WHISPER KOOL Extreme 3500 ti User manual

EXTREME SERIES
OWNER’S MANUAL
The Coolest Thing In Wine Storage
Extreme 3500 ti
Extreme 5000 ti
Extreme 8000 ti
Extreme 3500 tiR
Extreme 5000 tiR
Extreme 8000 tiR
Extreme 5000 tiR FD

Copyright © 2012. WhisperKOOL. All rights reserved.
WhisperKOOL copyrights this manual, the product design, and the design concepts, with all rights reserved. Your rights
with regard to the hardware and manual are subject to the restrictions and limitations imposed by the copyright laws of the
USA. Under copyright laws, this manual may not be copied, reproduced, translated, transmitted, or reduced to any printed
or electronic medium or to any machine-readable form, for any purpose, in whole or in part, without the written consent of
WhisperKOOL.
Every eort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing
or clerical errors.
WhisperKOOL reserves the right to make corrections or improvements to the information provided and to the related hardware
at any time, without notice.
Vinothèque and WhisperKOOL are registered trademarks, and ECE is a trademark of WhisperKOOL. All rights reserved.
Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a
recommendation. WhisperKOOL assumes no liability with regard to the performance or use of these products.
12.09.2015
We manufacture, test and certify 100% of our wine cooling units in
the USA. By sourcing the best components and closely controlling our
manufacturing processes, we can assure the highest-quality,
lowest defect manufacturing rates in the industry.

Extreme Series
Quick Reference Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Standard Controller Layout ..................................................4
Remote Controller Layout ...................................................4
Fan Speed...................................................................5
Unit Specications ..........................................................5
Introduction ...................................................................6
Receiving and Inspecting the Unit ...........................................7
Quick Start Guide .............................................................8
Preparing the Wine Cellar ....................................................9
Pre-Installation ................................................................12
Through-the-Wall Installation ................................................13
Preparing the Installation Location...........................................13
Optional Exterior Grille ......................................................15
Installing the Unit ...........................................................16
Ducted Installation............................................................17
Ducting Overview ...........................................................17
Ducting Congurations......................................................18
Installing the Duct Plenums..................................................20
Remote Controller Installation ...............................................21
Condensation Drain Line .....................................................23
Liquid Measuring Thermostat System (Bottle Probe) ......................24
Multi-Speed Fan Control......................................................25
Unit Operation ................................................................26
Standard Controller ...........................................................27
Functions ...................................................................27
Alarm Codes ................................................................28
CPSM (Customer Preference Selection Mode).................................28
Standard Controller Wiring Schematic........................................29
Remote Controller ............................................................30
Functions ...................................................................30
Alarm Codes ................................................................31
CPSM (Customer Preference Selection Mode).................................31
Remote Controller Wiring Schematic.........................................32
Troubleshooting Guide .......................................................34
Maintenance Schedule........................................................36
Technical Assistance ..........................................................37
Accessories for Cooling Units.................................................37
Product Warranty Information ...............................................38
TABLE OF CONTENTS

EXti 120915
Page 2 | 1-800-343-9463
QUICK REFERENCE GUIDE
Front / Side View
Rear / Side View
Controller
Bottle Probe
Probe Input
Grille w/Filter
Control Panel
(see page 12 for details)
Compressor
Access Panel
Fan Speed Control
Grille w/Filter
Drain Port
Drain Line
Access
Rear Power Option

www.whisperkool.com | Page 3
Extreme Series
Fully Ducted — Front / Side View
D
I
S
P
L
A
Y
B
O
T
T
L
E
P
R
O
B
E
Rear
D
I
S
P
L
A
Y
B
O
T
T
L
E
P
R
O
B
E
Remote Front / Side View
Controller w/Remote Box
Bottle Probe
Grille w/Filter
Control Panel
(see page 12 for details)
Compressor
Access Panel
Fan Speed Control
Drain Port
Controller w/Remote Box
Bottle Probe
Return Plenum
Supply Plenum
Control Panel
(see page 12 for details)
Compressor
Access Panel
Fan Speed Control
Exhaust Plenum
Intake Plenum

EXti 120915
Page 4 | 1-800-343-9463
Evaporator and Condenser Fan
Alarm Pre-Chill Display
Anti-Frost Compressor
Energy Reduction
SET Button
View Set Point 1
Change Set Point 3–5
SET + Scroll Down = CPSM 10–15
Reset Hi and Lo Button 3–5
• Display and modify set point.
• In programming mode it selects a parameter /
conrms an operation.
• Hold for three seconds when the min. or max.
temperature is displayed to RESET.
Energy Saving Button 1
Control ON/OFF Button
Cellar Pre-Chill Button 3–5
Hi Bottle Temp History and
Scroll Down Button 1
• Push to see the max. stored temperature.
• In programming mode use to browse the
parameter codes or increase the display value.
• Hold for 3 seconds to start fast freezing cycle.
Low Bottle Temp History and
Scroll Up Button 1
• Push to see the min. stored temperature.
• In programming mode use to browse the
parameter codes or decrease the display value.
Evaporator and Condenser Fan
Alarm Pre-Chill Display
Anti-Frost Compressor
SET Button
View Set Point 1
Change Set Point 3–5
SET + Scroll Down = CPSM 10–15
Reset Hi and Lo Button 3–5
• Display and modify set point.
• In programming mode it selects a parameter /
conrms an operation.
• Hold for three seconds when the min. or max.
temperature is displayed to RESET.
Inactive
Control ON/OFF Button
Hi Bottle Temp History and
Scroll Down Button 1
Cellar Pre-Chill Button 3–5
• Push to see the max. stored temperature.
• In programming mode use to browse the
parameter codes or increase the display value.
• Hold for 3 seconds to start fast freezing cycle.
Low Bottle Temp History and
Scroll Up Button 1
• Push to see the min. stored temperature.
• In programming mode use to browse the
parameter codes or decrease the display value.
Standard Controller Layout
If your unit is installed through-the-wall and does not have a remote keypad you have the Standard Controller
Note: The 1 or 3–5 qualies the amount of time in seconds that the button must be pushed to activate the feature.
Refer to page 30 for complete listing of buttons and symbols.
Remote Controller Layout
If your unit has a remote keypad then you have the Remote Controller
Note: The 1 or 3–5 qualies the amount of time in seconds that the button must be pushed to activate the feature.
Refer to page 33 for complete listing of buttons and symbols.

www.whisperkool.com | Page 5
Extreme Series
Unit Specications
Fan Speed
Fan speed selection is determined by the amount of heat that needs to be removed from the cellar and the type of installation
(through-the-wall or fully ducted). Fan speed selection is based on the cellar size, insulation factor, door seal and desired wine
temperature. When initially installing the unit, set the fan speed to the High setting for a quick chill down. Once the wine cellar
reaches the desired temperature, a lower fan speed may be selected (for all models except the Extreme 5000tiR FD). In the event
that the outdoor temperature rises above 90°F, (when exhausting to the outdoors) a higher fan speed may be required.
Fully ducted units need to be set to the high fan speed position at all times.
All Extreme 5000tiR FD models come from the factory with the fans wired in
high speed. The fan speed is not adjustable on these models.
3500ti | 3500tiR 5000ti | 5000tiR 8000ti | 8000tiR
Cellar Size* 800 cu. ft. 1250 cu. ft. 2000 cu.ft
Dimensions 14.25”W x 15.75”H x 28”D 14.25”W x 15.75”H x 28”D 14.25”W x 22.25”H x 28”D
Weight (lb.) 115 115 150
Amps (running) 9 9 10
dBA 51 low | 58 med | 66 high 51 low | 58 med | 66 high 57 low | 59 med | 61 high
Installation Through-the-Wall, Partially Ducted, Fully Ducted
Thermostat Digital control display
Temp. Delta 55°F temperature dierential
(maintains proper cellar temperature when exhaust environment does not exceed 110°F)
Outside Venting Can be done if the outside temperature does not exceed 110°F
The external grille cover is required
Ducting Options Unit can be fully ducted
Warranty 2-year parts and labor / 5-year compressor
* To get a feeling for decibels, a food blender at 3 ft. is 90 dBA, garbage disposal at 3 ft. is 85 dBA, vacuum cleaner at 10 ft. is 75 dBA,
normal speech at 3 ft. is 79 dBA, dishwasher in the next room is 55 dBA, a quiet night is 35 dBA
3500ti | 3500tiR 5000ti | 5000tiR 8000ti | 8000tiR 5000tiR FD
Speed Selection Low Med High Low Med High Low Med High Low Med High
Air Flow (CFM) 147 180 256 147 180 256 274 318 333 N/A N/A 256
Sound (dBA* In Cellar / Out of Cellar)
51/51 58/57 66/65 51/51 58/57 66/65 57/57 59/59 60/61 N/A N/A 66/65
Cooling Capacity (BTU/h) 2374 2514 2688 3099 3453 4126 5140 5606 5760 N/A N/A 3794
* Sizing the Unit to the Room
The specication chart will provide information on the units room size cooling capacity. There are circumstances in which a cellar
design may require a larger unit due to some existing design restrictions. There are several factors such as glass, stone, concrete, etc.
which will seem adequate but do not oer the insulation capacity required to maintain the optimum environment. We recommend
purchasing a unit with a larger capacity to compensate for the design limitations. Under sized cooling units can lead to pre-mature
failure and/or prevent the system from reaching the desired set temperature. As a result they are not covered under warranty.

EXti 120915
Page 6 | 1-800-343-9463
INTRODUCTION
Customer Service
Thank you for purchasing a WhisperKOOL Extreme Series cooling unit. We strive to provide the highest quality products and the
best possible customer service. If you have any questions about your WhisperKOOL unit, please call us at 1-800-343-9463 or visit
whisperkool.com.
Using the Manual
This Owner’s Manual is intended to assist in the proper installation and maintenance of the WhisperKOOL cooling unit. In
order to ensure the longevity of your cooling unit, the equipment should be installed properly and have a proper care and
maintenance schedule. Please read and review this Owner’s Manual carefully and keep it for future reference.
What is the WhisperKOOL Cooling Unit?
The WhisperKOOL cooling unit is a specialized refrigeration unit designed for one purpose only: to maintain the optimal
temperature and humidity levels conducive to the proper storage and aging of ne wines. It is a self-contained cooling unit
designed to be used as a forced-air through-the-wall unit.
How Does the WhisperKOOL Extreme Series Work?
The WhisperKOOL unit is especially designed for the use and application to maintain optimal conditions for wine storage and
aging. The unit is fully self-contained and can be installed as a through-the-wall application. The unit is also capable of a more
exible ducted application, which allows the unit to be placed in an indoor remote site, resulting in a quiet airow. The standard
through-the-wall and ducted units are temperature controlled via a bottle probe. The ducted unit comes standard with a remote
controller that can be located up to 50 ft. from the cooling unit
Note: Remote unit comes standard with a 50 ft. bottle probe and 50 ft. of cable for the remote controller, additional lengths
are optional.
Temperature Setting
The WhisperKOOL cooling unit can be set at any temperature within the acceptable wine aging range of 50–67°F.
It is designed to cool up to 55°F cooler than the ambient temperature of the space to which it is exhausting not to exceed 100˚F.

www.whisperkool.com | Page 7
Extreme Series
RECEIVING AND INSPECTING THE UNIT
Upon Receiving the WhisperKOOL Cooling Unit
• Lift only at the designated hand hold locations on the shipping container or fully support the unit from underneath.
A shipment may include one or more boxes containing accessories.
• Inspect the packaging for any obvious signs of damage or mishandling before opening the container.
• Note any discrepancies or visual damage on the Bill of Lading before signing.
• Place the box containing the WhisperKOOL unit on a tabletop to prepare it for testing prior to installing.
• Sit unit upright for 24 hours.
Note: WhisperKOOL units are manufactured in the USA and tested prior to shipment.
Review the Packing Slip to Verify Contents
• Check the model number to ensure it is correct.
• Check that all factory options ordered are listed.
If any items listed on the packing slip do not match your order information,
contact WhisperKOOL Customer Service immediately.
Check the Box for the Following Contents:
3500ti / 5000ti / 8000ti
Extreme Cooling Unit
• WhisperKOOL Extreme Series Owner’s Manual
Single Piece Mounting Bracket
Accessory Kit:
• 8’ Power Cord
• Mounting Bracket Insulation 14.5” Foam (2)
• Mounting Bracket Insulation 24.75” Foam (2)
• Bottle Temperature Probe
• 1¾ Standard Screws (9)
• ½ Self-Tapping Screws (5)
• ½ x ½ Barbx MNPT Fitting
• Drain Line tube 10’ (1)
• Connection “T” (1)
Please leave the WhisperKOOL unit in its original box until you are ready for installation. This will allow you to move the product
safely without damaging it. When you are ready to remove the product from the box, refer to the installation instructions.
TIP: Save your box and all packaging materials. They provide the only safe means of transporting/shipping the unit.
3500tiR / 5000tiR / 8000tiR
Extreme Cooling Unit
• Remote Controller
• Bottle Temperature Probe
• WhisperKOOL Extreme Series Owner’s Manual
Single Piece Mounting Bracket
Accessory Kit:
• 8’ Power Cord
• Mounting Bracket Insulation 14.5” Foam (2)
• Mounting Bracket Insulation 24.75” Foam (2)
• 1¾ Standard Screws (9)
• ½ Self-Tapping Screws (5)
• ½ x ½ Barbx MNPT Fitting
• Drain Line tube 10’ (1)
• Connection “T” (1)

EXti 120915
Page 8 | 1-800-343-9463
QUICK START GUIDE
This guide is meant to serve as a quick reference for installation of the WhisperKOOL unit. The remainder of this Owner’s Manual
will provide more detailed information and instructions.
Upon Receiving the WhisperKOOL Cooling Unit
1. Inspect the unit before installation. If damage is found, please contact your distributor or WhisperKOOL Customer Service
at 1-800-343-9463 ext. 799.
2. The unit should remain in an upright position for 24 hours prior to operation.
3. The WhisperKOOL unit requires a dedicated 115V 20A circuit. Use a surge protector with the WhisperKOOL unit.
Do not use a GFI (Ground Fault Interrupter) line.
4. For your convenience, the WhisperKOOL unit has two power inlets: one on the side of the unit, and the other on the back.
Use the selector switch, located on the right side of the unit, to select the inlet you would like to use.
5. It is Required to install a drain line to remove condensation from the unit.
6. The WhisperKOOL unit is intended for use in properly designed and constructed wine cellars. Hire a professional wine
storage consultant with a valid contractor’s license to build your wine cellar. Refer to the How to Build a Wine Cellar video
available on the WhisperKOOL website at www.whisperkool.com.
7. Install the foam strips along the inside edge of the unit’s ange to assure a proper seal against the wall.
Never try to open the WhisperKOOL unit, repair it yourself, or use a service company
without WhisperKOOL’s authorization. This will void your warranty.
If you encounter a problem with your WhisperKOOL unit, please refer to the Troubleshooting Guide on page 36. If you have
any further questions, concerns, or need assistance, please contact WhisperKOOL Customer Service at 1-800-343-9463 ext. 799.
Please be sure all testing has been completed prior to contacting Customer Service. Please have your results ready for your
representative.
