Whispbar K447 Install guide

FittingKit
K447
GB
Fitting Instruction for Accessory
x 1
x 1
x 6
x 6
x 6
x 6
x 2
x 4
x 2
x 4
1
Revision No:
3B

FittingKit
K447
GB
MAX kgs
MAX kgs
W/P
WHD
W/P
WHD
Volkswagen
Caddy Maxi, 5dr Van 08-+
ZA
100
100
Caddy Maxi, 5dr Van 08-+
EU
100
100
Caddy Maxi, 5dr Van 08-+
NZ
100
100
Caddy Maxi, 5dr Van 08-+
AU
100
100
2

FittingKit
K447
GB
First Time Installation
Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
This kit fits type A, B, C and D.
These instructions show type A crossbar
fitted. They also apply to type B, C and D.
Use keys to remove covers.
3

FittingKit
K447
GB
Use hex screwdriver to reverse adjusting
screw 10 turns.
Press adjusting screw and pull crossbar legs
out. Refer to the crossbar instructions for
crossbar adjustment.
Ensure each end of the crossbar is adjusted
equally.
Adjust crossbar in or out to suit vehicle.
Refer to the crossbar instructions for
crossbar adjustment.
Please check the rear of this manual for
information relating specifically to your
vehicle.
4

FittingKit
K447
GB
Tighten adjusting screw to 5 Nm (3.7 ft lb).
Remove plastic clamp block by gripping bar
leg with fingers and push firmly with thumbs
until clamp block drops out behind leg.
Select plastic internal block (from fitting kit)
and insert into foot.
Repeat for all legs.
5

FittingKit
K447
GB
Refer to the underside of the pad for the part
number.
It is important to put the pads in the correct
position on the vehicle.
Letters refer to the pad part numbers and
position.
Pad Part Number:
A = 11-04-218
B = 11-04-220
Fit rubber pads (supplied with fitting kit) to
foot. Pad may vary in shape to that shown.
Make sure the pad fits into the holes
underneath the foot.
6

FittingKit
K447
GB
Fitment
Remove fixed-point cover screws with 5mm
(1/4") Hex Key.
Fit the adaptor (A) to grubscrew (B).
Use the following grubscrew lengths for each
position:
A = M6 x 35mm (1 3/8")
B = M6 x 50mm (2")
7

FittingKit
K447
GB
Screw adaptor with grubscrew assembly into
roof. Tighten firmly.
Repeat for all four positions.
Place crossbar foot over clamp.
Tighten the red plastic knob.
In the fully tightened position, the knobs
should be parallel with the vehicle.
Repeat for all four positions.
8

FittingKit
K447
GB
Check crossbar is securely attached to the
vehicle.
Use keys to fit and lock covers
CAUTION:
Recheck all fasteners immediately after a load is
applied to the crossbars.
Regularly check screws are tight.
9

FittingKit
K447
GB
Clean the car roof and surfaces of the
product that will be in contact with the car
roof.
Follow the fitting instructions for fitting the
product to your vehicle. Make sure all steps
are carried out in order.
Set crossbars a minimum distance of 700mm
(27 1/2") apart where no other distance is
specified in the fitting instructions. This is
especially important when carrying long
loads.
Check unit is securely attached whenever
you refit it to the vehicle. If the unit feels
loose, refer to the fitting instructions and
readjust.
Some glass/panoramic roofs and radio
antennae may not be able to be used when
the product is fitted.
Do not modify this product.
Refer to the maximum permitted load
capacity specified in the fitting instructions.
Do not exceed the vehicle manufacturers
roof load rating if it is lower than the
maximum load capacity specified in the fitting
instructions.
Loads should not overhang the sides of the
product and be evenly distributed with the
lowest possible centre of gravity.
Long loads should be secured with non-
elastic straps to the front and rear of the
vehicle.
Objects with pointed ends (e.g. ski poles)
should be carried with the pointed ends to
the rear of the vehicle.
Remove all loose or removable objects from
the load prior to loading.
Make sure all loads are securely fastened
with non-elastic straps. Check regularly
during longer journeys.
10

FittingKit
K447
GB
A loaded roof rack system can alter the
performance of your vehicle. Be especially
aware of the effects of side winds, changing
of direction, and braking performance. Avoid
rapid acceleration and deceleration. Drive
carefully.
Note that the total height of the vehicle
increases when upright loads are carried.
Products should be locked during transport if
they have locks fitted.
Check and replace worn out or defective
parts.
Keep the product clean and maintained.
Never drive into a car wash with the roof rack
system fitted.
Lubricate locks and adjusting screws at
regular intervals.
Remove the products from the vehicle when
not in use. Make sure all loose parts are
stored safely.
Hubco Automotive Ltd
P. O. Box 11017
Christchurch
NEW ZEALAND
www.whispbar.com
www.whispbar.com.au
www.whispbar.co.nz
www.whispbar.co.uk
www.whispbar.co.za
www.whispbar.eu
www.whispbar.ca
11
