Installation Guide:
600 Series Strobe Lighthead
©2001 Whelen Engineering Company Inc.
Form No. 13643C (052311)
®
ENGINEERING COMPANY INC.
51 Winthrop Road
Chester, Connecticut 06412-0684
Phone: [phone]
Fax: [phone]
Internet: www.whelen.com
Sales e-mail: [e-mail]
Canadian Sales e-mail: [e-mail]
Customer Service e-mail: [e-mail]
Automotive: Lightheads
Safety First
This document provides all the necessary information to allow your Whelen product to be properly and safely installed.
Before beginning the installation and/or operation of your new product, the installation technician and operator must
read this manual completely. Important information is contained herein that could prevent serious injury or damage.
• Proper installation of this product requires the installer to have a good understanding of automotive electronics,
systems and procedures.
• If mounting this product requires drilling holes, the installer MUST be sure that no vehicle components or other
vital parts could be damaged by the drilling process. Check both sides of the mounting surface before drilling
begins. Also de-burr any holes and remove any metal shards or remnants. Install grommets into all wire
passage holes.
• If this manual states that this product may be mounted with suction cups, magnets, tape or Velcro®, clean the
mounting surface with a 50/50 mix of isopropyl alcohol and water and dry thoroughly.
• Do not install this product or route any wires in the deployment area of your air bag. Equipment mounted or
located in the air bag deployment area will damage or reduce the effectiveness of the air bag, or become a
projectile that could cause serious personal injury or death. Refer to your vehicle owner’s manual for the air bag
deployment area. The User/Installer assumes full responsibility to determine proper mounting location, based
on providing ultimate safety to all passengers inside the vehicle.
• For this product to operate at optimum efficiency, a good electrical connection to chassis ground must be
made. The recommended procedure requires the product ground wire to be connected directly to the NEGATIVE
(-) battery post.
• If this product uses a remote device to activate or control this product, make sure that this control is located in
an area that allows both the vehicle and the control to be operated safely in any driving condition.
• Do not attempt to activate or control this device in a hazardous driving situation.
• This product contains either strobe light(s), halogen light(s), high-intensity LEDs or a combination of these
lights. Do not stare directly into these lights. Momentary blindness and/or eye damage could result.
• Use only soap and water to clean the outer lens. Use of other chemicals could result in premature lens cracking
(crazing) and discoloration. Lenses in this condition have significantly reduced effectiveness and should be
replaced immediately. Inspect and operate this product regularly to confirm its proper operation and mounting
condition. Do not use a pressure washer to clean this product.
• It is recommended that these instructions be stored in a safe place and referred to when performing
maintenance and/or reinstallation of this product.
• FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT IN DAMAGE TO
THE PRODUCT OR VEHICLE AND/OR SERIOUS INJURY TO YOU AND YOUR PASSENGERS!
For warranty information regarding this product, visit www.whelen.com/warranty

Page 2
A/R
11
02-0363416-( )
A/R
A/R
A/R
A/R
A/R
38-0242717-00
1
68-3183587E50
10
68-3183587-50
PART NUMBER KEY:
CONNECTOR: 0 =
1=
AMP CONNECTOR
DEUTSCH CONNECTORCONNECTOR:
COLOR:
B=
G=
A=
C=
*=
5=
BLUE
GREEN
AMBER
CLEAR
SPLIT
KKKE-SPEC RED
R=RED
COLOR:
COLOR:
COLOR:
COLOR:
COLOR:
COLOR:
01-0663415-__
CONNECTOR
COLOR
BASIC P/N
68-3183587-40
9
8
68-3183587-30
7
68-3183587-10
5
A/R 4
15-061416-280
3
4
02-0363173-01
2
A/R
02-0363173-00
1
A/R
600 SERIES LINEAR STROBE / PARTS LIST
QTY ITEM DESCRIPTION
PART NUMBER
01-0663415-( )
6
68-3183587-20
LENS / SPLIT 600/
GASKET
LENS MODEL 600 KKKE-SPEC RED//
LENS MODEL 600 RED//
LENS MODEL 600 GREEN//
LENS MODEL 600 CLEAR//
LENS MODEL 600 AMBER//
SCREW #6 X 1-3/4" PPHSMS/
600 LINEAR STROBE DEUTSCH CONN/
600 LINEAR STROBE AMP CONN/
REFLECTOR ASSEMBLY
LENS MODEL 600 BLUE//
600 Series Linear Strobe Lighthead
MOUNTING DIMENSIONS
3.10"
1.452"
2" MINIMUM
REQUIRED MOUNTING DEPTH
2.545"
5.090"
1.885"
3.770"
1.625"
3.250"
2.875"
5.750"
.250" hole
(4 places)
12 11-76D258-000 1SCREW GROMMET FLANGE
AREA TO BE
REMOVED
45678910
12
11
12
Pos. 1 - Annode
Cathode
Trigger
Pos. 2 -
Pos. 3 -
Pos. - Annode
Cathode
Trigger
A
Pos. B -
Pos. C -
Installation:
WARNING! All customer supplied wires that connect to the positive terminal of the battery must be sized to supply at least 125% of
the maximum operating current and FUSED at the battery to carry that load. DO NOT USE CIRCUIT BREAKERS WITH THIS
PRODUCT!
WARNING! The strobe light power supply is a high voltage device. Do not touch or remove the strobe tube assembly while in
operation. Wait 10 minutes after disconnecting the unit from its power source before starting any work or trouble
shooting.
1. First check behind the proposed mounting area. Note that the mounting surface must be flat. There must be at least 2” clearance behind the
lighthead.
2. Using the measurements supplied, mark the locations for the mounting holes and lighthead cut-out hole onto the mounting surface. Be sure
to double-check all your measurements before cutting or drilling.
3. Drill the four .250” mounting holes for the screw grommet flange then cut the lighthead cut-out hole as indicated.
4. Connect the wires to your Strobe Power Supply (refer to your power supply manual for wiring information. Be sure to test for proper
operation of your lighthead prior to use.
