WhisperPower M-GV4 Piccolo User manual

Service manual Piccolo
5 Fuel
3 Water
2 Oil
4 Attachment
1 Canopy
7 Engine
6 Electrical
NAME
01-01-1900
M.F.
28-4-2015
SHEET 1 OF 8
ARTICLE NO.
TITLE:
REVISION
STATUS:
DATE
SIGNATURE
CHK'D
DRAWN
M-GV4 Piccolo
SHEET FORMAT:
Design Review
A2
9500MAN308001A152757 Servicepart manual
Piccolo
D.K.

7502P003 canopy
7019P142422 Pipe flash exhaust slot
7019P142415 Lashing strap canopy Piccolo
1003P11226
7502P008 rvs strip
7502P002 base
1. Canopy
NAME
01-01-1900
M.F.
28-4-2015
SHEET 2 OF 8
ARTICLE NO.
TITLE:
REVISION
STATUS:
DATE
SIGNATURE
CHK'D
DRAWN
M-GV4 Piccolo
SHEET FORMAT:
Design Review
A2
9500MAN308001A152757 Servicepart manual
Piccolo
D.K.

40401018 Oil pipes and fittings kit
40401029 Oil cooler GV ASSY KIT
40401029 Oil cooler GV ASSY KIT
40401340 Oil filter container WP1
OIL DIP STICK 50203333
40401284 Oil plug
2. Oil
NAME
28-4-2015
SHEET 3 OF 8
ARTICLE NO.
TITLE:
REVISION
STATUS:
DATE
SIGNATURE
CHK'D
DRAWN
M-GV4 Piccolo
SHEET FORMAT:
Design Review
A2
9500MAN308001A152757 Servicepart manual
Piccolo
D.K.

Kit nr. 40201271
1001P131328 Pump mounting brackets
Kit nr. 40209011
40201270 Complete pump
3. Water
NAME
28-4-2015
SHEET 4 OF 8
ARTICLE NO.
TITLE:
REVISION
STATUS:
DATE
SIGNATURE
CHK'D
DRAWN
M-GV4 Piccolo
SHEET FORMAT:
Design Review
A2
9500MAN308001A152757 Servicepart manual
Piccolo
D.K.

40401087 Fan
40401086
40401086-1 fillingring
1001P131230 Cover Generator PM 4kW
1001P131328 Pump mounting brackets
50261205 Bracket
40401333 Cover air filter
40401329 Air filter element
40401327 Airfilter base
4. Attachment
Gasket set contains all gaskets and o rings
set nr. 40401392
NAME
28-4-2015
SHEET 5 OF 8
ARTICLE NO.
TITLE:
REVISION
STATUS:
DATE
SIGNATURE
CHK'D
DRAWN
M-GV4 Piccolo
SHEET FORMAT:
Design Review
A2
9500MAN308001A152757 Servicepart manual
Piccolo
D.K.

50201160 Fuel lift pomp
Fuel hose kit 40401031
40209030 Fuel filter
Fuel hose kit 40401031
Fuel hose kit 40401031
5. Fuel
Fuel hose kit 40401031
NAME
31-1-2012
M.B.
28-4-2015
SHEET 6 OF 8
ARTICLE NO.
TITLE:
REVISION
STATUS:
DATE
SIGNATURE
CHK'D
DRAWN
M-GV4 Piccolo
SHEET FORMAT:
Design Review
A2
9500MAN308001A152757 Servicepart manual
Piccolo
D.K.

50209238 EXHAUST TEMP SWITCH
50209236 OIL PRESS SWITCH
50209239 Oilpressure switch 5,5 bar
50209219 Temperature sensor
40401060 wiring loom Piccolo
40401240 Fuel pump Solenoid
40401386 Starter motor
40401103 Rotor
40401104 Stator
6. Electrical
NAME
28-4-2015
SHEET 7 OF 8
ARTICLE NO.
TITLE:
REVISION
STATUS:
DATE
SIGNATURE
CHK'D
DRAWN
M-GV4 Piccolo
SHEET FORMAT:
Design Review
A2
9500MAN308001A152757 Servicepart manual
Piccolo
D.K.

40401221 Cylinder head gasket
40401380 Shim set
40401381 Fuel pump complete
40401385 Injector
40401352 Oil pump cover
40401353 Inner rotor(big)
40401354 Outer rotor(big)
40401355 O-ring 41.2x1.8-A
40401352 Oil pump cover
40401346 Lube oil pump
40401347 O-ring 34.5x1.8-A
7. Engine
NAME
18-08-2011
M.B.
28-4-2015
SHEET 8 OF 8
ARTICLE NO.
TITLE:
REVISION
STATUS:
DATE
SIGNATURE
CHK'D
DRAWN
M-GV4 Piccolo
SHEET FORMAT:
Design Review
A2
9500MAN308001A152757 Servicepart manual
Piccolo
D.K.
