Whirlpool CGM2751TQ - COMM GAS DRYR 3CYC 3TEMP 3LITE User manual

COMMERCIAL
GAS DRYER
c2012 WHIRLPOOL CORPORATION
MODELS
CGM2751TQ0
(WHITE)
CGM2751TQ1
(WHITE)
5−12 Litho in U.S.A. (CMS) (psw) Part No. W10119631 Rev. C

TOP AND CONSOLE PARTS
2
W10119631
For Models: CGM2751TQ0, CGM2751TQ1
(White) (White)

TOP AND CONSOLE PARTS
3W10119631
For Models: CGM2751TQ0, CGM2751TQ1
(White) (White)
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8577208 Instructions,
Installation
8533569 Wiring Diagram
W10119631 Repair Parts List
2 357213 Nut, Push−In
3 3361029 Bracket, Control
4 8316634 Panel, Control
5 8316516 Cap, End (R.H.)
6 3949734 Cap, End (L.H.)
7 97787 Screw
8 8316437 Switch, Pushbutton
9 8316433 Pushbutton
10 693995 Screw
11 3954665 Top
12 303921 Screw
13 3348109 Lens, Amber
14 689559 Nut, Push−In
15 8533971 Screw
16 343641 Screw
17 3954761 Plate,
Chute Adapter
(Includes
Illus. 25)
18 3978608 Panel, Rear
(Upper)
19 3390647 Screw
20 3954807 Kit, Vertical
8−Coin
(Includes
Illus. 54−56−57
59−60−61 & 62)
21 8318255 Strap, Console
22 8529870 Harness, Main
25 385421 Funnel, Coin
30 3954812 Cushion, Case
31 3406994 Case, Meter
32 3401126 Harness, Timer
33 387371 Lock, Plug
34 3349065 Bolt,
5/16−24 x 1
35
W10045440 Timer
(Includes
4−Pin Cam)
36 Timing Cam
3387974 3−Pin (60 Min)
343777 6−Pin (30 Min)
38 8281182 Screw
39 8316640 Lights, Indicator
Assembly
43 3351136 Door, Service
45 339805 Screw
46 3398893 Ground Wire
49 8317340 Cover, Terminal
Block
50 3390814 Screw
51 3347825 Plate−Mounting
52 98445 Screw
53 90406 Nut, Cage
Following Parts Supplied
On Whirlpool Coin
Equipped Models Only
54 8316526 Security Lock/Key
& Cam Assembly
55 8318517 Bolt, Slide
Mechanism
56 8316520 Slide Mechanism
(Vertical 8−Coin)
(Dollar Vend)
Inserts
(Not Shown)
8316264 Blank
8316265 25¢
57 8316525 Money Box W/Lock
58 Key (Money Box)
(When Ordering,
Specify Vendor
and Key Number)
59 Key (Service Door)
(When Ordering,
Specify Vendor
and Key Number)
60 8316523 Extension
61 8316524 Kit, Decal
62 8316532 Installation
Instructions
Coin Kit
63 3400086 Screw
Coin Mechanism Parts May be
Ordered From Whirlpool Or
The Vendor (s) Listed Below.
ESD
270 New Jersey Dr.
Fort Washington, PA
19034
1−800−523−1510
@
info esdcoin.com

CABINET PARTS
4
W10119631
For Models: CGM2751TQ0, CGM2751TQ1
(White) (White)

CABINET PARTS
5W10119631
For Models: CGM2751TQ0, CGM2751TQ1
(White) (White)
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3391943 Boot, Foot
2 356674 Cone, Wedge
3
W10045050 Screw
4 3391846 Clip, Front
Panel
5 3394881 Switch, Broken
Belt
6 697773 Screw
7 8310656 Cabinet
8 3392100 Foot, Dryer
(Plastic)
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 697750 Plug, Multivent
13 3388672 Pulley Assembly
14 3391915 Screw
15 3394331 Plate, Cover
16
W10167612 Wire, Belt Switch
17 693152 Bumper
18
W10121334 Washer, Thurst
19 297092 Clip
20 690997 Tri−Ring
21 3389247 Hinge And Pin
22 3353948 Bracket, Lock
23 3390663 Screw
24 345670 Lock−Top
25 63554 Rivet
26 3389249 Nut, "U"
27 8538264 Motor Assembly
(60 Hz.)
28 279731 4"− 90
Elbow
29 3394341 Pulley 60 Hz
30 3387610 Belt, Drive
31 3390902 Clip, Door
Hinge
32 3387118 Bracket, Motor
33 3387057 Screw
34 686590 Ignitor
35 3393909 Screw
36 3401401 Cord, Power
37 3387561 Clamp, Pipe
38 8281911 Valve, Gas
(Complete)
60 Hz.
39 3388674 Bracket, Idler
40 3390647 Screw
41 3406109 Door Switch
Assembly
42 98129 Screw
43 697215 Panel, Toe
(Includes
Illus. 17 )
44 3387242 Seal, Front Panel
45 342055 Screw
46 3388229 Retainer
47 3392563 Door, Rear
48 694091 Screw
49 3387872 Door, Front
50
W10116360 Handle, Door
51 3393081 Lower Front Panel
52 696144 Strike, Door
53 8533974 Screw−Ground
54 3398948 Wire, Jumper
55 8066120 Lever, Snap
Switch
56 3390735 Seal, Door
57 3392538 Catch, Door
Assembly
58 3401797 Burner Assembly
60 Hz.
(Refer To Pages
8 & 9 For Further
Breakdown)
59 8066134 Switch,
Assembly
60 3393657 Restrain, Belt
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
61 279818 White

BULKHEAD PARTS
6
W10119631
For Models: CGM2751TQ0, CGM2751TQ1
(White) (White)

BULKHEAD PARTS
7W10119631
For Models: CGM2751TQ0, CGM2751TQ1
(White) (White)
Illus. Part
No. No. DESCRIPTION
1 8575324 Shaft, R.H. Thread
2 697770 Seal, Cover Plate
3 8533971 Screw
4 90767 Screw
5 3394346 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3934666 Nut,
3/8 x 16 (R.H.)
9 8066224 Exhaust Pipe
10 8572105 Clip
11 3387230 Screw
12 3394986 Spring, Lint
Door
13 3390647 Screw
14 8066208 Clip−Spring
15
W10049370 Screen, Lint
16
W10001120 Nut,
3/8−16 (L.H.)
17 3387809 Bulkhead, Rear
18 3387459 Washer, Support
19 8575325 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 3392519 Thermal Fuse
23 3394985 Housing, Outlet
24 8299979 Grille, Outlet
25 8318215 Drum Complete
26
W10219342 Screw
27
W10166807 Seal, Drum
28 697557 Bulkhead, Front
29 697693 Baffle, Drum
30 3394984 Door, Lint Screen
31 487909 Screw
32 3357011 Screw
33
W10168564 Wheel, Blower
34 3387138 Thermostat
35 8544362 Housing, Blower
36 8066168 Lint Duct Assembly
37 8066047 Funnel, Burner
38 338906 Sensor, Radiant
39 3391912 Thermostat 255
(124 C)

3401797 BURNER ASSEMBLY
BA−133−A
USE WITH TYPE 1 − NATURAL, TYPE 2 − MIXED,
AND TYPE 4 − LIQUEFIED PROPANE AND BUTANE GASES
8
W10119631
For Models: CGM2751TQ0, CGM2751TQ1
(White) (White)

USE WITH TYPE 1 − NATURAL, TYPE 2 − MIXED,
AND TYPE 4 − LIQUEFIED PROPANE AND BUTANE GASES
Illus. Part
No. No. DESCRIPTION
3401797 BURNER ASSEMBLY
1 3401797 Burner Assembly
60 Hz.
(Type 1, 2 & 3)
(White Rodgers)
2 688617 Tube, Burner
3 694298 Bracket, Ignitor
4 686590 Ignitor
5 3393909 Screw & Washer
(8−32 x 5/8)
6 343641 Screw, 10−16 x 1/2
7 3389871 Base, Burner
8 3387057 Screw,
10−16 x 1/2 (3)
9 Orifice, Burner
3397656 Type 1
15775 Type 2
10 3401775 Valve, Gas
60 Hz. (Complete)
11 694421 Screw,
8−32 x 1/2 (2)
12 694538 Bracket, Coil
13 694540 Coil, 60 Hz.
(2 Terminal)
(Main)
14 694539 Coil, 60 Hz.
(Split)
(3 Terminal)
(Pilot Position)
15 694424 Leak, Limiter
16 694423 Screw, Regulator
Adjustment
17 694422 Spring, Regulator
20 239822 Plug, Pipe
21 3387224 Pipe, Gas Supply
22 697441 Valve & Union
Shut−Off
23 3393767 Pipe, Tail
24 233076 Nut, Compression
25 3387561 Clamp, Pipe
26 3389889 Bracket, Support
Following Parts Not Illustrated
694572 Conversion Kit
(Type 1 and 2)
to Type (4) L.P.G.
BA−133−A
9W10119631
For Models: CGM2751TQ0, CGM2751TQ1
(White) (White)

OPTIONAL PARTS (NOT INCLUDED)
10
W10119631
For Models: CGM2751TQ0, CGM2751TQ1
(White) (White)
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
4392067 Kit,
Dryer Repair
8522199 Kit, Dryer
Vent Testing
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
