Whirlpool ACM 959/WH User manual

SERVICE Whirlpool Europe
Customer Services ACM 959/WH
This documentation is only intended for qualified technicians who are aware of the respec-
tive safety regulations.
Date: 24.11.1997 Subject to modification
Document-No.: 4812 715 17349
Model ACM 959/WH
Version 8576 959 15000 Page
Technical data 2
Spare part list 3
Exploded view 4 - 5
Wiring diagram 6
Service Manual
Cooker
Gas/Electro
ACM 959/WH

SERVICE
24.11.1997 / Page 2 ACM959/WH Whirlpool Europe
Doc. No: 4812 715 17349 8576 959 15000 Customer Service
Technical data
Electrical connection
Voltage 230 V
400 3N V
Frequency 50 Hz
Upper heating element 850 W
Lower heating element 1200 W
Grill heating element 850 +1050 W
Oven lamp 15 W
Max. function with total absorbed power 7550 W
Hot plates
Front left (normal) ø 145 mm 1000 W
Front right (rapid) ø 180 mm 2000 W
Rear left (normal) ø 180 mm 1500 W
Rear right (normal) ø 145 mm 1000 W
Range dimensions
Height closed lid 840 mm
Width 550 mm
Depth 550 mm

SERVICE Whirlpool Europe ACM959/WH 24.11.1997 / Page 3
Customer Service 8576 959 15000 Doc. No: 4812 715 17349
Spare part list
Model ACM959/WH
Service No. 857695915000
Version 857695915000
Pos. No. 12NC Code Description
002 0 4819 442 39146 Lid
011 0 4819 462 48484 Foot
011 9 4819 462 58297 Foot
022 0 4819 442 38681 Side, range right
022 1 4819 442 38682 Side, range left
022 4 4819 526 28004 Magnet
022 8 4819 462 79942 Plug right
022 9 4819 462 79943 Plug left
031 0 4819 442 38686 Hob
031 1 4819 466 98874 Spacer hob rear
041 0 4819 417 19545 Hinge
043 0 4819 417 19517 Hinge
043 1 4819 462 58287 Cover
043 2 4819 417 19515 Hinge right
043 2 4819 417 19516 Hinge left
043 3 4819 404 79297 Support
043 4 4819 466 99136 Hinge
050 0 4819 442 38518 Door, small
050 1 4819 417 19254 Hinge right
050 1 4819 417 19255 Hinge left
050 2 4819 532 58253 Spacer
084 0 4819 466 99088 Cover,rubber Lid
110 0 4819 498 78179 Handle
121 0 4819 442 38678 Innerdoor,oven
141 0 4819 450 58096 Oven glass
142 0 4819 450 58173 Oven glass inner
191 0 4819 468 18298 Gasket
202 0 4819 442 38253 Bottom, oven
242 2 4819 417 19256 Hinge,lower left
242 3 4819 417 19257 Hinge,lower right
242 4 4819 532 68838 Spacer
245 0 4819 460 89248 Grid
245 1 4819 458 19892 Grid
247 0 4819 418 38369 Fat pan
247 1 4819 498 58528 Handle
256 0 4819 442 38257 Knob,protection
256 1 4819 532 58252 Spacer
301 3 4819 404 78804 Trim, lower
320 0 4819 453 58941 Control panel
331 0 4819 412 58556 Knob,switch
334 9 4819 492 58065 Spring knob
341 0 4819 413 79133 Scale elec.
341 1 4819 413 79135 Scale timer
341 5 4819 413 79156 Scale thermostat
354 0 4819 134 48486 Pilot lamp
354 1 4819 381 18232 Lens red
354 2 4819 381 18233 Lens yellow
452 0 4819 259 28787 Heating element upper/grill
456 0 4819 259 28785 Heating element lower
461 0 4819 259 21296 Cooking plate d 145 1000 W
461 1 4819 259 98501 Cooking plate D 180 1500 W
462 1 4819 259 21299 Cooking plate Rapid d 180 mm 2000 W
491 0 4819 290 68308 Terminal block
491 1 4819 401 18765 Clamp,cable
491 3 4819 401 18768 Clamp
Pos. No. 12NC Code Description
491 4 4819 466 98873 Spacer
503 0 4819 282 18475 Time switch
554 0 4819 271 28863 Thermostat oven
562 0 4819 271 28616 Thermostat safety
620 0 4819 276 18228 Switch,oven
622 0 4819 273 28353 Switch hot plate
651 0 4819 134 88135 Lamp E14 240 V 15 W
652 0 4819 255 18162 Holder,lamp
656 0 4819 450 69999 Cover,lamp
964 0 4819 468 18186 Gasket

SERVICE
24.11.1997 / Page 4 ACM959/WH Whirlpool Europe
Doc. No: 4812 715 17349 8576 959 15000 Customer Service
Exploded view

SERVICE Whirlpool Europe ACM959/WH 24.11.1997 / Page 5
Customer Service 8576 959 15000 Doc. No: 4812 715 17349
Exploded view

SERVICE
24.11.1997 / Page 6 ACM959/WH Whirlpool Europe
Doc. No: 4812 715 17349 8576 959 15000 Customer Service
Wiring diagram
