OPERATION & INSTALLATION MANUAL
Basic description and operation
of the
E-2010 CENTRAL CONTROL STATION
WARNING: This product can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or
other reproductive harm. For more information go to www.P65Warnings.ca.gov.
R
12 3
45 6
789
0ALL
#
DOWN
UP
MESSAGES
MENU SELECTIONS
ENTER
WARNING
TONES
VOICE
ROTATING
DIRECTION STATUS
PORT
SETUP
AUDIO
POLLING
SETUP
CALL
KEY TIME
DATE
SETUP
234
8765
12
11
10
9
16151413
SIREN ADDRESS
CALL KEY MENU
CANCEL
ACK.
ALARM
E-2010
CALL KEY SEND
CALL
KEY
117-26
27-36
37-46
47-56
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
KEY
KEY
CALL
KEY
CALL
KEY
CALL
KEY
CALL
SETUP
CALL
AUTO SYSTEM
SETUP
OPTION
09/15/98 09:45:02
WHELEN ENGINEERING CO., INC.
51 Winthrop Road
Chester, Connecticut 06412-0684
Phone: [phone]
Internet: www.whelen.com
Sales e-mail: [email protected]
Customer Service e-mail: [email protected]

i
WHELEN ENGINEERING CO., INC.
E-2010 CENTRAL CONTROL STATION
OPERATION & INSTALLATION MANUAL
The purpose of this manual is to provide operation and installation information about the use of a
Whelen Engineering Company, Inc. Model E-2010 Central Control Station.
Prior to reading this manual or using this product you should be familiar with Whelen Engineering
Company’s family of High Power Voice and Siren Systems.
Document # 04-0113382-00C
13382C
PIONEERS IN WARNING SIGNALS
ENGINEERING COMPANY, INC.
Route 145, Winthrop Rd., Chester, CT 06412-0684
Tel.: (800) 63SIREN •
••
•Fax: [phone]

ii
The information contained herein is proprietary to the Whelen Engineering Company, Inc. No
part of this manual may be reproduced, recorded or stored in a retrieval system, or transmitted,
in any form without prior permission of Whelen Engineering Company, Inc.
The software described in this manual is supplied with the understanding that it may not be
copied or otherwise redistributed without prior permission of Whelen Engineering Company,
Inc.
All materials and specifications contained in this document are subject to change without
notice.
Copyright, 1998 Whelen Engineering Company, Inc.
All rights reserved.
Printed in the United States of America.
Windows 95 and Access are registered
trademarks of Microsoft Corporation.

iii
Table of Contents
Introduction ........................................................................................................................1
Communication Protocol ...................................................................................................2
Area Code......................................................................................................................2
Remote Siren Address Code..........................................................................................2
Identification .................................................................................................................2
Command ......................................................................................................................2
Getting Started....................................................................................................................3
Keyboard Entries...........................................................................................................3
Function Definitions......................................................................................................3
Menu Selections..................................................................................................................4
Warning Tones..............................................................................................................4
Voice Messages.............................................................................................................4
Rotating Direction.........................................................................................................4
Status.............................................................................................................................4
Port Setup......................................................................................................................5
Polling Setup .................................................................................................................5
Auto Call Setup .............................................................................................................5
System Setup .................................................................................................................6
Audio.............................................................................................................................6
Call Key Setup...............................................................................................................6
Time Date....................................................................................................................6
Option............................................................................................................................6
Call Keys .............................................................................................................................7
Call Key Programming..................................................................................................7
Modify a Call Key.........................................................................................................8
Delete a Call Key...........................................................................................................8
Finishing a Call Key......................................................................................................9
Printing an Individual Call Key.....................................................................................9
Printing All Call Keys ...................................................................................................9
Remote Input Call Keys.................................................................................................10
Time-of-Day (Automatic) Call Keys .............................................................................10
Command Number Table ..............................................................................................10
Menu Activation .................................................................................................................11
Printing................................................................................................................................12
Alarms .................................................................................................................................13
PC Interface........................................................................................................................13
Installation...........................................................................................................................14
Troubleshooting..................................................................................................................16
Specifications.......................................................................................................................17

1
Introduction
The E-2010 Central Control Station is a full function, easy to use, activation and status display unit for
Whelen’s family of High Power Voice and Siren System products. The E-2010 uses Whelen’s standard,
reliable 10 digit DTMF communication protocol.
The E-2010 is an attractive, desktop unit designed for simple connection to a base station transmitter.
The E-2010 has a sealed membrane keyboard and a low power liquid crystal display. The typical warning
activation sequence consists of selecting a Call Key or following a four step process.
There are 62 Call Keys, which allow the user to program and execute pre-defined scenarios. Sixteen of
the Call Keys are “Hot Keys”, while 40 of the Call Keys are auxiliary or low use functions. In addition,
there are two Call Keys activated by Time-of-Day and four Call Keys Activated by Remote Activation
inputs (as described in a later section).
Individual selection and activation may be done as follows:
1. Make a Menu Selection
2. Enter the four digit Address.
3. Select the Channel.
4. Press the Send button.
The user may select from different command, control, status or test functions. The E-2010 supports up to
10,000 unique addresses.
The liquid crystal display (LCD) is a 4 line by 40 character configuration. The display is backlit for easy
reading in low ambient light. When the E-2010 is not in use, a running 24 hour clock, day of the week
and a stand by message are displayed.
Internal batteries are continuously “trickle” charged, to provide long life. The E-2010 will maintain its
internal clock for up to 3 months after being unplugged. The E-2010 comes with a UL listed, plug in, AC
wall mount power supply.
Two rear panel, two-piece, screw terminal connectors are available for field wiring to two base station
transceivers. Each connector supports transformer coupled audio, a Push To Talk closure, Squelch
monitor input (active high or low), and Channel Grant input for trunking systems.
A software interface with a PC stores all communication activity to the hard drive. In addition, this
software supports advanced data base handling for printing and manipulation of data.

2
Communication Protocol
The standard communication protocol for Whelen’s High Power Voice and Siren System products is a 10
digit DTMF (Dual Tone Multi-Frequency) format. This means that the activation command consists of
ten DTMF digits. The status feedback from a remote siren may have from 10 to 18 digits, depending on
the type of feedback status.
The activation command structure is as follows:
Digits 1-3 = System Area Code
Digits 4-7 = Remote Siren Address Code
Digit 8 = Identification Number
Digit 9,10 = Command
Area Code
Each warning system receives a factory assigned area code. Consideration is given to frequency
allocations to minimize the chance of false activation from a neighboring system.
Remote Siren Address Code
Each remote siren within a system is assigned a unique address. In order to accept a command string, the
remote siren must receive the proper area code and address in the proper order, in a certain time span. A
remote siren will reject any command string that does not meet these requirements.
System “all calls” are permitted through the use of the # symbol (or wildcard). The # may be used in all
four address digits to communicate with all remote siren within the area code or the # may be used in
specific positions to communicate with a group of remote sirens. The # may not be used in the area code.
Identification
The eighth digit identifies which Control Center transmitted the command. There may be up to eight
centers within a system.
Command
These digits define the command. This information is provided for reference only, since in the E-2010 all
commands are selected by name and all response strings are decoded into specific names.
(Do not confuse this with the Command Table used in Call Key programming.)

3
Getting Started
These are some general definitions which must be understood before using the E-2010.
KEYBOARD ENTRIES
SEND - Pressing the Send button will transmit a function. There is no second chance or “are you
sure” warning.
CALL KEY - This is a dual function button. Pressing this button, while a Call Key is in progress, will
CANCEL Cancel the Call Key. In addition, this button is used during Menu Selection operations to
escape or restart an operation.
ALARM - Pressing the Alarm Acknowledge button silences the internal alarm buzzer, if it is
ACK enabled. An Alarm Acknowledge message is printed. Output relays are turned off.
UP - Located in the Call Key Menu section. Used to scroll up through groups of Call Keys 17-
(large Up arrow) 26, 27-36, 37-46 or 47-56.
DOWN - Located in the Call Key Menu section. Used to scroll down through groups of Call Keys
(large Down arrow)17-26, 27-36, 37-46 or 47-56.
ENTER - Used to make selections in the Menu Selection portion of the keyboard.
# - The “wildcard” address entry, it equals numerical entries 0 through-9.
ALL - A one button method for entering four # signs, for selecting all remote siren addresses in
the system. This is sometimes referred to as “all call”.
FUNCTION DEFINITIONS
CHANNELS - There are two communication channels, referred to as Channel 1 and Channel 2. This
allows for operating with two radio frequencies or one RF link and one landline.
Transmissions may be sent via either channel. Channel 1 is the default. Channel
selection is part of every transmission.
POLLING - For feedback functions, the E-2010 automatically accesses each remote siren, one at a
time, based on the addresses entered in Polling Setup. This saves the user a considerable
amount of time in collecting information about an entire system. To initiate a Polling
function, select a Status feedback Command. Use an address of ####, press ENTER,
select the Channel and ENTER, and SEND. The following functions are supported by
Polling:
Status Request
Active Status
Counter
Battery/AC
Battery/Temperature
Instant Status
Rotor Position
S/N Status

4
Menu Selections
This section describes the function of each button in the Menu Selection portion of the keyboard. In
general, the Down arrow (within the Menu Selections portion of the keyboard) is used to scroll through
the functions as listed below. The Up arrow (within the Menu Selections portion of the keyboard) may
also be used to scroll up through the list. The four large buttons contain actual remote siren functions,
such as Warning Tones or Status Requests.
WARNING TONES
CANCEL Terminates all siren activity.
WAIL Activates the Wail Tone.
ATTACK Activates the Attack Tone.
ALERT Activates the Alert Tone.
PUBLIC ADDRESS Enables the Public Address mode.
AIR HORN Activates the Air Horn Tone.
HI-LO Activates the Hi-Lo Tone.
WHOOP Activates the Whoop Tone.
NOON TEST Activates the Noon Test function.
VOICE MESSAGES
MSG 1 Activates Digital Voice Message 1.
MSG 2 Activates Digital Voice Message 2.
MSG 3 Activates Digital Voice Message 3.
MSG 4 Activates Digital Voice Message 4.
MSG 5 Activates Digital Voice Message 5.
MSG 6 Activates Digital Voice Message 6.
MSG 7 Activates Digital Voice Message 7.
MSG 8 Activates Digital Voice Message 8.
MSG 9 Activates Digital Voice Message 9.
MSG 10 Activates Digital Voice Message 10.
MSG 11 Activates Digital Voice Message 11.
MSG 12 Activates Digital Voice Message 12.
MSG 13 Activates Digital Voice Message 13.
MSG 14 Activates Digital Voice Message 14.
MSG 15 Activates Digital Voice Message 15.
MSG 16 Activates Digital Voice Message 16.
ROTATING DIRECTION
NORTH Positions a 4000 Series Siren to North.
EAST Positions a 4000 Series Siren to East.
SOUTH Positions a 4000 Series Siren to South.
WEST Positions a 4000 Series Siren to West.
CLOCKWISE Increments a 4000 Series Siren 45°CW.
COUNTER CLOCKWISE Increments a 4000 Series Siren 45°CCW.
ROTOR POSITION Rotor/speaker position request.
STATUS
SILENT TEST Initiates the Silent Test function.
INST STAT Get real time (instant) status of Remote Siren.
BATT/TEMP Request battery voltage and cabinet temperature.

5
BATTERY/AC Request battery voltage and AC line voltage.
STATUS REQ Request the Status byte.
S/N STAT Request signal to noise measurement.
S/N REQ Executes the signal to noise check in the Remote Siren.
SIREN OFF Disable the Tone Generator, digital voice is active.
SIREN ON Enable the Tone Generator.
DIS-ARM Disable the Instant Status response.
ARM Enable the Instant Status response.
COUNT CLR Clear the software tone activation counter to zero.
COUNTER Request the software tone activation count.
STROBE TEST EAS only. Strobevisor test.
STROBE OFF De-activate a strobe through the Strobe Control Board.
STROBE ON Activate a strobe through the Strobe Control Board.
TEST CLEAR Clear LEDs and status.
ACTIVE STATUS Request multiple system status parameters.
The eight small buttons are used to configure the control system. The programmable choices are
presented on the display. In general, the Up and Down arrows scroll between the choices, and the Left or
Right arrows toggle between the available choices, such as On or Off.
Note that in Auto Call Setup the Left and Right arrows scroll between the choices and the Up or Down
arrows toggles between YES or NO.
PORT SETUP
Setup for the RS-232 communication port and the Printer port. The RS-232 port is dedicated to a PC
operating Whelen supplied software. The parameters are:
PRINTER ON or OFF Use the Left or Right arrow to toggle.
SERIAL PORT ON or OFF Use the Left or Right arrow to toggle.
Printing and serial interface are discussed in other sections. Set to OFF if not used.
POLLING SETUP
Setup for Status polling routine. This is a list of all of the remote siren address in the system. Unused
entries display as “EMPTY”. To delete an entry, select “ALL”.
AUTO CALL SETUP
Setup for automatic Time-of-Day Call Keys. A Call Key may be programmed to activate by day of the
week and by the time of day. Time is entered as military time (24 hour time). The Call Key must still be
programmed in the CALL KEY SETUP section. The Time-of-Day Call Keys are referred to as Call Keys
#61 and #62.
Use the Left or Right arrows to scroll through the days of the week. Use the Up or Down arrows to toggle
between Y to select the day or N to not select the day. The days are Sunday through Saturday. To get to
the time, scroll right past the last S, for Saturday. Enter the activation time, in military (24 hour time),
from the numeric keypad. Use the Left or Right arrows to move from time to the other Call Key. Do not
use the scroll arrows in the time section, unless moving to the other Call Key. Press ENTER to save the
setup.

6
SYSTEM SETUP
Setup for system variables. Use the Up or Down arrows to move through the choices. The following
parameters are set in this section:
Area Code 3 digits. A value other than 000 must be entered.
Xmitter Up Radio transmitter warm up time, in seconds or tenths of seconds. A
value other than 0 must be entered.
Base ID Base Station identification number, 0-7, for systems with more than one
E-2010.
Ch Grant Wait Channel grant waiting time, in seconds. For trunking radios only. The
time that the E-2010 waits until aborting a transmission, if Channel grant
is not received.
Ch Grant Delay Channel grant delay time, in seconds. The time that the E-2010 holds off
the transmission following the receipt of Channel Grant.
AUDIO
Audio output control. Use the Up or Down arrows to move through the choices. The following functions
are set in this section:
Speaker The speaker may be Off or set to Radio Channel 1 or 2. The speaker monitors
any audio on the selected Channel.
Microphone The Public Address microphone may be Off or set to Radio Channel 1 or 2.
Buzzer The Low Battery or Intrusion Alarm Buzzer may be On or Off.
CALL KEY SETUP
Setup for all Call Keys. Refer to the Call Key Section of the Manual.
TIME DATE
Routines for entering current time and date. Use to set the day of the week, the time and the date. Day of
week must be set for Auto Call Keys. Use the Up or Down arrows to select the day. Use the numeric
keypad to set time and date. Time is military time (24 hour time).
OPTION
Reserved for future use.
NOTE:
While in the Menu Selections portion of the keyboard, pressing
CALL KEY CANCEL will return the E-2010 to the standby
screen.

7
Call Keys
Call Keys are the easiest way to manage a siren system, for typical day-to-day situations. In general, a
Call Key is a preprogrammed scenario or sequence of commands, where each command is separated by a
time period. For example, a Wail command is issued to all addresses, followed by a one minute run
period, then a Cancel is sent, followed by a five second period, next a Digital Voice command is sent,
followed by a 30 second period, then a Cancel, followed by a five second period, and so on. The Call
Key may contain any of the commands listed in the Command Table. Each entry is referred to as a
sequence. A single Call Key may have up to 99 sequences (01-99), however, the total number of Call
Key sequences must be less than 2500. When a Call Key is selected and sent, it starts with sequence 01
and continues until the last programmed sequence, it does not repeat. A Call Key can not activate another
Call Key.
There are a total of 62 Call Keys in the E-2010. Sixteen of the Call Keys are “hot” Call Keys, that is,
they are available at the press of a single button, followed by SEND. These are labeled Call Key 1
through Call Key 16. Four additional buttons provide 40 auxiliary Call Keys, in groups of ten. To use an
auxiliary Call Key, press the group button, use the large Up or Down arrows to scroll to the desired Call
Key and press SEND. Four more Call Keys, numbers 57-60, are activated by remote inputs. These are
described in another section. Call Key 61 and Call Key 62 are available as Time-of-Day functions. These
are described in another section.
A Call Key in progress may be canceled by pressing the CALL KEY CANCEL button
CALL KEY PROGRAMMING
Call Keys are programmed one sequence at a time. Each sequence consists of a sequence number, a
command (entered by command number from the Command Number Table), a time (the time period
before the next sequence) and finally the selection of an Edit function. Normally the function will be
Insert, when creating a new Call Key. However, it may be Modify, Finish or Delete. These will be
discussed later.
The small Down arrow is used to scroll through the Call Key programming routine. Upon entering the
Call Key Setup, a screen will appear as shown.
The cursor is the small arrow pointing to the right. With the cursor at the Call Key # entry, use the
numeric keypad to type the number of the Call Key which is to be programmed.
Use the small Down arrow (in the Menu Selection portion of the keyboard) to move the cursor to Edit
Mode. Use the Left or Right arrow to toggle the Edit Mode to ON. Press ENTER. A new programming
screen will appear as shown.
The cursor is at the command prompt. Referring to the Command Number Table, type a command
number, from the numeric keypad. Use the small Down arrow to move the cursor to the Address prompt.
Type the address from the numeric keypad. Use the small Down arrow to move the cursor to the time
CALL KEY SETUP MENU
CALL KEY = >#
EDIT MODE = OFF PRINT MODE = OFF
SEQ #01 CHAN 1 >S#1
CMD=> S#2
ADDR= S#3
TIME= EDIT= Insert

8
prompt. Type the time, in seconds, between this sequence and the next sequence. Use leading zeroes for
values less than 100 seconds. Use the small Down arrow to move the cursor to the EDIT= prompt. Press
ENTER. S#1 now displays the first sequence. Program sequence 2, starting with the command and
continue as above.
After inserting the last sequence, scroll Down to Edit, then use the Left or Right arrow to select Finish
and press ENTER.
MODIFY A CALL KEY
A Call Key may be modified one Sequence at a time. Enter Call Key Setup, a screen will appear as
shown.
The cursor is the small arrow pointing to the right. With the cursor at the Call Key # entry, use the
numeric keypad to type the number of the Call Key which is to be modified.
Use the small Down arrow (in the Menu Selection portion of the keyboard) to move the cursor to Edit
Mode. Use the Left or Right arrow to toggle the Edit Mode to ON. Press ENTER. A new programming
screen will appear as shown.
The cursor is at the command prompt. Use the Down arrow to scroll the cursor around to the Sequence #.
Use the Left or Right arrow to move through to the desired Sequence #. Use the Down arrow to scroll to
the parameter that is to be modified. Type in the modification. Use the Down arrow to scroll to EDIT=,
use the Left or Right arrow to select Modify, press ENTER.
After completing any modifications, scroll Down to Edit, then use the Left or Right arrow to select Finish
and press ENTER.
DELETE A CALL KEY
A Call Key may be deleted one Sequence at a time. Enter Call Key Setup, a screen will appear as shown.
The cursor is the small arrow pointing to the right. With the cursor at the Call Key # entry, use the
numeric keypad to type the number of the Call Key which is to be deleted.
CALL KEY SETUP MENU
CALL KEY = >#
EDIT MODE = OFF PRINT MODE = OFF
SEQ #01 CHAN 1 >S#1
CMD=> S#2
ADDR= S#3
TIME= EDIT= Modify
CALL KEY SETUP MENU
CALL KEY = >#
EDIT MODE = OFF PRINT MODE = OFF

9
Use the small Down arrow (in the Menu Selection portion of the keyboard) to move the cursor to Edit
Mode. Use the Left or Right arrow to toggle the Edit Mode to ON. Press ENTER. A new programming
screen will appear as shown.
The cursor is at the command prompt. Use the Down arrow to scroll the cursor around to the Sequence #.
Use the Left or Right arrow to move through to the desired Sequence #. Use the Down arrow to scroll to
the parameter that is to be deleted. Use the Down arrow to scroll to EDIT=, use the Left or Right arrow to
select Delete, press ENTER.
After completing any deletions, scroll Down to Edit, then use the Left or Right arrow to select Finish and
press ENTER.
FINISHING A CALL KEY
All operations, such as, inserting, modifying or deleting, must be completed before finishing with a Call
Key. To Finish, use the Down arrow to scroll through to the EDIT= option. Use the Left or Right arrow
to select Finish and press ENTER.
PRINTING AN INDIVIDUAL CALL KEY
Call Keys may be printed individually or in entirety. To print a single Call Key, press Call Key Setup, a
screen will appear as shown.
The cursor is the small arrow pointing to the right. With the cursor at the Call Key # entry, use the
numeric keypad to type the number of the Call Key which is to be printed. Use the Down arrow to scroll
to PRINT MODE =. Use the Left or Right arrow to toggle to On. Press ENTER to print.
PRINTING ALL CALL KEYS
To print all Call Key, press Call Key Setup, a screen will appear as shown.
Use the Down arrow to move the cursor to PRINT MODE =. Use the Left or Right arrow to toggle to All.
Press ENTER to print all of the Call Keys.
SEQ #01 CHAN 1 >S#1
CMD=> S#2
ADDR= S#3
TIME= EDIT= Delete
CALL KEY SETUP MENU
CALL KEY = >#
EDIT MODE = OFF PRINT MODE = OFF
CALL KEY SETUP MENU
CALL KEY = >#
EDIT MODE = OFF PRINT MODE = ALL

10
REMOTE INPUT CALL KEYS
The E-2010 may be activated from four
remote inputs. The typical remote input
circuit is shown. A contact closure, capable
of sinking at least 10 mA, will activate the E-
2010. The closure must remain active for a
minimum of 1/2 a second.
The remote input activates Call Keys #57,
#58, #59 or #60. These Call Keys are
programmed just like Call Keys 1-56, as
previously described.
TIME-OF-DAY (Automatic) CALL KEYS
There are two Call Keys that will automatically activate based on the day of the week and the time of the
day. Refer to Auto Call Setup for more information.
These Call Keys are #61 and #62. These Call Keys are programmed just like Call Keys 1-56, as
previously described.
COMMAND NUMBER TABLE
00 = Cancel 49 = Voice Message 1 09 = North 15 = Silent Test
01 = Wail 50 = Voice Message 2 10 = East 63 = Active Status
02 = Attack 51 = Voice Message 3 11 = South 30 = Test Clear
03 = Alert 52 = Voice Message 4 12 = West 57 = Strobe On
04 = Public Address 53 = Voice Message 5 13 = Clockwise 58 = Strobe Off
05 = Air Horn 54 = Voice Message 6 14 = Counter Clockwise 37 = Strobe Test
06 = Hi-Lo 55 = Voice Message 7 21 = Rotor Position 22 = Counter
07 = Whoop 56 = Voice Message 8 23 = Counter Clear
08 = Noon Test 59 = Voice Message 9 24 = Arm
60 = Voice Message 10 25 = Dis-Arm
61 = Voice Message 11 26 = Siren On
62 = Voice Message 12 27 = Siren Off
17 = Voice Message 13 28 = S/N Request
18 = Voice Message 14 29 = S/N Status
19 = Voice Message 15 31 = Status Request
20 = Voice Message 16 33 = Battery/AC
34 = Battery/Temperature
35 = Instant Status
CONTACT+
560
330 18 Volt
12V
CONTACT-
Clamp
NOTE:
Any active Call Key may be terminated by pressing CALL KEY
CANCEL. The E-2010 will return to the standby screen.

11
Menu Activation
As an alternative to Call Keys, a second
way of operating the E-2010 is to use a 4
step procedure of selecting individual
functions and addresses through the Menu
Selections and Siren Address sections of the
Keyboard.
Step 1 involves the center portion of the
keypad, as shown. Choose from the Menu
Selections by pressing one of the four large
buttons, as previously described. The
display will show the first entry in the
selected group. Use the Up or Down arrows
to scroll through the functions, within the
selected group, stopping at the desired
function. Typically, scrolling starts with the
Down arrow.
The four large buttons are directly related to Remote Siren activation and status. The eight smaller
buttons are Setup and Configuration controls. Do not access one of the eight smaller buttons during
activation.
Step 2 involves the right-hand portion of the keypad, as shown.
Enter the four digit address of the target remote siren. The
address is entered with the most significant bit first. The # sign
represents a “wildcard” or all values 0 to 9. ALL is a quick way
to enter four # signs, to select all sirens in the system. Press
“ENTER” to accept the screen and to continue.
Example: To enter the address 1234, the press 1 first,
then 2, then 3, and 4 is last. The display will
change as shown below.
ADDR = 1???
ADDR = 12??
ADDR = 123?
ADDR = 1234
Note that entering more than four values will “bump” the address to the left. For instance, assume the
user presses the 5 key, at the end of the previous example. The address will change to 2345.
Step 3 consists of selecting communication channel 1 or 2. The default is 1. Press “ENTER” to accept
the screen and to continue.
Step 4, press “SEND” to make the transmission. This sends the command. There is no second
chance!!
MESSAGES
MENU SELECTIONS
ENTER
WARNING
TONES VOICE
ROTATING
DIRECTION STATUS
PORT
SETUP
AUDIO
POLLING
SETUP
CALL
KEY TIME
DATE
SETUP
SETUP
CALL
AUTO SYSTEM
SETUP
OPTION
SIREN ADDRESS
213
654
987
ALL0
#

12
Printing
The E-2010 supports an OKIDATA 184, 9 pin, dot matrix printer. All communication activity,
information that is transmitted or received, is printed. A typical printout consists of: Time, Type (transmit
or receive), Channel #, Raw Message (DTMF string), and the Decoded Message as shown.
In addition to the typical printout, the E-2010 prints the results of a polling function for quick reference,
as shown.
The E-2010 will store a small amount of print information if the printer is disconnected or turned off.
Typically, this is from 6 to 8 lines of data. This buffer is printed when the printer is reconnected or turned
back on.
The proper way to prevent printing is to select printer Off, through the Port Setup function, in Menu
Selections.
The printer is an option. Refer to the Okidata manual for more information regarding printer operation.
TIME T/R CHAN# RAW MESSAGE DECODED MESSAGE
============================================================================
09:25:56 TMX CHAN#1 123-4502-101 ENCODER#1 WAIL
09:26:14 TMX CHAN#1 123-4502-13F ENCODER#1 ACTIVE STATUS
09:26:16 REC CHAN#1 123-4502-8FF-0100AD00 ACTIVE STATUS
ACTIVE CMD- WAIL
DRIVER/AMPS- FAIL
BIAS OFF
INTRUSION OK
STROBE OK
SUPERVISION OK
BATTERY VOLTAGE - 23.7VDC
AC VOLTAGE - 0VAC
POLLING RESULTS
SIRENS POLLED - 4
NO RESPONSE - 1
4503
STATUS ERRORS - 1
4506
LOW BATTERY - 0
LOW AC PWR - 1
4506

13
Alarms
There are two remote siren conditions which will cause an alarm in the E-2010. They are Low Battery
and Intrusion.
Upon receipt of either alarm, the E-2010 sounds the internal buzzer (assuming it is enabled, see AUDIO
in the Menu Selections section) and activates the appropriate output relay. There are two relay closures.
One is for Low Battery and one is for Intrusion. Each closure is rated at 1/2 amp @ 120 VAC or 1 amp
@ 24 VDC. The connections are described in the Installation section.
Pressing ALARM ACK silences the buzzer and turns off the relay.
PC Interface
If desired, the E-2010 can interface with a personal computer (IBM compatible running Windows 95)
through an RS-232 Serial Communication port. Software is included to allow for the following:
Storing data to the hard drive.
Selectable printing, based on site or date.
Call Key programming (instead of using the E-2010 keyboard).
Call Key descriptions.
Storing data in a format compatible with Microsoft Access.
Follow the installation instructions on the CD-ROM to install and operate the interface software. Use the
9 position D connector cable to connect the Serial port of the E-2010 to a Serial communication port on
the PC.
Note:
The E-2010 operates independent of the PC. Therefore, even
if the PC is doing something else or is off, the E-2010
continues to operate normally.

14
Installation
This step-by-step procedure for installing the E-2010 is intended for use by a qualified radio technician.
A Phillips screwdriver and a very small flat blade screwdriver will be required for setup.
1. Inspect the E-2010 for any physical damage.
2. Look at the rear panel. From left to right are the following:
AC/DC wall mount power input plug.
User I/O connections.
DTMF Channel 1 connections.
DTMF Channel 2 connections.
Printer connector to Okidata.
Serial connector to PC.
Microphone input jack.
3. Make the Channel 1 DTMF transceiver (and Channel 2, if used) connections at pins 1 through
10. Channel Grant applies to trunking systems only.
Pin Signal
1 Push To Talk Output
2 Push To Talk Output
3 Audio Out Output
4 Audio Out Output
5 Squelch In Input
6 Ground
7 Channel Grant Input
8 Audio In Input
9 Audio In Input
10 Ground
4. Make any User I/O connections at the 12 position connector as follows:
Pin Signal
1 Remote Closure 2 Output (Intrusion)
2 Remote Closure 2 Output
3 Remote Closure 1 Output (Low Battery)
4 Remote Closure 1 Output
5 Remote Call Key 1 Input (Call Key 57)
6 Remote Call Key 1 Input (Call Key 57)
7 Remote Call Key 2 Input (Call Key 58)
8 Remote Call Key 2 Input (Call Key 58)
9 Remote Call Key 3 Input (Call Key 59)
10 Remote Call Key 3 Input (Call Key 59)
11 Remote Call Key 4 Input (Call Key 60)
12 Remote Call Key 4 Input (Call Key 60)
INPUT
POWER
INPUT
MIC.
12345678910
SERIAL
PRINTER
12345678910
123456789101112
DTMF 2
DTMF 1
USER I/O

15
5. Remove the two upper Phillips Head screws from each side and three from the back of the unit to
access the circuit board. Slowly lift the cover off, trying not to pull any of the connections apart.
Locate the jumpers and adjustment potentiometers in the center section of the circuit board.
6. The Squelch signal and the Channel Grant signal (Channel Grant is for trunking radio
transceiver only) may be active high or active low. The active state must be set by two jumpers,
inside of the E-2010. The settings must be made for both channels, if both are in use. Determine
the active state of the radio transceiver Squelch signal, and the Channel Grant signal (if
applicable) and set the jumpers, as shown to the right. Place the jumper in the “H” position for
active high or “L” for active low. Factory settings are active high.
7. Plug the AC wall mount into a 115 volt AC source.
8. Set the DTMF Transmit Audio Level, for Channel 1. With the E-2010 on, Send the CANCEL
Command to siren address 0001. While the tone is transmitting, adjust the level potentiometer
for 2.5 KHz deviation. Repeat this step as needed to adjust the level. Repeat for Channel 2, if
required.
9. Set the Microphone Level, for Channel 1. Plug the microphone into the MIC jack. Key up the
microphone and adjust the Microphone Level potentiometer for 4 KHz deviation, while speaking
into the microphone.
Note: The microphone is not included. Refer to Model WPSNCMIC, part # 01-0245719-00.
10. Receive Audio Level is factory set for an input signal of 0 to -10dB.
11. The speaker volume potentiometer is located through the small access hole on the right side of
the E-2010.
Located at the left rear of the E-2010 is a security keylock. Turning the key off will disable all keyboard
entries.
JP4
JP3
JP2
JP1
CHANNEL
GRANT
HI LO
HI LO
SQUELCH
LO HI LO
HI
CHANNEL
GRANT
SQUELCH
MICROPHONE LEVEL
CHANNEL 2
RECEIVE AUDIO LEVEL
TRANSMIT AUDIO LEVEL
CHANNEL 2
CHANNEL 2
TRANSMIT AUDIO LEVEL
CHANNEL 1
CHANNEL 1
RECEIVE AUDIO LEVEL
MICROPHONE LEVEL
CHANNEL 1
JUMPERand ADJUSTMENT
LOCATION
+=cw
+=ccw
+=ccw
+=ccw +=ccw
+=cw
CHANNEL2
CHANNEL1

16
TROUBLESHOOTING
PROBLEM
Display and backlight are blank.
Time clock is active, keyboard does not function.
Command is sent, but display still reads
“transmitting”.
No PC interaction.
No printer interaction.
Polling function does not work.
Time clock does not maintain time.
SOLUTION
Check AC power and DC power pack connection.
Security switch is off.
Area code is still at 000, must be set.
Transmitter warm-up is still 0.0, must be set to a
value other than 0.
Cable is not connected or the serial port is “off” in
Port Setup.
Cable is not connected or the printer port is “off” in
Port Setup.
Remote siren addresses were not entered in Polling
Setup.
Check internal battery voltage. Replace if less than
2.5 volts DC.
