]).
A service representative will assist you in conrming
that the problem you are experiencing is caused by a
defective product and if that product is covered under
warranty. The service representative will issue you a
Return Manufacturer’s Authorization (RMA) and other
details to obtain service for your product.
DO NOT RETURN YOUR PRODUCT WITHOUT THE PROPER
RETURN AUTHORIZATION (RMA)!
INTERNET WARNING
Wet Sounds, Inc. products sold on any non-authorized
web site or internet auction site are void of any and all
manufacturer’s warranty. Please contact Wet Sounds
(877-938-7757) or visit our website
(www.wetsounds.com) for a list of authorized online
sellers or to nd an authorized installing retailer near
you.
