Wheeltech EASIBRAKE User manual

Each Easibrake kit should contain: 5Retighten the brake clamp screws using the supplied
1# Easibrake unit (with left and right brake units, allen key to secure the brake unit in position
cable and brake handle)
1# small bracket
1# large braket
1# bracket screw
1# spring washer
1# bracket nut
3# cable ties
2# allen keys
6Repeat the previous steps for the left hand brake unit.
7The brake handle can be installed either on the
1Get the right hand brake unit handgrip or wheelchair tubing. Position the brake
handle similar to as shown below:
2
Loosen the screws on the existing brake clamp using
the allen key supplied, as shownin the photograph
below:
8Select either the small or large bracket to secure the
brake handle. Position and interlock the bracket with
the handle, as shown in the photograph below:
3
Remove the existing brake unit as shown below:
9Using the screw, washer and nut; clamp together the
4Replace with the Easibrake brake unit and position brake handle and bracket using the supplied allen
the brake unit in the desired place as shown below: key to secure.
10
A
djust the brake cable and reposition the brake units
if necessary to ensure effective braking. Then use the
Part code: Z15926 the cable ties to secure the cables to the chair frame
EASIBRAKE INSTALLATION INSTRUCTIONS
Installation instructions:
MEDICARE TECHNOLOGY LTD,
DALE HOUSE, ARMYTAGE ROAD, BRIGHOUSE, HD6 1PT.
TEL: [phone] FAX: [phone]

Enigma Steel self propel wheelchair
Enigma aluminium transit wheelchair
Part code: Z15926
EASIBRAKE USER MANUAL
MEDICARE TECHNOLOGY LTD,
DALE HOUSE, ARMYTAGE ROAD, BRIGHOUSE, HD6 1PT.
TEL: [phone] FAX: [phone]
Introduction
The Wheeltech Easibrake system offers an
affordable and reliable solution for combined user
and attendant wheelchair braking.
The Easibrake system can be operated by the
attendant via a cable brake handle, or by the user
who user the brakes like a conventional wheelchair
brake.The Easibrake system has patent pending
GB0027753.3
All Wheeltech products are manufactured to the
highest quality and are CE compliant. In addition,
Medicare Technology is an ISO 9001 certified
manufacturer and supplier.
Wheeltech also produces a wide range of products
such as manual wheelchairs, powered wheelchairs
and electric scooters.
How to Use
User operation
The user can operate the wheelchair brakes as
parking brakes. To apply the brakes, push the lever
on the actual brake unit to lock the brake in postion.
Repeat this the other brake.
Attendant operation
The brakes can be used by the attendant either as
parking brakes or brakes used for decelerating.
To use as parking brakes, use the brake lever to
lock the brakes, as the user operation above.
To use as brakes used for decelerating, squeeze
the brake handle to apply both brakes whilst the
wheelchair is in motion.
Safety Considerations
The Easibrake is designed only to aid decelaration
whilst the wheelchair is in motion.
The rate of decelaration is dependant to the
wheelchair, occupant, ground gradient and type of
tyre used.
The maximum gradient the Easibrake should be
used on is 16% (1 in 6).
When the wheelchair is static, the parking brakes
should always be applied.
Typical Installations
Using the Easibrake on other wheelchairs
The Easibrake has been designed for use on the
Medicare range of wheelchairs.
The Easibrake may also fit other makes of
wheelchair. Please note though that the warranty
only covers the Easibrake product and does not
extend to any wheelchair it may be fitted to.
Medicare wheelchairs are covered by their own
warranties. Medicare Technology accepts no liability
for any damage or injury sustained related to non-
Medicare products.
