White Knight 44AW User manual

Air Vented Tumble Dryer - UK
SERVICE MANUAL
Wiring Diagram
Exploded Views
Parts List
March 2011
0312 44A 15001
White Knight - 44AW

White Knight 44AW - Air Vented Tumble Dryer - Exploded View 1
352
211
377
235
248
369
196
353
386
370
376
199
372
201
403
394
362
203
366
365
364
363
359
367

144
446 112
447 432 101
402
427 399
400
413
230
390
395
227
125
142
408 228 393
White Knight 44AW - Air Vented Tumble Dryer - Exploded View 2
270
141
444
266
437

144
446 112
447 432 101
402
427 399
400
413
230a
390a
395
227
125
142
408 393
White Knight 44AW - Air Vented Tumble Dryer - Exploded View 2a
270
141
444
266
437
228a

440
441
442
248
454
445
446
447
229
445a
456
458
459
448
White Knight - Air Vented Tumble Dryer - Exploded View 3

Mains
Cable
F/E
B
G
TB-L
TB-N
B/K
1.5
G
DS B/K
1.5
G
D
D
F/E
1.25 EC Timer
D
3
4/7
5/8
A/K
1.5
B
E
B
E
CAP
BE
M
A
D
EX-TH
A/K
1.5
A*
1.5
A*
1.5 IN-TH
HE-SW
A
0.75
C
0.75
G*
1.0
MAN
TOC HE2 HE1
G*
1.0
TB-4
B11
B12
M
B3
B4
C9
C10
B9
B10
B6
B5
B7
B8
B2
B1
C11
C12
Component Code
TB
DS
M
EX-TH
IN-TH
HE
HE-SW
MAN TOC
A/C-SW
-
-
-
-
-
-
-
-
-
Terminal Block
Door Switch
Motor
Exhaust Thermostat
Inlet Thermostat
Heater
Heat Switch
Manual Reset Heater Cut-out
Anti-crease Switch
Wire Colour Code
A
B
C
D
E
F
G
H
K
N/A
-
-
-
-
-
-
-
-
-
-
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
White
Pink
Timer Connections
ABC
1
2
3
4
5
6
7
8
9
10
11
12
A/K
B/K
D
D
G
B
E
White Knight 44AW Wiring Diagram

White Knight 44AW AIR VENTED TUMBLE DRYER - SPARE PARTS LIST
ITEM DESCRIPTION CODE EXPLODED VIEW
101 Motor & 8uf Capacitor Assembly 4213 092 25611 2
112 8uf Capacitor 4213 092 08091 2
125 Drive Belt 4213 092 18601 2
141 Mains Cable & Plug 4213 076 35123 2
142 Terminal Block 4213 078 44613 2
144 Earth Tab Assembly 4213 092 41181 1
196 Cabinet Assembly 4213 092 43481 1
199 Plinth Assembly 4213 092 43491 1
201 Door Seal 4213 077 08344 1
203 Complete Curveline Door Assembly 4213 092 45611 1
203a Curveline Door Frame Assy 4213 092 45621 1
211 Timer 4213 078 55142 1
227 Heating Element 4213 092 05521 2
228 Heat TOC 4213 078 50161 2
228a Heat TOC 4213 078 57371 2a
229 Thermostat 4213 078 48373 3
230 Thermostat (inlet) 4213 078 56261 2
230a Thermostat (inlet) 4213 078 57361 2a
235 Heat Switch 4213 078 52401 1
248 Microswitch/Bracket Assembly 4213 092 05251 1 &3
266 Drum Assembly 4213 092 05531 2
270 Drum Shaft/Bearing Kit 4213 092 05591 2
352 Timer Knob Assembly 4213 092 45741 1
353 Control Panel Assembly 4213 092 43751 1
359 Door Hinge Assembly 4213 092 26071 1
362 Window 4213 077 44094 1
363 Curveline Door Frame & Insert 4213 092 45671 1
364 Latch Pivot 4213 075 13013 1
365 Latch Spring 4213 075 70833 1
366 Door Latch 4213 077 53413 1
367 Switch Strike 4213 077 83571 1
369 Loom Clip 4213 075 70941 1
370 Latch Guide 4213 077 40992 1
372 Timer Bracket 4213 070 10932 1
376 Front Panel 4213 092 45681 1 & 3
377 Centre Button 4213 077 92471 1
386 Top Cover 4213 092 46211 1
390 Gasket 4213 074 50862 2
390a Gasket 4213 092 45121 2a
393 Flex Support Clip 4213 077 40982 2
394 Foot 4213 077 39833 1
395 Heater Wires Clip 4213 075 70971 2
399 Heater Support 4213 080 06619 2
400 Heater Plate 4213 080 14551 2
402 Access Panel 4213 080 06558 2
408 Cable Clamp 4213 077 47303 2
413 Back Panel 4213 092 37601 2
427 Motor Spring Clip 4213 078 45362 2
0312 44A 15001

White Knight 44AW AIR VENTED TUMBLE DRYER - SPARE PARTS LIST
432 Motor Mount Bracket 4213 080 0675A 2
437 Rear Vent Assembly 0312 002 01000 2
440 Banjo Assembly 4213 092 17811 3
441 Front Bearing (short) 4213 077 40952 3
442 Front Seal 4213 077 40941 3
444 Lifter 4213 077 41009 2
445 Front Bearing (long) 4213 077 40962 3
445a Bearing & Seal Kit Assy 4213 092 21171 3
446 Fan 4213 077 40896 2 & 3
447 Access Cover Assembly 4213 092 18081 2 & 3
448 Spring Clip (Fan) 4213 075 71162 3
454 Filter 4213 092 17821 3
456 Banjo Seal 4213 077 07991 3
458 Banjo Insert No 2 4213 077 53502 3
459 Banjo Insert No 1 4213 077 53492 3
NOT SHOWN ON EXPLODED VIEW
INSTRUCTION BOOK - EXP VIEW 2 4213 094 5932C
INSTRUCTION BOOK - EXP VIEW 2a 4213 094 66581
We are in the process of developing a new Heat TOC and Inlet thermostat design
to avoid nuisance operations. Tumble dryers with the following serial numbers have
been fiited with the improved combination of thermostats, and have had removed
the black open-bladed Heat TOC ( see - expolded view 2, item 288 ) and Inlet
thermostat (see - exploded view 2, item 230).
To identify these machines, they will have serial numbers -
From 0702 491384 to 0702 491483
From 0703 496094 to 0703 496893
From 0703 494894 to 0703 495293
From 0703 502390 to 0703 502489
From 0703 494794 to 0703 494893
After week 0704, to identify these machines will have a prefix
of /19, for example 0312 44A 15001/19.
The improved design uses both a new Inlet thermostat and heat TOC combination.
These must be used as a pair and is not to be swapped with exsisting parts, or used
on dryers with the black open-bladed Heat TOC ( see exploded view 2a, item 228a)
please order the correct new parts indicated by bold text in the parts list.
If the Heat TOC has tripped and needs to be reset, it can only be reset from inside
the dryer, by removing the backpanel and depressing the small red button on the
rear of the Heat TOC. If the Heat TOC has tripped, the most likely reason is that the
Inlet thermostat has failed and must be replaced. Nuisance operation is most
unlikely, always look for a cause.
0312 44A 15001
